relay MITSUBISHI MONTERO 1998 Workshop Manual
[x] Cancel search | Manufacturer: MITSUBISHI, Model Year: 1998, Model line: MONTERO, Model: MITSUBISHI MONTERO 1998Pages: 1501, PDF Size: 25.81 MB
Page 465 of 1501
Fuel Pump Control Relay Behind right side of dash,
above ECM.
Generator Relay In engine compartment
relay box.
Page 466 of 1501
Headlight Relay In engine compartment
relay box.
Headlight Washer Relay On bracket, behind left side
of dash.
Horn Relay Left front of engine
compartment.
Ignition Key Hole Illumination Light
Timer Behind center console.
Intermittent Wiper Relay (Rear Wiper) In passenger compartment
relay box.
Intermittent Wiper Relay (Windshield
Wiper) Built-in to steering column
switch.
Power Window Relay In passenger compartment
relay box.
Starter Relay Behind center console.
Page 467 of 1501
Taillight Relay In engine compartment
relay box.
Turn Signal & Hazard Flasher Unit On bracket, behind left side
of dash.
\
\
\
\
\
\
\
CIRCUIT PROTECTION DEVICES
\
\
\
\
\
\
\
Component Component Location \
\
\
\
\
\
\
ABS Relay Box In right rear corner of
engine compartment.
Page 468 of 1501
Engine Compartment Relay Box On left inner fender panel,
behind battery.
Fusible Links In engine compartment
relay box.
Joint Connector (J/C) Behind left side of dash.
Page 469 of 1501
Junction Block Behind left side of dash.
Passenger Compartment Relay Box Behind left side of dash.
Power Seat Relay Box Under driver's seat.
\
\
\
\
\
\
\
CONTROL UNITS
\
\
\
\
\
\
\
Component Component Location \
\
\
\
\
\
\
ABS Control Unit Mounted on top of right rear
wheelwell, under metal plate.
A/C Control Unit On top of evaporator case.
Antenna Motor ECU Behind center console.
Auto-Cruise Control ECU Behind center of dash.
Page 474 of 1501
Center Differential Lock Operation
Detection Switch On transfer case.
Dual Pressure Switch On high pressure line, on
receiver-drier.
Engine Coolant Temperature Switch Top right front of engine.
Free Wheel Engage Switch Right side of engine
compartment.
High Range/Low Range Detection Switch On transfer case.
Low Range Operation Detection Switch On transfer case.
Oil Pressure Switch Lower left front of engine.
Parking Brake Switch At base of parking brake
lever.
Power Steering Pressure Switch On power steering pump.
Rear Differential Lock Detection
Switch Under rear of vehicle, on
differential.
Reed Switch Integral with speedometer.
Seat Belt Switch On driver-side seat belt
buckle.
Stoplight Switch On bracket, above brake pedal.
2WD/4WD Detection Switch On transfer case.
4WD Operation Detection Switch On transfer case.
\
\
\
\
\
\
\
MISCELLANEOUS
\
\
\
\
\
\
\
Component Component Location \
\
\
\
\
\
\
Amplifier Under center console, below
floor.
Data Link Connector (DLC) Behind left side of dash,
near relay box.
Page 478 of 1501
Ignition Power Transistor Top left side of engine, next
to ignition coil.
IOD Or Storage Connector In engine compartment relay
box.
Noise Capacitor Top of engine.
Resistor On blower motor housing.
\
\
\
\
\
\
\
Page 480 of 1501
IGNITION SWITCHES
INDICATOR LIGHTS
KEYLESS ENTRY KEYPADS AND TRANSMITTERS
KEYLESS ENTRY TRANSMITTERS
LEDS
LENSES
MICROPHONES
MIRRORS (ELECTROCHROMATIC AND HEATED)
MOTORS
NEUTRAL SAFETY SWITCHES
ODOMETERS
ODOMETERS, SPEEDOMETERS AND TACHOMETERS (CABLE-DRIVEN)
PULLEYS
RECEIVERS, AMPLIFIERS, EQUALIZERS AND SUB-WOOFER VOLUME CONTROLS
RELAY BOXES
RELAYS
SEALED BEAMS
SEAT HEATERS
SECURITY ALARM SENSORS
SIRENS
SOLENOIDS
SPEAKERS AND MICROPHONES
SPEEDOMETER AND TACHOMETER LINKAGES AND CABLES
SPEEDOMETER CABLES
SPEEDOMETERS
STARTERS
SUB-WOOFER VOLUME CONTROLS
SWITCHES
TACHOMETER CABLES
TACHOMETERS
TAPE PLAYERS AND CD PLAYERS
TENSIONERS
TIMERS
TIRE PRESSURE SENSORS
TRANSCEIVERS
TRANSDUCERS
VACUUM ACCUMULATORS (RESERVOIRS)
VACUUM RESERVOIRS
VOLTAGE REGULATORS
WASHER FLUID LEVEL SENDERS
WASHER PUMPS
WIPER ARMS AND BLADES
WIPER BLADES
WIPER HOSES AND NOZZLES
WIPER LINKAGES
WIPER NOZZLES
WIPER PUMP RESERVOIRS
WIRING HARNESSES AND CONNECTORS
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
The Motorist Assurance Program is the consumer outreach
effort of the Automotive Maintenance and Repair Association, Inc.
(AMRA). Participation in the Motorist Assurance Program is drawn from
retailers, suppliers, independent repair facilities, vehicle
manufacturers and industry associations.
Our organization's mission is to strengthen the relationship
between the consumer and the auto repair industry. We produce
materials that give motorists the information and encouragement to
take greater responsibility for their vehicles-through proper,
Page 513 of 1501
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Wire lead burned ........ A .. Require repair or replacement.
Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
(1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Malfunctioning includes inoperative, intermittent
operation, or failure to perform all functions.
( 3) - Make sure poor sound quality is not caused by
ignition/charging system or other forms of electrical
interference.
\
\
\
\
\
\
\
RELAY BOXES
RELAY BOX INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Broken, affecting
performance ............ A ............ Require replacement.
Broken, not affecting
performance ............ .. ........ No service suggested or
required.
Burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Burned, not affecting
performance ............ 2 ........... ( 1) Suggest repair or
replacement.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... ( 1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Cover missing ........... C ... Require replacement of cover.
Cracked, affecting
performance ............ A .. Require repair or replacement.
Cracked, not affecting
performance ............ 1 .. Suggest repair or replacement.
Melted, affecting
performance ............ A ........ ( 1) Require replacement.
Melted, not affecting
Page 514 of 1501
performance ............ 2 ........ (1) Suggest replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
( 1) - Determine cause and correct prior to repair or
replacement of part.
\
\
\
\
\
\
\
RELAYS
RELAY INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Housing broken .......... A ........... Require replacement.
Housing cracked ......... 2 ........... Suggest replacement.
Inoperative ............. A ........ ( 1) Require replacement.
Missing ................. C ........... Require replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 2) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
( 1) - Inoperative includes intermittent operation or out of OEM
specification.
( 2) - Determine cause and correct prior to repair or
replacement of part.
\
\
\
\
\
\
\
SEALED BEAMS
See BULBS, SEALED BEAMS AND LEDS .
