Mercury Grand Marquis 1997 Owner's Manuals

141
*
[SS31100( ALL)04/96]
half page art:0011238-C
Pulling out belt webbing
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997

142
*
[SS31200( ALL)01/96]
3. While holding the shoulder and lap belt
portions together, route the tongue through
the child seat according to the child seat
manufacturer's instructions. See Figure 2. Be
sure that the belt webbing is not twisted.
*
[SS31300( ALL)04/96]
half page art:0011239-C
Routing the lap/shoulder belt
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997

143
*
[SS31400( ALL)01/96]
4. Insert the belt tongue into the buckle for that
seating position until you hear and feel the
latch engage. See Figure 3. Make sure tongue
is latched securely to buckle by pulling on
tongue.
*
[SS31500( ALL)01/96]
half page art:0011240-B
Buckling the belt
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997

144
*
[SS31600( ALL)01/96]
5. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted and a click is heard. At this time,
the retractor is in the automatic locking
mode (child seat restraint mode). See Figure
4.
*
[SS31700( ALL)01/96]
NOTE: The dual-locking mode retractor must
be in the automatic locking mode to
properly restrain a child.
*
[SS31800( ALL)04/96]
half page art:0011241-B
Setting the retractor to automatic locking mode
*
[SS31900( ALL)01/96]
6. Allow the belt to retract. Pull up on the
shoulder webbing. A clicking sound will be
heard as the belt retracts. This indicates the
retractor is in the automatic locking mode.
Push down on the child seat while you pull
up on the belt to remove any slack in the
belt. See Figures 5 and 6.
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997

145
*
[SS32000( ALL)04/96]
half page art:0011242-B
Allowing shoulder belt to retract
*
[SS32100( ALL)01/96]
half page art:0011243-A
Removing slack from belt
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997

146
*
[SS32200( ALL)01/96]
7. Before placing the child in the child seat,
forcibly tilt the seat from side to side, and
tug it forward to make sure that the seat is
securely held in place. See Figure 7.
*
[SS32300( ALL)04/96]
half page art:0011244-B
Checking that the seat is secure
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997

147
*
[SS32400( ALL)01/96]
8. Double check that the retractor is in the
automatic locking mode. Try to pull more
belt out of the retractor. If you cannot, the
belt is in the automatic locking mode. See
Figure 8.
*
[SS32500( ALL)04/96]
half page art:0011245-C
Checking the retractor
*
[SS32600( ALL)01/96]
9. Check to make sure that the child seat is
properly secured prior to each use. If the
retractor is not locked, repeat steps 4
through 7.
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997

148 [SS34705( GV)05/96]Installing a Child Safety Seat at a Center
Seating Position with Adjustable Lap Belt
*
[SS34800( BCGV)01/96]
1. Lengthen the lap belt. To lengthen the belt,
hold the tongue so that its bottom is
perpendicular to the direction of webbing
while sliding the tongue up the webbing.
*
[SS34900( BCGV)01/96]
2. Place the child safety seat in the center
seating position.
*
[SS35000( BCGV)01/96]
3. Route the tongue and webbing through the
child seat according to the child seat
manufacturer's instructions.
*
[SS35100( BCGV)01/96]
4. Insert the belt tongue into the proper buckle
for the center seating position until you hear
a snap and feel it latch. Make sure the
tongue is securely fastened to the buckle by
pulling on tongue.
*
[SS35200( BCGV)01/96]
5. Push down on the child seat while pulling
on the loose end of the lap belt webbing to
tighten the belt.
[SS35300( BCGV)12/95]
6. Before placing the child into child seat,
forcibly tilt the child seat from side-to-side
and in forward direction to ensure that the
seat is held securely in place. If the child
seat moves excessively, repeat steps 5
through 6, or properly install the child seat
in a different position.
[SS35320( ALL)04/96]
Attaching Safety Seats with Tether Straps
*
[SS35340( ALL)04/96]
Some manufacturers make safety seats that
include a tether strap that goes over the back of
the vehicle seat and attaches to an anchoring
point. Other manufacturers offer the tether strap
as an accessory. Contact the manufacturer of
your child safety seat for information about
ordering a tether strap.
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997

149 %
*
[SS35360( ALL)04/96]
Tether anchorage hardware
[SS35380( ALL)05/96]
Attachment holes (at each rear seating position)
have been provided in your vehicle to attach
anchor hardware, if required. Tether anchor
hardware kits (Part number 613D74), including
instructions, may be obtained at no charge from
any Ford or Lincoln-Mercury dealer. All vehicles
built for sale in Canada include a tether anchor
hardware kit.
%*
[SS35400( ALL)01/96]
Safety Belts for Children
*
[SS35500( ALL)01/96]
Children who are too large for child safety seats
should always wear safety belts. (See instructions
with your child seat, or contact its manufacturer,
to determine maximum size of child that will
safely fit in the seat.)
*
[SS35600( ALL)01/96]
WARNING
If safety belts are not properly worn and
adjusted as described, the risk of serious
injury to the child in a collision will be
much greater.
*
[SS35700( ALL)01/96]
If the shoulder belt portion of one of the lap and
shoulder belts can be positioned so that it does
not cross or rest in front of the child's face or
neck, the child should wear the lap and shoulder
belt. Moving the child closer to the center of the
vehicle may help provide a good shoulder belt
fit.
[SS35900( GV)12/95]
WARNING
If the shoulder belt cannot be properly
positioned, the child should sit in the
center rear seat and use the lap belt or, if
that seat is unavailable, in the center front
seat and use the lap belt.
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997

150
*
[SS36000( ALL)01/96]
To improve the fit of lap and shoulder belts on
children who have outgrown child safety seats,
Ford recommends use of a belt-positioning
booster seat that is labelled as conforming to all
Federal motor vehicle safety standards.
Belt-positioning booster seats raise the child and
provide a shorter, firmer seating cushion that
encourages safer seating posture and better fit of
lap and shoulder belts on the child. A
belt-positioning booster should be used if the
shoulder belt rests in front of the child's face or
neck, or if the lap belt does not fit snugly on
both thighs, or if the thighs are too short to let
the child sit all the way back on the seat cushion
when the lower legs hang over the edge of the
seat cushion. You may wish to discuss the
specific needs of your child with your
pediatrician.
*
[SS36100( ALL)01/96]
WARNING
Do not use a belt-positioning booster with
a lap-only belt.
*
[SS36200( ALL)01/96]
Lap belts and the lap belt portion of lap and
shoulder belts should always be worn snugly
and below the hips, touching the child's thighs.
*
[SS36300( ALL)02/96]
WARNING
Children should always ride with the
seatback in the fully upright position.
