MITSUBISHI iMiEV 2015 Owner's Manual (in English)

Keyless entry system 5-6 Features and controls
5
The horn answerback function can be set to the following three conditions. Each time the horn answerback function isset, a chime will sound to tell you the condi- tion of the answerback function. 1. Remove the key from the electric motor switch.2. Open the driver’s door and turn the com- bination headlights and dimmer switch to the “OFF” position.3. Press the LOCK button (1) for 4 to 10 sec- onds and press the UNLOCK button (2) during this time.4. Release in sequence the UNLOCK and LOCK buttons within 10 seconds of pressing the UNLOCK button in step 3.
The turn signal lights answerback function can be changed. If you want to change the answerback func- tion, please contact a
certified i-MiEV dealer
for details.
N00543600105
The door and liftgate unlock function can be set so that all doors and liftgate unlock when the UNLOCK button (2) is pressed once.For details, please contact a certified i-MiEV dealer.
N00543700050
If you are near your vehicle and feel threat-ened, you may activate th
e alarm to call atten-
tion as follows: 1. Press the PANIC button (3) for more than 1 second. 2. The headlights will blink on and off and the horn will sound intermittently forabout 3 minutes. 3. To turn off the alarm, press any button on the remote control transmitter.
N00543800077
Only remote control transmitters pro-grammed with the vehicle’s electronics canlock or unlock all doors. If you lose the remote control transmitter, you can order a remote cont
rol transmitter from a
certified i-MiEV deal
er by referring to the
key number. To prevent vehicle theft, the ID codes for allthe remote control transmitters except the one for the lost key must be programmed again. Take your vehicle and all the remainingremote control transmitters to a certified i- MiEV dealer to have your ID codes pro- grammed again.
N00543900065
To add a remote control transmitter, you mustalready have one registered remote control transmitter. Registering the ID code can be done by your-self or by a certified i-MiEV dealer. For you to register the ID code yourself, follow the “Customer remote control transmitter pro-gramming” procedure below.
Horn deactivation/reactivation Number of chimes
Condition
One chime The horn will not sound. Two chimes The horn will sound. Three chimes
The horn will sound if the auto light switch is ON (if so equipped).
Four chimes
The horn will sound if the LOCK button is pressed twice quickly.
Changing the setting of the turn signal lights answerback function Setting of door unlock function Using the panic alarm
Replacement remote control transmitters Additional remote control transmitters
BK0209800US.book 6 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Keyless entry system
Features and controls 5-7
5
If you choose to have a certified i-MiEV dealer register the ID
code, take your vehicle
and all remaining keys to a certified i-MiEV dealer.
N00546100101
Your keyless entry system operates on a radiofrequency subject to
Federal Communica-
tions Commission (FCC)
Rules (For vehicles
sold in U.S.A.) and Industry Canada Rules (For vehicles sold in Canada). This device complies with Part 15 of the FCC Rules andRSS-Gen of the Industry Canada Rules. Operation is subject to the following two con- ditions.  This device may not
cause harmful inter-
ference.  This device must ac
cept any interference
received, including interference that maycause undesired operation.
N00544100110
1. Before replacing the
battery, remove static
electricity from your body by touching ametal grounded object. 2. With the Mitsubishi mark facing up, insert the cloth-covered tip of
a flat blade screw-
driver into the notch in the remote control transmitter case and
use it to open the
case.
3. Remove the remote control transmitter from the remote control transmitter case. Then, open the remote control transmitterusing the method described in step 1. 4. Remove the old battery.
NOTE
 You are provided with 2 remote control transmitters, but you may register up to 4 remote control transmitters.
General information
CAUTION Changes or modifica
tions not expressly
approved by the manufacturer for compli-ance could void the user’s authority to oper-ate the equipment.
Procedure for replacing the remote control transmitter bat- tery
NOTE
 Be sure to perform the procedure with the Mitsubishi mark facing up. If the Mitsubishimark is not facing up when you open theremote control transmitter case, the buttons may come out.
BK0209800US.book 7 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Door locks 5-8 Features and controls
5
5. Install a new battery with the + side (A) down. 6. Close the remote control transmitter firmly. 7. Place the remote control transmitter in theremote control transmitter case, then securely close the remote control trans- mitter case.8. Check the keyless entry system to see that it works.
N00509200534
Turn the key toward the front of the vehicle to lock the door. After checking that the door is
locked, turn the key back to the center and remove it.
NOTE
 A certified i-MiEV dealer can replace the battery for you if you prefer. CAUTION When the remote control transmitter case is opened, be careful to
keep water, dust, etc.
out. Also, do not touch
internal components.+ side - side Coin type battery CR1620
Door locks
WA R N I N GMake sure all doors are tightly closed and locked while driving.• Locked doors, in co
mbination with the
use of seat belts, can help reduce the riskof ejection in
an accident.
• Locked doors can help keep passengers, especially small children, from opening doors and falling out
of moving vehicles.
• Locked doors can help
prevent outsiders
from gaining access to your vehicle when you slow down or come to a stop.
 Lock your vehicle when
ever you leave it.
Children who get into
unlocked vehicles
may not be able to get out. Children trapped inside vehicles can quickly be overcome by heat
and suffer serious
injury or death due to heat stroke. Never leave children unattended inside a vehicle. In addition
to the risk of heat
stroke, children can activate switches and controls, resulting in an injury or fatalaccident.
To lock or unlock the door with the key
1- Insert or remove the key 2- Lock 3- Unlock
BK0209800US.book 8 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Power door locks
Features and controls 5-9
5
Move the lock knob to the lock position to lock the door. All doors should be kept locked while driv-ing. The driver’s door can be unlocked without using the lock knob by pulling on the insidedoor handle. 1. Move the inside lock knob to the locked position.
2. Be sure the keys are not inside the vehi- cle. Close the door.
N00549600240
If you open the driver’s door while the key isin the “LOCK” or “ACC” position, a tonewill sound, reminding you
to remove the key.
N00549700179
If the key is in the electric motor switch when you push the lock knob forward with the driver’s door or passenger’s door open, the lock knob will automatically return to theunlocked position.
N00509300607
To lock or unlock the door from the inside 1- Lock 2- Unlock To lock the door without using the key
Key reminder buzzer Lock out protection
Power door locks
NOTE
 When locking or unlocking with the key on the driver’s door, only the driver’s door willlock or unlock.  Repeated continuous
operation between lock
and unlock could acti
vate the power door
locking systems built-i
n protection circuit
and prevent the system’s from operating. Ifthis occurs, wait about
1 minute before oper-
ating the power door lock switch.
BK0209800US.book 9 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Child safety locks for rear door 5-10 Features and controls
5
All of the doors and the liftgate can be locked or unlocked by operating the power door lock switch on the driver’s or the passenger’s door.
N00563400095
All doors and the liftgate will unlock when the selector lever is moved to the “P” (PARK) position with the electric motor switch in the“ON” position.
N00509400288
Child safety locks help prevent rear passen-gers, especially child
ren, from opening the
rear door using the inside door handle. A lock lever for the child safety lock is pro- vided on each rear door.When the lever is in the lock position (1), the rear door cannot be opened using the inside door handle.To open the rear door when the child safety lock lever is in the lock position, pull the out- side door handle.When the lever is in the release position (2), the child safety lock is released and the rear
To lock and unlock by the power door lock switch 1- Lock 2- Unlock To unlock the doors and liftgate You can select the functions to unlock the doors and liftgate either using the electric motor switch position or using the selector lever position.These functions are not
activated when the
vehicle is shipped from the factory. To acti- vate or deactivate
these functions, please
contact a certified i-MiEV dealer.
Using the selector lever position
Child safety locks for rear door 1- To lock 2- To release
BK0209800US.book 10 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Liftgate
Features and controls 5-11
5
door can be opened using the inside door han- dle.
N00510100230
After unlocking the liftgate, push the switch(A) and pull up the liftgate.
Pull the liftgate grip (A) downward as illus- trated. Gently push the upper gate from the outside with enough force so that it is com- pletely closed. Always ensure the liftgate issecurely closed.
WA R N I N G Always keep the door
s tightly closed and
locked when driving. An unlocked door may be accidentally
opened by a passen-
ger, especially by
a child who could fall
out. Also, if the doors are not locked, there is a greater risk of
someone being thrown
from the vehicle
in an accident.
Liftgate
WA R N I N GWhen opening and closing the liftgate, make sure that there are no people nearby and be careful not to hit your head or pinch your hands, neck, etc.
To open
NOTE
 If you do not open the li
ftgate immediately
after pulling the handle,
the liftgate can not
be lifted. If this happens, pull the handle again and lift
the liftgate.
 The liftgate cannot be opened when the bat- tery is flat or disconnected.
To close
CAUTION To avoid injuring your hand or arm, do not attempt to close the liftgate the gate grip (A). Before starting the vehi
cle, be sure to con-
firm that the liftgate is locked. If the liftgate opens while driving the vehicle, objectsstored in the luggage compartment could fall out into the road. When closing the liftga
te, always ensure that
everybody removes their hands and fingers from the liftgate opening.NOTE
 Gas struts (B) are instal
led to support the lift-
gate.To prevent damage or faulty operation. • Do not hold the gas struts when closing the liftgate. • Also, do not push or pull on the gas struts.
BK0209800US.book 11 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Theft-alarm system 5-12 Features and controls
5
N00510200244
The theft-alarm system is designed to provide protection from unauthorized entry into thevehicle. This system
is operated in three
stages: the first is the “armed” stage, the sec- ond is the “alarm” stage, and third is the “dis-armed” stage. If triggered, the system provides both audible and visual alarm sig- nals.
Park the vehicle and stop the electric motor unit. Arm the system
as described below.
1. Remove the key from the electric motor switch.
2. Lock all doors and the liftgate by using the keyless entry system. At this time, the theft-alarm indicator (A) in the meter cluster
flashes for confirma-
tion.
• Do not attach any pl
astic material, tape,
etc., to the gas struts. • Do not tie anything, etc., around the gas struts. • Do not hang any objects on the gas struts.
Theft-alarm system
NOTE
CAUTION Do not modify or add parts to the theft-alarm system. Doing so could
cause the theft-alarm
to malfunction.
Armed stage
Arm the system and leave
BK0209800US.book 12 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Theft-alarm system
Features and controls 5-13
5
3. The system has ente
red the armed stage
after about 20 seconds, when the theft-alarm indicator flashi
ng becomes slower.
The theft-alarm indicator continues to flash while the system is in the armedstage.
The alarm will be activated if the following occurs while the vehicle is parked and the system is armed.  One of the doors and the liftgate is opened without using the keyless entry system.
When the alarm is activated: 1. The headlights blink on and off for 3 min- utes. After 3 minutes the headlights automati-cally shut off. 2. The horn will sound intermittently for 3 minutes.
The alarm can be deacti
vated in the following
ways.  By using the keyless entry system to lock or unlock the doors and liftgate. Turn the electric motor switch to the “ON” position.
The system will be disarmed if the following operation is performed.  The electric motor switch is turned to the “ON” position.
NOTE
 The system will be disarmed if, while the theft-alarm indicator is
illuminated, all doors
and the liftgate are
unlocked by using the
keyless entry system.  The system will be disarmed if, while the theft-alarm indicator is illuminated, the elec-tric motor switch is turned to the “ON”.  The system will not be armed if a door or the liftgate is not completely closed. If this hap- pens, rearm the system
as described above.
 The theft-alarm system can be activated when people are riding inside the vehicle or when the windows are open. To prevent acci-dental activati
on of the alarm, do not set the
system to the system armed mode while peo- ple are riding in the vehicle.  If the answerback function (flashing of the turn signal lights by locking and unlockingthe doors and the liftgate
) is deactivated, the
turn signal lights do not flash after the lock- ing and unlocking operation.For information on the answerback function, refer to “Keyless entry system” on pages 5-5.
Alarm stage Type of alarm Horn sounds!Headlights blink on and off!
NOTE
 The alarm will continue to operate for 3 min- utes. At the end of that
period, the alarm will
automatically shut off
to save battery power.
The system will then
be rearmed until the
proper disarming step is taken.  The alarm will resu
me if unauthorized
actions are taken again, even if the alarm has stopped.
Alarm deactivation Disarmed stage
BK0209800US.book 13 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Power window control 5-14 Features and controls
5
 All doors and the lift
gate are unlocked by
using the keyless entry system.
Use the following proce
dure to test the sys-
tem:
1. Lower the driver’s window. 2. Arm the system as explained in “Armedstage”. 3. Make sure that the theft-alarm indicator comes on and flashe
s for approximately
20 seconds. 4. Wait a few seconds and then unlock the driver’s side door by using the inside doorlock knob. Open the door. 5. Make sure that the horn sounds intermit- tently and the headlights blink when a door is opened. 6. Disarm the system by unlocking all doorsand the liftgate by using the keyless entry system.
N00510800396
NOTE
 If the UNLOCK button on the remote control transmitter is operated when all doors and the liftgate are closed and no door is opened within approximately 30 seconds, re-armingwill automatically occur.  The amount of time afte
r unlocking until the
vehicle relocks automatically can be adjusted. See a certified i-MiEV dealer for details.  Once the system has been disarmed, it can- not be rearmed except
by repeating the arm-
ing procedure.
Testing the theft-alarm system Disarm...by using the keyless entry system
Power window control 1- Open (down) 2- Close (up)
NOTE
 Never try to operate the main switch and sub-switch in different
directions at the same
time. This will free
ze the window in posi-
tion.  Operating the power windows repeatedly with the electr
ic motor unit stopped will run
down the 12V starter battery. Use the win- dow switches only while the electric motorunit is operating.WA R N I N G Before operating the power windows, make sure that nothing can be trapped (head, hands, fingers, etc.) in the window. Never leave the vehi
cle without carrying
the key. Never leave children
or unreliable adults
unattended inside the vehicle.
BK0209800US.book 14 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Power window control
Features and controls 5-15
5
N00548700127
The main switch located on the driver’s door can be used to opera
te all the windows.
A window can be opened
or closed by operat-
ing the corresponding switch. Press the switch down to open the window,and pull up the switch to close it. If the driver’s door window switch is fully pressed down, the driver’s door window auto- matically opens completely. If you want to stop the window movement,operate the switch lightly in the reverse direc- tion.
N00548800115
Each sub-switch can be
used for it’s own pas-
senger door window, unless the driver’s win-dow lock switch is activated.
N00548900145
The power windows can be run up or downwhen the electric motor switch is in the “ON” position. The door windows can be opened or closedfor a 30-second period after the electric motor switch is turned to the “ACC” or “LOCK” position. However, once the driver’s door orthe front passenger’s door is opened, the power windows cannot be operated.
N00549000156
When this switch is in the lock mode, the pas-senger door switches cannot be used to open or close the door windows, and the mainswitch will open or close only the driver’s door window. To unlock the switch, press it again.
Main switch 1- Driver’s door window switch2- Front passenger door window switch3- Left rear door window switch 4- Right rear door window switch 5- Lock switch
Sub switch 1- Close2- OpenPower window timer function
Lock switch 1- Lock 2- UnlockWA R N I N G Before driving with a child in the vehicle, be sure to lock the window switch to make it inoperative. Children tampering withthe switch could easily trap their hands or heads in the window.
BK0209800US.book 15 ページ ２０１４年１月１４日　火曜日　午前９時２６分
