sensor MITSUBISHI LANCER EVOLUTION 2007 Service Owner's Guide

INDEX - In order of connector No.C-8
Wiring diagram
page Circuit diagram page Parts name Connector
No.
CC-223Fuel pump relay 1B-54,55,87,95B-23,29
C-224Power window relayB-54,55,158,159,165B-23,29
C-225No connectionB-54,55,78B-23,29
C-226ETACS-ECUB-54,55,105,108,112,113,116,117,118,
119,120,121,122,123,125,126,128,
129,134,136,137,138,140,141,158,
164,165, 170,171,172,173,188,189B-23,29
C-227ETACS-ECUB-125,128,170,172B-23,29
C-228ETACS-ECUB-105,108,112,113,116,117,118,119,
122,123,125,126,128,129,136,137,
140,141,158,159,164,165,170,171,
172,173, 188,189,258B-23,29
C-230Steering wheel sensorB-202,210,218,226,236,246B-23,29
DD-01Door switch (Front:RH)B-108,116,120,121,164B-30,32
D-02Floor wiring harness (RH) and rear door
wiring harness (RH) combinationB-160,166,171,173B-30,32
D-03Room lampB-118,122B-30,32
D-04Wheel speed sensor (Rear:RH)
B-203,211,217,225,233,243B-30,32
D-05Rear room lampB-118,122B-30,32
D-06Door switch (Rear:RH)B-120,121B-30,32
D-08Door switch (Rear:LH)B-120,121B-30,32
D-09Fuel pump and fuel gauge unit (Main)B-93,101,148,152,156B-30,32
D-10Wheel speed sensor (Rear:LH)
B-203,211,217,225,233,243B-30,32
D-12Floor wiring harness (LH) and rear door
wiring harness (LH) combinationB-161,167,171,173B-30,32
D-13Door switch (Front:LH)B-105,112,120,121,158B-30,32
D-15Instrument panel wiring harness and
console wiring harness combinationB-195B-31,32
D-18Cigarette lighterB-195B-31,33
D-19Cigarette lighterB-195B-31,33
D-20Ashtray illumination lampB-195B-31,33
D-21Cigarette lighter illumination lampB-195B-31,33
D-22Oxygen sensor (Rear)B-88,96B-31,33
D-23Parking brake switchB-157,201,209,213,221,232,242B-31,33
D-26Seat belt pretensioner (RH)B-249,251B-31,33

INDEX - In order of connector No.C-9
Wiring diagram
page Circuit diagram page Parts name Connector
No.
DD-27Fuel gauge unit (Sub)B-148,152,156B-31,33
D-28Seat belt pretensioner (LH)B-249,251B-31,33
D-29Floor wiring harness (RH) and fuel
wiring harness combinationB-93,101B-31,33
D-30Floor wiring harness (RH) and fuel
wiring harness combinationB-93,101,148,152,156,203,211,217,
225,233,243B-31,33
D-32G sensor (Longitudinal)B-200,208,213,221,229,239B-31,33
D-33G sensor (Lateral)B-200,208,213,221,229,239B-31,33
D-34Intercooler water spray switchB-257B-31,33
EE-02Remote controlled mirror (LH)B-192,193B-34,36
E-04Spare connector speaker (LH)>B-196B-34,36
E-05Power window motor (Front:LH)B-162,165B-34,36
E-07Power window main switchB-162,163,168,169B-34,36
E-08Door lock actuator (Front:LH)B-170,173B-34,36
E-10Power window motor (Rear:LH)B-161,167B-34,36
E-11Power window sub switch (Rear:LH)B-161,167B-34,36
E-12Door lock actuator (Rear:LH)B-171,173B-34,36
E-13Remote controlled mirror (RH)B-192,193B-34,36
E-16Door lock key cylinder switch (RH)B-170B-35
E-17Door lock key cylinder switch (LH)B-172B-37
E-18Door lock actuator (Front:RH)B-171,172B-35,37
E-19Power window sub switch (Passenger’s
side)B-159,165B-35,37
E-20Power window motor (Front:RH)B-159,168B-35,37
E-21Spare connector speaker (RH)>B-196B-35,37
E-23Door lock actuator (Rear:RH)B-171,173B-35,37
E-24Power window sub switch (Rear:RH)B-160,166B-35,37
E-25Power window motor (Rear:RH)B-160,166B-35,37
FF-01Spare connector (LH)>B-197B-38,39
F-04Luggage compartment lampB-119,123B-38,39
F-05High mounted stop lampB-144,145B-38,39
F-06Defogger ( - )B-185B-38,39

INDEX - In order of connector No.C-10
Wiring diagram
page Circuit diagram page Parts name Connector
No.
FF-08Spare connector (RH)>B-197B-38,39
F-09Rear combination lamp (RH)B-111,115,129,134,138,142,144,145B-38,39
F-10Trunk lid latch switchB-119,123B-38,39
F-12Licence plate lamp (RH)B-110,114B-38,39
F-13Licence plate lamp (LH)B-110,114B-38,39
F-14Floor wiring harness (LH) and bumper
wiring harness combinationB-110,114B-38,39
F-16Rear combination lamp (LH)B-110,114,126,134,138,143,144,145B-38,39
F-19Defogger (+)B-185B-38,39
F-21Windshield washer motorB-186,190B-38,39
F-23Electric pump B-216,224,234,244B-38,39
F-24Floor wiring harness (LH) and 4WD
wiring harness combination B-216,224,234,235,244,245B-38,39
F-25Direction valve (LH) B-235,245B-38,39
F-26Direction valve (RH) B-235,245B-38,39
F-27Proportioning valve (for ACD control)B-216,224,235,245B-38,39
F-28Proportioning valve (for AYC control)B-235,245B-38,39
F-29Pressure sensor B-216,224,234,244B-38,39

INDEX - In order of parts nameC-11
INDEX
In order of parts name
Parts nameConnector
No.Circuit diagram pageWiring diagram
page
4WD-ECU C-43B-201,209,212,213,214,215,216,218,
219,220,221,222,223,224,226,227,
228,230,231,232,234,236,237,238,
240,241,242,244, 246,247B-19,25
4WD-ECU C-44B-201,209,212,213,216,217,219,220,
221,224,225,227,228,229,232,234,
235,237,238,239,242,244,245,247B-19,25
AA/C compressorA-47B-178,184B-7,9
A/C compressor relayB-12XB-73,178,184B-10,14
A/C-ECU or heater control unitC-32B-175,181,185B-19,25
ABS-ECUB-123B-198,200,201,202,203,204,205,206,
208,209,210,211,229,232,233,239,
242,243B-13,17
ACD mode changeover switchC-142B-214,222,230,240B-21,27
Air bag module (squib) C-207B-248,250B-22,28
Air bag module (squib) side>C-109B-249,251B-20,26
Air flow sensorB-31B-90,98B-11,15
AlternatorB-21B-84B-11,15
AlternatorB-22B-84B-11,15
Ashtray illumination lampD-20B-195B-31,33
BBack-up lamp switchB-108B-142,143B-12,16
Blower motorC-14B-174,180B-18,24
Blower relayC-215B-54,55,174,180B-23,29
Blower switchC-131B-174,180B-21,27
Brake fluid level switchB-04B-157B-10,14
CCamshaft position sensorB-116B-88,96B-12,16
Cigarette lighterD-18B-195B-31,33
Cigarette lighterD-19B-195B-31,33
Cigarette lighter illumination lampD-21B-195B-31,33
ClockC-04B-194B-18,24
Clock spring C-204B-248,250B-22,28
Clock spring C-205B-146B-22,28

INDEX - In order of parts nameC-12
Wiring diagram
page Circuit diagram page Connector
No. Parts name
CColumn switchC-203B-104,107,112,116,125,128,137,141,
187,191B-22,28
Combination meterC-01B-84,87,95,103,106,118,122,126,129,
135,139,148,149,152,153,156,157,
198,206,214,222,230,240,248,250,
256, 258B-18,24
Combination meterC-02B-110,115,118,122,126,129,135,139,
148,149,152,153,156,157,198,206,
248, 250,256,258B-18,24
Condenser fan motorA-45B-177,183B-7,9
Condenser fan motorA-46B-177,183B-7,9
Condenser fan relay (HI)A-07XB-73,177,183B-6,8
Condenser fan relay (LO)A-06XB-73,177,183B-6,8
Control wiring harness and battery
wiring harness combinationB-14B-79,84,91,99,157B-10,14
Control wiring harness and floor wiring
harness (LH) combination
C-46B-224,244B-25
Crank angle sensorB-121B-88,96B-13,16
DDefogger (-)F-06B-185B-38,39
Defogger (+)F-19B-185B-38,39
Defogger relayC-214B-54,55,78,185B-23,29
Detonation sensorB-122B-89,97B-13,17
Diagnosis connectorC-22B-92,100,105,108,113,117,119,123,
125,128,137,141,150,154,158,164,
170,172,188,189,204,205,219,227,
237,247,248,250,252,254B-18,24
Diagnosis connectorC-23B-92,100B-18,24
Direction valve (LH) F-25B-235,245B-38,39
Direction valve (RH) F-26B-235,245B-38,39
Door lock actuator (Front:LH)E-08B-170,173B-34,36
Door lock actuator (Front:RH)E-18B-171,172B-35,37
Door lock actuator (Rear:LH)E-12B-171,173B-34,36
Door lock actuator (Rear:RH)E-23B-171,173B-35,37
Door lock key cylinder switch (LH)E-17B-172B-37
Door lock key cylinder switch (RH)E-16B-170B-35
Door switch (Front:LH)D-13B-105,112,120,121,158B-30,32
Door switch (Front:RH)D-01B-108,116,120,121,164B-30,32

INDEX - In order of parts nameC-13
Wiring diagram
page Circuit diagram page Connector
No. Parts name
DDoor switch (Rear:LH)D-08B-120,121B-30,32
Door switch (Rear:RH)D-06B-120,121B-30,32
Dual pressure switchA-36B-178,184B-7,9
EEGR solenoid valveB-112B-91,99B-12,16
Electric pump F-23B-216,224,234,244B-38,39
Electric pump relay B-139B-216,224,234,244B-13,17
Engine control relayB-11XB-73,86,94,252,254B-10,14
Engine coolant temperature gauge unitB-110B-148,152B-12,16
Engine coolant temperature sensorB-118B-89,97B-12,16
Engine speed detection connectorB-05XB-73,82,83,90,98B-10,14
Engine-ECUC-115B-87,88,89,90,91,92,93,95,96,97,98,
99,100,101,215,223,231,241,257B-20,26
Engine-ECUC-118B-82,83,88,90,91,92,93,96,98,99,100,
101,149,153,252,254,256B-20,26
Engine-ECUC-122B-84,86,87,90,91,93,94,95,98,99,101,
177,178,183,184,252,254,256,257B-20,26
Engine-ECUC-126B-82,83,86,88,89,90,91,93,94,96,97,
98,99, 101,102,178,184B-20,26
ETACS-ECUC-226B-54,55,105,108,112,113,116,117,118,
119,120,121,122,123,125,126,128,
129,134,136,137,138,140,141,158,
164,165, 170,171,172,173,188,189B-23,29
ETACS-ECUC-227B-125,128,170,172B-23,29
ETACS-ECUC-228B-105,108,112,113,116,117,118,119,
122,123,125,126,128,129,136,137,
140,141,158,159,164,165,170,171,
172,173, 188,189,258B-23,29
FFan controllerA-21B-102,176,182B-7,8
Floor wiring harness (LH) and 4WD
wiring harness combination F-24B-216,224,234,235,244,245B-38,39
Floor wiring harness (LH) and bumper
wiring harness combinationF-14B-110,114B-38,39
Floor wiring harness (LH) and J/B
combination C-216B-54,55,105,110,112,119,120,134,
158,171,185B-23
Floor wiring harness (LH) and rear door
wiring harness (LH) combinationD-12B-161,167,171,173B-30,32
Floor wiring harness (RH) and fuel
wiring harness combinationD-29B-93,101B-31,33
Floor wiring harness (RH) and fuel
wiring harness combinationD-30B-93,101,148,152,156,203,211,217,
225,233,243B-31,33

INDEX - In order of parts nameC-15
Wiring diagram
page Circuit diagram page Connector
No. Parts name
GG sensor (Lateral)D-33B-200,208,213,221,229,239B-31,33
G sensor (Longitudinal)D-32B-200,208,213,221,229,239B-31,33
HHazard warning switchC-03B-136,140B-18,24
Headlamp (HI:LH)A-16B-103,106B-6,8
Headlamp (HI:RH)A-28B-103,106B-7,9
Headlamp leveling switchC-36B-131,133B-19,25
High mounted stop lampF-05B-144,145B-38,39
Horn (HI)A-23B-146B-7,8
Horn (LO)A-25B-146B-7,9
Horn relayA-05XB-73,146B-6,8
Horn switch C-206B-146B-22,28
IIdle speed control servoB-115B-88,96B-12,16
Ignition coil 1B-114B-82,83B-12,16
Ignition coil 2B-119B-82,83B-12,16
Ignition coil relay or no
connection B-09XB-73,83B-10,14
Ignition switchC-201B-76B-22,28
Injector 1B-27B-89,97B-11,15
Injector 2B-26B-89,97B-11,15
Injector 3B-25B-89,97B-11,15
Injector 4B-24B-89,97B-11,15
Instrument panel wiring harness and
A/C wiring harness combinationC-107B-175,181B-20,26
Instrument panel wiring harness and
console wiring harness combinationD-15B-195B-31,32
Instrument panel wiring harness and
control wiring harness combinationC-128B-153,181,184,198,200,202,203,205,
206,208,209,211,213,214,216,217,
218,229,230,233,234,235,236,239,
242,243B-21,26
Instrument panel wiring harness and
control wiring harness combinationC-129B-79,80,83,87,89,93,95,97,101,142,
143,149,186,190,212,228,253B-21,26
Instrument panel wiring harness and
control wiring harness combinationC-130B-84,87,92,95,100,142,143,148,150,
152,154,157,175,178,198,200,201,
204,205,206,212,213,216,219,228,
229,232,235,237,252,254,255,256,
257B-21,27

INDEX - In order of parts nameC-18
Wiring diagram
page Circuit diagram page Connector
No. Parts name
KKey reminder switchC-202B-253,255B-22,28
LLicence plate lamp (LH)F-13B-110,114B-38,39
Licence plate lamp (RH)F-12B-110,114B-38,39
Luggage compartment lampF-04B-119,123B-38,39
NNo connectionA-08XB-73B-6,8
No connectionA-34-B-9
No connectionB-07XB-73B-10,14
No connectionB-08XB-73B-10,14
No connectionB-10XB-73B-10,14
No connectionC-220B-54,55B-23,29
No connectionB-06XB-73B-10,14
No connectionC-225B-54,55,78B-23,29
No connection C-34-B-25
OOil pressure switchB-20B-157B-11,15
Outside/Inside air selection damper
control motor and potentiometerC-10B-175,181B-18,24
Oxygen sensorB-34B-88,96B-11,15
Oxygen sensor (Rear)D-22B-88,96B-31,33
PParking brake switchD-23B-157,201,209,213,221,232,242B-31,33
Power steering oil pressure switchA-48B-90,98B-7,9
Power window main switchE-07B-162,163,168,169B-34,36
Power window motor (Front:LH)E-05B-162,165B-34,36
Power window motor (Front:RH)E-20B-159,168B-35,37
Power window motor (Rear:LH)E-10B-161,167B-34,36
Power window motor (Rear:RH)E-25B-160,166B-35,37
Power window relayC-224B-54,55,158,159,165B-23,29
Power window sub switch (Passenger’s
side)E-19B-159,165B-35,37
Power window sub switch (Rear:LH)E-11B-161,167B-34,36
Power window sub switch (Rear:RH)E-24B-160,166B-35,37
Pressure sensor F-29B-216,224,234,244B-38,39
Proportioning valve (for ACD control)F-27B-216,224,235,245B-38,39
Proportioning valve (for AYC control)F-28B-235,245B-38,39

INDEX - In order of parts nameC-20
Wiring diagram
page Circuit diagram page Connector
No. Parts name
SSRS-ECUC-41B-249,251B-19,25
StarterB-18B-79B-11,15
StarterB-19B-79B-11,15
Steering wheel sensorC-230B-202,210,218,226,236,246B-23,29
Stop lamp switchC-103B-144,145,198,206,212,220,228,238B-20,26
TThrottle position sensorB-02B-89,97,215,223,231,241B-10,14
Trunk lid latch switchF-10B-119,123B-38,39
VVehicle speed sensorB-03B-92,100,150,154,197B-10,14
WWaste gate solenoid valveB-36B-91,99B-11,15
Wheel speed sensor (Front:LH)A-03B-203,211,217,225,233,243B-6,8
Wheel speed sensor (Front:RH)A-37B-203,211,217,225,233,243B-7,9
Wheel speed sensor (Rear:LH)
D-10B-203,211,217,225,233,243B-30,32
Wheel speed sensor (Rear:RH)
D-04B-203,211,217,225,233,243B-30,32
Windshield washer motorF-21B-186,190B-38,39
Windshield wiper motorB-01B-186,190B-10,14

GENERAL -How to Use Troubleshooting/Inspection Service Points00-13
INSPECTION SERVICE POINTS FOR A BLOWN
FUSE
Remove the blown fuse and measure the resistance between
the load side of the blown fuse and the earth. Set the switches
of all circuits which are connected to this fuse to a condition
of continuity. If the resistance is almost 0Ωat this time,
there is a short somewhere between these switches and the
load. If the resistance is not 0Ω, there is no short at the
present time, but a momentary short has probably caused
the fuse to blow.
The main causes of a short circuit are the following.
DHarness being clamped by the vehicle body
DDamage to the outer casing of the harness due to wear
or heat
DWater getting into the connector or circuitry
DHuman error (mistakenly shorting a circuit, etc.)
POINTS TO NOTE FOR INTERMITTENT
MALFUNCTIONS
Intermittent malfunctions often occur under certain conditions,
and if these conditions can be ascertained, determining the
cause becomes simple. In order to ascertain the conditions
under which an intermittent malfunction occurs, first ask the
customer for details about the driving conditions, weather
conditions, frequency of occurrence and trouble symptoms,
and then try to recreate the trouble symptoms. Next, ascertain
whether the reason why the trouble symptom occurred under
these conditions is due to vibration, temperature or some
other factor. If vibration is thought to be the cause, carry
out the following checks with the connectors and components
to confirm whether the trouble symptom occurs.
The objects to be checked are connectors and components
which are indicated by inspection procedures or given as
probable causes (which generates diagnosis codes or trouble
symptoms.)
DGently shake the connector up, down and to the left and
right.
DGently shake the wiring harness up, down and to the
left and right. Check the branch point of wiring harness
connector closely.
DGently rock each sensor and relay, etc. by hand.
DGently shake the wiring harness at suspensions and other
moving parts.
NOTE
If determining the cause is difficult, the flight recorder function
of the MUT-IIcan also be used.
Fuse
Battery
Load
switch
Load
Short circuit
occurrence
section
