steering MITSUBISHI MONTERO 1998 Service Manual

Fig. 31: Exploded View Of Steering Column (3000GT)
Courtesy of Mitsubishi Motor Sales of America

Fig. 34: Testing Ignition Switch & Key Reminder Switch (3000GT)
Courtesy of Mitsubishi Motor Sales of America
Wiper/Washer Switch Test (Front)
Disconnect steering column combination switch connector.

Check continuity between specified terminals. See Figs. 31 and 33. If
continuity is not as specified, replace steering column combination
switch.
REMOVAL & INSTALLATION
* PLEASE READ THIS FIRST *
WARNING: Deactivate air bag system before performing any service
operation. See AIR BAG RESTRAINT SYSTEMS article. DO NOT
apply electrical power to any component on steering column
without first deactivating air bag system. Air bag may
deploy.
IGNITION SWITCH
Removal & Installation (Diamante)
Remove instrument panel lower cover. Remove upper and lower
steering column covers. See Fig. 1. Remove ignition switch. To
install, reverse removal procedure.
Removal & Installation (Eclipse)
1) Remove knee protector mount screw plugs. Remove knee
protector. Remove hood lock release handle. Remove upper and lower
steering column covers. See Fig. 6. Remove ignition key illumination
light.
2) Remove steering lock cylinder. Remove A/C-heater system
lap cooler and shower ducts. On A/T models, remove key interlock cable
and slide lever. On all models, remove ignition switch. To install,
reverse removal procedure.
Removal & Installation (Galant)
Remove knee protector. Remove upper and lower column covers.
See Fig. 11 . Remove ignition switch. To install, reverse removal
procedure.
Removal & Installation (Mirage)
Remove knee protector. Remove steering column cover. See
Fig. 15 . Remove clip and cover. On A/T models, remove key interlock
cable, spring and slide lever. On all models, remove ignition switch.
To install, reverse removal procedure.
Removal & Installation (Montero & Montero Sport)
Remove lower instrument panel cover. Remove upper and lower
column covers. See Fig. 19 or 25. Remove ignition switch. To install,
reverse removal procedure.
Removal & Installation (3000GT)
Remove knee protector. Remove upper and lower steering column
covers. See Fig. 31. Remove A/C-heater system lap cooler duct and foot
duct. Remove key reminder switch. Remove ignition switch. To install,
reverse removal procedure.
STEERING COLUMN SWITCH
CAUTION: DO NOT hammer on steering shaft. Collapsible steering column
mechanism may be damaged.
Removal & Installation (Diamante)
Remove air bag module. See AIR BAG RESTRAINT SYSTEMS article.
Remove steering wheel. Remove instrument panel lower cover. Remove
upper and lower steering column covers. See Fig. 1. Remove steering

column switch. To install, reverse removal procedure.
Removal & Installation (Eclipse)
Remove air bag module. See AIR BAG RESTRAINT SYSTEMS article.
Remove horn pad and steering wheel. Remove hood lock release handle.
Remove column pad and upper and lower column covers. See Fig. 6.
Remove A/C-heater system lap cooler duct and foot shower duct. Remove
steering column switch. To install, reverse removal procedure.
Removal & Installation (Galant)
Remove air bag module. See AIR BAG RESTRAINT SYSTEMS article.
Remove steering wheel. Remove column pad. Remove foot duct. Remove
upper and lower steering column covers. See Fig. 11. Remove steering
column switch. To install, reverse removal procedure.
Removal & Installation (Mirage)
Remove air bag module. See AIR BAG RESTRAINT SYSTEMS article.
Remove steering wheel. Remove hood release handle. Remove knee
protector. Remove upper and lower steering column covers. See Fig. 15.
Remove steering column switch. To install, reverse removal procedure.
Removal & Installation (Montero)
Remove air bag module. See AIR BAG RESTRAINT SYSTEMS article.
Remove steering wheel. Remove foot duct. Remove lower instrument panel
cover. Remove upper and lower steering column covers. See Fig. 19.
Remove steering column switch. To install, reverse removal procedure.
Removal & Installation (Montero Sport)
Remove air bag module. See AIR BAG RESTRAINT SYSTEMS article.
Remove steering wheel. Remove instrument panel lower cover. Remove
upper and lower steering column covers. See Fig. 25. Remove steering
column switch. To install, reverse removal procedure.
Removal & Installation (3000GT)
Remove air bag module. See AIR BAG RESTRAINT SYSTEMS article.
Remove steering wheel. Remove knee protector. Remove upper and lower
steering column covers. Remove A/C-heater system lap cooler duct and
foot duct. Remove left or right steering column switch. See Fig. 31.
To install, reverse removal procedure.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE








\









\









\









\









\









\






Application Ft. Lbs. (N.m)
Steering Wheel Nut
Diamante, Montero, Montero Sport
& 3000GT ...................................... 29 (39)
Eclipse, Galant & Mirage ....................... 30 (41)
INCH Lbs. (N.m)
Air Bag Module Bolts/Nuts
Diamante, Eclipse & Mirage .................... 53 (6.0)
Galant & Montero .............................. 80 (9.0)
Montero Sport ................................. 78 (8.8)
3000GT ....................................... 39 (4.4)









\









\









\









\









\









\






WIRING DIAGRAMS

STEERING COLUMN
1998 Mitsubishi Montero
1997-98 STEERING
Mitsubishi - Steering Columns - RWD & 4WD
Mitsubishi: Montero, Montero Sport
DESCRIPTION & OPERATION
WARNING: Vehicle is equipped with a Supplemental Restraint System
(SRS) that includes an air bag located in steering wheel.
Use caution when working around steering column. Ensure
battery is disconnected before attempting any repair. DO NOT
apply electrical power to any component on steering column
without disconnecting air bag module (air bag could deploy).
Steering column consists of a collapsible steering shaft with
lower joint assembly. Vehicle is equipped with a Supplemental
Restraint System (SRS) that includes an air bag and clockspring
located in steering column wheel.
NOTE: For information not covered in this article, air bag
DIAGNOSIS & TESTING or DISPOSAL PROCEDURES, see AIR BAG
RESTRAINT SYSTEM article.
DISABLING & ACTIVATING AIR BAG SYSTEM
WARNING: Wait at least 60 seconds after disconnecting negative
battery cable before servicing SRS. System reserve capacitor
maintains SRS voltage for about 60 seconds after battery is
disconnected. Servicing SRS before 60-second period may
cause accidental air bag deployment and possible personal
injury.
To disable system, turn ignition switch to OFF position.
Disconnect and isolate negative battery cable end. Wait at least 60
seconds. To activate system, reconnect negative battery cable.
AIR BAG SERVICE PRECAUTIONS
The following precautions should be observed when working
with SRS:
* Disable SRS before servicing any SRS or steering column
component. Failure to do this may result in accidental air
bag deployment and possible personal injury. See DISABLING &
ACTIVATING AIR BAG SYSTEM.
* Wait at least 60 SECONDS after disabling air bag system. SRS
system retains enough voltage, for a short time after system
is disabled, to deploy air bag.
* After repairs, always turn ignition on to ensure SRS warning
light is working properly and no system faults are indicated.
* Always wear safety glasses when servicing or handling an air
bag.
* DO NOT expose air bag module and clockspring to temperatures
more than 200
F (93C).
* When placing a live air bag on a bench or other surface,
always face air bag and trim cover up, away from surface.
This will reduce motion of module if air bag accidentally

deploys.
* After air bag deploys, air bag surface may contain deposits
of sodium hydroxide, which irritate skin. Always wear safety
glasses, rubber gloves and long-sleeved shirt during clean
up. Wash hands using mild soap and water. Follow correct
clean-up and disposal procedures.
* Because of critical system operating requirements, DO NOT
service any SRS components. Repairs are only made by
replacing defective part(s).
* DO NOT allow any electrical source near inflator on the back
of air bag module.
* When carrying live air bag module, trim cover should be
pointed away from body to minimize injury in case of
accidental air bag deployment.
* If SRS is not fully functional for any reason, DO NOT drive
vehicle until system is repaired and is fully functional. DO
NOT remove bulbs, modules, sensors or other components, or in
any way disable system from operating normally. If SRS is not
functional, park vehicle until repairs are made.
REMOVAL & INSTALLATION
STEERING WHEEL
WARNING: Wait at least 60 seconds after disconnecting negative
battery cable before servicing SRS. System reserve capacitor
maintains SRS voltage for about 60 seconds after battery is
disconnected. Servicing SRS before 60-second period may
cause accidental air bag deployment and possible personal
injury.
Removal
Disable air bag. See DISABLING & ACTIVATING AIR BAG SYSTEM .
Ensure steering wheel is straight ahead. Remove air bag. Place
reference mark on steering wheel and steering column shaft for
installation reference. Remove steering wheel nut and washer. Using
steering wheel puller, remove steering wheel.
CAUTION: DO NOT hammer on steering wheel during removal or
installation, as it may damage steering column.
Installation
To install, reverse removal procedure. Ensure reference marks
are aligned. Tighten fasteners to specification. See
TORQUE SPECIFICATIONS . Activate air bag. See DISABLING & ACTIVATING
AIR BAG SYSTEM.
COMBINATION SWITCH
CAUTION: When installing steering wheel, if rotating part of
clockspring is not properly centered with steering column
and front wheels, clockspring failure will result.
Removal & Installation
Remove lower instrument cover and lower heater duct. Remove
air bag and steering wheel. See STEERING WHEEL under
REMOVAL & INSTALLATION . Remove upper and lower steering column covers.
Disconnect clockspring electrical connector. Remove screws attaching
colckspring and remove clockspring. Disconnect combination switch
electrical connectors. Remove screws and combination switch. To
install, reverse removal procedure.

IGNITION SWITCH
Removal & Installation
1) Remove upper and lower steering column covers. Disconnect
harness connector from ignition switch. Using hacksaw, cut slots in
bolt heads of lock assembly. Using screwdriver, remove bolts and lock
assembly.
2) To install, reverse removal procedure. Tighten new bolts
until heads of bolts sheer off.
STEERING COLUMN
WARNING: Failure to follow air bag service precautions may result in
air bag deployment and personal injury. See AIR BAG SERVICE
PRECAUTIONS. Follow all service precautions before
attempting repairs. After component replacement, perform a
system operational check to ensure proper system operation.
CAUTION: Applying excessive pressure or causing impact to steering
shaft during service may cause column to collapse. Before
removing steering column, ensure wheels are in
straight-ahead position. Note steering wheel location for
installation reference.
Removal
1) Remove steering wheel. Remove combination switch and
ignition switch (if necessary). See STEERING WHEEL under
REMOVAL & INSTALLATION .
2) Remove lower instrument panel cover and air duct.
Disconnect all electrical connections. Disconnect brake pedal return
spring (if equipped). Disconnect gearshift control cable.
3) Remove bolts for dust cover at firewall. Remove bolt from
clamp at steering gear. Remove steering column bolts and remove
steering column.
Installation
To install, reverse removal procedure. Apply sealant (3M ATD
8663) to dust cover bolts before installing. Tighten bolts to
specification. See TORQUE SPECIFICATIONS .
OVERHAUL
STEERING COLUMN
WARNING: Failure to follow air bag service precautions may result in
air bag deployment and personal injury. See AIR BAG SERVICE
PRECAUTIONS. Follow all service precautions before
attempting repairs. After component replacement, perform a
system operational check to ensure proper system operation.
NOTE: Vehicle steering column is not repairable. See below for
joint assembly and steering lock removal and installation.
Disassembly
Remove steering column from vehicle. See STEERING COLUMN
under REMOVAL & INSTALLATION . Remove clamp bolt from joint assembly.
See Fig. 1 . Remove assembly. Remove lower boot, upper boot and dust
cover from joint assembly. To remove steering lock, use a hacksaw to
cut bolts at steering lock bracket side. Remove steering lock and
bracket.

Fig. 1: Exploded View Of Steering Column (Montero Shown, Montero
Sport Similar)
Courtesy of Mitsubishi Motor Sales of America.
Reassembly
1) To reassemble, reverse disassembly procedure. Install
upper boot on joint assembly. Install lower boot and dust cover on
joint assembly. Leave boots on shafts without assembling them to
universal joint.
2) Apply multipurpose grease to universal joints of joint
assembly. When installing upper boot, lower boot and dust cover,
ensure arrows on boots align with slit area on yoke. Align steering

lock with column boss. Ensure steering lock is operational. Tighten
bolt until bolt head breaks off.
3) Assemble upper steering column with lower joint assembly.
Ensure mating mark on lower steering shaft aligns with yoke groove in
upper steering shaft. See Fig. 2. Apply thread sealant to bolts and
nuts of lower steering column.
Fig. 2: Aligning Mating Mark
Courtesy of Mitsubishi Motor Sales of America.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS








\









\









\









\









\









\









\








Application Ft. Lbs. (N.m)\
Column Bracket Bolts
Montero ................................................. 16 (22)\
Montero Sport ............................................... ( 1)
Lower Steering Shaft Clamp Bolt
Montero ........................................... 22-25 (30-34)\
Montero Sport ........................................... 14 (19)\
Steering Wheel Nut ......................................... 29 (40)\
Upper Steering Shaft Clamp Bolt ............................ 13 (18)\
Dust Cover Bolt
Montero ................................................... 3 (4)\
Montero Sport ............................................... ( 1)
Air Bag Bolts ................................................ 7 (9)\
Steering Column Tube Clamp ................................... 4 (5)\
( 1) - Tighten bolts to 106 INCH lbs. (12 N.m).
( 2) - Tighten bolts to 43 INCH lbs. (4.9 N.m).









\









\









\









\









\









\









\








STEERING SYSTEM - POWER RECIRCULATING BALL
1998 Mitsubishi Montero
1997-98 STEERING
Mitsubishi - Power Recirculating Ball
Montero, Montero Sport
DESCRIPTION & OPERATION
STEERING GEAR
The power steering gear displaces fluid to provide hydraulic
pressure assist while turning. A one-piece rack piston nut is geared
to cross shaft. Backlash is adjusted with an adjusting screw.
STEERING LINKAGE
Linkage consists of an idler arm, relay rod, steering
knuckles and adjustable tie rods. Components are connected by ball
joints. Linkage assembly is connected to steering gear by pitman arm.
LUBRICATION
FLUID TYPE
Recommended fluid type is Dexron-II ATF.
FLUID LEVEL CHECK
Place vehicle in level position. Start engine and let idle.
Turn steering wheel left and right. Replace fluid if it has bubbles or
has become White. Fluid level should be between MIN and MAX marks on
dipstick. Fill to proper level.
FLUID REPLACEMENT
CAUTION: DO NOT crank engine for more than 15-20 seconds at a time.
1) Remove reservoir cap. Disconnect return hose at reservoir.
Drain fluid. Disconnect coil high tension wire. Raise and support
vehicle.
2) Turn steering wheel lock-to-lock several times while
cranking engine to drain fluid from steering gear. Reconnect hose.
Fill power steering system with fluid. Bleed system. See
HYDRAULIC SYSTEM BLEEDING .
HYDRAULIC SYSTEM BLEEDING
CAUTION: DO NOT crank engine for more than 15-20 seconds at a time.
Add fluid as needed during procedure to prevent reservoir
level from dropping.
1) Ensure reservoir is filled before bleeding. Add fluid (if
necessary) during bleeding. Raise and support front of vehicle.
Disconnect coil high tension wire.
2) While cranking engine, turn steering wheel lock-to-lock 5
or 6 times. Lower vehicle. Connect coil wire. Start engine and let
idle. Turn steering wheel lock-to-lock until no more bubbles appear in
oil reservoir.
