[CF60100( GV)05/96]
Unlocking the Doors with the Keyless
Entry System
[CF60200( GV)05/96]
You must unlock the driver's door before you
unlock any of the other doors or trunk. If you
let more than five seconds pass between pressing
numbers, the system shuts down, and you have
to enter the code again. The system has shut
down if the keypad light is out. If the keyless
entry system does not work properly, use the
key or transmitter(s) to lock and unlock the
doors or unlock the trunk.
*
[CF60300( GV)05/96]
1. To unlock the driver's door, enter the factory
code or your personal code. All codes have
five numbers. After you press the fifth
number, the driver's door unlocks.
[CF60400( GV)05/96]
2. To unlock the passenger's door, press the
3/4 button within five seconds of unlocking
the driver's door or trunk, or re-enter the
code to open the driver's door, then press
3/4.
*
[CF60500( GV)03/96]
3. To unlock the trunk, press the 5/6 button
within five seconds of unlocking the driver's
or passenger's doors, or re-enter the code to
open the driver's door, then press 5/6.
[CF60600( GV)05/96]
As long as the driver's door has been unlocked
first, you can open the passenger door or the
trunk in any order.
*
[CF60700( GV)05/96]
Locking the Doors with the Keyless Entry
System
*
[CF60800( GV)05/96]
Along with unlocking your doors, you can use
the keyless entry system to lock the doors. You
can also use the Autolock feature to
automatically lock the doors after you get in the
vehicle.
[CF60900( GV)05/96]
To lock all of the vehicle's doors at the same
time, press 7/8 and 9/0 at the same time. It is
not necessary to first enter the keypad code.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

111 % [CF61000( GV)05/96]
Autolock (With Keyless Entry if Equipped)
*
[CF61100( GV)05/96]
The Autolock feature will automatically lock all
the doors when:
[CF61200( GV)05/96]
q
the vehicle doors are fully closed
*
[CF61300( GV)05/96]
q
the ignition key is turned to the ON position
[CF61400( GV)05/96]
q
someone is sitting in the driver's seat or a
heavy object is placed on the seat, and
*
[CF61500( GV)03/96]
q
the vehicle is in any forward or reverse gear.
*
[CF61600( GV)05/96]
The Autolock feature will repeat when:
*
[CF61700( GV)05/96]
q
the ignition key remains in the ON position
[CF61800( GV)05/96]
q
someone remains sitting in the driver's seat
or a heavy object is on the seat
*
[CF61900( GV)05/96]
q
a door is opened and then closed
*
[CF62000( GV)03/96]
q
the vehicle is in any forward or reverse gear.
*
[CF62100( GV)05/96]
If you do not want to use the Autolock feature,
it can be deactivated by using the buttons for
the keyless entry system.
[CF62200( GV)05/96]
To deactivate the Autolock feature:
*
[CF62300( GV)05/96]
1. Enter your permanent five-digit entry code
(not the user code you may have set).
*
[CF62400( GV)05/96]
2. Within 5 seconds, press and hold 7/8.
*
[CF62500( GV)05/96]
3. Within 5 more seconds, press and release
3/4.
*
[CF62600( GV)05/96]
4. Release 7/8.
*
[CF62700( GV)05/96]
To reactivate the Autolock feature, simply repeat
the instructions for deactivating the system. The
Autolock feature can be turned on and off using
the instructions above.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

112 %
*
[CF62800( GV)05/96]
Programming Your Own Entry Code
*
[CF62900( GV)05/96]
You can program a personal code to unlock
your vehicle. This code does not replace the
permanent code that the dealership gave you.
Use your personal code in the same manner as
you would your original code.
*
[CF63000( GV)05/96]
To program your own code:
*
[CF63100( GV)05/96]
1. Select five digits for your personal code.
*
[CF63200( GV)05/96]
2. Enter the permanent code that the dealership
gave you.
*
[CF63300( GV)05/96]
3. Within five seconds, press 1/2.
[CF63400( GV)04/96]
4. Within five seconds of pressing 1/2, enter
your personal code, pressing each digit
within five seconds of the previous digit.
[CF63500( GV)05/96]
5. Five seconds after you press the fifth digit,
your door lock system will lock and unlock
the vehicle doors to confirm successful
programming.
*
[CF63600( GV)05/96]
The keyless entry system registers this
second code. To open your vehicle, you can
now use either code. The module remembers
only one personal code at a time. Entering a
second personal code will erase the first,
replacing it with the new second one.
*
[CF63700( GV)05/96]
To erase your personal code:
*
[CF63800( GV)05/96]
1. Enter the original permanent code.
[CF63900( GV)03/96]
2. Press and release 1/2 within five seconds of
Step 1.
[CF64000( GV)12/95]
3. Press the 1/2 button a second time and hold
for two seconds.
*
[CF64100( GV)05/96]
The keyless entry system automatically
erases your personal code. The system will
now only respond to the permanent code.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

113
*
[CF64200( GV)05/96]
Do not set a code that presents the numbers in
sequential order, such as 1/2, 3/4, 5/6, 7/8, 9/0.
Studies show that people who idly press the
buttons usually press a sequential pattern. Also,
do not select a code that uses the same button
five times. Thieves can easily figure out these
types of codes.
[CF64300( GV)12/95]
Your door lock system will lock and unlock the
vehicle doors to confirm successful erasure. The
system will now only respond to the permanent
code.
%*
[CF64400( GV)05/96]
Battery Saver
*
[CF64500( GV)12/95]
When the ignition is turned off, the vehicle will
turn off battery voltage to the vehicle lamps as
follows:
*
[CF64600( GV)12/95]
q
Courtesy lights (lights which come on when a
door is opened): after 10 minutes.
[CF64700( GV)12/95]
q
Map/Glove compartment/Trunk/Hood
lamps: after 30 minutes.
[CF64800( GV)12/95]
q
Headlamps/Park lamps (only if headlamp
switch is left in Headlamp position): after 10
minutes.
*
[CF64900( GV)05/96]
This will prevent draining of the battery if those
lights have been left on inadvertently or if a
door is not completely closed. Battery voltage to
these lamps will be restored when the keyless
entry keypad is used, the remote entry
transmitter is used, any door is opened, the
trunk is opened, or the ignition key is turned to
the ON position.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

114
*
[CF65000( ALL)05/96]
Remote Entry System
(If equipped)
*
[CF65100( ALL)05/96]
If your vehicle has the remote entry system, you
can lock and unlock the vehicle doors and open
the trunk without using a key. The remote also
has a personal alarm feature. The controls for
the system are located on the hand held
transmitter(s) that came with your vehicle.
*
[CF65200( ALL)01/96]
The system will work with up to four
transmitters. Your vehicle came with two
transmitters. Additional transmitters can be
ordered from your dealer.
[CF65400( GV)12/95]
The remote entry features only operate with the
transmission in P (Park) or N (Neutral).
[CF65600( GV)12/95]
one third page art:0011287-A
Remote entry transmitter
%*
[CF65700( ALL)02/96]
Unlocking the doors and opening the
trunk
*
[CF65800( ALL)04/96]
To unlock the driver's door, press the UNLOCK
control.
*
[CF65900( ALL)04/96]
To unlock the other doors, press the UNLOCK
control a second time within five seconds of
unlocking the driver's door.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

115
*
[CF66000( ALL)05/96]
To open the trunk, press the TRUNK control.
[CF66100( GV)12/95]
To open the trunk, press the TRUNK control
twice within five seconds.
*
[CF66200( ALL)04/96]
Locking the doors
*
[CF66300( ALL)04/96]
To lock all the doors, press the LOCK control.
[CF66500( GV)05/96]
The doors will lock and the horn will chirp to
indicate the vehicle is locked.
*
[CF66600( GV)05/96]
The door lock Horn Chirp is a programmable
feature. To deactivate the Horn Chirp feature:
*
[CF66700( GV)12/95]
1. Enter your permanent five-digit code (not
the user code you may have set).
*
[CF66800( GV)01/96]
2. Within five seconds, press and hold 7/8.
[CF66900( GV)12/95]
3. Within five more seconds, press and release
1/2.
*
[CF67000( GV)05/96]
4. Release 7/8.
[CF67100( GV)12/95]
To reactivate the Horn Chirp feature, simply
repeat the instructions for deactivating the
feature.
%*
[CF67200( ALL)03/96]
Activating the remote personal alarm
*
[CF67300( ALL)04/96]
If you wish to activate the remote personal
alarm, press the PANIC control. This will honk
the horn and flash the parking lamps and tail
lamps for approximately two minutes and
forty-five seconds. You can turn it OFF by
pressing the PANIC control again or by turning
the ignition key to the RUN position.
[CF67400( ALL)05/96]
When you use the remote entry UNLOCK,
TRUNK or PANIC controls, the illuminated
entry system turns on the interior lights for 25
seconds. You can turn these lights off with the
LOCK control or by turning the ignition to the
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

116RUN position. The interior lights will not turn
off if you have turned them on manually or if a
door is open.
%*
[CF68400( ALL)03/96]
Replacing the batteries
*
[CF68600( GV)01/96]
The remote entry transmitter is powered by two
coin type three-volt lithium 1616
batteries (included) that should last for several
years of normal use. If you notice a significant
decrease in operating range, the batteries should
be replaced. Replacement batteries can be
purchased at most pharmacies, watch stores or
at your Ford or Lincoln-Mercury dealer.
*
[CF68700( ALL)01/96]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
%*
[CF69000( ALL)02/96]
Replacement/additional transmitters
*
[CF69200( GV)12/95]
In the event a transmitter is lost, a new one may
be purchased from your dealer.
*
[CF69300( GV)12/95]
To program replacement or additional
transmitters you must have all the transmitters
intended for use on your vehicle.
*
[CF69400( GV)12/95]
Initiating the following procedure erases all prior
programmed transmitters, thus ALL must be
reprogrammed at the same time.
*
[CF69500( GV)12/95]
1. Enter the factory keyless entry code. Your
personal code will not allow programming.
*
[CF69700( GV)12/95]
2. Press the 1/2 button.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

117
*
[CF69800( GV)12/95]
3. Press one button on each of the transmitters
to be programmed. Each transmitter button
must be pressed within seven (7) seconds of
the prior one. Each time a transmitter is
successfully programmed, all of the vehicle
doors will lock and then unlock to verify
programming. If the doors did not
lock/unlock, your transmitter was not
programmed.
*
[CF69900( GV)01/96]
Additional transmitters may be purchased from
your dealer (remote entry system will work with
up to four transmitters). Follow the same
programming procedure as above.
*
[CF70000( ALL)01/96]
THIS DEVICE COMPLIES WITH PART 15 OF
THE FCC RULES. OPERATION IS SUBJECT
TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
*
[CF70100( GV)12/95]
NOTE: All transmitters to be used on your
vehicle must be
programmed/reprogrammed at the same
time.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

119
Seating and Safety
Restraints
%*
[SS00200( ALL)05/96]
Seats
%*
[SS00300( ALL)05/96]
Head Restraints
*
[SS00400( ALL)01/96]
If you use them properly, head restraints will
help protect your head and neck in a collision.
*
[SS00500( ALL)01/96]
A head restraint helps protect you best if you
position it behind your head and not behind
your neck.
*
[SS00600( ALL)12/95]
Standard head restraints
*
[SS00700( ALL)12/95]
You can adjust the head restraints for your
comfort and protection.
[SS00800( ALL)12/95]
one third page art:0010048-C
Adjusting the head restraint
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997

120 % [SS01300( GV)12/95]Adjusting the Front Passenger Seat
Manually
*
[SS01400( ALL)01/96]
In the front seats, you can move the whole seat
forward or backward or tilt the back of the seat
forward or backward.
*
[SS01600( GV)08/95]
To move the seat forward or backward:
[SS01700( BCGV)12/95]
1. Find the adjustment bar underneath the front
part of the seat.
[SS01900( BCGV)12/95]
2. Lift the bar to unlatch the seat.
*
[SS02100( ALL)01/96]
3. Move the seat to the desired position.
*
[SS02200( BCGV)01/96]
4. Release the bar to latch the seat in its new
position. Make sure the seat locks securely in
place.
[SS02600( GV)12/95]
one third page art:0010173-B
The front seat adjustment bar
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997
