MAZDA CX90 2024 Owners Manual

Winter Driving
Carry emergency gear, including tire
chains, window scraper, flares, a small
shovel, jumper cables, and a small bag
of sand or salt.
Ask an Authorized Mazda Dealer to
check the following:
Have the proper ratio of antifreeze in
the radiator.
Refer to Inspecting the Coolant on
page 9-14.
Inspect the battery and its cables.
Cold reduces battery capacity.
Use an engine oil appropriate for the
lowest ambient temperatures that
the vehicle will be driven in (page
9-18).
Inspect the ignition system for
damage and loose connections.
Use washer fluid made with
antifreeze―but do not use engine
coolant antifreeze for washer fluid
(page 9-17).
When driving on ice or in water, snow,
mud, sand, or similar hazards:
Be cautious and allow extra distance
for braking.
Avoid sudden braking and sudden
maneuvering.
Do not pump the brakes. Continue
to press down on the brake pedal.
Refer to Antilock Brake System (ABS)
on page 5-84.
If you get stuck, select a lower gear
and accelerate slowly. Do not spin
the rear wheels.
For more traction in starting on
slippery surfaces such as ice or
packed snow, use sand, rock salt,
chains, carpeting, or other nonslip
material under the rear wheels.
NOTE
Remove snow before driving. Snow
left on the windshield is dangerous
as it could obstruct vision.
Do not apply excessive force to a
window scraper when removing ice
or frozen snow on the mirror glass
and windshield.
Never use warm or hot water for
removing snow or ice from windows
and mirrors as it could result in the
glass cracking.
Drive slowly. Braking performance
can be adversely affected if snow or
ice adheres to the brake
components. If this situation occurs,
drive the vehicle slowly, releasing the
accelerator pedal and lightly applying
the brakes several times until the
brake performance returns to
normal.
Driving
Winter Driving
5-240
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Snow Tires
WARNING
Use only the same size and type tires
(snow, radial, or non-radial) on all 4
wheels:
Using tires different in size or type is
dangerous. Your vehicle's handling
could be greatly affected and result in
an accident.
CAUTION
Check local regulations before using
studded tires.
Use snow tires on all 4 wheels
Do not go faster than 120 km/h (75
mph) while driving with snow tires.
When installing winter tires, use tires of
the specified size and adjust the air
pressure of all the tires to the specified
value. (page 10-71).

The vehicle is originally equipped with
all season radials designed to be used
all year around. In some extreme
climates you may find it necessary to
replace them with snow tires during
the winter months to further improve
traction on snow and ice covered
roads.
Tire Chains
Check local regulations before using
tire chains.
CAUTION
 Chains may aff ect handling.
 Do not go faster than 50 km/h (30
mph) or the chain manufacturer's
recommended limit, whichever is
lower.
 Drive carefully and avoid bumps,
holes, and sharp turns.
 Avoid locked-wheel braking.
 Do not use chains on a temporary
spare tire; it may result in damage to
the vehicle and to the tire.
 Do not use chains on roads that are
free of snow or ice. The tires and
chains could be damaged.
 Chains may scratch or chip
aluminum wheels.
NOTE
The tire pressure monitoring system
may not function correctly when using
tire chains.
Install the chains on the rear tires only.
Do not use chains on the front tires.
Please consult an Authorized Mazda
Dealer.
Installing the chains
1. Secure the chains on the rear tires
as tightly as possible. Always follow
the chain manufacturer's
instructions.
2. Retighten the chains after driving 1/2 ―1 km (1/4 ―1/2 mile).
Driving
Winter Driving
5-241
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

MEMO
5-242
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

6
Equipment to Make Cabin More
Comfortable
Fully Automatic Climate Control
(Front)..................................... 6-2Air Vents............................... 6-2
How to Use the Air Vents....... 6-2
Fully Automatic Climate
Control................................. 6-4
Fully Automatic Climate Control
Overview.............................. 6-6
How to Use the Fully Automatic
Climate Control..................... 6-7
Operating Each Switch........... 6-8
Convenient Ways to Use the Fully
Automatic Climate Control ..........
.......................................... 6-12
Fully Automatic Climate Control
(Rear).................................... 6-15 Air Vents............................. 6-15
How to Use the Air Vents..... 6-15
Fully Automatic Climate Control
System................................ 6-16
Fully Automatic Climate Control
System Overview................. 6-17
How to Use the Fully Automatic
Climate Control System........ 6-19
Operating Each Switch......... 6-20
Seat Warmer.......................... 6-22 Seat Warmer
*...................... 6-22
Warnings and Cautions For Using
the Seat Warmer.................. 6-22
How to Use the Seat
Warmer...............................6-23
Convenient Ways to Use the Seat
Warmer...............................6-24
Heated Steering Wheel............ 6-25 Heated Steering Wheel
*........6-25
Warnings and cautions For Using
the Heated Steering Wheel ..........
.......................................... 6-25
How to Use Heated Steering
Wheel................................. 6-26
Convenient Ways to Use Heated
Steering Wheel.................... 6-26
Seat Ventilation...................... 6-27 Seat Ventilation
*.................. 6-27
Warnings and cautions For Using
the Seat Ventilation..............6-27
How to Use the Seat
Ventilation.......................... 6-28
Convenient Ways to Use the Seat
Ventilation.......................... 6-29
Driver Personalization System ..........
............................................ 6-30 Driver Personalization System
*.....
.......................................... 6-30
Warnings and Cautions For Using
the Driver Personalization
System................................ 6-30
How to Use the Driver
Personalization System......... 6-31
*Some models.6-1
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Air Vents
The location and the direction airflow
exits the air vents changes depending
on the air vent adjustment.
How to Use the Air Vents
Air vent open/closet
Move the dial fully in the fully open or
fully closed direction.
Side Vents
1. Open
2. Close
Center Vents
1. Open
2. Close

Equipment to Make Cabin More Comfortable
Fully Automatic Climate Control (Front)
6-2
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Airflow direction adjustment
Side Vents

Center Vents


Airflow selection
Dashboard Vents
Dashboard and Floor Vents
Floor Vents
Equipment to Make Cabin More Comfortable
Fully Automatic Climate Control (Front)
6-3
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Defroster and Floor Vents
Defroster Vents
Fully Automatic ClimateControl
The following functions are
automatically controlled according to
the set temperature.
Airflow temperature controlAirflow amount controlAirflow mode switchingRecirculate/fresh air mode switchingAir conditioning (cooling/
dehumidifying functions) on/off
Seat warmer level selection*
Heated steering wheel operation*
Seat ventilation level selection*
NOTE
To prevent cold airflow immediately
after heating starts when the hybrid
system is cold, the airflow amount is
decreased.
Fully automatic air-conditioning uses
the sunlight and interior temperature
sensors to control the temperature in
the cabin by measuring interior and
exterior temperatures, humidity, and
sunlight. Do not cover the sunlight/
interior temperature sensor.
Sunlight sensor
Equipment to Make Cabin More Comfortable
Fully Automatic Climate Control (Front)
6-4*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Interior temperature sensor
Equipment to Make Cabin More Comfortable
Fully Automatic Climate Control (Front)
6-5
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Fully Automatic Climate Control Overview
1. AUTO switch
2. Driver’s side temperature setting switch
3. Driver’s side temperature setting display
4. Linked auto-comfort display
*1
Refer to Convenient Ways to Use the Seat Warmer on page 6-24.
Refer to Convenient Ways to Use Heated Steering Wheel on page 6-26.
Refer to Convenient Ways to Use the Seat Ventilation on page 6-29.
5. Airflow display
6. Mode selector display
7. Air intake selector display
8. Front passenger’s side te mperature setting display
9. Front passenger’s side temperature setting switch
10.SYNC (synchronized temperature) switch
11.A/C switch
12.Air intake selector switch
13.Mode selector switch
14.Fan control switch
15.Climate control system power switch
16.Rear window defogger switch
17.Windshield defroster switch
*1 The display differs depending on the clim ate control systems, or whether or not
the seat warmer, seat ventilation, and steering warmer are equipped.
Equipment to Make Cabin More Comfortable
Fully Automatic Climate Control (Front)
6-6
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the FullyAutomatic Climate Control
1. Start the hybrid system.
2.
The AUTO switch indicator light
turns on.
3. Press the temperature setting switch to set the desired temperature.
Each function is automatically
controlled according to the set
temperature.
4. To stop the operation, press the climate control system power
switch.
NOTE
The recommended set temperature
is 22 °C (72 °F).
If any mode selector switch, fan
control switch, or windshield
defroster switch is operated during
auto operation, the AUTO switch
indicator light turns off. The
functions for switches other than
those operated will continue to
operate in auto control.
The power consumption of the air
conditioner changes depending on
the set temperature and the ambient
temperature. If the set temperature is
too low or high, the remaining
distance-to-full discharge shortens.
The climate control system can be
used while charging when the
vehicle power is switched ON.
Equipment to Make Cabin More Comfortable
Fully Automatic Climate Control (Front)
6-7
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
