Page 31 of 56
DVD video/DVD-VR33
DVD video/DVD-VR
■
Audio menu Audio language number:
the number for the currently playing audio language
is displayed. Language:English is displayed as Eng (DVD-VIDEO only) →“Language codes” (P42,43) Audio recording format:the audio recording format is displayed.
: Dolby AC-3
MPEG : MPEG1,2
LPCM : Linear PCM
DTS : DTS
SDDS : SDDS
There will be no audio output even when selecting
DTS or SDDS.NOTE
· The title number, chapter number, angle number and
other displayed numbers are recorded on the DVD
video or
DVD-VR
. The numbers may vary depending
on the DVD video or
DVD-VR
.
· Dolby and the double-D symbol are registered
trademarks of Dolby Laboratories.
The CURSOR menu
The CURSOR menu
Display the system CURSOR menu to
confi rm DVD operations and playback
mode.
During DVD video or DVD-VR
playback, Press the CURSOR
button to display CURSOR menu
DVD video
mc4400
JpnSUBTITLE
ANGLE
TITLE CHAPTER
SOUND
ONLPCM
001
01
Jpn01
012 0:12:34
1
DVD-VR
mc4444
SUBTITLE
ANGLE
TITLE CHAPTER
SOUND
001- - 01
0012 0:12:34
1
ƒ
CURSOR menu display information■ Status display Title number:
the number for the currently playing title is
displayed. Chapter number:
the number for the currently playing chapter is
displayed. Playback time: the playback time is displayed. The audio mode is displayed. (DVD-VR only) The play mode (repeat and random modes) is
displayed. (DVD-VR only) Playback status:
the current playback status is displayed. Angle number:the number for the currently playing angle is
displayed.■
Subtitle menu Subtitle language number:
the number for the currently playing subtitle
language is displayed.
(DVD-VIDEO only)
Language:English is displayed as Eng (DVD-VIDEO only) →“Language codes” (P42,43) Display ON/OFF:Choose the ON setting to display subtitles and the
OFF setting to make them disappear.
Page 32 of 56
DVD video/DVD-VR
34
DVD video/DVD-VR
NOTE
· The audio mode may not be switchable for some
DVD-VR discs.To change the play mode (DVD-VR only) While CURSOR menu is displayed,
move the JOYSTICK
left and right
to select play mode.
Move the JOYSTICK
up and down
to change play mode.
Play mode
ALL
: Play from the beginning of the disc : Repeat play within the title.
ƒ
: Repeat play within the chapter.
Press the RTN
button
NOTE
• After a while, the CURSOR menu will go away
automatically without pressing the RTN
button, and
the selections will be set.
To change the angle, audio language, or subtitle language
To change the angle
While CURSOR menu is displayed,
move the JOYSTICK
left and right
to select
the angle number
Move the JOYSTICK
up and down
to change the angle number
Press the RTN
button
NOTE
· For scenes that have different camera angles
available, the
mark is displayed on screen.
· It is possible to hide the
symbol.
→“To set indications” (P40)· It may take some time for the angle to change.
To change the audio language While CURSOR menu is displayed, move the JOYSTICK
left and right
to select the audio language number
Move the JOYSTICK
up and down
to change the audio language
number
Press the RTN
button
To change the subtitle language and turn subtitles ON or OFF(For DVD-VR, subtitles can only be turned ON or OFF.)
While CURSOR menu is displayed,
move the JOYSTICK
left and right
to select the subtitle language
number, or select Subtitles (ON/
OFF).
Move the JOYSTICK
up and down
to change the subtitle language or
turn it ON or OFF.
Press the RTN
button
After a while, the CURSOR menu will go away,
and the set subtitle language will be displayed.To change the audio mode (DVD-VR only) While CURSOR menu is displayed,
move the JOYSTICK
left and right
to select audio mode.
Move the JOYSTICK
up and down
to change audio mode.
Audio mode
: Stereo: L channel monaural : R channel monaural
Press the RTN
button
ALL
ƒ
Page 33 of 56
DVD video/DVD-VR35
DVD video/DVD-VR
To enter a title number/chapter number and playTo enter a title number/chapter number and playTo play a DVD video/DVD-VR by entering a title number Press the STOP
button
Press the CURSOR
button
The numbering input screen is displayed.
Clear
Cancel All Clear
Set
PLEASE INPUT THE TITLE NUMBER1234 5
6789 0
mc4438
Number input entry instructions
: Number input screen → P30
The disc is played from the start of the track
corresponding to the entered title number.
To play a DVD video/DVD-VR by entering a chapter number Press the CURSOR
button during
DVD-VIDEO or DVD-VR playback.
The CURSOR menu is displayed. Press the CURSOR
button again.
The number input screen is displayed.
Clear
Cancel All Clear
Set
PLEASE INPUT THE CHAPTER NUMBER1234 5
6789 0
mc4439
Number input entry instructions
: Number input screen →P30
The disc is played from the start of the track
corresponding to the entered chapter number.To change between ORIGINAL and PLAYLIST (DVD-VR only)If the DVD-VR has a playlist, select whether to play
the tracks by original title or by the playlist title.
Press the STOP
button
Move the JOYSTICK
up and down
to select ORIGINAL or PLAYLIST.
MODE
ORIGINAL
PLAYLIST
mc4440
ORIGINAL: Plays from original titles
PLAYLIST: Plays from playlist titles
Press the ENTER
button.
The number input screen is displayed.
Number input entry instructions
: Number input screen →P30
The disc is played from the start of the track
corresponding to the entered title number.
Page 34 of 56
DVD video/DVD-VR
36
DVD video/DVD-VR
In the selected screen, move the
JOYSTICK
up and down, select the
item to adjust and press the ENT
button
Mark Audio Aspect
Rating
LanguageMenu Language English
Audio Language English
Sub-Title Language English
mc4402
Move the JOYSTICK
to each item
and select
After selecting, press the ENT
button
When setup is complete, press the
SET UP
or RTN
button
To return to the screen displayed before the setup
screen was displayed.NOTE
· When settings are preset according to DVD
specifi cations, those settings are displayed.
Set up In setup, DVD video/DVD-VR settings
such as the audio language, subtitle
language, and ratings may be adjusted.
Discs can be set up using the setup
menu when they are inserted no matter
what type of disc they are. However, the
settings will only be implemented for the
disc inserted.
To display the setup screen When the system is in DISC mode,
press the SET UP
button
In the setup screen, move the JOYSTICK
left and right to select the
desired screen
Mark Audio Aspect
Rating
LanguageMenu Language English
Audio Language English
Sub-Title Language English
mc4402
Mark Audio Aspect
Rating
LanguageRating Change
LevelÎCountry Change ÎÎÎÎ
Passeord Change
mc4403
Mark Audio Aspect
Rating
LanguageOn-Screen Mark
OffAngle Mark
Mode Priority On
MP3
mc4404
Mark Audio Aspect
Rating
LanguageAudio DRC
Line
mc4405
Mark Audio Aspect
Rating
LanguageTV Aspect 16:9
mc4406
Page 35 of 56
DVD video/DVD-VR37
DVD video/DVD-VR
To set languages
Languages can be set for the disc menus,
audio, and subtitles.
■
Available language settings Menu Language:
the language in which the title menu will be displayed
can be set.
Audio Language:
the playback audio language can be set.
Sub-Title Language:
the subtitle language displayed during playback can
be set.
Display the setup screen Move the JOYSTICK
left and right
and select Language
Mark Audio Aspect
Rating
LanguageMenu Language English
Audio Language English
Sub-Title Language English
mc4402
Move the JOYSTICK
up and down,
select the desired language and
press ENT
button
Mark Audio Aspect
Rating
LanguageMenu Language English
French Japanese
Audio Language English
Sub-Title Language English
mc4410
The language list is displayed.
NOTE
· Languages that are not recorded on the DVD video/DVD-VR are not available, even if they are
selected. Move the JOYSTICK
up and down
to select Language
Mark Audio Aspect
Rating
LanguageMenu Language English
French
German
Audio Language English
Sub-Title Language English
mc4411
→“Language codes” (P42,43) Press the ENT
button
The selected language is set.
NOTE
· Perform the same operations to set Audio
Language and Subtitle Language.· When no language is set the languages will play according to the DVD video/DVD-VR
specifi cations.
Page 36 of 56
DVD video/DVD-VR
38
DVD video/DVD-VR
Press the ENT
button
Mark Audio Aspect
Rating
LanguageRating Change
Level 6Country Change ÎÎÎÎ
Passeord Change
mc4415
The selected rating level is set.NOTE
8 No Limit: no restrictions are applied
▲
▼
1 All Limit: maximum restrictions are applied
To set the rating (parental cotrol) To change the rating (parental control)Some DVD videos contain a rating or
parental control function that allows for the
playback of some scenes to be restricted.
To change the rating of such DVD videos,
enter a password and make the desired
setting changes.
Move the JOYSTICK
left and right
and select Rating
Mark Audio Aspect
Rating
LanguageRating Change
LevelÎCountry Change ÎÎÎÎ
Passeord Change
mc4403
Move the JOYSTICK
up and down,
select Rating Change and press
ENT
button
The number input screen is displayed.
When changing the ratings, enter
the password (4 digits).
Clear
Cancel All Clear
Set
PLEASE INPUT A 4-DIGIT PASSWORD1234 5
6789 0
mc4412
Move the JOYSTICK
up, down, left, and
right, and select the desired number.
Number input screen → P30
NOTE
▪ The factory installed password is 0000.
▪ Numbers are only displayed on the screen as they are being entered. Entered numbers will
be displayed as “ Γ. When the password is entered, a
rating level list is displayed.
Mark Audio Aspect
Rating
LanguageRating Change 8 No Limit
7Country Change
ÎÎÎÎ
Passeord Change
mc4413
Move the JOYSTICK
up and down,
and select the rating level.
Mark Audio Aspect
Rating
LanguageRating Change 6
5 7Country Change
ÎÎÎÎ
Passeord Change
mc4414
Page 37 of 56
DVD video/DVD-VR39
DVD video/DVD-VR
Number input entry instructions:
Number input screen → P30 When the password is entered, the
number input screen is displayed
again.
Clear
Cancel All Clear
Set
PLEASE INPUT A NEW 4-DIGIT PASSWORD1234 5
6789 0
mc4419
Enter a new password.
Clear
1111
Cancel All Clear
Set
PLEASE INPUT A NEW 4-DIGIT PASSWORD1234 5
6789 0
mc4441
The new password is set.
NOTE
▪ When entering the new password, all of the numbers can be seen.
▪ If the password is entered incorrectly, "INVALID INPUT PLEASE RETRY" is displayed.Enter the
correct password.
Country change
Ratings vary depending on the country, so
it is necessary to set the desired country
code
NOTE
▪ It is not necessary to set a country code when playing a DVD video/DVD-VR that does not
have ratings.
▪ When the country code is not set (the country code is left as [ ÎÎÎÎ]) the rating function is
not activated. Move the JOYSTICK
up and down,
select Country Change and press
ENT
Mark Audio Aspect
Rating
LanguageRating Change
Level 6Country Change
ÎÎÎÎ
Passeord Change
mc4416
The number input screen is displayed.
When changing the country code,
enter the password (4 digits).Move the
JOYSTICK
up, down, left, and right,
and select the desired number.
Number input entry instructions:
Number input screen → P30
When the password is entered, a
country code list is displayed.
United Kingdom
United States United Arab EmiratesMark Audio Aspect
Rating
LanguageRating Change
Level 6Country ChangePasseord Change
mc4417
→ “Country codes“ (P44,45) Move the JOYSTICK
up and down
to select country code
Press the ENT
button
The selected country code is set. To change the passwordMove the JOYSTICK
up and down,
select Password Change and press
ENT
United KingdomMark Audio Aspect
Rating
LanguageRating Change Level 6
Country ChangePasseord Change
mc4418
The number input screen is displayed. When changing the password, enter
the password (4 digits).Move the JOYSTICK
up, down, left, and right,
and select the desired number.
Page 38 of 56
DVD video/DVD-VR
40
DVD video/DVD-VR
To set audio
To set audio content on DVD videos
Move the JOYSTICK
left and right
and select Audio , and press the
ENT
button
Mark Audio Aspect
Rating
LanguageAudio DRC
Line
mc4405
Move the JOYSTICK
up and down,
select NON, LINE, or RF and press
the ENT
button
Mark Audio Aspect
Rating
LanguageAudio DRC
Line
RF None
mc4422
To set indications
To set indications regarding DVD video■
Available indication settings On-Screen Mark:
Set whether the current DVD video/
DVD-VR playback status (play, fast
forward, and so on) is displayed on
screen or not.
On: Playback status is displayed.
Off:
Playback status is not displayed.
Angle Mark:
Set whether the
mark, which
indicates two or more available
viewing angles, is displayed on
screen or not.
On:
When two or more viewing
angles are available, the
mark is
displayed.
Off: When two or more viewing
angles are available, the
mark is
not displayed.
Mode Priority
Set priority of playback when a disc (CD-R/RW, etc.)
with both MP3 and video CD fi les are inserted.
Move the JOYSTICK
left and right
and select Mark
Mark Audio Aspect
Rating
LanguageOn-Screen Mark
OffAngle Mark
Mode Priority On
MP3
mc4404
Move the JOYSTICK
up and down,
select the item to be changed and
press the ENT
button
Mark Audio Aspect
Rating
LanguageOn-Screen Mark
OffOff
Angle Mark
Mode Priority On
MP3
mc4420
Move the JOYSTICK
up and down,
select On/Off and press the ENT
button
For Mode Priority, select MP3 or Video CD.
Mark Audio Aspect
Rating
LanguageOn-Screen Mark
Off
Angle Mark
Mode Priority MP3ONOff
mc4421
Page 39 of 56
DVD video/DVD-VR41
DVD video/DVD-VR
4:3 (Pan Scan) A 16:9 image is displayed as a 4:3
aspect ratio by cropping the left and
right images.
16:9 A 16:9 aspect ratio image is displayed with the original ratio.Select 16:9 for this setting.
Types of audio
■ Audio DRC
Audio DRC is an abbreviation for Dynamic
Range Control. The dynamic range is
controlled so that all audio is played at a
level that is easy to hear. Use this setting
to either enable audio DRC or to play
audio with the standard volume. NON Plays audio with the standard
volume.
LINE Plays audio with DRC enabled.
RF Used when audio cannot be heard in LINE mode.
Audio quality may suffer in RF
mode. Use NON and LINE modes
whenever possible.
To set aspect
Set the aspect ratio.
Move the JOYSTICK
left and right
and select Aspect, and press the
ENT
button.
Mark Audio Aspect
Rating
LanguageTV Aspect 16:9
mc4406
Move the JOYSTICK
up and down,
select 16:9, 4:3(Pan Scan) , 4:3(Let-
ter Box) and press the ENT
button
Mark Audio Aspect
Rating
LanguageTV Aspect 4:3(Pan Scan)
16:9 4:3(Lettr Box)
mc4423Aspect ratio:
the width to height ratio of a screen or image.4:3 (Letter Box) An image with 16:9 aspect ratio is displayed as a 4:3 aspect ratio by
placing a black band on the top and
bottom.
Page 40 of 56
DVD video/DVD-VR
42
DVD video/DVD-VR
Language
Malay May
Maltese Mlt
Burmese Bur
Nauru Nau
Nepali Nep
Norwegian Nor
Occtian Oci
Oromo Orm
Oriya Ori
Panjabi Pan
Polish Pol
Pashto, Pushto Pus
Portuguese Por
Quechua Que
Rhaeto-Romance Roh
Kirundi Run
Romanian Rum
Kinyarwanda Kin
SanSkrit San
Sindhi Snd
Sangho Sag
Serbo-Croatian Srb
Singhalese Sin
Slovak Slo
Slovenian Slv
Samoan Smo
Shona Sna
Language
Catalan Cat
Breton Bre
Catalan Cat
Corsican Cos
Czech Cze
Welsh Wel
Danish Dan
Bhutani Dzo
Esperanto Epo
Estonian Est
Basque Baq
Persian Per
Finnish Fin
Fiji Fij
Faroese Fao
Friesian Fry
Irish Gle
Scots-Gaelic Gla
Galician Glg
Guarani Grn
Gujarati Guj
Hausa Hau
Hindi Hin
Croatian Hrv
Hungarian Hun
Armenian Arm
Interlingua Ina
Language
Japanese Jpn
English Eng
French Fre
German Ger
Italian Ita
Spanish Spa
Dutch Dut
Russian Rus
Chinese Chi
Korean Kor
Greek Gre
Afar Aar
Abkhazian Abk
Afrekaans Afr
Amharic Amh
Arabic Ara
Assamase Asm
Aymara Aym
Azerbaijani Aze
Bashkir Bak
Byelorussian Bel
Bulgarian Bul
Bihari Bih
Bislama Bis
Bengali Ben
Tibetan Tib
Breton Bre
Language
Interlingue Ile
Inupiak Ipk
Indonesian Ind
Icelandic Ice
Hebrew Heb
Yiddish Yid
Javanese Jav
Gorgian Geo
Kazakh Kaz
Greenlandic Kal
Cambodian Khm
Kannada Kan
Kashmiri Kas
Kurdish Kur
Kirghiz Kir
Latin Lat
Lingala Lin
Laothian Lao
Lithuanian Lit
Latvian Lav
Malagasy Mlg
Maori Mao
Macedonian Mac
Malayalam Mal
Mongolian Mon
Moldavian Mol
Marathi Mar
Language codes
(1/2)
Use to change audio language, or subtitle languages.
→ “To set languages”
(P37)
