IGNITION SYSTEM
ENGINE ELECTRICAL16-33
IGNITION COIL
REMOVAL AND INSTALLATION M1163004000448
REMOVAL STEPS
ENGINE COVER (REFER TO
GROUP 11C, ENGINE ASSEMBLY
11A-14).
1. IGNITION COIL CONNECTORS
(LH)
2. IGNITION COILS (LH)
3. SPARK PLUGS (LH)INTAKE MANIFOLD PLENUM
(REFER TO GROUP 15, INTAKE
MANIFOLD PLENUM P.15-5).
4. IGNITION COIL CONNECTORS
(RH)
5. IGNITION COILS (RH)
6. SPARK PLUGS (RH)REMOVAL STEPS (Continued)

IGNITION SYSTEM
ENGINE ELECTRICAL16-34
CAMSHAFT POSITION SENSOR
REMOVAL AND INSTALLATION M1163003400476
REMOVAL STEPS
1. CAMSHAFT POSITION SENSOR
CONNECTOR2. CAMSHAFT POSITION SENSOR
3. O-RINGREMOVAL STEPS (Continued)

IGNITION SYSTEM
ENGINE ELECTRICAL16-35
CRANKSHAFT POSITION SENSOR
REMOVAL AND INSTALLATION M1163003500473
Pre-removal and Post-installation Operation
Timing Belt Lower Cover Removal and Installation (Refer to
GROUP 11C, Timing Belt 11A-46).

IGNITION SYSTEM
ENGINE ELECTRICAL16-36
KNOCK SENSOR
REMOVAL AND INSTALLATION M1163002800589
Required Special Tool:
MD998773: Knock Sensor Wrench
REMOVAL SERVICE POINT
.
<> KNOCK SENSOR REMOVAL
Use special tool MD998773 to remove the knock sensor.
Pre-removal and Post-installation Operation
Intake Manifold Removal and Installation (Refer to GROUP
15, Intake Manifold P.15-7).
REMOVAL
<> >>A<<1. KNOCK SENSOR

IGNITION SYSTEM
ENGINE ELECTRICAL16-37
INSTALLATION SERVICE POINT
.
>>A<< KNOCK SENSOR INSTALLATION
Use special tool MD998773 to install the knock sensor.

SPECIFICATIONS
ENGINE ELECTRICAL16-38
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONSM1161002100506
GENERAL SPECIFICATIONSM1161000200411
ITEM SPECIFICATION
Charging system
Alternator bracket bolt49
9 Nm (36 7 ft-lb)
Alternator bolt49
9 Nm (36 7 ft-lb)
Alternator terminal nut12
2 Nm (102 22 in-lb)
Ignition system
Camshaft position sensor bolt 11
1 Nm (98 8 in-lb)
Crankshaft position sensor bolt 9.0
1.0 Nm (80 9 in-lb)
Ignition coil bolt 10
2 Nm (89 17 in-lb)
Knock sensor 23
2 Nm (17 1 ft-lb)
Spark plug 25
4 Nm (18 3 ft-lb)
Starting system
Starter bolt 30
3 Nm (23 2 ft-lb)
Starter cover bolt 4.9
1.0 Nm (44 8 in-lb)
Starter terminal nut 12
2 Nm (102 22 in-lb)
ITEMS SPECIFICATIONS
Alternator
Type Positive battery positive voltage sensing
Identification number
Part No. MN180394
Rated output V/A 12/110
Voltage regulator Electronic built-in type
Starter Motor
Type Reduction drive with planetary gear
Identification number M000T31172
Part No. 1810A090
Rated output kW/V 1.2/12
Number of pinion teeth 8
Ignition Coil
Type Molded 6 coil
Spark Plugs
BOSCH FR8DI30

SPECIFICATIONS
ENGINE ELECTRICAL16-39
SERVICE SPECIFICATIONSM1161000300322
ITEMS STANDARD VALUE LIMIT
Alternator
Regulated voltage
(Ambient temperature at voltage
regulator)
20C (4F)14.2 15.4
20C (68F) 13.9 14.9
60C (140F) 13.4 14.5
80C (176F) 13.1 14.5
Alternator output wire voltage drop (at 30 A) VMaximum 0.3
Nominal Output current 110A 70 % of normal output
current
Field coil resistance
Approximately 2 5
Brush protrusion length mm (in)Minimum 2 (0.08)
Starter motor
Free running characteristics Terminal voltage
V11
Current A 95
Speed r/min 2,500 or more
Pinion gap mm (in) 0.5 2.0 (0.02 0.07)
Commutator run-out mm (in) 0.05 (0.002) Minimum 0.1 (0.004)
Commutator diameter mm (in) 29.4 (1.16) Minimum 28.8 (1.13)
Undercut depth mm (in) 0.5 (0.02) Minimum 0.2 (0.008)
Ignition parts
Spark plug gap mm 1.0 1.1

SPECIFICATIONS
ENGINE ELECTRICAL16-40

32-1
GROUP 32
POWER PLANT
MOUNT
CONTENTS
GENERAL DESCRIPTION. . . . . . . . .32-2
SPECIAL TOOL . . . . . . . . . . . . . . . . .32-3
ENGINE MOUNTING . . . . . . . . . . . . .32-4
REMOVAL AND INSTALLATION . . . . . . . . 32-4
TRANSAXLE MOUNTING . . . . . . . . .32-5
REMOVAL AND INSTALLATION . . . . . . . . 32-5
ENGINE ROLL STOPPER AND
CENTREMEMBER . . . . . . . . . . . . . . .32-7
REMOVAL AND INSTALLATION . . . . . . . . 32-7
CROSSMEMBER . . . . . . . . . . . . . . . .32-9
REMOVAL AND INSTALLATION . . . . . . . . 32-9
INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . 32-14
SPECIFICATIONS . . . . . . . . . . . . . . .32-15
FASTENER TIGHTENING
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . 32-15

GENERAL DESCRIPTION
POWER PLANT MOUNT32-2
GENERAL DESCRIPTIONM1321000100373
The engine front mounting bracket is a
dome-shaped fluid-filled mount for improved
responsiveness during acceleration and more
stable vehicle performance against road distur-
bances.The liquid-filled transaxle mounting body side
bracket improves riding comfort by its refined
insulator.
A roll stopper bracket in the upper area limits
engine rolling. Furthermore, large diameter insu-
lator reduces idle vibration.
CONSTRUCTION DIAGRAM
