when filling.
— Keep the pump nozzle in contact
with the container while you are
filling it.
— Use only approved portable fuel
containers for flammable liquid.
Never pour fuel into the throttle body
to attempt to start your vehicle.
CAUTION
If fuel is spilled on the vehicle body,
flush it away with water to avoid
paint damage.
Tighten until the fuel filler cap clicks.
Failure to tighten the fuel filler cap
properly may cause the
mal-
function indicator lamp (MIL) to illu-
minate. If the
lamp illuminates
because the fuel filler cap is loose or
missing, tighten or install the cap and
continue to drive the vehicle. The
lamp should turn off after a few
driving trips. If the
lamp doesnot turn off after a few driving trips,
have the vehicle inspected by a
NISSAN dealer.
For additional information, see the
“Malfunction indicator lamp (MIL)” in
the “Instruments and controls” sec-
tion.
TILT OPERATIONThe steering wheel will pop up when the lock
lever is pulled as illustrated
1.
Keep holding the lock lever and adjust the
steering wheel to the desired position
2.
Release the lock lever to lock the steering wheel.
WARNING
Do not adjust the steering wheel
while driving. You could lose control
SPA1582
STEERING WHEEL
3-28
Pre-driving checks and adjustments
04.8.3/Z50-D/V5.0
Page 142 of 321
of your vehicle and cause an acci-
dent.
Do not put anything on or near the
steering wheel when tilting.
The accelerator and brake pedals can be ad-
justed for driving comfort.
Use the pedal adjusting switch to adjust the
brake and accelerator pedal position forward
1
or backward
2. Pedal adjustment can only be
performed when:
Ignition switch is in the OFF or ACC position,
or
Ignition switch is ON and the shift lever is in
the P (Park) position
The brake and accelerator pedals cannot be
adjusted separately.
CAUTION
Do not adjust the pedal position with
your foot on the pedal.
SPA1574
PEDAL POSITIONADJUSTMENT
(if so equipped)
Pre-driving checks and adjustments
3-29
04.8.3/Z50-D/V5.0
Page 143 of 321
CAUTION
Do not store the main sun visor be-
fore storing the extension sun visor.
Do not pull the extension sun visor
forcedly downward.
1. To block out glare from the front, swing down
the main sun visor
1.
2. To block glare from the side, remove the main
sun visor from the center mount and swing it
to the side
2.
3. Draw out the extension sun visor
3from the
main sun visor
4
to block further glare.
INSIDE MIRRORWhile holding the inside rearview mirror, adjust
the mirror angles until the desired position is
achieved.
The adjusting lever
1
can be operated when
the glare from the headlights of the vehicle
behind you obstructs your vision at night.
WARNING
Use the night position only when neces-
sary, because it reduces rear view clar-
SPA1592B
SPA1756
SUNVISORS MIRRORS3-30
Pre-driving checks and adjustments
04.8.3/Z50-D/V5.0
Page 144 of 321
ity.
AUTOMATIC ANTI-GLARE INSIDE
MIRROR (if so equipped)The inside mirror is designed so that it automati-
cally changes reflection according to the inten-
sity of the headlights of the vehicle following you.
The anti-glare system will be automatically
turned on when you turn the ignition switch to
the ON position.
When the inside MIRROR switch
A
is turned
on (The indicator light
B
will illuminate), exces-
sive glare from the headlights of the vehicle
behind you will be reduced. Push the MIRROR
switch
A
to turn the system off (the indicatorlight goes off), and the inside mirror will operate
normally.
To turn on the system again, push the MIRROR
switch once again.
For the HomeLink
Universal Transceiver and
the compass display, see the description in the
“2. Instruments and controls” section.
Do not hang any object on the mirror or
apply glass cleaner. Doing so will reduce
the sensitivity of the sensor, resulting in
improper operation.
SPA1448B
Pre-driving checks and adjustments
3-31
04.8.3/Z50-D/V5.0
Page 145 of 321
OUTSIDE MIRRORS
WARNING
Objects viewed in the outside mirror on
the passenger side are closer than they
appear. Be careful when moving to the
right. Using only this mirror could cause
an accident. Use the inside mirror or
glance over your shoulder to properly
judge distances to other objects.
The outside mirror switch, located in front of theshift lever, will operate only when the ignition
switch is in the ACC or ON position.
Move the switch to right
A
or left
B
to select
the right or left outside mirror, then adjust the
mirror to the desired position by pushing the
button
C.
Foldable outside mirrorsFold the outside mirror by pushing it toward the
rear of the vehicle.
SPA1449A
SPA1829
3-32
Pre-driving checks and adjustments
04.8.3/Z50-D/V5.0
Page 146 of 321
The automatic drive positioner system has two
features:
Entry/exit function
Memory storageENTRY/EXIT FUNCTIONThis system is designed so that the driver’s seat
and outside mirror will automatically move when
the shift lever is in the P (Park) position. This
allows the driver to get into and out of the
driver’s seat more easily.
The driver’s seat will slide backward:
The driver’s seat will slide backward when the
driver’s door is opened with the ignition switch
(knob) in the LOCK position.
The driver’s seat will return to the previous
position:
When the key is inserted into the ignition
switch after closing the driver’s door, or when
the driver’s door is closed after inserting the
key into the ignition switch.
When the ignition switch is pushed with the
driver’s door closed. (Intelligent Key
equipped model)
When the key or ignition switch is turned to
the ON position.The entry/exit feature can be canceled. See “4.
Display screen, heater, air conditioner and audio
systems” section of this manual.
The entry/exit function can be activated or can-
celled by pressing and holding the SET switch
for more than 10 seconds while the ignition key
is in the LOCK position. The indicator light will
blink once when the function is cancelled, and
the indicator light will blink twice when the
function is activated. If the battery cable is
disconnected, or if the fuse opens, the entry/exit
function will be cancelled. In such a case, after
connecting the battery or replacing with a new
fuse, open and close the driver’s door more than
two times with the ignition key or ignition switch
in the LOCK position to activate the entry/exit
function.
MEMORY STORAGETwo positions for the driver’s seat, pedals (Brake
and Accelerator) and outside mirrors can be
stored in the automatic drive positioner memory.
Follow these procedures to use the memory
system.
1. Set the selector lever to the P (Park) position.
2. Adjust the driver’s seat, pedals (Brake and
Accelerator) and outside mirrors to the de-
sired positions by manually operating each
adjusting switch. For additional information,
see “Seats” in the “1. Safety — seats, seat
belts and supplemental restraint system”
SPA1584
AUTOMATIC DRIVE POSITIONER
(if so equipped)
Pre-driving checks and adjustments
3-33
04.8.3/Z50-D/V5.0
Page 147 of 321
section and “Pedal position adjustment” and
“Outside mirrors” earlier in this section.
3. Turn the ignition ON.
4. Push the SET switch and, within 5 seconds,
push the memory switch (1 or 2) fully for at
least 1 second.
The indicator light for the pushed memory
switch will come on and stay on for approxi-
mately 5 seconds after pushing the switch.
After the indicator light goes off, the selected
positions are stored in the selected memory
(1 or 2).
If memory is stored in the same memory switch,
the previous memory will be deleted.
Linking a remote keyless entry to a
stored memory positionA remote keyless entry can be linked to a stored
memory position with the following procedure.
1. Follow the steps for storing a memory posi-
tion.
2. While the indicator light for the memory
switch being set is illuminated for 5 seconds,
push the unlock button on the remote keyless
entry. The indicator light will blink. After the
indicator light goes off, the remote keyless
entry is linked to that memory setting.With the key removed from the ignition switch,
push the unlock button on the keyfob. The
driver’s seat, pedals (Brake and Accelerator)
and outside mirrors will move to the memorized
position.
Confirming memory storageTurn the ignition switch to the ON position
and push the SET switch. If the main memory
has not been stored, the indicator light will
come on for approximately 0.5 seconds.
When the memory has stored the position,
the indicator light will stay on for approxi-
mately 5 seconds.Selecting the memorized position1. Set the sift selector lever to the P (Park)
position.
2. Turn the ignition ON.
3. Push the memory switch (1 or 2) fully for at
least 1 second.
The driver’s seat, pedals (Brake and Accel-
erator) and outside mirrors will move to the
memorized position with the indicator light
flashing, and then the light will stay on for
approximately 5 seconds.SYSTEM OPERATIONThe automatic drive positioner system will notwork or will stop operating under the following
conditions:
when the vehicle speed is above 4 MPH (7
km/h).
when any two or more of the memory
switches and the SET switch is simulta-
neously pushed while the automatic drive
positioner is operating.
when the adjusting switch for the driver’s
seat, pedals and outside mirror are operated
while the automatic drive positioner is oper-
ating.
when the memory switch (1 or 2) and the
SET switch is not pushed for at least 1
second.
when the seat has been already moved to the
memorized position.
when no seat position is stored in the
memory switch.
when the engine is started while moving the
automatic drive positioner.
when the shift selector lever is moved from
the P position to any other position (However,
it will not be cancelled if the switch is pushed
while the seat is returning to the previous
positions (entry/exit function).).
3-34
Pre-driving checks and adjustments
04.8.3/Z50-D/V5.0
Page 148 of 321
MEMO
Pre-driving checks and adjustments
3-35
04.8.3/Z50-D/V5.0
Page 149 of 321
MEMO3-36
Pre-driving checks and adjustments
04.8.3/Z50-D/V5.0
Page 150 of 321
4 Display screen, heater, air conditioner and
audio systemsSafety note .............................................................................. 4-2
Control panel buttons — without navigation system .... 4-2
How to use joystick and “ENTER” button ................. 4-3
How to use “PREV” button ........................................... 4-3
How to use the “TRIP” button ...................................... 4-3
How to use “FUEL ECON” BUTTON ........................ 4-4
Clock ................................................................................... 4-4
How to use “E/M” button .............................................. 4-4
How to use “MAINT” (Maintenance) button ............. 4-5
How to use “SETTING” button .................................... 4-6
“DAY/NIGHT” utton......................................................... 4-7
Control panel buttons — with navigation system .......... 4-8
How to use joystick and “ENTER” button ................. 4-8
How to use “PREV” button ........................................... 4-8
Setting up the start-up screen ..................................... 4-9
How to use the “TRIP” button ...................................... 4-9
Maintenance notice ....................................................... 4-11
How to use the “SETTING” button .......................... 4-12
“DAY/NIGHT” button.................................................... 4-17
Rear view monitor (if so equipped) ................................ 4-17
How to read the displayed lines................................ 4-18
Rear view monitor setting............................................ 4-18Operating tips................................................................. 4-18
Ventilators .............................................................................. 4-19
Heater and air conditioner (Automatic) ......................... 4-20
Automatic operation ...................................................... 4-21
Manual operation ........................................................... 4-22
Operating tips................................................................. 4-22
In-cabin microfilter ......................................................... 4-23
Servicing air conditioner .................................................... 4-23
Audio system ........................................................................ 4-24
FM radio reception ........................................................ 4-24
AM radio reception ....................................................... 4-25
Satellite radio reception ............................................... 4-25
Audio operation precautions....................................... 4-25
FM-AM-SAT radio with cassette player and
compact disc (CD) player (TYPE A)/CD changer
(TYPE B) .......................................................................... 4-28
CD care and cleaning .................................................. 4-34
Steering switch for audio control
(if so equipped).............................................................. 4-35
Antenna ............................................................................ 4-36
Car phone or CB radio .................................................... 4-36
04.8.3/Z50-D/V5.0
