Drive shaft
DRIVESHAFT ASSEMBL Y
FRONT AXLE26-16
2.Remove th e dr ivesh a f t from th e h ub b y p u lling the
bo ttom of the brake disc toward s you.
CAUTION
•Do not pull on the driveshaft; doing so will
damage the TJ; be sure to use the pry bar.
•
AC100141
Transmission
TJ assembly Pry bar
AG
When pulling the driveshaft out from the
transmission, be careful that the spline part of
the driveshaft does not damage the oil seal.
3. Insert a pry bar between the transmission case and the driveshaft, and then pry and remove the
driveshaft from the transmission.
AC102554
MB991460
AC
4. Use special tool plug (MB991460) to prevent the
entry of foreign material into the transmission
case.
AC102555 AC
MB991017
MB991000
CAUTION
Do not apply pressure to the wheel bearing by
the vehicle weight to avoid possible damage
when the driveshaft is removed. If, however, vehi
-
cle weight must be applied to the bearing in mov-
ing the vehicle, temporarily secure the wheel
bearing by using the following special tools.
•Spacer (MB991000)
•Front hub remover and installer (MB991017)
INSTALLATION SERVICE POINTS
>>A<< DRIVESHAFT INSTALLATION
CAUTION
When installing the driveshaft, be careful that the
spline part of the driveshaft does not damage the
oil seal.
>>B<< STABILIZER
RUBBER/SELF-LOCKING NUT
(STABILIZER BAR CONNECTION)
INSTALLATION
AC210393
AC
A
Install the stabilizer rubber and collar as shown in the
figure, and tighten the self-locking nut so that the
protruding length of the stabilizer bar mounting bolt
protruding part meets its standard value (A).
Standard value (A): 22 ± 1.5 mm

DRIVESHAFT ASSEMBLY
FRONT AXLE26-20
REASSEMBLY SERVICE POINTS
>>A<< DYNAMIC DAMPER/DAMPER
BAND/TJ BOOT INSTALLATION
CAUTION
There should be no grease adhered to the rubber
part of the dynamic damper.
AC101695AC
L
1. Install the dynamic damper in the position (L)
shown in the figure .
L: 230 ± 3 mm , 415 ± 3 mm
2. Secure the damper bands.
3. Wrap plastic tape around the shaft spline, and then install the TJ boot band (small) and TJ boot.
>>B<< SPIDER ASSEMBLY
INSTALLATION
CAUTION
•The driveshaft joint use special grease. Do
not mix old and new or different types of
grease.
•If the spider assembly has been cleaned, take
special care to apply the specified grease.
1. Apply the specified grease furnished in the repair kit to the spider assembly between the spider axle
and the roller.
Specified grease: Repair kit grease
AC102654AC
Chamfered
side
2. Install the spider assembly to the shaft from the direction of the spline chamfered side.
>>C<< TJ CASE INSTALLATION
CAUTION
The driveshaft joint use special grease. Do not
mix old and new or different types of grease.
AC102656AC
After applying the specified grease to the TJ case,
insert the driveshaft and apply grease one more
time.
Specified grease: Repair kit grease
Amount to use:
<1300-LH, 1600-LH, 2000-LH>: 120 ± 10 g
<1300-RH, 1600-A/T-RH>: 110 ± 10 g
<1600-M/T-RH, 2000-A/T-RH>: 120 ± 10 g
<2000-M/T-RH>: 105 ± 10 g
NOTE: The grease in the repair kit should be divided
in half for use, respectively, at the joint and inside the
boot.
>>D<< TJ BOOT BAND (SMALL)/TJ BOOT
BAND (LARGE) INSTALLATION
AC102657
A
AC
Set the TJ boot bands at the specified distance in
order to adjust the amount of air inside the TJ boot,
and then tighten the TJ boot band (small), TJ boot
band (large) securely.
Standard value (A):
<1300-RH, 1600-A/T-RH>: 85 ± 3 mm
<1300-LH, 1600-M/T, 1600-A/T-LH, 2000>: 90 ± 3
mm

27-1
GROUP 27
REAR AXLE
CONTENTS
GENERAL INFORMATION . . . . . . . .27-2
SERVICE SPECIFICATIONS . . . . . . .27-2
SEALANT . . . . . . . . . . . . . . . . . . . . . .27-2
SPECIAL TOOLS . . . . . . . . . . . . . . . .27-3
ON-VEHICLE SERVICE . . . . . . . . . . .27-4
WHEEL BEARING AXIAL PLAY CHECK . . 27-4
REAR HUB ROTARY-SLIDING
RESISTANCE CHECK . . . . . . . . . . . . . . . . 27-4
HUB BOLT REPLACEMENT . . . . . . . . . . . . 27-4
REAR AXLE HUB ASSEMBLY . . . . .27-5
REMOVAL AND INSTALLATION . . . . . . . . 27-5
INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . 27-6

ON-VEHICLE SERVICE
REAR AXLE27-4
ON-VEHICLE SERVICE
WHEEL BEARING AXIAL PLAY CHECKM1271000900452
1. Remove the caliper assembly, and suspend the caliper assembly with a wire and remove the
brake disc.
AC303736AB
2.Check the be aring ' s axial play . Place a dial gau ge
ag ainst th e hub su rface; then mo ve t he hu b in the
axial dire ction and check whe t her or not the r e is
axial pla y .
Limit: 0.05 mm
3.If the play e xce eds the limit, the self -lockin g nut
should be tighte ned to the specified torque and
check the axial play again .
Ti ghte n ing torque: 175 ± 25 N⋅m
4.Replace the re ar hub a s sembly if an ad justmen t
cannot be made to within the limit.
REAR HUB ROTA R Y -SLIDING
RESIST
ANCE CHECK
M127100 1 1 0024 4
1.Remove the caliper assembly , a nd suspe nd the
caliper assembly with a wire an d remove t he
bra k e d i sc.
2.T u rn the hu b a few times to seat th e bea ring.
AC303737
3.Wind a rope a r ound the hu b bolt and turn t he hub
b y pullin g at a 90
° angle with a spring balance.
Measure to d
e
termine whe t her or not the
ro
t
a
ry-sliding resist an ce of the rea r hub is at the
limit va
lue.
Limit: 19 N
4.If limit value is exceeded , loo s en the self-locking
n u t and then tighten it to the specified torque and
check the rear hu b rot a ry sliding resist ance again.
Ti ghte n ing torque: 175 ± 25 N⋅m
5.Replace the re ar hub assembly if an a d justmen t
canno t be made to within the limit.
HUB BOLT REPLACEMENTM12710010 0025 8
1.Remove the calip er assembly and suspe nd it with
wire so t hat it does not fa ll.
2.Remove the bra k e d i sc.
AC302114
MB991618
AD
Hub bolt
3.Use spe c ia l too l hub bolt remover (MB99161 8) to
re move the h ub bo lt s.
AC104588
MB990767
Plain
washer
AC
4. In st all the plain wa sher to the n e w hub b o lt, a nd
inst all the bolt with a nu t while hold i ng the hub
wit h spe c ia l too l fron t hub a nd end yoke holder
(MB99076 7).
5.In st all the bra k e d i sc, ca lip er assembly and
tighten th e caliper assembly mount ing bolt s to the
specifie d torqu e 60
± 5 N⋅m.

REAR AXLE HUB ASSEMBLY
REAR AXLE27-5
REAR AXLE HUB ASSEMBLY
REMOVAL AND INSTALLATIONM1271002000381
CAUTION
•Care must be taken not to scratch or damage the teeth of the ABS rotor. The ABS rotor must never
be dropped. If the teeth of the ABS rotor are chipped, resulting in a deformation of the ABS rotor,
it will not be able to accurately detect the wheel rotation speed, and the system will not function
normally.
•
AC504437
Semi-drying sealant:
3M ATD Part No. 8663 or
equivalent
2
3
5
6
4
N
175 ± 25 N·m
3
AB
1
60 ± 5 N·m
2
56


Removal steps
<>1.Caliper assembly
2.Brake disc
3.Hub cap
<>>>B<<4.Self-locking nut
5.Rear hub assembly
<>>>A<<6.ABS rotor
The rear hub assembly should not be dismantled. When removing the rear hub assembly, the
wheel bearing inner race may be left at the spindle side. In this case, always replace the rear hub
assembly, otherwise the hub will damage the oil seal, causing oil leaks or excessive play.
REMOVAL SERVICE POINTS
<> CALIPER ASSEMBLY REMOVAL
Secure the removed caliper assembly with wire, etc.
<> SELF-LOCKING NUT REMOVAL
AC303738
CAUTION
Do not apply the vehicle weight to the wheel
bearing while loosening the self-locking nut, or
the wheel bearing will be damaged.
