1) Connect ohmmeter negative lead to terminal No. 3 and
positive lead to terminal No. 8. See Fig. 11. Continuity should exist.
Reverse ohmmeter leads. Continuity should not exist.
2) Remove motor cover. Connect ohmmeter negative lead to
terminal No. 7 and positive lead to terminal No. 8. See Fig. 11.
Continuity should not exist. Continuity should exist when light is
shone onto sensor receiver. Replace rotation sensor if continuity is
not as specified.
Fig. 11: Checking Motor Rotation Sensor (3000GT)
Courtesy of Mitsubishi Motor Sales of America
REMOVAL & INSTALLATION
Page 1227 of 1501
install, open roof glass panel about 7.9" (200 mm). Using crank
handle, rotate drive motor until alignment hole of intermittent gear
is aligned with center of drive gear. See Fig. 13. To complete
installation, reverse removal procedure.
Removal & Installation (Montero Sport & 3000GT)
Remove sun roof switch and dome light assembly. Remove
bracket. Remove headliner. Remove drive motor. To install, reverse
removal procedure.
Fig. 12: Inspecting Drive Gear Position (Galant)
Courtesy of Mitsubishi Motor Sales of America
Fig. 13: Inspecting Drive Gear Position (Montero)
Courtesy of Mitsubishi Motor Sales of America
Page 1228 of 1501
SUN ROOF R & I
Removal & Installation (Eclipse & Galant)
1) Remove side trim covers by lightly pulling panels straight
down. Unbolt and remove roof glass panel with adjust plates. See
Fig. 1 . Operate sun roof drive cable assembly to fully open position.
Remove deflector. Remove guide rail cover. Operate sun roof drive
cable assembly to fully closed position and remove rear drip channel.
2) Remove overhead switch assembly. Remove rear seat. Push
down on rear seat cushion and pull seat release lever. Unbolt and
remove seat back. Remove front and rear door scuff plate.
3) Remove center pillar lower and upper trim. Remove roof
rail and sun roof trim strips. Remove front and rear pillar trim.
Remove assist handle. Remove headliner. Disconnect motor harness
connector. Remove motor mounting bolts and remove motor.
4) Attach protective tape around roof opening. Pull sliding
roof assembly forward through roof opening. Disconnect drain hoses. If
drain hoses need replacement, attach cord to exterior end of drain
hose. Pull drain hose from interior end. Remove housing assembly and
set brackets.
5) To install components, reverse removal procedure. Sun roof
drive cables must be properly indexed to drive motor drive gear.
Remove drive motor cam gear cover. Using manual closure wrench
(included in tool pouch), rotate motor to correct position. See
Fig. 12 . Install motor. Install remaining components. To adjust roof
glass panel, see SUN ROOF GLASS FIT under ADJUSTMENTS.
Removal & Installation (Montero)
1) Remove trim covers. Unbolt roof glass panel from sliding
assembly and remove. Remove sun roof switch assembly and drive motor.
Remove front and rear door scuff plate.
2) Remove center pillar lower and upper trim. Remove roof
rail and sun roof trim strips. Remove front and rear pillar trim.
Remove assist handle. Remove headliner. Remove rear set bracket.
Remove sun roof assembly. Disconnect drain hoses.
3) If drain hoses need replacement, attach cord to exterior
end of drain hose. Pull drain hose from interior end. To install
components, reverse removal procedure. See DRIVE MOTOR R & I for
installation procedures.
Removal & Installation (Montero Sport & 3000GT)
Remove sun roof switch and dome light assembly. Remove
bracket behind dome light. Remove headliner. Remove drain hose
retaining clips and remove drain hose. Remove sun roof assembly. To
install, reverse removal procedure.
WIRING DIAGRAMS
Page 1255 of 1501
![MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
\
AIR RIDE SUSPENSION - WARNING LAMPS
AIR RIDE SU](/img/19/57333/w960_57333-1254.png "MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
\
AIR RIDE SUSPENSION - WARNING LAMPS
AIR RIDE SU")
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - WARNING LAMPS
AIR RIDE SUSPENSION - WARNING LAMP INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Bulb burned out ......... A ............ Require replacement.
Warning light does
not come on during
bulb check ............. .. . Further inspection required to
determine cause.
Warning light flashes ... .. . Further inspection required to
determine cause.
Warning light is
intermittent ........... .. . Further inspection required to
determine cause.
Warning light stays
on after initial
bulb check ............. .. . Further inspection required to
determine cause.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - WIRING HARNESSES
AIR RIDE SUSPENSION - WIRING HARNESS INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Connector bent .......... A .. Require repair or replacement.
Connector broken ........ A .. Require repair or replacement.
Connector loose ......... A .. Require repair or replacement.
Damaged (cut, burned, or
chafed) ................ A .. Require repair or replacement.
Excessive resistance .... B .. Require repair or replacement.
Fuse blown .............. A ............ Require replacement.
Fusible link blown ...... A ............ Require replacement.
Open .................... A .. Require repair or replacement.
Poor ground ............. A .. Require repair or replacement.
Routed incorrectly ...... B .. Require rerouting according to
vehicle manufacturer's
specifications.
Shorted ................. A .. Require repair or replacement.
Terminal bent ........... A .. Require repair or replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal corroded ....... A .. Require repair or replacement.
Terminal loose .......... A .. Require repair or replacement.
\
\
\
\
\
\
\
BALL JOINTS
Before requiring or suggesting ball joint replacement, the
approved OEM procedure must be used to measure ball joint wear. The
measurement(s) obtained, along with the vehicle manufacturer's
specifications, must be noted on the inspection report. Some states
require that these measurements also appear on the invoice.
NOTE: The term "perceptible movement," defined as any visible
movement in any direction, has been the industry standard
for determining the need for replacement of follower ball
joints. Some vehicle manufacturers are now publishing
specifications for follower ball joints that were
Page 1322 of 1501
3.5L, Engine Performance Circuits, Federal (3 of 3)
EXTERIOR LIGHTS
Page 1326 of 1501
Ground Distribution Circuit
HEADLIGHTS
Page 1327 of 1501
Headlight Circuit
HORN
Page 1331 of 1501
Instrument Cluster Circuit (3 of 3)
INTERIOR LIGHTS
Page 1355 of 1501
and remove. Disconnect all external solenoid and switch connections.
3) On Montero 4WD, remove catalytic converter and front
exhaust pipe. On all models, disconnect speedometer cable and control
cables at transmission. Remove starter and bellhousing cover. Place
reference mark on torque converter and drive plate for reassembly
reference. Remove torque converter bolts. Push torque converter back
and away from drive plate.
4) Disconnect transmission cooler lines. Remove oil filler
tube. Secure transmission on a jack. Raise transmission slightly to
take weight off mount. Remove crossmember-to-mount bolts and
crossmember.
5) Remove transfer case mounting bracket and mount (if
equipped). Remove transmission-to-engine mounting bolts. Carefully
lower transmission from vehicle.
CAUTION: Ensure torque converter is fully seated in transmission
before installation.
Installation
1) To install, reverse removal procedure. Tighten
transmission-to-engine bolts and torque converter-to-drive plate bolts
to specification. See TORQUE SPECIFICATIONS. Tighten mount bolts with
weight of engine and transmission on mounts. Ensure reference marks on
drive shaft(s) and torque converter-to-drive plate are matched.
2) Apply sealant to transfer case gearshift assembly gasket
before installation. Coat transmission oil filler tube "O" ring with
transmission fluid before installation. Refill transmission fluid to
specified level. See LUBRICATION in TRANSMISSION SERVICING - A/T
article. Adjust all control cables. See ADJUSTMENTS in
TRANSMISSION SERVICING - A/T article.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS - FWD MODELS \
\
\
\
\
\
\
Applications Ft. Lbs. (N.m)\
Ball Joint Nut ............................................ 74 (100)\
Center Crossmember Assembly Front Bolt ..................... 69 (93)\
Center Crossmember Assembly Rear Bolt ...................... 52 (70)\
Starter Bolts .............................................. 22 (30)\
Tie Rod End Nut ............................................ 21 (28)\
Torque Converter-To-Drive Plate Bolt ................. 33-38 (45-52)\
Transaxle-To-Engine Block Bolt
8-mm Bolt .................................................... ( 1)
10-mm Bolt ......................................... 22-25 (30-34)\
12-mm Bolt ......................................... 31-40 (42-54)\
Upper Coupling Bolts
2.4L ..................................................... 35 (48)\
3.0L ..................................................... 54 (73)\
Lower Coupling Bolts
2.4L ..................................................... 35 (48)\
3.0L ..................................................... 65 (88)\
( 1) - Tighten to 84-108 INCH lbs. (10-12 N.m).
\
\
\
\
\
\
\
TORQUE SPECIFICATIONS - RWD MODELS \
\
\
\
\
\
\
Applications Ft. Lbs. (N.m)\
Engine-To-Transmission Bolt ................................ 65 (88)\
Page 1366 of 1501
TROUBLE SHOOTING - BASIC PROCEDURES
1998 Mitsubishi Montero
GENERAL TROUBLE SHOOTING
* PLEASE READ THIS FIRST *
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.
ACCESSORIES & ELECTRICAL
CHARGING SYSTEM TROUBLE SHOOTING
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.
BASIC CHARGING SYSTEM TROUBLE SHOOTING CHART
\
\
\
\
\
\
\
CONDITION POSSIBLE CAUSE CORRECTION \
\
\
\
\
\
\
Vehicle Will Not Dead battery Check battery cells,
Start alternator belt
tension and alternator
output
Loose or corroded battery Check all charging
connections system connections
Ignition circuit or switch Check and replace as
malfunction necessary
\
\
\
\
\
\
\
Alternator Light Loose or worn alternator Check alternator drive
Stays On With drive belt tension and
Engine Running condition, See Belt
Adjustment in TUNE-UP
article in the
TUNE-UP section
Loose alternator wiring Check all charging
connections system connections
Short in alternator light See Indicator Warning
wiring Lights in STANDARD
INSTRUMENTS in the
ACCESSORIES &
EQUIPMENT section
Defective alternator stator See Bench Tests in
or diodes ALTERNATOR article
Defective regulator See Regulator Check in
