Turning the power ON and OFF
Press the
POWER
button
The power comes ON.
· The POWER indicator illuminates. Press the POWER
button again
The power goes OFF.NOTE
· If the display screen is left open when the ACC is turned OFF, the next time the
ACC is turned ON, the system power automatically comes on and the last source
displayed on the system is displayed again.· If the display screen is closed when the ACC is turned OFF, the next time the
ACC is turned ON, the system power does not automatically come on.
Open the display screen to turn on the system power.· To turn the power ON with the display screen closed, press the POWER
button.
· Do not press in the POWER
button and the
EJECT
button hard.
Basic system operations
mc4382
Page 22 of 56
24Basic operations
Basic operations
To select a system source
Press the
SOURCE
button
Each time the
SOURCE
button is pressed, the
system source changes as shown in the fi gure
below.
DISC
The video screen from the disc (such as DVD video, DVD-VR) in the
system is displayed.
If no disc is inserted, "NO DISC LOADED" is displayed.
mc4387
VIDEO(if so
equipped) Images from video devices (such as
video cameras, games) connected
to the video input terminals are
displayed.
NOTE
· When the
SOURCE
button is pressed, the
currently selected source is displayed in the upper
left corner of the screen.
· If the car is not equipped with the Auxiliary Video
connector (RCA), the VIDEO mode cannot be
used. (The image will not be displayed even when
switching to VIDEO mode.)
To insert/eject the disc
To insert a disc
mc4395
Insert the disc into the disc loading slot with the
playing side facing down.
When the disc is inserted, it is loaded and the
DISC indicator illuminates. To eject the discPush the
EJECT
button to eject the disc.
mc4395a
NOTE
· If a disc is inserted when the system power is OFF,
the power will automatically come ON.· When a disc is ejected and left in the disc loading
slot for 10 seconds, the disc will automatically be
reloaded into the system.· Discs can be ejected even when the ACC is turned
OFF.
Sample image for vehicles equipped with the MMCS
Page 23 of 56
25
Basic operations
Basic operations
Basic operations for playing a disc
Insert a disc
When a disc is inserted, the screen automatically changes to
DISC and the disc begins to play.
If a disc is already inserted, press the
SOURCE
button, select DISC, and
press the PLAY
button.
NOTE
· When a DVD video is inserted, the main menu is sometimes displayed.In this case,
use the disc menu to operate the DVD.
To pause
Press the PAUSE
button
Playback pauses. With a DVD video, DVD-VR, or video CD, the paused image
will remain displayed.
Pressing the PAUSE
button again while in pause mode resumes playback.
To stop the disc
Press the STOP
button
Playback stops.
To Play a disc
mc4383
Page 24 of 56
26Basic operations
Basic operations
To move to the start of a previous chapter or track (song)
Press the PREW
button
The disc will skip to the beginning of the current
chapter or track (song).
Pressing this button twice in a row will cause
the disc to skip to the beginning of the previous
chapter or track (song).
Chapter (track) in play
Chapter 1
Track 1
Chapter 2
Track 2
Chapter 3
Track 3
…
PREW
Once
PREW
Twice
To fast forward/fast reverse
Press the FWD
(fast forward) or
REW
(fast reverse) button
While these buttons are depressed, the disc fast
forwards or fast reverses. When the buttons are
released, the fast forward or fast reverse function
stops.
To cause slow playback
(During DVD video, DVD-VR, or Video CD
playback)
Press the SLOW
button
While this button is depressed, the disc plays in
slow playback mode.
When this button is released, the slow playback
function stops. To move to the start of a chapter or track (song)To move to the start of a subsequent
chapter or track (song)
Press the NEXT
button
The disc will skip to the beginning of the next
chapter or track (song).
Chapter (track) in playChapter 1
Track 1
Chapter 2
Track 2
Chapter 3
Track 3
…
NEXT
Operating status symbols
The following symbols are displayed
according to the playback operating
status.
PlaySlow playback, (SLOW) (DVD video, DVD-
VR, video CD)PauseFast forward (FWD)Fast reverse (REW)STOP (when there is no resume data)STOP (when there is resume data)Displayed when angle change operations
are possible during DVD video or DVD-VR
playbackNOTE
· Depending on the type of disc and its operating
status, it might have an operating status symbol
that is not displayed in the CURSOR menu.For
details, refer to the section on each disc.
Page 25 of 56
27
Basic operations
Basic operations
To adjust display attributes
Press the DISP
button
Display attribute adjustment items (BRIGHT, CONTRAST, COLOR, TINT) are
displayed on the screen.
PICTURE CONTROL
BRIGHT
CONTRAST
TINT
G
R
COLOR
Move the JOYSTICK
up and down to select the item to be
adjusted, then move the JOYSTICK
left and right to make
the adjustment
BRIGHT
Moving right increases brightness.
Moving left decreases brightness.
CONTRAST
Moving right increases the contrast.
Moving left decreases the contrast.
COLOR
Moving right darkens the color.
Moving left lightens the color.
TINT
Moving right increases the green hue.
Moving left increases the red hue.
After making adjustments, wait a while and the display adjustment items will disappear.
NOTE
· Brightness can be adjusted for daytime (LIGHT OFF) and nighttime (LIGHT ON) respectively
To adjust display attributes and screen size
mc4384
Page 26 of 56
28Basic operations
Basic operations
Move the
JOYSTICK
up and down to
select the desired screen size
Screen sizes FULL
Displays a screen enlarged horizontally to fi t the display.
NORMAL
Displays the screen at a ratio of 4:3 (width to height).
ZOOM
Displays the screen at a ratio of 16:9 (width to height).
After making adjustments, wait a while and the
display adjustment items will disappear.
NOTE
· If the video is viewed in an aspect ratio of 16:9,
set it to FULL.· If ZOOM is set, part of the top and bottom of the
menu on the screen may be cut off.
To adjust screen size
Press the
DISP
button
When display attribute adjustment items are
displayed, press the
DISP
button again
Screen size adjustment items (FULL, NORMAL,
ZOOM) are displayed.
DISPLAY 4 * ; &
FULL
NORMAL
ZOOM
Page 27 of 56
29
Basic operations
Basic operations
To view video on the system (if so equipped)Video devices can be used by connecting them to the Auxiliary Video connector (RCA).
Press the
SOURCE
button and
change the system mode to VIDEO
NOTE
· If there are no video devices connected when
VIDEO mode is selected, no video will be
displayed
· Video devices can only be operated from the device(not by the video entertainment system
controls).
· Refer to the user manual that came with the video device for connecting or operating
instructions.
Front audio / MMCS (if so equipped)To listen to audio from a disc or video
playing from the system
.
Source audio selected by the system can be
listened to with Front Audio and MMCS. For
details, refer to the user manual for each
system.
NOTE
· Headphones can be used during audio playback from the system with Front Audio and
MMCS.
· If the system is OFF, video audio can be listened to with Front Audio and MMCS.
Page 28 of 56
30Basic operations
Basic operations
Number input screen
Numbers are entered directly for the title/chapter and
password.
Clear
Cancel All Clear
Set
PLEASE INPUT THE TITLE NUMBER1234 5
6789 0
mc4424
Number: Select 0 - 9 Clear: Erase the last number entered. All Clear: Erase all numbers entered. Set: Set the numbers entered. Cancel: Close the number input screen.
Entry instructions
Enter numbers in order from the top
digit. Move the JOYSTICK
up, down,
left, and right, select the desired
number, and press ENT button.Clear
Cancel All Clear
Set
PLEASE INPUT THE TITLE NUMBER1234 5
6789 0
1
mc4425
Select the number for the next digit in
the same way, and press the
ENT
button.
Clear
Cancel All Clear
Set
PLEASE INPUT THE TITLE NUMBER1234 5
6789 0 12
mc4426
When all the numbers have been
entered, select "Set" with the
JOYSTICK
, and press the ENT
button.
Clear
Cancel All Clear
Set
PLEASE INPUT THE TITLE NUMBER1234 5
6789 0 1234
mc4427
The selected number is set.The disc is played from the start of the track
corresponding to the speci
fi ed title and chapter
numbers.
NOTE
· The number input screen will turn off
automatically after a while.· The disc can also be played by pressing the PLAY
button upon entering the title number
and chapter number.
Number input screen
