AT-36
TROUBLE DIAGNOSIS
How to Perform Trouble Diagnosis for Quick and Accurate Repair
ECS00FWX
INTRODUCTION
The TCM receives a signal from the vehicle speed sensor, accelera-
tor pedal position sensor or PNP switch and provides shift control or
lock-up control via A/T solenoid valves.
Input and output signals must always be correct and stable in the
operation of the A/T system. The A/T system must be in good oper-
ating condition and be free of valve seizure, solenoid valve malfunc-
tion, etc.
It is much more difficult to diagnose a error that occurs intermittently
rather than continuously. Most intermittent errors are caused by poor
electric connections or improper wiring. In this case, careful check-
ing of suspected circuits may help prevent the replacement of good
parts.
A visual check only may not find the cause of the errors. A road test
with CONSULT-II or a circuit tester connected should be performed.
Follow theAT-37, "
WORK FLOW".
Before undertaking actual checks, take a few minutes to talk with a
customer who approaches with a driveability complaint. The cus-
tomer can supply good information about such errors, especially
intermittent ones. Find out what symptoms are present and under
what conditions they occur. A “DIAGNOSTIC WORKSFEET” as
shown on the example (Refer toAT-38
) should be used.
Start your diagnosis by looking for “conventional” errors first. This will
help troubleshoot driveability errors on an electronically controlled
engine vehicle.
Also check related Service bulletins.
SAT631IB
SAT632I
SEF234G
Page 47 of 3171

TROUBLE DIAGNOSIS
AT-39
D
E
F
G
H
I
J
K
L
MA
B
AT
4oPerform all road tests and enter checks in required inspection items.AT- 4 6
4-1.Check Before Engine Is StartedAT- 4 6
oAT- 1 7 7 , "OD OFF Indicator Lamp Does Not Come On"
oPerform self-diagnosis. Enter checks for detected items.AT- 8 0,AT- 8 9
oAT-91, "DTC U1000 CAN COMMUNICATION LINE"
oAT-94, "DTC P0615 START SIGNAL CIRCUIT"
oAT-98, "DTC P0700 TCM"
oAT-99, "DTC P0705 PARK/NEUTRAL POSITION SWITCH"
oAT-103, "DTC P0720 VEHICLE SPEED SENSOR A/T (REVOLUTION SENSOR)"
oAT-108, "DTC P0725 ENGINE SPEED SIGNAL"
oAT-110, "DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE"
oAT-112, "DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)"
oAT-114, "DTC P0745 LINE PRESSURE SOLENOID VALVE"
oAT-116, "DTC P1705 THROTTLE POSITION SENSOR"
oAT-118, "DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT"
oAT-123, "DTC P1716 TURBINE REVOLUTION SENSOR"
oAT-125, "DTC P1721 VEHICLE SPEED SENSOR MTR"
oAT-127, "DTC P1730 A/T INTERLOCK"
oAT-130, "DTC P1731 A/T 1ST ENGINE BRAKING"
oAT-132, "DTC P1752 INPUT CLUTCH SOLENOID VALVE"
oAT-134, "DTC P1754 INPUT CLUTCH SOLENOID VALVE FUNCTION"
oAT-137, "DTC P1757 FRONT BRAKE SOLENOID VALVE"
oAT-139, "DTC P1759 FRONT BRAKE SOLENOID VALVE FUNCTION"
oAT-142, "DTC P1762 DIRECT CLUTCH SOLENOID VALVE"
oAT-144, "DTC P1764 DIRECT CLUTCH SOLENOID VALVE FUNCTION"
oAT-147, "DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE"
oAT-149, "DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE
FUNCTION"
oAT-152, "DTC P1772 LOW COAST BRAKE SOLENOID VALVE"
oAT-154, "DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION"
oAT-156, "DTC P1841 ATF PRESSURE SWITCH 1"
oAT-158, "DTC P1843 ATF PRESSURE SWITCH 3"
oAT-160, "DTC P1845 ATF PRESSURE SWITCH 5"
oAT-162, "DTC P1846 ATF PRESSURE SWITCH 6"
4-2.Check at IdleAT- 4 7
oAT- 1 7 7 , "Engine Cannot Be Started in“P”or“N”Position"
oAT- 1 7 8 , "In“P”Position, Vehicle Moves When Pushed"
oAT- 1 7 9 , "In“N”Position, Vehicle Moves"
oAT- 1 8 0 , "Large Shock (“N”to“D”Position)"
oAT- 1 8 2 , "Vehicle Does Not Creep Backward in“R”Position"
oAT- 1 8 4 , "Vehicle Does Not Creep Forward in“D”Position"
4-3.Cruise TestAT- 4 8
Part 1
oAT- 1 8 6 , "
Vehicle Cannot Be Started from D1"
oAT- 1 8 8 , "A/T Does Not Shift: D1®D2"
oAT- 1 9 0 , "A/T Does Not Shift: D2®D3"
oAT- 1 9 2 , "A/T Does Not Shift: D3®D4"
oAT- 1 9 4 , "A/T Does Not Shift: D4®D5"
oAT- 1 9 6 , "A/T Does Not Perform Lock-up"
oAT- 1 9 7 , "A/T Does Not Hold Lock-up Condition"
oAT- 1 9 9 , "Lock-up Is Not Released"
oAT- 1 9 9 , "Engine Speed Does Not Return to Idle"
Page 48 of 3171

AT-40
TROUBLE DIAGNOSIS
44-3Part 2AT- 5 0
oAT-186, "Vehicle Cannot Be Started from D1"
oAT-188, "A/T Does Not Shift: D1®D2"
oAT-190, "A/T Does Not Shift: D2®D3"
oAT-192, "A/T Does Not Shift: D3®D4"
Part 3AT- 5 1
oAT-200, "A/T Does Not Shift: 5th Gear®4th Gear"
oAT-202, "A/T Does Not Shift: 4th Gear®3rd Gear"
oAT-203, "A/T Does Not Shift: 3rd Gear®2nd Gear"
oAT-204, "A/T Does Not Shift: 2nd Gear®1st Gear"
oAT-206, "Vehicle Does Not Decelerate by Engine Brake"
oPerform self-diagnosis. Enter checks for detected items.AT- 8 0,AT- 8 9
oAT- 9 1 , "DTC U1000 CAN COMMUNICATION LINE"
oAT- 9 4 , "DTC P0615 START SIGNAL CIRCUIT"
oAT- 9 8 , "DTC P0700 TCM"
oAT- 9 9 , "DTC P0705 PARK/NEUTRAL POSITION SWITCH"
oAT-103, "DTC P0720 VEHICLE SPEED SENSOR A/T (REVOLUTION SENSOR)"
oAT-108, "DTC P0725 ENGINE SPEED SIGNAL"
oAT- 11 0 , "DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE"
oAT- 11 2 , "DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)"
oAT- 11 4 , "DTC P0745 LINE PRESSURE SOLENOID VALVE"
oAT- 11 6 , "DTC P1705 THROTTLE POSITION SENSOR"
oAT- 11 8 , "DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT"
oAT-123, "DTC P1716 TURBINE REVOLUTION SENSOR"
oAT-125, "DTC P1721 VEHICLE SPEED SENSOR MTR"
oAT-127, "DTC P1730 A/T INTERLOCK"
oAT-130, "DTC P1731 A/T 1ST ENGINE BRAKING"
oAT-132, "DTC P1752 INPUT CLUTCH SOLENOID VALVE"
oAT-134, "DTC P1754 INPUT CLUTCH SOLENOID VALVE FUNCTION"
oAT-137, "DTC P1757 FRONT BRAKE SOLENOID VALVE"
oAT-139, "DTC P1759 FRONT BRAKE SOLENOID VALVE FUNCTION"
oAT-142, "DTC P1762 DIRECT CLUTCH SOLENOID VALVE"
oAT-144, "DTC P1764 DIRECT CLUTCH SOLENOID VALVE FUNCTION"
oAT-147, "DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE"
oAT-149, "DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE
FUNCTION"
oAT-152, "DTC P1772 LOW COAST BRAKE SOLENOID VALVE"
oAT-154, "DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION"
oAT-156, "DTC P1841 ATF PRESSURE SWITCH 1"
oAT-158, "DTC P1843 ATF PRESSURE SWITCH 3"
oAT-160, "DTC P1845 ATF PRESSURE SWITCH 5"
oAT-162, "DTC P1846 ATF PRESSURE SWITCH 6"
5oInspect each system for items found to be NG in the self-diagnosis and repair or replace the malfunctioning parts.
6oPerform all road tests and enter the checks again for the required items.AT- 4 6
7oFor any remaining NG items, perform the “Diagnosis Procedure” and repair or replace the malfunctioning
parts. See the chart for diagnosis by symptoms. (This chart also contains other symptoms and inspection pro-
cedures.)AT- 5 3
8oErase the results of the self-diagnostics from TCM.AT- 8 2AT- 9 0
Page 53 of 3171

TROUBLE DIAGNOSIS
AT-45
D
E
F
G
H
I
J
K
L
MA
B
AT
4. Securely engage the parking brake so that the tires do not turn.
5. Start the engine, then measure the line pressure at both idle and
the stall speed.
CAUTION:
lKeep the brake pedal pressed all the way down during
measurement.
lWhen measuring the line pressure at the stall speed.
Refer toAT-43, "
STALL TEST".
6. After the measurements are complete, install the oil pressure
detection plug and tighten to the specified torque. Refer toAT-
251, "Components".
CAUTION:
lDo not reuse O-ring.
lApply ATF to O-ring.
Line Pressure
Judgement of Line Pressure Test
SAT513G
SAT493G
Engine speedLine pressure [kPa (bar, kg/cm
2,psi)]
“R” position “D” position
At idle speed 425 - 465 (4.3 - 4.6, 4.3 - 4.7, 62 - 67) 379 - 428 (3.8 - 4.3, 3.9 - 4.4, 55 - 62)
At stall speed 1,605 - 1,950 (16.0 - 19.5, 16.4 - 19.9, 233 - 283) 1,310 - 1,500 (13.1 - 15.0, 13.4 - 15.3, 190 - 218)
Judgement Possible cause
Idle speedLow for all positions
(“P”, “R”, “N” and “D”)Possible causes include malfunctions in the pressure supply system and low oil pump output.
For example
lOil pump wear
lPressure regulator valve or plug sticking or spring fatigue
lOil straineroil pumppressure regulator valve passage oil leak
lEngine idle speed too low
Only low for a specific
positionPossible causes include an oil pressure leak in a passage or device related to the position
after the pressure is distributed by the manual valve.
HighPossible causes include a sensor malfunction or malfunction in the line pressure adjustment
function.
For example
lAccelerator pedal position signal malfunction
lA/T fluid temperature sensor malfunction
lLine pressure solenoid malfunction (sticking in OFF state, filter clog, cut line)
lPressure regulator valve or plug sticking
Page 54 of 3171

AT-46
TROUBLE DIAGNOSIS
ROAD TEST
Description
lThe road test inspects overall performance of A/T and analyzes possible malfunction causes.
lThe road test is perform in the following three stages.
1. Check before engine is started. Refer toAT-46
.
2. Check at idle. Refer toAT-47
.
3. Cruise test.
lInspect all the items from Part 1 to Part 3. Refer toAT-48,AT-50,AT-51.
lBefore beginning the road test, check the test procedure and inspection items.
lTest all inspection items until the symptom is uncovered. Diagnose NG items when all road tests are com-
plete.
CheckBeforeEngineIsStartedECS00FX1
1.CHECK OD OFF INDICATOR LAMP
1. Park vehicle on level surface.
2. Move selector lever to “P” position.
3. Turn ignition switch OFF and wait at least 10 seconds.
4. Turn ignition switch ON. (Do not start engine.)
Does OD OFF indicator lamp light up for about 2 seconds?
YES >> 1. Turn ignition switch OFF.
2. Perform self-diagnosis and record all NG items onAT-38, "
DIAGNOSTIC WORKSHEET".
Refer toAT-80, "
SELF-DIAGNOSTIC RESULT MODE",AT-89, "TCM SELF-DIAGNOSTIC
PROCEDURE (WITHOUT CONSULT-II)".
3. Go toAT-47, "
Check at Idle".
NO >> Stop the road test and go toAT- 1 7 7 , "
OD OFF Indicator Lamp Does Not Come On".
Stall speedOil pressure does not
rise higher than the oil
pressure for idle.Possible causes include a sensor malfunction or malfunction in the pressure adjustment
function.
For example
lAccelerator pedal position signal malfunction
lTCM malfunction
lLine pressure solenoid malfunction (shorting, sticking in ON state)
lPressure regulator valve or plug sticking
lPilot valve sticking or pilot filter clogged
The pressure rises, but
does not enter the stan-
dard position.Possible causes include malfunctions in the pressure supply system and malfunction in the
pressure adjustment function.
For example
lAccelerator pedal position signal malfunction
lLine pressure solenoid malfunction (sticking, filter clog)
lPressure regulator valve or plug sticking
lPilot valve sticking or pilot filter clogged
Only low for a specific
positionPossible causes include an oil pressure leak in a passage or device related to the position
after the pressure is distributed by the manual valve. Judgement Possible cause
Page 61 of 3171

TROUBLE DIAGNOSIS
AT-53
D
E
F
G
H
I
J
K
L
MA
B
AT
Symptom ChartECS00FX8
lThe diagnostic item numbers show the sequence for inspection. Inspect in order from item 1.
lOverhaul and inspect inside the A/T only if A/T fluid condition is NG. Refer toAT-43, "A/T Fluid Con-
dition Check".
No. Items Symptom Condition Diagnostic ItemReference
page
1
Shift
ShockLarge shock. (“N”®“D”
position)
Refer toAT-180,
"Large Shock (“N”to
“D”Position)".ON vehicle1. Engine idle speedEC-38
2. Engine speed signalAT-108
3. Accelerator pedal position sensorAT- 11 6
4. Control cable adjustmentAT- 2 11
5. A/T fluid temperature sensorAT- 11 8
6. ATF pressure switch 1 and front brake solenoid valveAT-156,
AT-137
7. CAN communication lineAT- 9 1
8. A/T fluid level and stateAT- 4 3
9. Line pressure testAT- 4 4
10. Control valve with TCMAT-218
OFF vehicle11. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer toAT- 1 4 , "Cross-
Sectional View (2WD Models)",AT- 1 5 , "Cross-Sectional View
(4WD Models)".)AT-263
2Shock is too large
when changing D1
®D2.ON vehicle1. Accelerator pedal position sensorAT- 11 6
2. Control cable adjustmentAT- 2 11
3. ATF pressure switch 5 and direct clutch solenoid valveAT-160,
AT-142
4. CAN communication lineAT- 9 1
5. Engine speed signalAT-108
6. Turbine revolution sensorAT-123
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-103,
AT-125
8. A/T fluid level and stateAT- 4 3
9. Control valve with TCMAT-218
OFF vehicle 10. Direct clutchAT-298
3Shock is too large
when changing D2
®D3.ON vehicle1. Accelerator pedal position sensorAT- 11 6
2. Control cable adjustmentAT- 2 11
3. ATF pressure switch 6 and high and low reverse clutch
solenoid valveAT-162,
AT-147
4. CAN communication lineAT- 9 1
5. Engine speed signalAT-108
6. Turbine revolution sensorAT-123
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-103,
AT-125
8. A/T fluid level and stateAT- 4 3
9. Control valve with TCMAT-218
OFF vehicle 10. High and low reverse clutchAT-296
Page 62 of 3171

AT-54
TROUBLE DIAGNOSIS
4
Shift
ShockShockistoolarge
when changing D3
®D4.ON vehicle1. Accelerator pedal position sensorAT- 11 6
2. Control cable adjustmentAT- 2 11
3. ATF pressure switch 3 and input clutch solenoid valveAT- 1 5 8,
AT- 1 3 2
4. CAN communication lineAT- 9 1
5. Engine speed signalAT- 1 0 8
6. Turbine revolution sensorAT- 1 2 3
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 3,
AT- 1 2 5
8. A/T fluid level and stateAT- 4 3
9. Control valve with TCMAT- 2 1 8
OFF vehicle 10. Input clutchAT- 2 8 6
5Shockistoolarge
when changing D4
®D5.ON vehicle1. Accelerator pedal position sensorAT- 11 6
2. Control cable adjustmentAT- 2 11
3. ATF pressure switch 1 and front brake solenoid valveAT- 1 5 6,
AT- 1 3 7
4. CAN communication lineAT- 9 1
5. Engine speed signalAT- 1 0 8
6. Turbine revolution sensorAT- 1 2 3
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 3,
AT- 1 2 5
8. A/T fluid level and stateAT- 4 3
9. Control valve with TCMAT- 2 1 8
OFF vehicle10. Front brake (brake band)AT- 2 5 111. Input clutchAT- 2 8 6
6Shockistoolargefor
downshift when accel-
erator pedal is
pressed.ON vehicle1. Accelerator pedal position sensorAT- 11 6
2. Control cable adjustmentAT- 2 11
3. CAN communication lineAT- 9 1
4. Engine speed signalAT- 1 0 8
5. Turbine revolution sensorAT- 1 2 3
6. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 3,
AT- 1 2 5
7. A/T fluid level and stateAT- 4 3
8. Control valve with TCMAT- 2 1 8
OFF vehicle9. Front brake (brake band)AT- 2 5 110. Input clutchAT- 2 8 6
11. High and low reverse clutchAT- 2 9 6
12. Direct clutchAT- 2 9 8
No. Items Symptom Condition Diagnostic ItemReference
page
Page 63 of 3171

TROUBLE DIAGNOSIS
AT-55
D
E
F
G
H
I
J
K
L
MA
B
AT
7
Shift
ShockShock is too large for
upshift when accelera-
tor pedal is released.ON vehicle1. Accelerator pedal position sensorAT- 11 6
2. Control cable adjustmentAT- 2 11
3. Engine speed signalAT-108
4. CAN communication lineAT- 9 1
5. Turbine revolution sensorAT-123
6. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-103,
AT-125
7. A/T fluid level and stateAT- 4 3
8. Control valve with TCMAT-218
OFF vehicle9. Front brake (brake band)AT-25110. Input clutchAT-286
11. High and low reverse clutchAT-296
12. Direct clutchAT-298
8Shock is too large for
lock-up.ON vehicle1. Accelerator pedal position sensorAT- 11 6
2. Control cable adjustmentAT- 2 11
3. Engine speed signalAT-108
4. CAN communication lineAT- 9 1
5. Turbine revolution sensorAT-123
6. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-103,
AT-125
7. Torque converter clutch solenoid valveAT- 11 0
8. A/T fluid level and stateAT- 4 3
9. Control valve with TCMAT-218
OFF vehicle 10. Torque converterAT-263
9Shock is too large dur-
ing engine brake.ON vehicle1. Accelerator pedal position sensorAT- 11 6
2. Control cable adjustmentAT- 2 11
3. CAN communication lineAT- 9 1
4. A/T fluid level and stateAT- 4 3
5. Control valve with TCMAT-218
OFF vehicle6. Front brake (brake band)AT-2517. Input clutchAT-286
8. High and low reverse clutchAT-296
9. Direct clutchAT-298
No. Items Symptom Condition Diagnostic ItemReference
page
Page 64 of 3171

AT-56
TROUBLE DIAGNOSIS
10
No Up
ShiftGear does not change
from D
1®D2or from.
Refer toAT-188, "
A/T
Does Not Shift: D1®
D2".ON vehicle1. A/T fluid level and stateAT- 4 3
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 3,
AT- 1 2 5
3. ATF pressure switch 5 and direct clutch solenoid valveAT- 1 6 0,
AT- 1 4 2
4. Line pressure testAT- 4 4
5. CAN communication lineAT- 9 1
6. Control valve with TCMAT- 2 1 8
OFF vehicle 7. Direct clutchAT- 2 9 8
11Gear does not change
from D2®D3or from.
Refer toAT-190, "
A/T
Does Not Shift: D2®
D3".ON vehicle1. A/T fluid level and stateAT- 4 3
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 3,
AT- 1 2 5
3. ATF pressure switch 6 and high and low reverse clutch
solenoid valveAT- 1 6 2,
AT- 1 4 7
4. Line pressure testAT- 4 4
5. CAN communication lineAT- 9 1
6. Control valve with TCMAT- 2 1 8
OFF vehicle 7. High and low reverse clutchAT- 2 9 6
12Gear does not change
from D
3®D4or from.
Refer toAT-192, "
A/T
Does Not Shift: D3®
D4".ON vehicle1. A/T fluid level and stateAT- 4 3
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 3,
AT- 1 2 5
3. ATF pressure switch 3 and input clutch solenoid valveAT- 1 5 8,
AT- 1 3 2
4. ATF pressure switch 1 and front brake solenoid valveAT- 1 5 6,
AT- 1 3 7
5. Line pressure testAT- 4 4
6. CAN communication lineAT- 9 1
7. Control valve with TCMAT- 2 1 8
OFF vehicle 8. Input clutchAT- 2 8 6
13Gear does not change
from D
4®D5or from.
Refer toAT-194, "
A/T
Does Not Shift: D4®
D5".ON vehicle1. A/T fluid level and stateAT- 4 3
2. Overdrive control switchAT- 1 7 2
3. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 3,
AT- 1 2 5
4. ATF pressure switch 1 and front brake solenoid valveAT- 1 5 6,
AT- 1 3 7
5. ATF pressure switch 5 and direct clutch solenoid valveAT- 1 6 0,
AT- 1 4 2
6. Turbine revolution sensorAT- 1 2 3
7. Line pressure testAT- 4 4
8. CAN communication lineAT- 9 1
9. Control valve with TCMAT- 2 1 8
OFF vehicle10. Front brake (brake band)AT- 2 6 311. Input clutchAT- 2 8 6
No. Items Symptom Condition Diagnostic ItemReference
page
Page 65 of 3171

TROUBLE DIAGNOSIS
AT-57
D
E
F
G
H
I
J
K
L
MA
B
AT
14
No Down
ShiftIn “D” position, does
not downshift to 4th
gear.
Refer toAT-200, "A/T
Does Not Shift: 5th
Gear®4th Gear".ON vehicle1. A/T fluid level and stateAT- 4 3
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-103,
AT-125
3. ATF pressure switch 1 and front brake solenoid valveAT-156,
AT-137
4. ATF pressure switch 5 and direct clutch solenoid valveAT-160,
AT-142
5. CAN communication lineAT- 9 1
6. Line pressure testAT- 4 4
7. Control valve with TCMAT-218
OFF vehicle8. Front brake (brake band)AT-2639. Input clutchAT-286
15In “D” or “3” position,
does not downshift to
3rd gear.
Refer toAT-202, "A/T
Does Not Shift: 4th
Gear®3rd Gear".ON vehicle1. A/T fluid level and stateAT- 4 3
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-103,
AT-125
3. ATF pressure switch 3 and input clutch solenoid valveAT-158,
AT-132
4. ATF pressure switch 1 and front brake solenoid valveAT-156,
AT-137
5. CAN communication lineAT- 9 1
6. Line pressure testAT- 4 4
7. Control valve with TCMAT-218
OFF vehicle 8. Input clutchAT-286
16In “D” or “2” position,
does not downshift to
2nd gear.
Refer toAT-203, "A/T
Does Not Shift: 3rd
Gear®2nd Gear".ON vehicle1. A/T fluid level and stateAT- 4 3
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-103,
AT-125
3. ATF pressure switch 6 and high and low reverse clutch
solenoid valveAT-162,
AT-147
4. CAN communication lineAT- 9 1
5. Line pressure testAT- 4 4
6. Control valve with TCMAT-218
OFF vehicle 7. High and low reverse clutchAT-296
17In “D” or “1” position,
does not downshift to
1st gear.
Refer toAT-204, "A/T
Does Not Shift: 2nd
Gear®1st Gear".ON vehicle1. A/T fluid level and stateAT- 4 3
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-103,
AT-125
3. ATF pressure switch 5 and direct clutch solenoid valveAT-160,
AT-142
4. CAN communication lineAT- 9 1
5. Line pressure testAT- 4 4
6. Control valve with TCMAT-218
OFF vehicle 7. Direct clutchAT-298
No. Items Symptom Condition Diagnostic ItemReference
page
