Starting
%*
[TO00200( ALL)01/96]
Fuel-Injected Engines
*
[TO00300( ALL)01/96]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
*
[TO00400( ALL)01/96]
Starting Your Vehicle
%*
[TO00500( ALL)01/96]
Preparing to Start Your Vehicle
*
[TO00600( ALL)02/96]
RWARNING
Do not start your vehicle in a closed
garage or in other enclosed areas. Exhaust
fumes can be toxic. Always open the
garage door before you start the engine.
*
[TO00700( ALL)01/96]
Before you start your vehicle, do the following:
*
[TO00800( ALL)01/96]
1. Make sure all occupants in the vehicle
buckle their safety belts. SeeSafety Restraints
in the Index for more details.
*
[TO00900( ALL)01/96]
2. Make sure the headlamps and other
accessories are turned off when starting.
*
[TO01200( BCGV)01/96]
3. Make sure that the gearshift is in P (Park)
and the parking brake is set before you turn
the key.
File:08rctog.ex
Update:Tue Jun 11 13:57:50 1996

152
*
[TO01300( ALL)02/96]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to the
Instrumentationchapter.
%*
[TO01400( ALL)01/96]
Starting Your Engine
*
[TO01500( ALL)01/96]
To start your engine:
*
[TO01600( ALL)01/96]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[TO01700( ALL)01/96]
2. Turn the ignition key to the ON position.
*
[TO01800( ALL)01/96]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
*
[TO01900( ALL)01/96]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[TO02000( ALL)05/96]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
%*
[TO02100( ALL)01/96]
For a cold engine:
*
[TO02200( ALL)01/96]
q
At temperatures10ÊF (-12ÊC) andbelow:If
the engine does not start infifteen (15)
secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you
do not flood the engine, then try again.
*
[TO02300( ALL)01/96]
q
At temperaturesabove10ÊF(-12ÊC):If the
engine does not start infive (5) secondson
the first try, turn the key to OFF, wait
approximately ten (10) seconds so you do not
flood the engine, then try again.
File:08rctog.ex
Update:Tue Jun 11 13:57:50 1996

153 %
*
[TO02400( ALL)01/96]
For a warm engine:
*
[TO02500( ALL)01/96]
q
Do not hold the key in the START position
for more thanfive (5) secondsat a time. If
the engine does not start within five (5)
seconds on the first try, turn the key to the
OFF position. Wait a few seconds after the
starter stops, then try again.
*
[TO02600( ALL)01/96]
Whenever you start your vehicle, release the key
as soon as the engine starts. Excessive cranking
could damage the starter.
*
[TO02700( ALL)01/96]
After you start the engine, let it idle for a few
seconds. Keep your foot on the brake pedal and
put the gearshift lever in gear. Release the
parking brake. Slowly release the brake pedal
and drive away in the normal manner.
*
[TO02800( ALL)12/95]
NOTE: Your vehicle has an interlock that
prevents you from shifting out of P
(Park) unless your foot is on the brake
pedal.
%*
[TO02900( ALL)01/96]
If the engine does not start after two attempts:
*
[TO03000( ALL)01/96]
1. Turn the ignition key to the OFF position.
*
[TO03100( ALL)01/96]
2. Press the accelerator all the way to the floor
and hold it.
*
[TO03200( ALL)01/96]
3. Turn the ignition key to the START position.
*
[TO03300( ALL)01/96]
4. Release the ignition key when the engine
starts.
*
[TO03400( ALL)03/96]
5. Release the accelerator gradually as the
engine speeds up.
[TO03500( ALL)03/96]
If the engine still does not start, the fuel pump
shut-off switch may have been triggered. For
directions on how to reset the switch seeFuel
Pump Shut-Off Switchin the Index.
File:08rctog.ex
Update:Tue Jun 11 13:57:50 1996

154
*
[TO03600( ALL)01/96]
A computer system controls the engine's idle
speed. When you start your vehicle, the engine's
idle speed normally runs higher than when it's
warmed up. These faster engine speeds will
make your vehicle move slightly faster than its
normal idle speed. It should, however, slow
down after a short time. If it does not, have the
idle speed checked.
*
[TO03700( ALL)01/96]
If the engine idle speed does not slow down
automatically, do not allow your vehicle to idle
for more than 10 minutes. Have the vehicle
checked.
*
[TO03800( ALL)01/96]
RWARNING
Extended idling at high engine speeds can
produce very high temperatures in the
engine and exhaust system, creating the
risk of fire or other damage.
*
[TO03900( ALL)01/96]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[TO04000( ALL)01/96]
If you consistently start your vehicle in subzero
temperatures, use an engine block heater (if
your vehicle has this option).
%*
[TO04100( ALL)01/96]
Engine Block Heater (If equipped)
*
[TO04200( ALL)01/96]
Engine block heaters are strongly recommended
if you live in a region where temperatures reach
-10ÊF (-23ÊC) orbelow. An engine block heater
warms the engine coolant, which improves
starting, warms up the engine faster, and allows
the heater-defrost system to respond quickly.
File:08rctog.ex
Update:Tue Jun 11 13:57:50 1996

155
*
[TO04300( ALL)01/96]
To turn the heater on, simply plug it into a
grounded 110-volt outlet. Ford recommends that
you use a 110-volt circuit that is protected by a
ground fault circuit interrupter.
*
[TO04400( ALL)01/96]
RWARNING
To prevent electrical shock, do not use
your heater with ungrounded electrical
systems or two-pronged (cheater) adapters.
*
[TO04500( ALL)01/96]
For best results, plug the heater in at least three
hours before you start your vehicle. Using the
heater for longer than three hours will not
damage the engine, so you can plug it in at
night to start your vehicle the following
morning.
*
[TO04600( ALL)01/96]
NOTE: Be sure to disconnect the engine block
heater before driving your vehicle.
*
[TO04700( ALL)12/95]
Guarding Against Exhaust Fumes
*
[TO04800( ALL)01/96]
Carbon monoxide, although colorless and
odorless, is present in exhaust fumes. Take
precautions to avoid its dangerous effects.
*
[TO04900( ALL)02/96]
RWARNING
Do not start your vehicle in a closed
garage or in other enclosed areas. Exhaust
fumes can be toxic. Always open the
garage door before you start the engine.
*
[TO05000( ALL)01/96]
RWARNING
If you smell exhaust fumes inside your
vehicle, have your dealer inspect your
vehicle immediately. Do not drive if you
smell exhaust fumes.
File:08rctog.ex
Update:Tue Jun 11 13:57:50 1996

156
*
[TO05100( ALL)01/96]
Have the exhaust and body ventilation systems
checked whenever:
*
[TO05200( ALL)01/96]
q
your vehicle is raised for service
*
[TO05300( ALL)01/96]
q
the sound of the exhaust system changes
*
[TO05400( ALL)01/96]
q
your vehicle has been damaged in a collision
*
[TO05500( ALL)01/96]
Improve your ventilation by keeping all air inlet
vents clear of snow, leaves, and other debris.
[TO05600( ALL)12/95]
If the engine is idling while you are stopped in
an open area for long periods of time, open the
windows at least one inch (2.5 cm). Also, the
heating or air conditioning system should be set
to any function except MAX A/C or AUTO.
[TO05800( BCGV)12/95]
q
If you use the heater, set the fan speed on
MEDIUM or HIGH with the function control
on any position except OFF and the
temperature control at any desired position.
[TO06000( BCGV)12/95]
q
If you use the air conditioner, set the fan
speed on MEDIUM or HIGH with the
function control on any position except OFF
or MAX and the temperature control at any
desired position.
*
[TO06100( ALL)01/96]
Pushing
[TO06300( BCGV)01/96]
Vehicles with automatic transmissions cannot be
started by pushing. Follow the directions under
If Your Vehicle Needs a Jump-Start.
File:08rctog.ex
Update:Tue Jun 11 13:57:50 1996

157
Driving
%*
[GF00500( ALL)05/96]
Brakes
%*
[GF00600( ALL)01/96]
Applying the Brakes
[GF00700( ALL)12/95]
Braking non ABS models
[GF01100( GV)12/95]
Your vehicle has front and rear disc brakes with
anti-lock (optional). They adjust automatically as
the brake pads wear down.
*
[GF01200( ALL)01/96]
Apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
wheels to continue to roll while you are slowing
down, which lets you steer properly.
[GF01300( ALL)12/95]
On vehicles without anti-lock brakes, extreme
braking can make the wheels lock and slide,
possibly decreasing your control of the steering.
If you lock the wheels, release the brake pedal
and repeat the ªsqueezeº technique.
[GF01400( ALL)12/95]
Braking with ABS brakes
[GF01500( ALL)12/95]
On vehicles with anti-lock brakes, the wheels
will not lock and slide when you press down
hard on the brake pedal. The anti-lock brakes
automatically start releasing and reapplying the
front brakes independently and the rear brakes
together whenever your wheels start to lock. Do
not ªpumpº the brake pedal on vehicles
equipped with anti-lock brakes. When this
happens, you will feel the brake pedal pulse.
This ªpulseº may be an unfamiliar feeling but it
is normal and indicates the ABS is working as
designed.
File:09rcgfg.ex
Update:Thu Sep 19 12:26:42 1996

158
*
[GF01600( ALL)01/96]
Do not drive with your foot resting on the brake
pedal; you will wear out the linings and increase
your vehicle's stopping distance. Brake rotor
damage may also eventually occur.
*
[GF01700( ALL)02/96]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
%*
[GF01800( ALL)01/96]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes louder or more frequent, have your
brakes inspected by your dealer or a qualified
service technician.
[GF01900( ALL)12/95]
Ford Motor Company has not found any
detrimental effects of popular mobile radio
transmitting equipment installed on vehicles
with the anti-lock brake system, if the equipment
is installed according to the manufacturer's
instructions. However, if mobile radio
transmitting equipment is installed in your
vehicle and, if either the anti-lock brake system
cycles or the check anti-lock light comes on at
any time other than right after you turn the key
to ON or during a sudden stop, have your
mobile radio dealer inspect the installation.
File:09rcgfg.ex
Update:Thu Sep 19 12:26:42 1996

159 %
*
[GF02000( ALL)05/96]
Parking Brake
*
[GF02100( ALL)03/96]
The parking brake should be used whenever
you park your vehicle.
[GF02300( BCGV)12/95]
The parking brake pedal is suspended just below
the bottom of the instrument panel to the left of
the brake pedal.
[GF02600( GV)12/95]
To manually set the parking brake after parking
your vehicle, apply the brake pedal with your
right foot and hold it while you push the
parking brake down firmly and fully with your
left foot. The brake system warning light will
glow. The parking brake will not set with the
transmission in any forward gear position.
[GF02900( GV)12/95]
one third page art:0010319-E
The parking brake
*
[GF03100( BCGV)05/96]
RWARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
*
[GF03400( GV)12/95]
Your vehicle has an automatic parking brake
release. As you move the gearshift selector to
any forward gear with the engine running, the
parking brake automatically releases. Your
parking brake will not release automatically
File:09rcgfg.ex
Update:Thu Sep 19 12:26:42 1996

160when you shift into R (Reverse). To release the
parking brake manually, pull the brake release
handle [marked (P)] located on the lower left
corner of the instrument panel. The pedal is now
released and will reset the next time you press
the pedal. The Brake System Warning Light will
glow if the parking brake is not fully released
when the engine is running.
*
[GF03500( GV)01/96]
RWARNING
To prevent personal injury, do not release
the parking brake while outside the
vehicle.
*
[GF03600( ALL)01/96]
Always check the Brake Warning Light each
time you start your engine. Driving with the
parking brake on will cause the brakes to wear
out quickly and will reduce the fuel economy.
*
[GF03700( ALL)02/96]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
[GF03800( ALL)12/95]
The parking brake system is designed for static
parking only and is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
File:09rcgfg.ex
Update:Thu Sep 19 12:26:42 1996
