LEXUS RX450h 2015 Owners Manual

7214-3. Do-it-yourself maintenance
4
Maintenance and care ■
Discharge headlights (if equipped)
If voltage to the discharge bulbs is insufficient, the bulbs may not come on, or may
go out temporarily. The discharge bulbs will come on when normal power is
restored.■
LED light bulbs
The LED headlight low beams (if equipped), daytime running lights, parking lights,
front side marker lights, LED front fog ligh ts (if equipped), side turn signal lights,
stop lights, high mounted stoplight and licence plate lights consist of a number of
LEDs. If any of the LEDs burn out, take your vehicle to your Lexus dealer to have the
light replaced.■
Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not indi-
cate a malfunction. Contact your Lexus dealer for more information in the following
situations: ●
Large drops of water are built up on the inside of the lens.●
Water has built up in side the headlight.
CAUTION■
Replacing light bulbs ●
Turn off the lights. Do not attempt to replace the bulb immediately after turning
off the lights.
The bulbs become very hot and may cause burns.●
Do not touch the glass portion of the li ght bulb with bare hands. When it is
unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid
getting moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.
●
Fully install light bulbs and any parts used to secure them. Failure to do so may
result in heat damage, fire, or water en tering the headlight unit. This may damage
the headlights or cause condensation to build up on the lens.

7224-3. Do-it-yourself maintenance
CAUTION
■
Discharge headlights (if equipped) ●
Contact your Lexus dealer be fore replacing discharge he adlights (including light
bulbs).●
Do not touch the discharge headlight’s high voltage socket when the headlights
are turned on.
An extremely high voltage of 30000 V wi ll be discharged and could result in
serious injury or death by electric shock.●
Do not attempt to take apart or repair the low beam discharge headlight bulbs,
connectors, power supply circuits, or related components.
Doing so could result in electric shock and serious injury or death.■
To prevent damage or fire
Make sure bulbs are fully seated and locked. ●
Vehicles with discharge headlights:
While the low beam headlights are turned
on, and for a short time after they have
been turned off, metal components at the
rear of the headlight assembly will be
extremely hot. To prevent burns, do not
touch these metal components until you
are certain they have cooled down.Metal components

7234-3. Do-it-yourself maintenance
4
Maintenance and care

When trouble arises
5
7235-1. Essential information
Emergency flashers............... 724
If your vehicle needs to be
towed ...................................... 725
If you think something is
wrong ...................................... 732 5-2. Steps to take in an
emergency
If a warning light turns on
or a warning buzzer
sounds... ................................. 733
If a warning message is
displayed................................. 743
If you have a flat tire................ 764
If the hybrid system will
not start ................................... 777
If the shift lever cannot be
shifted from P ........................ 779
If you lose your keys .............. 780
If the electronic key does
not operate properly........... 781
If the vehicle 12-volt
battery is discharged ......... 784
If your vehicle overheats ..... 788
If the vehicle becomes
stuck........................................ 793
If your vehicle has to
be stopped in an
emergency ............................ 795

7245-1. Essential information
Emergency flashers
■
Emergency flashers
If the emergency flashers are used for a long time while the hybrid system is not
operating (while the “READY” indicator is not illuminated), the 12-volt battery may
discharge.The emergency flashers are used to warn other drivers when the vehicle
has to be stopped in the road due to a breakdown, etc.
Press the switch. All the turn signal lights will flash.
To turn them off, press the switch
once again.

5
When trouble arises
7255-1. Essential information
If your vehicle needs to be towed
Situations needs to contact dealers before towing
The following may indicate a problem with your transmission. Contact
your Lexus dealer before towing.
● A warning message for the hybrid system is shown on the multi-infor-
mation display and the vehicle does not move.
● The vehicle makes an abnormal sound.If towing is necessary, we recommend having your vehicle towed by your
Lexus dealer or a commercial towing service, using a lift-type truck or a
flatbed truck.
Use a safety chain system for all towi ng, and abide by all state/provincial
and local laws.
2WD models: If towing your vehicle wi th a wheel-lift type truck from the
front, the vehicle's rear wheels and axles must be in good conditions.
(  P. 726, 730)
If they are damaged, use a to wing dolly or flatbed truck.
AWD models: If towing your vehicle with a wheel-lift type truck, use a tow-
ing dolly. (  P. 7 2 6 , 7 3 0 )

7265-1. Essential information
Towing with a sling-type truck
Do not tow with a sling-type truck
to prevent body damage.
Towing with a wheel-lift type truck
From the front (2WD models)
Release the parking brake.
From the front (AWD models)
Use a towing dolly under the rear
wheels.

5
When trouble arises
7275-1. Essential information
From the rear
Use a towing dolly under the front
wheels.
Using a flatbed truck
If your Lexus is transported by a
flatbed truck, it should be tied
down at the locations shown in the
illustration.
If you use chains or cables to tie
down your vehicle, the angles
shaded in black must be 45  .
Do not overly tighten the tie downs
or the vehicle may be damaged.

7285-1. Essential information
Emergency towing
If a tow truck is not available in an emergency, your vehicle may be tem-
porarily towed using a cable or chain secured to the emergency towing
eyelet. This should only be attempted on hard surfaced roads for short
distance at under 18 mph (30 km/h).
A driver must be in the vehicle to s teer and operate the brakes. The vehi-
cle’s wheels, drive train, axles, steering and brakes must be in good condi-
tion.
Emergency towing procedure
Take out the towing eyelet. (  P. 764)
Type A
Insert the mechanical key (  P.
52) into the groove and release
the claws. With the mechanical key
inserted, remove the eyelet cover
by pulling it towards you. STEP 1
STEP 2

5
When trouble arises
7295-1. Essential information
Type B
Insert the mechanical key (  P.
52) into the groove and release
the claws. With the mechanical key
inserted, remove the eyelet cover
by pulling it towards you.
Insert the towing eyelet into the
hole and tighten as much as possi-
ble by hand.
Using the tip of the wheel nut
wrench, tighten down the towing
eyelet securely without interfering
with the bumper.
Securely attach a cable or chain to the towing eyelet.
Take care not to damage the vehicle body.
Enter the vehicle being towed and start the hybrid system.
If the hybrid system does not start, turn the “POWER” switch to ON
mode.
Shift the shift lever to N and release the parking brake.
When the shift lever cannot be shifted:  P. 7 7 9STEP 2
STEP 3
STEP 4
STEP 5
STEP 6
STEP 7
