sensor MITSUBISHI LANCER EVOLUTION 2007 Service User Guide

WIRING HARNESS CONFIGURATION DIAGRAMS
B-115
B-114
B-118
B-108
B-116B-110
4
11
12
B-13
B-121 (3-B) Crank angle sensor
B-122 (2-GR) Detonation sensor
B-123 (34-B) ABS-ECU
B-138 (6-B) ResistorB-139 (5-B) Electric pump relay
B-140 (4) Fuel pump relay 3
B-141 (2-B) Fuel pump resistor
B-142 (2-B) Secondary air control solenoid valve

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
-01
thru
-37
B
Earth cable
B-27B-26B-04
B-22B-21
B-37
B-34
B-23
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-14
ENGINE AND TRANSMISSION
R.H. drive vehicles
B-01 (5-GR) Windshield wiper motor
B-02 (4-B) Throttle position sensor
B-03 (3-B) Vehicle speed sensor
B-04 (2-GR) Brake fluid level switch
B-05X (1) Engine speed detection connector
B-06X (5) No connection
B-07X (4) No connectionB-08X (4) No connection
B-09X (4) Ignition coil relay
B-10X (4) No connection
B-11X (4) Engine control relay
B-12X (4) A/C compressor relay
B-14 (10-B) Control wiring harness and battery wiring
harness combination

WIRING HARNESS CONFIGURATION DIAGRAMS
B-25
B-18
B-24B-02B-01
B-05X
B-06X
B-07X
B-08X
B-09X
B-10X
B-11X
B-12X
B-14
B-03
B-36
B-19B-20B-31
4
11
12
B-15
B-18 (1) Starter
B-19 (1-B) Starter
B-20 (1-B) Oil pressure switch
B-21 (1) Alternator
B-22 (4-GR) Alternator
B-23 (2-B) Purge control solenoid valve
B-24 (2-B) Injector 4B-25 (2-B) Injector 3
B-26 (2-B) Injector 2
B-27 (2-B) Injector 1
B-31 (7-B) Air flow sensor
B-34 (4-B) Oxygen sensor
B-36 (2-GR) Waste gate solenoid valve
B-37 (2-B) Fuel pressure solenoid valve

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
-108
thru
-142
B
Earth cable
B-119
B-121
B-112B-122B-142
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-16
R.H. drive vehicles
B-108 (2-B) Back-up lamp switch
B-110 (1-B) Engine coolant temperature gauge unit
B-112 (2-BR) EGR solenoid valve
B-114 (3-GR) Ignition coil 1B-115 (6-B) Idle speed control servo
B-116 (3-B) Camshaft position sensor
B-118 (2-B) Engine coolant temperature sensor
B-119 (3-GR) Ignition coil 2

WIRING HARNESS CONFIGURATION DIAGRAMS
B-115
B-114B-116B-110B-108
B-123
B-118
B-139B-140B-138B-141
4
11
12
B-17
B-121 (3-B) Crank angle sensor
B-122 (2-GR) Detonation sensor
B-123 (34-B) ABS-ECU
B-138 (6-B) ResistorB-139 (5-B) Electric pump relay
B-140 (4) Fuel pump relay 3
B-141 (2-B) Fuel pump resistor
B-142 (2-B) Secondary air control solenoid valve

WIRING HARNESS CONFIGURATION DIAGRAMS
JUNCTION BLOCK
(Front view)(Rear view)
Dedicated
fuse
C-208C-209C-210C-226
C-220C-219C-218C-216C-228C-227
C-211
C-213
C-214
C-215
C-225
C-224
C-223
C-222
C-221
B-23
C-214 (5) Defogger relay
C-215 (5) Blower relay
C-216 (15) Floor wiring harness (LH) and J/B
combination
C-218 (3) Roof wiring harness (RH) and J/B
combination
C-219 (4) Rear fog lamp relay
C-220 (4) No connection
C-221 (4) Fuel pump relay 2C-222 (4) Intercooler water spray relay
C-223 (4) Fuel pump relay 1
C-224 (5) Power window relay
C-225 (2) No connection
C-226 (20) ETACS-ECU
C-227 (24) ETACS-ECU
C-228 (24-GR) ETACS-ECU
C-230 (5) Steering wheel sensor

WIRING HARNESS CONFIGURATION DIAGRAMS
JUNCTION BLOCK
(Front view)(Rear view)
Dedicated fuse
C-226C-208C-209C-210
C-211
C-213
C-214
C-215
C-227C-228C-217C-218C-219C-220
C-222
C-221
C-223
C-224
C-225
B-29
C-214 (5) Defogger relay
C-215 (5) Blower relay
C-217 (15) Floor wiring harness (RH) and J/B
combination
C-218 (3) Roof wiring harness (RH) and J/B
combination
C-219 (4) Rear fog lamp relay
C-220 (4) No connection
C-221 (4) Fuel pump relay 2C-222 (4) Intercooler water spray relay
C-223 (4) Fuel pump relay 1
C-224 (5) Power window relay
C-225 (2) No connection
C-226 (20) ETACS-ECU
C-227 (24) ETACS-ECU
C-228 (24-GR) ETACS-ECU
C-230 (5) Steering wheel sensor

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
D
D-23
D-22
D-21
D-20
D-19
D-18
D-34D-15D-33D-32D-30D-29
D-06D-05D-04D-03D-02D-26D-01
Y
B-30
FLOOR AND ROOF
L.H. drive vehicles
D-01 (3) Door switch (Front: RH)
D-02 (8) Floor wiring harness (RH) and rear door
wiring harness (RH) combination
D-03 (2) Room lamp
D-04 (2-B) Wheel speed sensor (Rear: RH)

D-05 (2-GR) Rear room lamp
D-06 (3) Door switch (Rear: RH)D-08 (3) Door switch (Rear: LH)
D-09 (5-GR) Fuel pump and fuel gauge unit (Main)
D-10 (2-B) Wheel speed sensor (Rear: LH)

D-12 (8) Floor wiring harness (LH) and rear door
wiring harness (LH) combination
D-13 (3) Door switch (Front: LH)
D-15 (4) Instrument panel wiring harness and
console wiring harness combination

WIRING HARNESS CONFIGURATION DIAGRAMS
D-13
D-27
D-08
D-09
D-10
D-12
D-28 Y
9
10
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-31
D-18 (1) Cigarette lighter
D-19 (1-B) Cigarette lighter
D-20 (2-B) Ashtray illumination lamp
D-21 (2-B) Cigarette lighter illumination lamp
D-22 (4) Oxygen sensor (Rear)
D-23 (1-B) Parking brake switch
D-26 (2-R) Seat belt pretensioner (RH)
D-27 (2) Fuel gauge unit (Sub)
D-28 (2-R) Seat belt pretensioner (LH)D-29 (1) Floor wiring harness (RH) and fuel wiring
harness combination
D-30 (8) Floor wiring harness (RH) and fuel wiring
harness combination
D-32 (3-B) G sensor (Longitudinal)
D-33 (3-B) G sensor (Lateral)
D-34 (6) Intercooler water spray switch

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
D
D-01D-26D-02D-03D-04D-05D-06
D-34D-15D-33D-32D-30D-29
D-23
D-22
D-21
D-20
D-19
D-18Y
B-32
FLOOR AND ROOF
R.H. drive vehicles
D-01 (3) Door switch (Front: RH)
D-02 (8) Floor wiring harness (RH) and rear door
wiring harness (RH) combination
D-03 (2) Room lamp
D-04 (2-B) Wheel speed sensor (Rear: RH)

D-05 (2-GR) Rear room lamp
D-06 (3) Door switch (Rear: RH)
D-08 (3) Door switch (Rear: LH)D-09 (5-GR) Fuel pump and fuel gauge unit (Main)
D-10 (2-B) Wheel speed sensor (Rear: LH)

D-12 (8) Floor wiring harness (LH) and rear door
wiring harness (LH) combination
D-13 (3) Door switch (Front: LH)
D-15 (4) Instrument panel wiring harness and
console wiring harness combination
