Wiring Diagram — D/LOCK — /For RoadsterNIS0000J
TIWT1571E

BL-32
POWER DOOR LOCK SYSTEM
Revision: 2006 November2007 350Z
TIWT1572E

POWER DOOR LOCK SYSTEM
BL-33
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
TIWT1573E

BL-34
POWER DOOR LOCK SYSTEM
Revision: 2006 November2007 350Z
Terminals and Reference Value for BCMNIS0000K
*When interior lamp battery saver control is in OFF: Approx. 5V
Terminal and Reference Value for Power Window Main SwitchNIS0000L
Te r m i -
nalWire
colorItemSignal
Input/
OutputConditionVoltage (V)
(Approx.)
12 P Passenger side door switch Input ON (Open) → OFF (Closed) 0 → 5
22 Y Power window switch serial linkInput/
Output—
30 P Back door opener switch InputPress the back door opener
switch when driver side door is
unlocked5 → 0
37 B/R Ignition key switch (insert) InputON (Key inserted) → OFF (Key
removed from IGN key cylinder)Battery voltage → 0
39 L CAN-HInput/
Output——
40 P CAN-LInput/
Output——
42 GY Power source (Fuse) Input — Battery voltage
44 YDriver side door lock actuator
(unlock)OutputDoor lock / unlock switch
(Free → Unlock)0 → Battery voltage → 0
50 PU All door lock actuator (lock) OutputDoor lock / unlock switch
(Free → Lock)0 → Battery voltage → 0
51 W/RPassenger side door lock actua-
tor (unlock)OutputDoor lock / unlock switch
(Free → Unlock)0 → Battery voltage → 0
52 B Ground — — 0
55 R Power source (Fusible link) Input — Battery voltage
58 R/W Back door switch Input ON (Open) → OFF (Closed) 0 → Battery voltage *
62 L Driver side door switch Input ON (Open) → OFF (Closed) 0 → 5
68 L/R Back door opener output OutputPress the back door opener
switch when driver side door is
unlocked0 → Battery voltage
PIIA2344J
TerminalWire
colorItem ConditionVoltage (V)
(Approx.)
6 B/R Key cylinder switch lock signalKey position
(Neutral → Locked)5 → 0
7 SB Key cylinder switch unlock signalKey position
(Neutral → Unlocked)5 → 0
12 PU/W Power window switch serial link —
15 B Ground — 0
PIIA2344J

POWER DOOR LOCK SYSTEM
BL-35
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
Work FlowNIS0000M
1. Check the symptom and customer's requests.
2. Understand the outline of system. Refer to BL-23, "
System Description" .
3. Does power door lock system operate normally? If Yes, GO TO 6, If No, GO TO 4.
4. INSPECTION END.
CONSULT-III Function (BCM)NIS0000N
CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.
WORK SUPPORT
DATA MONITOR
*1: For Coupe
*2: For Roadster
ACTIVE TEST
BCM diagnosis
partInspection item, self-diagnosis
modeContent
Door lockWork support Changes the setting for each function.
Data monitor Displays BCM input data on real-time basis.
Active test Sends drive signals to door lock actuator to perform operation check.
Work item Description
DOOR LOCK-UNLOCK SET Select unlock mode can be changed in this mode. Selects ON-OFF of select unlock mode.
ANTI-LOCK OUT SETKey reminder door mode can be changed in this mode. Selects ON-OFF of key reminder door
mode.
Monitor item “operation” Content
KEY ON SW “ON/OFF” Indicates [ON/OFF] condition of key switch.
LOCK SW DR/AS “ON/OFF” Indicates [ON/OFF] condition of lock signal from lock/unlock switch of driver and passenger side.
UNLK SW DR/AS “ON/OFF”Indicates [ON/OFF] condition of unlock signal from lock/unlock switch of driver and passenger
side.
KEY CYL LK-SW “ON/OFF” Indicates [ON/OFF] condition of lock signal from key cylinder.
KEY CYL UN-SW “ON/OFF” Indicates [ON/OFF] condition of unlock signal from key cylinder.
LK BUTTON/SIG “ON/OFF” Indicates [ON/OFF] condition of lock signal from key fob.
UN BUTTON/SIG “ON/OFF” Indicates [ON/OFF] condition of unlock signal from key fob.
IGN ON SW “ON/OFF” Indicates [ON/OFF] condition of ignition switch.
DOOR SW-DR “ON/OFF” Indicates [ON/OFF] condition of driver side door switch.
DOOR SW-AS “ON/OFF” Indicates [ON/OFF] condition of passenger side door switch.
BACK DOOR SW*
1“ON/OFF” Indicates [ON/OFF] condition of back door switch.
TRNK OPN MNTR*
2“ON/OFF” Indicates [ON/OFF] condition of trunk lid opener switch.
Test item Content
ALL D/LK MTRThis test is able to check all door lock actuators lock operation. These actuators lock when “ON” on
CONSULT-III screen is touched.
DR D/UN MTRThis test is able to check driver side door lock actuator unlock operation. This actuator unlock when
“ON” on CONSULT-III screen is touched.
NON DR D/UNThis test is able to check door lock actuators (except driver side door lock actuator) unlock operation.
These actuator unlock when “ON” on CONSULT-III screen is touched.

BL-36
POWER DOOR LOCK SYSTEM
Revision: 2006 November2007 350Z
Trouble Diagnoses Symptom ChartNIS0000O
Symptom Diagnoses service procedure Reference to page
Key reminder door system does not operate properly.1. Check power supply and ground circuit of BCM.BL-37
2. Check key switch (Insert) .BL-40
3. Check door switch . BL-38
4. Replace BCM.BCS-17
Power door lock does not operate by door lock and unlock
switch on power window main switch or power window
sub-switch.1. Check power supply and ground circuit of BCM.BL-372. Check door lock and unlock switch .BL-42
3. Check driver side door lock actuator .BL-45
4. Check passenger side door lock actuator .BL-46
5. Replace BCMBCS-17
Driver side door lock actuator does not operate.1. Check power supply and ground circuit of BCM.BL-372. Check driver side door lock actuator .BL-45
Passenger side door lock actuator does not operate.1. Check power supply and ground circuit of BCM.BL-372. Check passenger side door lock actuator .BL-46
Power door lock does not operate by door key cylinder
operation, but operates by door lock and unlock switch.1. Check power supply and ground circuit of BCM. BL-372. Check door key cylinder switch . BL-47
3. Replace power window main switch. —
Back door opener does not operate.1. Check power supply and ground of BCM.BL-37
2. Check back door opener switch .BL-48
3. Check back door opener actuator .BL-50

POWER DOOR LOCK SYSTEM
BL-37
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
Check Power Supply and Ground Circuit of BCMNIS0000P
CHECK FUSE
1. FUSE INSPECTION
1. Turn ignition switch OFF.
2. Check the following.

40A fusible link (letter F , located in the fuse and fusible link box)

10A fuse [No.18, located in the fuse block (J/B)]
NOTE:
Refer to BL-21, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
4, "POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
1. Disconnect BCM connector.
2. Check voltage between BCM harness connector M91 terminal 42, 55 and ground.
OK or NG
OK >> GO TO 3.
NG >> Check BCM power supply circuit for open or short.
3. CHECK GROUND CIRCUIT
Check continuity between BCM harness connector M91 terminal 52 and ground.
OK or NG
OK >> Power supply and ground circuit is OK.
NG >> Check BCM ground circuit for open or short.42 (GY) - Ground : Battery voltage
55 (R) – Ground : Battery voltage
PIIA6374E
52 (B) – Ground Continuity should exist.
PIIA9326E

BL-38
POWER DOOR LOCK SYSTEM
Revision: 2006 November2007 350Z
Check Door Switch NIS0000Q
1. CHECK DOOR SWITCH INPUT SIGNAL
With CONSULT-III
Check door switches (“DOOR SW-AS” and “DOOR SW-DR”) in “DATA MONITOR” mode with CONSULT-III.
Without CONSULT-III
Check voltage between BCM connector and ground.
OK or NG
OK >> Door switch is OK.
NG >> GO TO 2.
Monitor item Condition
DOOR SW-DROPEN : ON
CLOSE : OFF
DOOR SW-ASOPEN : ON
CLOSE : OFF
ItemTerminals
Condition
of door
switchVoltage (V)
(Approx.) Con-
nector(+)
(–)
Te r m i n a l
(Wire color)
Driver side door
switch B83 62 (L)
GroundOpen 0
Close 5
Passenger side
door switchM90 12 (P)Open 0
Close 5
PIIA9539E

POWER DOOR LOCK SYSTEM
BL-39
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
2. CHECK DOOR SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect door switch and BCM connector.
3. Check continuity between door switch harness connector B17, B23, terminals 1 and BCM harness con-
nector B83 terminals 62 (driver side) or M90 terminal 12 (passenger side).
4. Check continuity between door switch harness connector B17,
B23, terminals 1 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. CHECK DOOR SWITCH
Check continuity between door switch harness connector B17 (driver side) or B23 (passenger side) terminal 1
and ground.
OK or NG
OK >> Further inspection is necessary. Refer to symptom
chart.
NG >> Replace malfunction door switch.Driver side door
1 (L) – 62 (L) : Continuity should exist.
Passenger door
1 (P) – 12 (P) : Continuity should exist.
1 (L or P) – Ground : Continuity should not exist.
PIIA9540E
Terminal (Wire color) Door switch Continuity
1 (L or P) GroundPushed No
Released Yes
PIIA3351E

BL-40
POWER DOOR LOCK SYSTEM
Revision: 2006 November2007 350Z
Check Key Switch (insert) NIS0000R
1. CHECK KEY SWITCH INPUT SIGNAL
With CONSULT-III
Check ignition key cylinder switch “KEY ON SW” in “DATE MONITOR” mode with CONSULT-II

When key is inserted in ignition key cylinder

When key is removed in ignition key cylinder
Without CONSULT-III
Check voltage between BCM connector and ground.
OK or NG
OK >> Key switch is OK.
NG >> GO TO 2.
2. CHECK KEY SWITCH (INSERT)
1. Turn ignition switch OFF.
2. Disconnect key switch connector.
3. Check continuity between key switch terminals 1 and 2.
OK or NG
OK >> GO TO 3.
NG >> Replace key switch.KEY ON SW :ON
KEY ON SW :OFF
ConnectorTerminal
(Wire color)
Condition Voltage (V)
(Approx.)
(+) (-)
M90 37 (B/R) GroundKey is inserted Battery voltage
Key is removed 0
PIIA9541E
Connector Terminals Condition Continuity
M25 1 2Key is inserted in ignition key cylinder Yes
Key is removed from ignition key cylinder No
PIIA2627E
