MERCEDES-BENZ M-Class 2001 W163 Comand Manual

99
Introduction Audio TelephoneNavigationIndex
S y s te m s e ttin g s
Enter cross street name:
Use the joystick to select the first character (9) of the
desired street and press . The character will appear in
the text window (10) and all streets starting with this
character will appear in the street name list (11).
To enter additional characters, repeat this step. All
unnecessary characters are shaded out.To correct the last character select “Delete” (12) with the
joystick and press .
Select the desired street name from the street name list
with the joystick and press .
If the complete address has been entered the Confirm
Destination menu will appear.
Select “OK to Proceed” with the joystick and press ,
the MCS will begin calculating the route.
Select “Save in Address Book” with the joystick and
press , the address will be stored in the Address
Book, page 110.
Select “Add to Today’s Plan” with the joystick and press
, the entry will be added to Today’s Plan, page 115.P82.85-5029-26
Destination input

100
Introduction Audio TelephoneNavigationIndex
S y s te m s e ttin g s
Searching for a destination by Point of Interest
by Place Name
Press .
Select “Dest” with the joystick and press .
The Destination menu appears. Select “Point of Interest”
with the joystick and press .Select “Place Name” with the joystick and press .
P82.85-5101-26
P82.85-5070-26
Destination input

101
Introduction Audio TelephoneNavigationIndex
S y s te m s e ttin g s
Enter Place Name:
Select the first character (1) of the desired Place Name
with the joystick and press . The character will
appear in the text window (2) and all places starting
with this character will appear in the Place Name
list (3).To enter additional characters, repeat this step. All
unnecessary characters are shaded out.
To correct the last character select “Delete” (4) with the
joystick and press .
Select the desired Place Name with the joystick from the
Place Name list and press .
Note:
Duplicate place names are listed in order of proximity
(nearest place first).
The Confirm Destination menu will appear.
Select “OK to Proceed” with the joystick and press ,
the MCS will begin calculating the route.
Select “Save in Address Book” with the joystick and
press , the address will be stored in the Address
Book, page 110.
Select “Add to Today’s Plan” with the joystick and press
, the entry will be added to Today’s Plan, page 115.P82.85-5084-26
Destination input

102
Introduction Audio TelephoneNavigationIndex
S y s te m s e ttin g s
Searching for a destination from Recent Routes
If your destination is one of the twenty most recent
route calculations, you can recall that destination.
Press .
Select “Dest” with the joystick and press .
The destination menu appears. Select “Recent Route”
with the joystick and press .A list of up to the 20 most recent destinations is dis-
played. Select the desired destination with the joystick
and press .
P82.85-5102-26
P82.85-5022-26
Destination input

103
Introduction Audio TelephoneNavigationIndex
S y s te m s e ttin g s
The Confirm Destination menu will appear.
Select “OK to Proceed” with the joystick and press ,
the MCS will begin calculating the route.
Select “Save in Address Book” with the joystick and
press , the address will be stored in the Address
Book, page 110.
Select “Add to Today’s Plan” with the joystick and press
, the entry will be added to Today’s Plan, page 115.Searching for a destination in the Address Book
If a location has already been placed into the address
book, you can recall this location for use as a destina-
tion.
Press .
Select “Dest” with the joystick and press .
The destination menu appears. Select “Address Book”
with the joystick and press .P82.85-5027-26
P82.85-5103-26
Destination input

104
Introduction Audio TelephoneNavigationIndex
S y s te m s e ttin g s
A list with all locations saved in Address Book is dis-
played. Select the desired destination with the joystick
and press .The Confirm Destination menu will appear.
Select “OK to Proceed” with the joystick and press ,
the MCS will begin calculating the route.
Select “Add to Today’s Plan” with the joystick and press
, the entry will be added to Today’s Plan, page 115.P82.85-5104-26
P82.85-5027-26
Destination input

105
Introduction Audio TelephoneNavigationIndex
S y s te m s e ttin g s
Searching for a destination with the Map Cursor
A destination can be found by pointing to the location of
the destination on the map.
Press .
Select “Dest” with the joystick and press .
The destination menu appears. Select “Map Cursor”
with the joystick and press .The Place Cursor menu appears. Select “Directly on
Map” or “Within a City” with the joystick and press .
If you selected “Directly on Map” the menu “Select an
Area” will appear.
If you selected “Within a City” the menu “Select a City
Name” will first appear. See page 92 on how to enter a
city name.
P82.85-5114-26
P82.85-5024-26
Destination input

106
Introduction Audio TelephoneNavigationIndex
S y s te m s e ttin g s
If you have selected the map in a large scale, the “Select
an Area” menu appears with a five mile scale map of the
vehicle’s position. The vehicle’s current position icon
and the map cursor are shown on the map.
Move the map cursor to the desired destination with the
joystick and press to select the destination.
To return to the previous screen press .The “Select a Destination” menu appears with a detail
map (0.5 miles square) of the select destination. Select
“Directly on Map” with the joystick and press .
For a detailed view, press .
Move the map cursor to the desired location with the
joystick and press . The closest street segment to the
selected destination will be highlighted. If this street
segment is acceptable, press once again. If not, move
the joystick to choose another destination and press
again.P82.85-5030-26
P82.85-5031-26
Destination input

107
Introduction Audio TelephoneNavigationIndex
S y s te m s e ttin g s
The Confirm Destination menu will appear.
Select “OK to Proceed” with the joystick and press ,
the MCS will begin calculating the route.
Select “Save in Address Book” with the joystick and
press , the address will be stored in the Address
Book, page 110.
Select “Add to Today’s Plan” with the joystick and press
, the entry will be added to Today’s Plan, page 115.Searching for a street segment directly from the Map
Display
A destination can be found directly in map mode by
pointing to the location of the destination on the map. It
operates even while in guidance mode.
Refer to;
Starting Map, page 85.
Starting guidance mode, page 137.P82.85-5099-26
P82.85-5033-26
Destination input

108
Introduction Audio TelephoneNavigationIndex
S y s te m s e ttin g s
During normal navigation with the detailed display map
in view, move the present vehicle position icon to the
new desired street destination. You do not need to know
the street name. Once you have selected the correct
position press .A new destination point appears along with a call-out
indicating the street and city name.
Next, a warning appears asking if you would like to
change your destination. Press if you want to change
your destination. Press if you do not want to
change the destination.P82.85-5035-26
P82.85-5034-26
Destination input
