NISSAN NOTE 2016 Service Repair Manual

C1115 WHEEL SENSORBRC-83
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
3. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
4. Start the engine.
5. Drive the vehicle at approx. 50 km/h ( 31 MPH) or more for approx. 2 minutes.
NOTE:
Vehicle must be driven after repair or replacement to erase the previous DTCs.
6. Stop the vehicle.
7. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
8. Start the engine. NOTE:
Wait at least 10 seconds after starting the engine.
9. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C 111 5” detected?
YES >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Instal-
lation".
NO >> Inspection End.
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-84
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1116 STOP LAMP SWITCH
C1116 STOP LAMP SWITCH
DTC DescriptionINFOID:0000000012430866
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the
ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Turn the ignition switch OFF, and wait 10 seconds or more.
2. Start the engine.
NOTE:
Stop the vehicle.
3. Wait 1 minute or more. NOTE:
Never depress brake pedal.
4. Depress brake pedal by 100 mm (3.94 in) or more, and ma intain at that position for a minimum of 1 minute
or more.
5. Release brake pedal, and wait 1 minute or more.
6. Repeat step 4 to 5 ten or more times.
7. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
8. Start the engine. NOTE:
Wait at least 10 seconds after starting the engine.
9. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1116” detected?
YES-1 >> “C1116” is displayed as “CRNT”: Proceed to BRC-85, "Diagnosis Procedure".
YES-2 >> “C1116” is displayed as “PAST”: Inspection End (Erase “Self Diagnos tic Result” of “ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
DTC Display Item
(Trouble diagnosis content) Malfunction detected condition
C 111 6 STOP LAMP SW
(Stop lamp switch) • When stop lamp switch signal is not input when brake pedal operates.
• When stop lamp switch signal is input when brake pedal is not operated.
PAST DTC
CRNT DTC
• Harness or connector
• Stop lamp switch signal circuit • Harness or connector
• Stop lamp switch
• ABS actuator and electric unit (control unit)
• ABS actuator and electric unit
(control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery
Revision: August 2015 2016 Versa Note

cardiagn.com

C1116 STOP LAMP SWITCHBRC-85
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Diagnosis ProcedureINFOID:0000000012430867
NOTE:
DTC “C1116” may be detected when the brake pedal and the accelerator pedal are simultaneously depressed
for 1 minute or more while driving the vehicle. This is not a malfunction.
1.INTERVIEW FROM THE CUSTOMER
Check if the brake pedal and the accelerator pedal ar e simultaneously depressed for 1 minute or more while
driving the vehicle.
Is there such a history?
YES >> GO TO 2.
NO >> GO TO 3.
2.PERFORM SELF-DIAGNOSIS
With CONSULT
1. Erase “Self Diagnostic Result” of “ABS”
2. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
3. Start the engine.
NOTE:
Stop the vehicle.
4. Depress the brake pedal several times.
5. Turn the ignition switch OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
6. Start the engine. NOTE:
Wait at least 10 seconds after starting the engine.
7. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C 111 6” detected?
YES >> GO TO 3.
NO >> Inspection End.
3.STOP LAMP FOR ILLUMINATION
Depress brake pedal and check that stop lamps turn ON.
Do the stop lamps turn ON?
YES >> GO TO 5.
NO >> Check the stop lamp system. Refer to EXL-63, "
Wiring Diagram". GO TO 4.
4.CHECK DATA MONITOR (1)
With CONSULT
1. Erase “Self Diagnostic Result” of “ABS”
2. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
3. Start the engine.
NOTE:
Stop the vehicle.
4. Select “DATA MONITOR” of “ABS”, check “STOP LA MP SW”. Check that data monitor displays “On” or
“Off” when brake pedal is depressed or released. Refer to BRC-36, "
Reference Value".
Is the inspection result normal?
YES >> Inspection End.
NO >> GO TO 5.
5.CHECK CONNECTOR AND TERMINAL
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check the ABS actuator and electric unit (contro l unit) harness connector for disconnection or looseness.
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-86
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1116 STOP LAMP SWITCH
4. Check the ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with
harness connector.
5. Disconnect stop lamp switch harness connector.
6. Check the stop lamp switch harness connector for disconnection or looseness.
7. Check the stop lamp switch pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair / replace harness, connector, or terminal, and GO TO 6.
6.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY AND GROUND CIR-
CUIT
Check the ABS actuator and electric unit (contro l unit) power supply and ground circuits. Refer to BRC-121,
"Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair / replace harness, connector, fuse, or fusible link.
7.CHECK DATA MONITOR (2)
With CONSULT
1. Erase “Self Diagnostic Result” of “ABS”
2. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
3. Start the engine. NOTE:
Stop the vehicle.
4. Select “DATA MONITOR” of “ABS”, check “STOP LA MP SW”. Check that data monitor displays “On” or
“Off” when brake pedal is depressed or released. Refer to BRC-36, "
Reference Value".
Is the inspection result normal?
YES >> Inspection End.
NO >> GO TO 8.
8.CHECK STOP LAMP SWITCH CIRCUIT (1)
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check the voltage between ABS actuator and elec tric unit (control unit) harness connector and ground.
4. Turn the ignition switch ON.
5. Check the voltage between ABS actuator and elec tric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Instal-
lation".
NO >> Repair / replace harness or connector, and GO TO 9.
9.CHECK STOP LAMP SWITCH CIRCUIT (2)
1. Turn the ignition switch OFF.
ABS actuator and electric unit (control unit) — Condition Vo l ta g e
(Approx.)
Connector Terminal
E33 12Ground Brake pedal depressed
10 − 16 V
Brake pedal not depressed 0 V
ABS actuator and electric unit (control unit)
— Condition Vol tag e
(Approx.)
Connector Terminal
E33 12Ground Brake pedal depressed
10 − 16 V
Brake pedal not depressed 0 V
Revision: August 2015 2016 Versa Note

cardiagn.com

C1116 STOP LAMP SWITCHBRC-87
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
2. Disconnect stop lamp switch harness connector.
3. Check the continuity between ABS actuator and electric unit (control unit) harness connector and stop lamp switch harness connector.
4. Check the continuity between ABS actuator and el ectric unit (control unit) harness connector and the
ground.
Is the inspection result normal?
YES >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Instal-
lation".
NO >> Repair / replace harness or connector, and GO TO 10.
10.CHECK DATA MONITOR (3)
With CONSULT
1. Connect ABS actuator and electric unit (control unit) harness connector.
2. Connect stop lamp switch harness connector.
3. Erase “Self Diagnostic Result” of “ABS”
4. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
5. Start the engine.
NOTE:
Stop the vehicle.
6. Select “DATA MONITOR” of “ABS”, check “STOP LA MP SW”. Check that data monitor displays “On” or
“Off” when brake pedal is depressed or released. Refer to BRC-36, "
Reference Value".
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-144, "
Removal and Instal-
lation".
Component InspectionINFOID:0000000012430868
1.CHECK STOP LAMP SWITCH
1. Turn the ignition switch OFF.
2. Disconnect stop lamp switch harness connector.
3. Check the continuity when stop lamp switch is operated.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace the stop lamp switch. Refer to BR-20, "
Removal and Installation".
ABS actuator and electric unit (control unit) Stop lamp switch
Continuity
Connector TerminalConnector Terminal
E33 12E13 (WITH CVT)
2Yes
E57 (WITH M/T)
ABS actuator and electric unit (control unit)
—Con tin uit y
Connector Terminal
E33 12Ground No
Stop lamp switch
Condition Continuity
Te r m i n a l
1 – 2 When stop lamp switch is released
(When brake pedal is depressed) Ye s
When stop lamp switch is pressed (When brake pedal is released) No
Revision: August 2015
2016 Versa Note

cardiagn.com

BRC-88
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1120, C1122, C1124, C112
6 ABS IN VALVE SYSTEM
C1120, C1122, C1124, C1126 ABS IN VALVE SYSTEM
DTC DescriptionINFOID:0000000012430869
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
2. Start the engine. NOTE:
Wait at least 10 seconds after starting the engine.
3. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1120”, “C1122”, “C1124” or “C1126” detected?
YES-1 >> “C1120”, “C1122”, “C1124” or “C1126” is displayed as “CRNT”: Proceed to BRC-88, "Diagnosis
Procedure".
YES-2 >> “C1120”, “C1122”, “C1124” or “C1126” is disp layed as “PAST”: Inspection End (Erase “Self Diag-
nostic Result” of “ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
Diagnosis ProcedureINFOID:0000000012430870
1.CHECK CONNECTOR
DTC Display Item
(Trouble diagnosis content) Malfunction detected condition
C1120 FR LH IN ABS SOL
(Front LH ABS IN solenoid valve) When a malfunction is detected in front LH ABS IN valve.
C1122 FR RH IN ABS SOL
(Front RH ABS IN solenoid valve) When a malfunction is detected in front RH ABS IN valve.
C1124 RR LH IN ABS SOL
(Rear LH ABS IN solenoid valve) When a malfunction is detected in rear LH ABS IN valve.
C1126 RR RH IN ABS SOL
(Rear RH ABS IN so
lenoid valve)When a malfunction is detected in rear RH ABS IN valve.
PAST DTC
CRNT DTC
• Harness or connector
• ABS actuator and electric unit (control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery • Harness or connector
• ABS actuator and electric unit (control unit)
• ABS actuator and electric unit
(control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery
Revision: August 2015 2016 Versa Note

cardiagn.com

C1120, C1122, C1124, C1126 ABS IN VALVE SYSTEM
BRC-89
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
1. Turn the ignition switch OFF.
2. Check the ABS actuator and electric unit (contro l unit) harness connector for disconnection or looseness.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair / replace harness or connector, securely lock the connector, and GO TO 2.
2.PERFORM SELF-DIAGNOSIS
With CONSULT
1. Turn the ignition switch OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
2. Start the engine.
NOTE:
Wait at least 10 seconds after starting the engine.
3. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1120”, “C1122”, “C1124” or “C1126” detected?
YES >> GO TO 3.
NO >> Inspection End.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY AND GROUND CIR-
CUIT
Check the ABS actuator and electr ic unit (control unit) power supply and ground circuits. Refer to BRC-121,
"Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair / replace harness, connector, fuse, or fusible link.
4.CHECK TERMINAL
Check the ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with har-
ness connector.
Is the inspection result normal?
YES >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Instal-
lation".
NO >> Repair / replace harness, connector, or terminal.
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-90
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1121, C1123, C
1125, C1127 ABS OUT VALVE SYSTEM
C1121, C1123, C1125, C1127 ABS OUT VALVE SYSTEM
DTC DescriptionINFOID:0000000012430871
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
2. Start the engine. NOTE:
Wait at least 10 seconds after starting the engine.
3. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1121”, “C1123”, “C1125” or “C1127” detected?
YES-1 >> “C1121”, “C1123”, “C1125” or “C1127” is displayed as “CRNT”: Proceed to BRC-90, "Diagnosis
Procedure".
YES-2 >> “C1121”, “C1123”, “C1125” or “C1127” is disp layed as “PAST”: Inspection End (Erase “Self Diag-
nostic Result” of “ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
Diagnosis ProcedureINFOID:0000000012430872
1.CHECK CONNECTOR
DTC Display Item
(Trouble diagnosis content) Malfunction detected condition
C1121 FR LH OUT ABS SOL
(Front LH ABS OUT solenoid valve) When a malfunction
is detected in front LH ABS OUT valve.
C1123 FR RH OUT ABS SOL
(Front RH ABS OUT solenoid valve) When a malfunction is detected in front RH ABS OUT valve.
C1125 RR LH OUT ABS SOL
(Rear LH ABS OUT solenoid valve) When a malfunction is detected in rear LH ABS OUT valve.
C1127 RR RH OUT ABS SOL
(Rear RH ABS OUT so
lenoid valve)When a malfunction
is detected in rear RH ABS OUT valve.
PAST DTC CRNT DTC
• Harness or connector
• ABS actuator and electric unit (control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery • Harness or connector
• ABS actuator and electric unit (control unit)
• ABS actuator and electric unit
(control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery
Revision: August 2015 2016 Versa Note

cardiagn.com

C1121, C1123, C1125, C1127 ABS OUT VALVE SYSTEM
BRC-91
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
1. Turn the ignition switch OFF.
2. Check the ABS actuator and electric unit (contro l unit) harness connector for disconnection or looseness.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair / replace harness or connector, securely lock the connector, and GO TO 2.
2.PERFORM SELF-DIAGNOSIS
1. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
2. Start the engine. NOTE:
Wait at least 10 seconds after starting the engine.
3. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1121”, “C1123”, “C1125” or “C1127” detected?
YES >> GO TO 3.
NO >> Inspection End.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY AND GROUND CIR-
CUIT
Check the ABS actuator and electr ic unit (control unit) power supply and ground circuits. Refer to BRC-121,
"Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair / replace harness, connector, fuse, or fusible link.
4.CHECK TERMINAL
Check the ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with har-
ness connector.
Is the inspection result normal?
YES >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Instal-
lation".
NO >> Repair / replace harness, connector, or terminal.
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-92
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1130 ENGINE SIGNAL
C1130 ENGINE SIGNAL
DTC DescriptionINFOID:0000000012430873
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the
ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Turn the ignition switch OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
2. Start the engine.
NOTE:
Wait at least 10 seconds after starting the engine.
3. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1130” detected?
YES-1 >> “C1130” is displayed as “CRNT”: Proceed to BRC-92, "Diagnosis Procedure".
YES-2 >> “C1130” is displayed as “PAST”: Inspection End (Erase “Self Diagnostic Result” of “ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
Diagnosis ProcedureINFOID:0000000012430874
1.CHECK ENGINE SYSTEM
With CONSULT
Perform “Self Diagnostic Result” of “ENGINE”.
Is DTC detected?
YES >> Check the DTC. Refer to EC-87, "DTCIndex".
NO >> GO TO 2.
DTC Display Item
(Trouble diagnosis content) Malfunction detected condition
C1130 ENGINE SIGNAL 1
(Engine system signal) When a malfunction is detected in ECM system.
PAST DTC
CRNT DTC
• Harness or connector
• ABS actuator and electric unit (control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery
• CAN communication line • Harness or connector
•ECM
• ABS actuator and electric unit (control unit)
• ABS actuator and electric unit
(control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery
• CAN communication line
Revision: August 2015 2016 Versa Note

cardiagn.com
