Mercury Grand Marquis 1997 Owner's Manuals

100
*
[CF38700( ALL)01/96]
RWARNING
Make sure you can see clearly through the
rearview mirror at all times. Do not block
your vision. If you cannot see through the
mirror, it could result in a collision,
injuring yourself and others.
%*
[CF39100( GV)05/96]
Automatic Dimming Inside Rearview
Mirror (If equipped)
[CF39200( GV)12/95]
quarter page art:0010037-C
The automatic non-glare mirror
*
[CF39300( GV)01/96]
The electronic day/night mirror will change
from the normal state to the non-glare state
when bright lights (glare) reach the mirror. This
mirror functions at night, and has a limited
function at dusk or dawn. From the non-glare
state, the mirror will return to the normal state
after a short delay. The delay starts when the
glare goes away. The delay prevents excessive
changing of the mirror as traffic moves behind
and around the vehicle, or on rolling hills and
curves.
[CF39400( GV)12/95]
To turn the mirror on, push the ON/OFF
switch, located on the bottom of the mirror, to
latch it in the ON position. The switch will
illuminate and the mirror will be in the
automatic dimming mode. To turn the switch
illumination and automatic dimming feature off,
push the ON/OFF switch again.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

101
*
[CF39500( GV)01/96]
The electronic mirror measures the brightness of
the light coming in from the rear of the vehicle.
It automatically makes a correction in the glare
state. The mirror may be turned off in either the
normal or non-glare position.
[CF39600( GV)12/95]
There are two light sensors (photocells) in this
mirror. The sensor that detects rear glare is
located inside a window in the center of the
mirror. The second light sensor which
determines outside light level is located on the
backside of the mirror case.
*
[CF39605( GV)05/96]
NOTE: Do not block the sensor on the
backside of the mirror (i.e., with a
parking tag, car deodorizer, etc.) since
this may impair proper mirror
performance.
*
[CF39700( GV)05/96]
One important safety feature is that the mirror
automatically returns to the normal position
whenever the vehicle is placed in R (Reverse)
(when the mirror is in the ON position). This
feature ensures a bright clear view in the mirror
when backing up.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

102
%*
[CF39800( ALL)05/96]
Sun Visors
% [CF40300( ALL)04/96]
Turning on the Mirror Light on the Sun
Visors (If equipped)
[CF40400( ALL)12/95]
To turn on the visor mirror light, lift the mirror
cover.
[CF40700( GV)12/95]
one third page art:0010278-B
The mirror on the sun visor
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

103
%*
[CF40800( ALL)02/96]
Doors
[CF40850( BCGV)03/96]
Two map pockets are provided on the panels of
the front doors.
%*
[CF40900( GV)04/96]
Childproof Locks for the Rear Doors
*
[CF41000( GV)12/95]
In addition to power locks, your vehicle has
childproof locks for the rear doors. If you set
these locks, the rear doors cannot be opened
from the inside of the vehicle. The doors can still
be opened from the outside when the lock knobs
are raised.
[CF41100( GV)12/95]
half page art:0010652-A
The childproof locks for the rear doors
*
[CF41200( GV)01/96]
To set the childproof lock on each rear door,
open the rear door.
[CF41300( GV)12/95]
Find the lever inside the label with the word
LOCKED. Move the lever up.
*
[CF41400( GV)04/96]
To release the childproof lock, open the rear
door from the outside and move the lever down.
*
[CF41500( GV)05/96]
Move the lever down.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

104 %
*
[CF41800( ALL)01/96]
Power Door Locks (If equipped)
[CF41900( ALL)12/95]
If your vehicle has power door locks, the
controls to lock the doors are on the trim panel
of the front door. When you close the doors
after you set the door locks, the doors remain
locked. If the power mechanism fails, the manual
door locks will override the power controls.
Pulling on a front inside door handle will
automatically override and release the front door
lock.
[CF42300( GV)12/95]
one third page art:0010224-D
The power locks on the driver's door
%*
[CF42410( GV)9/96]
Using the Illuminated Entry System
*
[CF42500( GV)05/96]
The interior lights will illuminate for
approximately 25 seconds on vehicles without
the keyless entry system
*
[CF42510( GV)09/96]
q
when the outside driver door handle is lifted
*
[CF42520( GV)09/96]
q
when the front passenger door handle is
lifted
%*
[CF42530( GV)09/96]
and on vehicles with the keyless entry system
*
[CF42540( GV)09/96]
q
when any button on the keyless entry pad is
pushed
*
[CF42550( GV)09/96]
q
when the remote entry system UNLOCK
button is pressed.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

105
*
[CF43000( GV)05/96]
If the Autolamp is turned to the on position and
the amount of light outside is below a
predetermined level, the exterior lamps will also
illuminate.
%
*
[CF43405( ALL)04/96]
Windows
%*
[CF43415( BCGV)12/95]
Using the Power Windows
*
[CF43425( GV)12/95]
Each door has a power control that opens and
closes the window on that door. The driver's
door has a master control panel that operates all
four windows.
*
[CF43430( ALL)12/95]
Power windows can only be opened or closed
when the ignition switch is in the ON or ACC
position.
*
[CF43435( ALL)01/96]
RWARNING
Do not let children play with the power
windows.
[CF43450( GV)12/95]
one third page art:0010234-D
The master controls on the driver's door
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

106
*
[CF43455(M GV)12/95]
To lock out all window switches except the
master controls, press the right side of the
window lock switch. To restore control to the
individual windows, press the left side of the
switch.
%*
[CF43460(M GV)03/96]
There is also an Express Down feature on the
driver's power window.
*
[CF43465(M GV)05/96]
To operate, briefly press the driver's window
switch to the down position. The window will
then open automatically. To stop automatic
operation, briefly press the switch again to either
the up or down position. More than a quick
press of the switch provides conventional power
window operation. Closing of the power
window is conventional operation only.
% [CF43600( BCGV)03/96]Adjusting the Dual Electric
Remote Control Mirrors
[CF43700( GV)12/95]
Your vehicle is equipped with electric remote
control side view mirrors; the switch for
controlling their operation is a control knob in
the armrest.
%*
[CF44000( ALL)12/95]
Do not clean the housing or glass of any mirror
with harsh abrasives, fuel or other
petroleum-based cleaning products.
[CF44100( GV)12/95]
one third page art:0010273-C
The mirror controls on the driver's left armrest
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

107
*
[CF44400( ALL)01/96]
To adjust the side mirrors:
*
[CF44500( ALL)05/96]
1. Find the control switch in the driver's door
panel.
*
[CF44600( ALL)05/96]
2. Select the right or left mirror by moving the
selector switch to R or L.
[CF44700(M GV)05/96]
3. Move the knob in the direction of the arrows
for the direction you want to move the
mirror.
*
[CF44800( ALL)05/96]
4. Return the selector switch to the middle
position to keep the mirror in place.
[CF44900( ALL)12/95]
The Right Side Convex Mirror
*
[CF45000( ALL)12/95]
The side view mirror on the right is a convex
mirror. This mirror gives you a wider view of
the lanes on your right and behind you.
*
[CF45100( ALL)05/96]
RWARNING
The right side view mirror makes objects
appear smaller and farther away than they
actually are.
% [CF51000( ALL)12/95]
Positive Location Floor Mat
[CF51200( GV)12/95]
When installing or removing the driver's side
floor mat you must attach/detach the positive
location grommet from the hook on the floor.
The hook is just forward of the center of the
driver's seat. This is done by rotating the
grommet one quarter turn, slipping the eyelet
onto the hook, and sliding it to the floor.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

108 [CF51400( GV)12/95]
half page art:0001094-BThe positive location floor mat hook
[CF51500( ALL)12/95]
Trunk
[CF51600( ALL)12/95]
Opening the Trunk Manually
[CF52100( GV)12/95]
The trunk in your vehicle gives you plenty of
room for storage Ð 20.6 cubic feet (.58 cubic
meters).
[CF52200( ALL)12/95]
To open and close the trunk from the outside:
[CF52400( BCGV)12/95]
1. Insert the key into the lock on the trunk.
[CF52500( ALL)12/95]
2. Turn the key to the right until the trunk
opens.
[CF52600( ALL)12/95]
3. Remove the key before you close and lock
the lid.
[CF52700( ALL)12/95]
4. Shut the trunk lid completely.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

109
%*
[CF59200( GV)05/96]
Keyless Entry System
(If equipped)
[CF59300( GV)05/96]
If your vehicle has the keyless entry system, you
can lock or unlock the vehicle doors and trunk
without using a key. The buttons for the system
are above the outside door handle on the
driver's side.
[CF59400( GV)03/96]
one third page art:0010477-B
The keyless entry buttons
*
[CF59500( GV)05/96]
When you bought your vehicle, you were given
a computer code that operates the system for
your vehicle. For your convenience, we have
duplicated this code in two places.
*
[CF59600( GV)05/96]
The code is:
*
[CF59700( GV)05/96]
q
on your owner's wallet card found in the
glove compartment
[CF59800( GV)05/96]
q
taped to the underside of the trunk lid
[CF60000( GV)05/96]
When you use this entry system, the illuminated
entry system turns on the interior lights for 25
seconds and the buttons on the keypad light up.
Do not push the buttons with a key, ballpoint
pen, pencil, or any other hard object. These
objects could damage the buttons.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996
