MAZDA CX90 2024 Owners Manual

TTW and GCWR
The total trailer weight (TTW), gross combination weight rating (GCWR), gross axle
weight rating (GAWR), trailer load, and trailer tongue load must be within the
prescribed limits.
The total trailer weight (TTW) is the sum of the weights of the trailer load (trailer
weight plus cargo). Never allow the total trailer weight (TTW) to exceed specifications in the Trailer towing-load table.
The maximum GCWR is the combination weight of the trailer and load plus the
towing vehicle (including trailer hitch, vehicle passengers, and load). It must not
exceed the specifications in the load table.
GAWR and GVWR
Do not exceed front and rear GAWR (gross axle weight rating) and GVWR (gross
vehicle weight rating). If you do, vehicle handling , braking , and performance will be
affected. These values are also on the Motor Vehicle Safety Standard Label posted
on the driver's door frame.
Trailer frontal area table
Frontal area is the total area that a moving vehicle and trailer exposes to air
resistance. Exceeding this limit may reduce the performance of your towing vehicle.
(U.S.A. and Canada)
Limitation items Limit values
MAX. FRONTAL AREA
2.79 m2 (30 ft2)
Before driving
Have your cooling and braking system checked by an Authorized Mazda Dealer.Before starting out, inspect the operation of all vehicle and trailer lights and all
vehicle-to-trailer connections. Stop and re-inspect all lights and connections after
driving a short distance.
Trailer hitch
Use only a hitch ball recommended by the trailer manufacturer that conforms to the
gross trailer weight requirement.
When not towing a trailer, remove the trailer hitch (if detachable) to reduce the
possibility of damage as a result of the vehicle being rear-ended.
Tires
When towing a trailer, make sure that the tire pressures of the rear tires are at 20
kPa (0.2 bar, 2.9 psi) higher than the recommended tire pressures indicated on
the tire pressure chart on the driver's door frame.
Other Equipment
Towing (U.S.A. and Canada)
7-64
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Trailer tire size, load rating, and inflation pressures should conform to tire
manufacturer specifications.
Do not exceed 100 km/h (62 mph) with a trailer in tow. If the local legal
maximum speed with a trailer in tow is less than 100 km/h (62 mph), do not
exceed the legal speed.
Safety chains
Safety chains must be used as a precautionary measure should the trailer become
unintentionally unhitched. They should cross under the trailer tongue and attach to
the hitch. Leave enough slack to allow full turns. Consult literature published by your
trailer or hitch manufacturer for more details.
Tra i l e r l i g h t s
Trailer lights must comply with all federal, state, and local regulations. Equip your
trailer as required before towing it day or night.
Trailer brakes
If the total trailer weight exceeds 450 kg (1,000 lb), trailer brakes are required. If
your trailer has brakes, make sure they comply with all federal, state, and local
regulations.
Driving
Your Mazda will handle differently with a trailer in tow, so practice turning ,
backing , and stopping in a traffic-free area.
Take time to get accustomed to the extra weight and length.Allow more room between your vehicle and the one in front because braking
distance increases with a trailer. For each 16 km/h (10 mph) of speed, allow at
least one vehicle and trailer length between your Mazda and the vehicle ahead.
Avoid jerky starts or sudden acceleration.Avoid sudden braking. It may cause loss of control and result in
jackknifing,
especially so on wet or slippery roads.
Shift the selector lever to the D position when towing a trailer in hilly terrain or
when heavily loaded.
The D position will allow operating the vehicle without frequent shifting.
Lane changes and turning
Avoid quick lane changes, sudden turns, and tight turns. Slow down before turning
to avoid the need of sudden braking.
A turning trailer will make a tighter arc than the tow vehicle. Compensate with turns
that are larger than normal.
Pa s s i n g
Plan well ahead to pass other vehicles, and provide plenty of room before changing
lanes. Crosswinds from passing vehicles, especially larger ones, and the effects of
rough roads will affect handling.
Other Equipment
Towing (U.S.A. and Canada)
7-65
CX-90_8KG7-EA-22L_Edition1_new
2022-11-17 16:05:04

If swaying occurs, firmly grip the steering wheel and reduce speed immediately, but
gradually.
Steer straight ahead. If no extreme correction of steering or braking is made, the
combination of less speed and firm steering will result in stability.
Backing up
Backing a vehicle with a trailer requires practice and patience. Back slowly, and have
a helper outside at the rear of the trailer to reduce the risk of an accident.
To turn the trailer, place your hand at th e bottom of the steering wheel and turn it in
the direction you want the trailer to go. Make only slight movements to prevent
sharp or prolonged turning.
Ascending a hill
Shift into a lower gear to reduce the poss ibility of overloading or overheating the
engine, or both.
Descending a hill
Shift into a lower gear and use engine compression as a braking effect.
Pa r k i n g
Always make sure the tires of the trailer and the tow vehicle are blocked while
parked.
Apply the parking brake firmly and put the transmission in P.
Avoid parking on an incline, but if you must, follow these instructions:
1. Depress and hold down the brake pedal.
2. Have a helper put wheel blocks against the downhill side of all vehicle and trailer tires.
3. Then release the brake pedal slowly until the blocks bear the load.
If the grade is downhill, turn the steering wheel so that the front of the front
tires face the curb.
If it is uphill, face the rear of the front tires against the curb.
4. Firmly apply the parking brake.
5. Shift the transmission into P, and stop the engine.
To restart after parking on an incline:
1. With the transmission in P, start the engine. (Be sure to depress and hold the brake pedal.)
2. Shift into gear.
3. Release the parking brake (also the foot brake) and pull away from the wheel blocks. Stop; apply the parking brake and shift into P.
4. Have a helper retrieve the wheel blocks.
Maintenance
If you tow a trailer frequently, have your vehicle serviced as shown in Scheduled
Maintenance (page 9-4).
Other Equipment
Towing (U.S.A. and Canada)
7-66
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Recreational towing
An example of "recreational towing" is towing your vehicle behind a motorhome.
The transmission is not designed for towing this vehicle on all 4 wheels.
When doing recreational towing refer to "Having the Vehicle Towed" (page 8-5)
and "Using the Towing Hooks" (page 8-6) and carefully follow the instructions.
Other Equipment
Towing (U.S.A. and Canada)
7-67
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

HomeLink WirelessControl System
The HomeLink system replaces up to 3
hand-held transmitters with a single
built-in component in the
auto-dimming mirror. Pressing the
HomeLink button on the
auto-dimming mirror activates garage
doors, gates and other devices
surrounding your home.
NOTE
HomeLink and HomeLink house are
registered trademarks of Gentex
Corporation.
Warning and Cautions for Using the HomeLink
Wireless Control System
WARNING
Do not use the HomeLink system with
any garage door opener that lacks the
safety stop and reverse feature.
Using the HomeLink system with any
garage door opener that lacks the
safety stop and reverse feature as
required by federal safety standards is
dangerous. (This includes garage doors
manufactured before April 1, 1982.)
Using these garage door openers can
increase the risk of serious injury or
death. For further in formation, contact
HomeLink at www.homelink.com or
www.youtube.com/HomeLinkGentex
or an Authorized Mazda Dealer.
Always check the areas surrounding
garage doors and gates for people or
obstructions before programming or
during operation of the HomeLink
system.
Programming or operating the
HomeLink system without verifying the
safety of areas surrounding garage
doors and gates is dangerous and
could result in an unexpected accident
and serious injury if someone were to
be hit.
Other Equipment
HomeLink Wireless Control System
7-68
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the
HomeLink Wireless Control System
Programming the HomeLink System
The HomeLink system provides 3
buttons which can be individually
selected and programmed using the
transmitters for current, on-market
devices as follows:
1. Verify that there is a remote control transmitter available for the device
you would like to program.
NOTE
It is recommended that a new
battery be placed in the hand-held
transmitter of the device being
programmed to HomeLink for
quicker training and accurate
transmission of the radio-frequency
signal.
2. Press and release the HomeLink button you would like to program.
The indicator light flashes slowly in
amber when the button is pressed.
1. Indicator light
2. HomeLink button
3. Hold the hand-held transmitter 3 to 7 cm (1.2 to 2.7 in) away from the
HomeLink button you would like to
program while keeping the
indicator light in view.
NOTE
Depending on the hand-held
transmitter, it may be easier to do
the programming by holding it
about 20 cm (7.9 in) away from the
HomeLink button.
4. Press the hand-held transmitter button continuously until the
indicator light changes from amber
(flashing) to green (on/flashing).
NOTE
Some gate operators and garage
door openers may require you to
replace this Programming Step 4
with procedures noted in the “Gate
Operator/Canadian Programming”
section.
5. Press the HomeLink button again to check if the programming has been
completed.
If the indicator light remains on in
green, the programming is
complete and the device becomes
operational.
If the indicator light flashes rapidly
in green, firmly press and hold the
Homelink button and release it
after two seconds have passed.
Repeat this process up to three
times to complete the
programming. The device becomes
operational and programming is
complete. If the device does not
operate, go to the next step.
6. At the garage door opener receiver (motor-head unit) in the garage,
locate the “learn” or “smart” button.
This can usually be found where the
hanging antenna wire is attached to
the motor-head unit.
7. Firmly press and release the “learn” or “smart” button. (The name and
color of the button may vary by
manufacturer.)
Other Equipment
HomeLink Wireless Control System
7-69
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

NOTE
Complete the programming within
30 seconds.
8. Return to the vehicle and firmly press and hold the Homelink
button, and then release it after two
seconds have passed. Repeat the
“press/hold/release” sequence a
second time, and, depending on
the brand of the garage door
opener (or other rolling code
equipped device), repeat this
sequence a third time to complete
the programming process.
Press the programmed HomeLink
button and make sure that the
HomeLink System operates.
If the status indicator arrows are
flashing , refer to Programming
two-way communication.
1. Indicator light
For questions or comments, please
contact HomeLink at
www.homelink.com or
www.youtube.com/
HomeLinkGentex, or the HomeLink
toll-free hotline at 1-800-355-3515
(for calls placed outside of the USA,
Canada, and Puerto Rico,
international rates will apply and
may differ based on landline or
mobile phone).
Gate operator/Canadian
Programming
Canadian radio-frequency laws require
transmitter signals to “time-out” (or
quit) after several seconds of
transmission ― which may not be long
enough for HomeLink to pick up the
signal during programming. Similar to
this Canadian law, some U.S. gate
operators are designed to “time-out”
in the same manner.
If you live in Canada or are having
difficulties programming a gate
operator by using the programming
procedures (regardless of where you
live), replace Step 4 of Programming
the HomeLink System with the
following:
NOTE
If programming a garage door opener
or gate operator, it is advised to unplug
the device during the “cycling” process
to prevent possible overheating.
While the indicator light is flashing in
amber, press the button on the
hand-held transmitter for 2 seconds
and release it repeatedly until the
indicator light changes from amber to
green.
Go back to Step 5 of Programming the
HomeLink System to complete the
procedure.
Operating the HomeLink System
Press the programmed HomeLink
button to operate a programmed
device.
Reprogramming the HomeLink system
To program a device to HomeLink
using a HomeLink button previously
trained, follow these steps:
1. Press and hold the desired
HomeLink button. Do not release
the button.
2. After 20 seconds, the indicator light
flashes in amber. After the indicator
light flashes, release the HomeLink
button.
Other Equipment
HomeLink Wireless Control System
7-70
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

3. Go back to Step 3 of Programmingthe HomeLink System to complete
the procedure.
NOTE
If the programming has not been
completed, the system returns to the
previous programming.
Programming two-way
communication
The garage door two-way
communication is a function that
communicates with the garage door
opener and indicates whether the
garages door is open or closed using
the indicator lights in the rear view
mirror. It can indicate the status of the
garage door within a range up-to 250
m (820 ft).
NOTE
The communication range may shorten
depending on obstructions.
Within five seconds after programming
a new HomeLink button, both of the
garage door status indicator lights will
flash rapidly in green indicating that
the garage door two-way
communication has been established.
If the garage door status indicator
lights flash, the two-way
communication programming is
complete.
If the garage door status indicator
lights do not flash, the two-way
communication programming is not
completed. For additional HomeLink
information and programming videos,
refer to the following Websites:
www.HomeLink.comwww.youtube.com/
HomeLinkGentex
Operating the garage door two-way
communication
By pressing HomeLink buttons 1 and 2
at the same time for two seconds, the
status of the garage door is indicated
for about 3 seco nds as follows:
1. HomeLink button 1
2. HomeLink button 2
Garage door
status Indicator light
Closing Amber flashes
Opening Amber flashes
Closed
Green turns on
Opened Green turns on
Other Equipment
HomeLink Wireless Control System
7-71
CX-90_8KG7-EA-22L_Edition1_new
2022-11-17 16:05:04

Erasing Programmed HomeLink
Buttons
Press the two outer HomeLink buttons
continuously at the same time until the
indicator light flashes.
1. HomeLink button 1
2. HomeLink button 3
NOTE
All of the programmed HomeLink
buttons are reset. If there is
programming you do not want to
delete, reprogram if necessary. Refer
to Programming the HomeLink
System.
Verify that the programming has
been erased if you resell the vehicle.
The programming will not be erased
even if the battery is disconnected.
Other Equipment
HomeLink Wireless Control System
7-72
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warnings and Cautions
For Using the Accessories
CAUTION
When installing accessories using
electrical or electronic components,
consult an Authorized Mazda Dealer.
There is a possibility of accidents due
to brake or air bag mis-operation,
vehicle damage or malfunctions.
Other Equipment
Accessories
7-73
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
