CARGO NET (if so equipped)The cargo net helps keep packages in the cargo
area from moving around while your vehicle is
driven.
To install the cargo net, attach the hooks to the
retainers
A
on both sides.
To remove the cargo net, detach the hooks from
the cargo net retainers.
For more retainers, refer to “Vehicle loading
information” in the “9. Technical and consumer
information” section.
WARNING
Properly secure all cargo to help pre-
vent it from sliding or shifting.
Be sure to secure all four hooks into
the retainers. The cargo restrained in
the net must not exceed 30 lbs (13.6
kg) or the net may not stay secured.
TONNEAU COVER (if so equipped)The tonneau cover keeps the luggage compart-
ment contents hidden from the outside.
To open the tonneau cover, pull it out and hang
both sides on the hooks. To close the tonneau
cover, remove it from the hooks and put the hookAon the guide
Bthen release it as illustrated.
To open the subcover
C, pull out and hang
both sides on the hooks behind the rear seat
head restraint. To close the subcover, remove it
from the hooks and release it.
To remove the tonneau cover, pull the holder to
the opposite side
1.
SIC2061
SIC2629
2-34
Instruments and controls
04.8.3/Z50-D/V5.0
Page 102 of 321
WARNING
Never put anything on the tonneau
cover, no matter how small. Any ob-
ject on it could cause an injury in an
accident or sudden stop.
Close the tonneau and sub covers
when folding the rear seat.
Do not leave the tonneau cover in the
vehicle with it disengaged from the
holder.
Properly secure all cargo to help pre-
vent it from sliding or shifting. Do not
place cargo higher than the seat-
backs. In a sudden stop or collision,
unsecured cargo could cause per-
sonal injury.
The child restraint top tether strap
may be damaged by contact with the
tonneau cover or items in the cargo
area. Remove the tonneau cover from
the vehicle or secure it and any cargo.
Your child could be seriously injured
or killed in a collision if the top tether
strap is damaged.
POWER WINDOWS
WARNING
Make sure that all passengers have
their hands, etc. inside the vehicle
while it is in motion and before clos-
ing the windows. Use the window
lock switch to prevent unexpected
use of the power windows.
Do not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches or controls
and become trapped in a window.
Unattended children could become
involved in serious accidents.
The power windows operate when the ignition
switch is in the ON position and for about 45
seconds, after the ignition switch is turned to the
ACC or OFF position. If the driver’s door or the
front passenger’s door is opened during this
period of about 45 seconds, power to the
windows is canceled.
Main power window switch (driver’s
side)1. Rear left passenger’s side window
2. Driver’s side window
3. Window lock button
4. Rear right passenger’s side window
5. Front passenger’s side window
To open or close the window, push down
A
or
pull up
B
the switch and hold it. The main
switch (driver side switches) will open or close
all the windows.
SIC2630
WINDOWS
Instruments and controls
2-35
04.8.3/Z50-D/V5.0
Page 103 of 321
Locking passenger’s windowsWhen the lock button
C
is pushed in, only the
driver side window can be opened or closed.
Push it in again to cancel.
Passenger side power window switchThe passenger side switch will open or close
only the corresponding window. To open or
close the window, hold the switch down
A
or
up
B.
Automatic operationTo fully open or close the driver’s or front
passenger’s side window, completely push
down
Aor pull up
Bthe switch and release it;
it need not be held. The window will automati-
cally open or close all the way. To stop the
window, just push or lift the switch on the
opposite side.
Auto reverse function (For front
window)If the control unit detects something caught in a
front window as it moves up, the window will be
immediately lowered.
SIC1892F
SIC1893E
2-36
Instruments and controls
04.8.3/Z50-D/V5.0
Page 104 of 321
The auto reverse function can be activated when
a front window is closed by automatic operation
when the ignition switch is in the ON position or
for about 45 seconds after the ignition switch is
turned to the OFF position. The doors remain
closed.
Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the window
occurs.
WARNING
There are some small distances imme-
diately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., in-
side the vehicle before closing the win-
dow.
AUTOMATIC SUNROOFThe sunroof will only operate when the ignition
switch is in the ON position.
The automatic sunroof is operational for about
45 seconds, even if the ignition switch is turned
to the ACC or OFF position. If the driver’s door
or the front passenger’s door is opened during
this period of about 45 seconds, power to the
sunroof is canceled.Sliding the sunroofTo open the roof, slide the switch to the
side
1. When the roof is tilted up, it will
automatically tilt down and then open.To close the roof, slide the switch to the
side
2.
Sliding position of lid can be chosen according
to sliding amount of switch.
To fully open or close the roof, completely move
the switch to the
1
or
2
side.
Tilting the sunroofTo tilt up, push the
side
3
of the tilt
switch. When the roof is open, it will automati-
cally close and then tilt up. To tilt down the
sunroof, push the
side
4. When the roof
is open, it will automatically close.
Restarting the sunroof sliding switchThe sliding switch will become inoperable after
the battery terminal is disconnected, the electri-
cal supply interrupted and/or some abnormality
detected. Use the following re-set procedure to
return sunroof operation to normal.
1. Keep pushing the tilting switch toward tilt UP.
2. After the lid has tilted up gradually, it will
automatically close all the way, then return to
normal operation.Auto reverse function (When closing
the sunroof)If the control unit detects something caught in
SIC2062
SUNROOF (if so equipped)
Instruments and controls
2-37
04.8.3/Z50-D/V5.0
Page 105 of 321
the sunroof as it moves to the front or tilts down,
the sunroof will immediately open backward or
tilt up.
The auto reverse function can be activated when
the sunroof is closed by automatic operation
when the ignition switch is in the ON position or
for about 45 seconds after the ignition switch is
turned to the OFF position.
Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the sunroof
occurs.
If the auto reverse function malfunctions and
repeats opening or tilting up the sunroof, keep
pushing toward the close position or keep push-
ing the tilt down switch within 5 seconds after it
happens, then the sunroof will fully close gradu-
ally. In this case, make sure nothing is caught in
the sunroof.
WARNING
There are some small distances imme-
diately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., in-side the vehicle before closing the
sunroof.
Sun shadeOpen or close the sun shade by sliding it
backward or forward.
The shade will open automatically when the
sunroof is opened. However, it must be closed
manually.Comfortable position (
A)
Depending on the driving speed and air recircu-
lating conditions, wind noise may occur when
the sunroof is fully opened. Closing the sunroof
one step toward the front position
A
from full
open will decrease the wind noise.
WARNING
In an accident you could be thrown
from the vehicle through an open
sunroof. Always use seat belts and
child restraints.
Do not allow anyone to stand up or
extend any portion of their body outof the sunroof opening while the ve-
hicle is in motion or while the sun-
roof is closing.
CAUTION
Remove water drops, snow, ice or
sand from the sunroof before open-
ing.
Do not place any heavy object on the
sunroof or surrounding area.If the sunroof does not closeHave a NISSAN dealer check and repair the
sunroof.
2-38
Instruments and controls
04.8.3/Z50-D/V5.0
Page 106 of 321
CEILING LIGHTThe ceiling light has a three-position switch.
When the switch is in the ON position
1, the
light will illuminate.
When the switch is in the OFF position
2, the
light will turn off.
When the switch is in the DOOR position3,
the light will illuminate when a door is opened.
The light will stay on for about 30 seconds when:
The doors are unlocked by the remote key-
less entry system, a key, power door lock
switch or using the Intelligent Key systemwhile all doors are closed.
The driver’s door is opened and then closed
while the key is removed from the ignition
switch or the ignition switch is turned to the
LOCK position (Intelligent Key system).
The key is removed from the ignition switch or
the ignition switch is turned to the LOCK
position (Intelligent Key system) while all
doors are closed.
The ceiling light will turn off while the 30 second
timer is activated, when:
The driver’s door is locked by the remote
keyless entry system, a key or the power door
lock switch.
The ignition switch is turned ON.
When the ceiling light switch or map light
switch or rear personal light switch is in the
ONposition, the ceiling, map, rear and
vanity mirror lights will automatically turn
off 30 minutes after the ignition switch has
been turned to the ACC or OFF position. To
turn on the light again, turn the ignition
switch to the ONposition.
After the above procedure, the ceiling, map, rear
personal and vanity mirror lights will automati-
cally turn off 30 minutes after the latest operationof the following with the ignition switch in the
ACC or OFF position:
Opening or closing any door
Locking or unlocking with the remote keyless
entry system, a key, the lock-unlock switch or
the ignition switch is turned to the LOCK
position (Intelligent Key system).
Inserting or removing a key from the ignition
switch
These lights will turn on again when any of the
above operations is performed after the lights
have turned off automatically. (The lights will turn
off 30 minutes after the latest operation of the
above as well.)
CAUTION
Turn off the ceiling, map, rear and
vanity mirror lights when you leave
the vehicle.
Do not use for extended periods of
time with the engine stopped. This
could result in a discharged battery.
SIC2063
INTERIOR LIGHTS
Instruments and controls
2-39
04.8.3/Z50-D/V5.0
Page 107 of 321
MAP LIGHTTo turn on the light, push the plastic surface
A
of the light. Push it again to turn off the light.
REAR PERSONAL LIGHTThe rear personal light has a three-position
switch. (
A: DOOR,
B: OFF,
C: ON)
When the switch is in the DOOR position
A,
the light will illuminate when a door is opened.
When the ceiling light or the map light
switch or rear personal light switch is in the
ONposition
C, the ceiling, map, rear per-
sonal and vanity mirror lights will auto-
matically turn off 30 minutes after the ig-
nition switch has been turned to the OFF
position
B. To turn on the light again, turn
the ignition switch to the ONposition.
CAUTION
Turn off the ceiling, map, rear and
vanity mirror lights when you leave
the vehicle.
Do not use for extended periods of
time with the engine stopped. This
could result in a discharged battery.
SIC2068
Front
SIC2069
Rear
2-40
Instruments and controls
04.8.3/Z50-D/V5.0
Page 108 of 321
LUGGAGE LIGHTWhen the switch is in the ON position
A, the
light illuminates while the back door is opened.
When the back door is closed, the light will go
off.
When the switch is in the OFF position
B, the
light will turn off.The light on the vanity mirror will turn on when
the cover on the vanity mirror is opened.
When the ceiling light or the map light
switch or rear personal light switch is in the
ONposition, the ceiling, map, rear per-
sonal and vanity mirror lights will auto-
matically turn off 30 minutes after the ig-
nition switch has been turned to the OFF
position. To turn on the light again, turn the
ignition switch to the ONposition.The HomeLink
Universal Transceiver provides a
convenient way to consolidate the functions of
up to three individual hand-held transmitters into
one built-in device.
HomeLink
Universal Transceiver:
Will operate most Radio Frequency (RF)
devices such as garage doors, gates, home
and office lighting, entry door locks and se-
curity systems.
Is powered by your vehicle’s battery. No
separate batteries are required. If the vehi-
cle’s battery is discharged or is discon-
nected, HomeLink
will retain all program-
ming.
Once the HomeLinkUniversal Transceiver
is programmed, retain the original trans-
mitter for future programming procedures
(Example: new vehicle purchases). Upon
sale of the vehicle, the programmed
HomeLink
Universal Transceiver buttons
should be erased for security purposes.
For additional information, refer to “Pro-
gramming HomeLink
” later in this sec-
tion.
SIC2131
SIC2064
VANITY MIRROR LIGHT (if so
equipped)HomeLink
UNIVERSAL
TRANSCEIVER (if so equipped)Instruments and controls
2-41
04.8.3/Z50-D/V5.0
Page 109 of 321
WARNING
Do not use the HomeLink
Universal
Transceiver with any garage door
opener that lacks safety stop and
reverse features as required by fed-
eral safety standards. (These stan-
dards became effective for opener
models manufactured after April 1,
1982). A garage door opener which
cannot detect an object in the path of
a closing garage door and then auto-
matically stop and reverse, does not
meet current federal safety stan-
dards. Using a garage door opener
without these features increases the
risk of serious injury or death.
During programming procedure, your
garage door or security gate may
open or close. Make sure that people
and objects are clear of the garage
door, gate, etc. that you are program-
ming.
Your vehicle’s engine should be
turned off while programming theHomeLink
Universal Transceiver.
PROGRAMMING HomeLinkTo program your HomeLink
Transceiver to op-
erate a garage door, gate, or entry door opener,
home or office lighting, you need to be at the
same location as the device. Note: Garage door
openers (manufactured after 1996) have “rolling
code protection”. To program a garage door
opener equipped with “rolling code protection”;
you will need to use a ladder to get up to the
garage door opener motor to be able to access
the “smart or learn” program button.
2-42
Instruments and controls
04.8.3/Z50-D/V5.0
Page 110 of 321
1. To begin, push and hold the 2 outer
HomeLink
buttons (to clear the memory)
until the indicator light
A
blinks (after 20
seconds). Release both buttons.
2. Position the end of the hand-held transmitter
1-3 inches away from the HomeLink
sur-
face.3. Using both hands, simultaneously push and
hold both the HomeLink
button you want to
program and the hand-held transmitter but-
ton.
DO NOT release the buttons until step 4 has
been completed.
4. Hold down both buttons until the indicator
light on the HomeLinkflashes, changing
from a “slow blink” to a “rapid blink”. This
could take up to 90 seconds. When the
indicator light blinks rapidly, both buttons
may be released. The rapidly flashing light
indicates successful programming. To acti-
vate the garage door or other programmed
device, push and hold the programmedHomeLink
button - releasing when the de-
vice begins to activate.
5. If the indicator light on the HomeLink
blinks
rapidly for two seconds and then turns solid,
HomeLink
has picked up a “rolling code”
garage door opener signal. You will need to
proceed with the next steps to train the
HomeLinkto complete the programming
which may require a ladder and another
person for convenience.
6. Push and release the training button located
on the garage door opener’s motor to acti-
vate the “training mode”. This button is usu-
ally located near the antenna wire that hangs
down from the motor. If the wire originates
from under a light lens, you will need to
remove the lens to access the training button.
NOTE:
Once you have pushed and released the
training button on the garage door open-
er’s motor and the “training light” is lit, you
have 30 seconds in which to perform step
7. Use the help of a second person for
convenience to assist when performing
this step.
7. Quickly within 30 seconds of pushing and
releasing the garage door opener training
button, firmly push and release the
SIC2071C
SIC2072
Instruments and controls
2-43
04.8.3/Z50-D/V5.0
