MAZDA CX90 2024 Owners Manual

Wireless Charger (Qi)
You can charge mobile devices such as
Smartphones which comply with the
Qi Wireless Charging standard.
Only use mobile devices that have a
maximum power consumption of 5 W,
or 15 W or below.
Trademarks
“Qi” and the Qi symbol are trademarks
or registered trademarks of the
Wireless Power Consortium (WPC).
Warnings and Cautions
When Using the Wireless Charger (Qi)
WARNING
Radio waves from the Wireless
Charger (Qi) may affect the operation
of medical devices such as
implanted-type cardiac pacemakers
or defibrillators.
 Before using the Wireless Charger
(Qi) near people who use medical
devices, ask the medical device
manufacturer or your physician if
radio waves from the Wireless
Charger (Qi) will affect the device.
 The Wireless Charger (Qi) can be
disabled to prevent it from affecting
medical devices. Consult an
Authorized Mazda Dealer for details.
Heed the following cautions.
Otherwise, the Wireless Charger (Qi)
may malfunction or be damaged,
which could cause a fire, burns due to
heat generation, or an accident such
as electrical shock.
 Do not install, remove, disassemble,
or change the wiring of the Wireless
Charger (Qi). If the Wireless Charger
(Qi) needs to be installed or
removed, consult an Authorized
Mazda Dealer.
 Do not use the Wireless Charger (Qi)
when it is malfunctioning. In
addition, if smoke, abnormal noise,
or abnormal smell is emitted from
the Wireless Charger (Qi), stop the
vehicle in a safe place, turn off the
Wireless Charger (Qi), and consult
an Authorized Mazda Dealer.
Other Equipment
Wireless Charger (Qi)
7-54
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

When using the Wireless Charger
(Qi) to store items on, turn off the
Wireless Charger (Qi).
 Do not place any metal object
between the charging area and the
mobile device. Also, do not apply
items such as a metallic sticker to the
Wireless Charger (Qi).
 When charging, do not place any
item other than the mobile device to
be charged on the Wireless Charger
(Qi). In addition, do not place any
metal object, IC card, coin, or
magnetic item near the charging
area.
 Remove dust or dirt from the
charging area before use.
 Do not apply strong force or impact
to the Wireless Charger (Qi) or get it
wet.
 Use only mobile devices which
support the Wireless Charger (Qi).
CAUTION
While a mobile device is placed on
the charging area, keep the vehicle
key away from the Wireless Charger
(Qi). The vehicle key may not be
detected due to radio wave
interference by the Wireless Charger
(Qi).
 Charging may not operate normally
under the following conditions:
 The mobile device is fully charged.
 There is foreign matter between
the mobile device and the charging
area.
 The temperature of the mobile
device is high.
 The mobile device is placed with
the charging side facing upward.
 The mobile device is placed in a
position extremely deviating from
the center of the charging area.
Your vehicle is in an area where
strong radio waves or electrical
noise occur such as near a
television tower, power plant, or
airport.
 The Near Field Communication
(NFC) function setting of the
mobile device is on (depends on
the model of the mobile device).
 Keep the following items away from
the charging area. Otherwise the
data stored on the mobile device
could be erased or the device could
malfunction.
 Magnetic items such as magnets,
magnetic cards, and magnetic
recording media.
 High precision devices such as
wristwatches.
 Before using the Wireless Charger
(Qi), make sure to back up the data
stored on the mobile device. The
data on the mobile device could be
deleted.
 Do not wipe the Wireless Charger
(Qi) using oil, alcohol, or thinner, or
spray hairspray or insecticide onto it.
Otherwise, it could cause damage or
cracking.
 Do not leave mobile devices in the
cabin. The temperature inside the
cabin may become very hot, causing
the devices to malfunction.
Other Equipment
Wireless Charger (Qi)
7-55
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the WirelessCharger (Qi)
1. Start the hybrid system.The power for the Wireless Charger
(Qi) turns on and the LED indicator
turns on.
2. Place a device compliant with the
Qi Wireless Charging standard
(portable device with a maximum
power consumption of 5 W or 15
W or below) in the center of the
charging area on the tray.
1. Charging area
2. LED indicator
The LED indicator turns on in amber
or green when charging starts.
Charging starts when all the doors
and liftgate are closed.
For details on the LED indicator, refer
to the following LED indicator table.
Charging status display
The charging status of the Wireless
Charger (Qi) can be checked with the
LED indicator or the icon displayed on
the center display.
Illumina-
tion/flash pattern Icon indi-
cation Status
Does not turn on ―Indicates that charg-
ing is turned
off.
Tu r n s o n i n white
Indicates that charg-
ing is possible.
Tu r n s o n i n amber
Indicates normal
charging.
Tu r n s o n i n green
Indicates fast charg-
ing*1.
Flashes in white
Indicates that the
charging conditions
are not met.
Flashes in red
Indicates that charg-
ing is not possible
because a high tem-
perature is detected.
Indicates that charg-
ing is not possible
because foreign mat-
ter is detected.
Tu r n s o n i n red
Indicates that there
is a problem with
Wireless Charger
(Qi) and it needs to
be repaired. Consult
an Authorized Maz-
da Dealer.
*1 Some mobile devices can switchbetween normal charging and fast
charging.
Other Equipment
Wireless Charger (Qi)
7-56
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

NOTE
Charging efficiency may be reduced
or charging may not be possible
depending on the use environment
and conditions.
Depending on the mobile device
case or accessories used, the mobile
device may not charge, or the
charging efficiency may be reduced
resulting in a longer charging time. If
charging does not start even when a
mobile device is placed on the
charging area, remove the case or
accessory.
Depending on the vehicle condition,
charge amount may be temporarily
restricted and charging may be
canceled, however, this does not
indicate a problem.
If the mobile device temperature
rises during charging, charging may
stop due to the protection function
of the device. If that happens, wait
until the mobile device cools down
sufficiently and then recharge it.
When using the Wireless Charger
(Qi), applications using the Near
Field Communicatio
n (NFC) function
may launch, however, this does not
indicate a problem with the Wireless
Charger (Qi).
While i-stop is operating, charge
amount may be temporarily
restricted and charging may be
temporarily canceled, however, this
does not indicate a problem.
Charging may be temporarily
canceled depending on the vehicle
conditions, such as when the engine
is stopped.
Convenient Ways to Use
the Wireless Charger (Qi)
The Wireless Charger (Qi) can be
turned on/off and the connection
mode can be switched.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Other Equipment
Wireless Charger (Qi)
7-57
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warnings and CautionsWhen Using the Assist Grips
WARNING
Never hang heavy or sharp objects on
the assist grips and coat hooks.
Hanging heavy or sharp-ended objects
such as a coat hanger from the assist
grips or coat hooks is dangerous as
they can fly off and hit an occupant in
the cabin if a curtain air bag was to
deploy, which could result in serious
injury or death.
Do not use the assist grips when
getting in and out of the vehicle or
getting out of a seat.
An assist grip could break under a
heavy load resulting in injury.
How to Use the Assist
Grips
Use the assist grips to support your
body while seated in the vehicle and
while the vehicle is moving.
Other Equipment
Assist Grip
7-58
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

To w i n g
Your Mazda was designed and built
primarily to carry passengers and
cargo.
If you tow a trailer, follow these
instructions because driver and
passenger safety depends on proper
equipment and safe driving habits.
Towing a trailer will affect handling,
braking , durability, performance, and
economy.
Never overload vehicle or trailer.
Consult an Authorized Mazda Dealer if
you need further details.
NOTE
Your vehicle is equipped with a
Trailer Stability Control (TSC)
mechanism, which enhances vehicle
stability when towing a trailer.
Refer to Trailer Stability Control
(TSC) on page 5-90.
When towing a trailer, do not use the
following safety systems (If a Mazda
genuine trailer hitch is used, these
systems are automatically turned off
when the trailer's electrical
connector is connected):
Blind Spot Monitoring (BSM)Rear Cross Traffic Alert (RCTA)Smart Brake Support (SBS) reverse
drive detection
Parking Sensor System (Rear)Emergency Lane Keeping (ELK)
Blind Spot Assist
Emergency Lane Keeping (ELK)
Head-on traffic avoidance assist
Turn off the aforementioned safety
systems when towing a trailer
without a genuine Mazda trailer
hitch.
Your vehicle is equipped with a
Mazda intelligent Drive Select
(Mi-Drive) towing mode which
enhances vehicle stability when
towing a trailer.
Refer to Mazda intelligent Drive
Select (Mi-Drive) on page 5-96.
Other Equipment
Towing (U.S.A. and Canada)
7-59
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warnings and Cautionsfor Using the Towing
WARNING
Always keep tow loads within
specified limits as indicated in the
Trailer Towing-Load Table:
Attempting to tow loads greater than
those specified is dangerous as it may
cause serious handling and
performance problems that could
result in personal injury or vehicle
damage, or both.
Load your trailer with the weight
about 60 % toward the front and
40 % toward the rear:
Loading the trailer with more weight in
the rear than in the front is dangerous.
Doing so could cause you to lose
control. The trailer tongue load must
be 10 % ―15 % of the total trailer load
(sum of the weights of the trailer and
cargo).
Always have the total trailer weight
and tongue load determined prior to
departure:
Attempting to tow loads without
determining the total trailer weight and
tongue load is dangerous. Trailer sway
from crosswinds, rough roads or other
causes could result in loss of control
and a serious accident.
Always make sure the trailer hitch is
securely attached before departure:
An unsecured trailer hitch is dangerous
as it causes greater trailer sway from
crosswinds, rough roads or other
causes, resulting in loss of control and
a serious accident.
Examine all trailer-hitch mounting
bolts regularly and tighten any that are
loose. If the hitch is removed, seal any
open mounting holes to prevent
exhaust, dust, water, dirt and other
foreign elements from filtering in,
possibly endangering personal safety
and damaging your vehicle.
Do not install a hitch that stiffens the
bumper as it will reduce the bumper's
performance.
Make sure there are no exhaust gas
leaks into the passenger compartment
if any mounting bolts are connected
to the body:
Modifying your vehicle exhaust system
is dangerous. Exhaust gas entering the
vehicle could cause loss of
consciousness or even death.
When mounting the trailer hitch, make
no modifications to the vehicle exhaust
system.
Never use the temporary spare tire
when towing:
Using the temporary spare tire on your
vehicle when towing a trailer is
dangerous as it could result in tire
failure, loss of control, and injury to
vehicle occupants.
Make sure the safety chain is securely
attached to both the trailer and the
vehicle prior to departure:
Towing a trailer without using a safety
chain securely attached to both the
trailer and the vehicle is dangerous. If
damage occurs to the coupling unit or
hitch ball, the trailer could wander into
another lane and cause a collision.
Other Equipment
Towing (U.S.A. and Canada)
7-60
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Do not connect a hydraulic
trailer-brake system to your vehicle's
brake system:
Connecting a hydraulic trailer-brake
system directly to the vehicle brake
system is dangerous and will result in
inadequate braking and possible injury.
Always use lower gears to reduce
speed:
Holding the brake pedal down too
long or too frequently is dangerous as
it could cause the brakes to overheat
and lose power, resulting in loss of
control and a serious accident. Use
lower gears to help reduce speed. Pull
off the road and allow brakes to cool
down whenever braking performance
feels reduced.
CAUTION
Do not tow a trailer during the first
1,000 km (600 miles) of your new
Mazda. If you do, you may damage
the engine, transmission, differential,
wheel bearings, and other
power-train components.
 Be aware of the towing load weight
differences when towing at high
altitudes. For altitudes exceeding
1,000 meter (3,280 ft 10 in), always
reduce the towing load by 10 % for
every 1,000 meter (3,280 ft 10 in)
increase in altitude from the load
indicated under the maximum
GCWR heading in the trailer
towing-load table. If the determined
maximum total towing load weight is
exceeded, the engine and other
power-train parts may be damaged.
 The total trailer weight and tongue
load can be determined by weighing
the trailer on platform scales at a
highway weight station or a trucking
company.
Make all hitch adjustments with
actual loads. Do not load and
unload vehicle while adjusting hitch.
This action will change the vehicle
height.
 Do not use an axle-mounted hitch.
This may damage the axle and
related parts.
 If the vehicle exceeds 100 km/h (62
mph) with a trailer in tow, the
vehicle could be damaged.
 Do not connect a trailer lighting
system directly to the lighting system
of your Mazda. This may damage
your vehicle's electrical system and
lighting systems. Have a recreational
vehicle dealer or trailer rental agency
connect the system, and inspect the
brake lights and turn signals yourself
before each trip.
Other Equipment
Towing (U.S.A. and Canada)
7-61
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the Towing
NOTE
The three main causes of vehicle-trailer accidents are driver error, excessive speed,
and improper trailer loading.
Trailer towing causes higher fuel consumption.The extra weight of the trailer may strain the engine on hot days and on long or
steep upgrades. If the temperature gauge indicates overheating, turn off the air
conditioner, drive safely to the side of the road, park off the right-of-way and wait
for engine to cool.
Verify that your Mazda maintains a near-normal attitude when a loaded or
unloaded trailer is connected. Do not drive if it has an abnormal front-up or
front-down position. Inspect for incorrec t tongue load, worn suspension parts,
and trailer overloading.
Make sure the trailer is properly loaded and the cargo is secure to prevent it from
shifting.
Make sure the mirrors conform to all govern ment regulations. If they do not, install
required rear view mirrors appropriate for towing purposes.
Trailer towing-load table
Because vehicle weights vary, adjustments must be made to meet the requirements
in this table.
(U.S.A.)
Limitation items Limit values
19 inch wheel ve- hicle 21 inch wheel ve-
hicle
MAX. TTW
1,588 kg (3,500 lb)
MAX. GCWR
4,150 kg (9,148 lb)
MAX. GAWR
Front 1,320 kg (2,910 lb) 1,313 kg (2,895 lb)
Rear 1,855 kg (4,090 lb) 1,797 kg (3,962 lb)
MAX. GVWR
3,109 kg (6,854 lb)
Other Equipment
Towing (U.S.A. and Canada)
7-62
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Limitation itemsLimit values
19 inch wheel ve- hicle 21 inch wheel ve-
hicle
TRAILER-TONGUE
LOAD To n g u e l o a d
Tongue load/Trailer load × 100 = 10 %
to 15 %
Trailer load
DISTRIBUTION OF
TRAILER LOADFront 60 %
Rear 40 %
(Canada)
Limitation items Limit values
19 inch wheel ve- hicle 21 inch wheel ve-
hicle
MAX. TTW
1,588 kg (3,500 lb)
MAX. GCWR
4,116 kg (9,073 lb)
MAX. GAWR
Front 1,320 kg (2,910 lb) 1,313 kg (2,895 lb)
Rear 1,855 kg (4,090 lb) 1,797 kg (3,962 lb)
MAX. GVWR
3,109 kg (6,854 lb)
TRAILER-TONGUE
LOAD To n g u e l o a d
Tongue load/Trailer load × 100 = 10 %
to 15 %
Trailer load
DISTRIBUTION OF
TRAILER LOADFront 60 %
Rear 40 %
Other Equipment
Towing (U.S.A. and Canada)
7-63
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
