DASH PANEL
CONFIGURATION DIAGRAMS80-21
DASH PANEL (CONTINUED)
AC304414AB
(Front view)(Rear view)
C-208 C-209 C-210 C-211
C-212
C-213
C-214
C-216
C-217 C-218 C-219 C-220 C-221 C-222 C-223 C-224C-225
C-226 C-227
JUNCTION BLOCKConnector
symbol
-201
thru
-227C
STEERING COLUMN
C-207
C-206
C-205 C-204 C-203
C-203 C-202 C-201 Instrument panel
wiring harness
Clock spring
Y
C-201 (6) Ignition switch
C-202 (7) Key reminder switch
C-203 (10) Column switch
C-204 (6) Clock spring
C-205 (4-Y) Clock spring
C-206 (1) Horn switch
C-207 (2) Air bag module (squib)
C-208 (13) Instrument panel wiring harness and J/B
combination
C-209 (14) Instrument panel wiring harness and J/B
combination
C-210 (6) Instrument panel wiring harness and J/B
combination
C-211 (1-B) Instrument panel wiring harness and J/B
combination
C-212 (28) Instrument panel wiring harness and J/B
combinationC-213 (5) Rear window defogger relay
C-214 (5) Blower relay
C-216 (15) Floor wiring harness (RH) and J/B
combination
C-217 (3) Roof wiring harness and J/B combination
C-218 (4) Rear fog lamp relay
C-219 (4) Accessory socket relay
C-220 (4) Fuel pump relay (2)
C-221 (4) No connection
C-222 (4) Fuel pump relay (1)
C-223 (5) Power window relay
C-224 (2) No connection
C-225 (20) ETACS-ECU
C-226 (24) ETACS-ECU
C-227 (24-GR) ETACS-ECU

J/B
CIRCUIT DIAGRAMS90-4
J/B
M1901000200972
POWER
WINDOW
RELAY
FUEL
PUMP
RELAY (2)
FUEL
PUMP
RELAY (1)
REAR
WINDOW
DEFOGGER
RELAYBLOWER
RELAY
REAR FOG
LAMP
RELAY
J/B SIDE HEATED
SEAT RELAY
ACCESSORY
SOCKET
RELAY
: LHD
: RHD
CONNECTOR NUMBERS ARE KEYED TO THE CONFIGIRATION
DIAGRAM (DASH PANEL) AND EACH CIRCUIT DIAGRAM. NOTE
·
·
·

J/B
CIRCUIT DIAGRAMS90-5
NOTE: .
•The triangle mark on the relay housing should face that on the J/B and the relay box.
AC209083
Front side
C-208
C-222C-224
C-220C-221
C-219
C-217 C-218C-212C-211 C-210
C-209
Fuel pump
relay (1)
Fuel pump
relay (2) Heated seat
relay
Rear fog
lamp relay No connection
To roof wiring
harnessTo floor wiring
harnessRear
window
defogger
relayBlower
relay To instrument panel
wiring harnessTo instrument panel
wiring harness
Power
window
relayETACS-ECU
C-225
AM
Rear side
C-223C-214C-213
1
23
4
Fuses
(No.1 to 20)
1
23
4 1
23
4 1
23
4 1
23
4
Accessory
socket relay
1
7
132
8
143
9
154
10
165
11
176
12
20
19
18
C-215
C-216

J/C
CIRCUIT DIAGRAMS90-6
J/C
M1901014201075
NOTE: IN ACTUAL VEHICLES, ANY OF THE TERMINALS CONNECTED IN J/C
ARE USED. THE TERMINAL ARRANGEMENT DESCRIBED IN THE CIRCUIT
DIAGRAM MAY NOT BE IDENTICAL TO THOSE OF THE VEHICLES.
·CENTRAL DOOR
LOCKING SYSTEM
·FRONT FOG
LAMP
·HEADLAMP
·HEADLAMP
WASHER
·POWER WINDOWS
·REAR FOG LAMP
·ROOM LAMP AND
LUGGAGE
COMPARTMENT
LAMP
·ROOM LAMP
PERSONAL LAMP
AND LUGGAGE
ROOM LAMP ·TAIL LAMP,
POSITION LAMP,
LICENCE PLATE
LAMP AND
LIGHTING MONITOR
BUZZER
·TURN-SIGNAL
