Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair / replace harness, connector, or terminal.
8.CHECK TERMINAL
1. Check the ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with harness connector.
2. Check the IPDM E/R pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Instal-
lation".
NO >> Repair / replace harness, connector, or terminal.
ABS actuator and electric unit (control unit)
—Contin u it y
Connector Terminal
E33 13
Ground Yes
38
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-124
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
PARKING BRAKE SWITCH
PARKING BRAKE SWITCH
Component Function CheckINFOID:0000000012430903
1.CHECK PARKING BRAKE SWITCH OPERATION
Check that brake warning lamp in combination me ter turns ON/OFF when parking brake is actuated.
Is the inspection result normal?
YES >> Inspection End.
NO >> Proceed to diagnosis procedure. Refer to BRC-124, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430904
Regarding Wiring Diagram information, refer to BRC-44, "Wiring Diagram".
1.CONNECTOR INSPECTION
1. Turn ignition switch OFF.
2. Disconnect combination meter and parking brake switch connectors.
3. Check connectors and terminals for deformation, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace as necessary.
2.CHECK PARKING BRAKE SWITCH
Check parking brake switch. Refer to BRC-125, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace parking brake switch. Refer to PB-9, "
Removal and Installation".
3.CHECK PARKING BRAKE SWITCH SIGNAL
With CONSULT.
1. Connect combination meter connector and parking brake switch connectors.
2. Turn ignition switch ON.
3. In “Data Monitor” select “PKB SW” and check parking brake switch signal.
Is the inspection result normal?
YES >> Refer to BRC-52, "Work Flow".
NO >> GO TO 4.
4.CHECK PARKING BRAKE SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter and parking brake switch connectors.
3. Check continuity between combination meter connector M82 (type A) or M 24 (type B) terminal 10 and
parking brake switch connector M17 terminal 1.
Condition DATA MONITOR
Actuate parking brake On
Release parking brake Off
Combination meterParking brake switchContinuity
Connector TerminalConnector Terminal
M82 (type A) 10M17 1 Yes
M24 (type B)
Revision: August 2015 2016 Versa Note

cardiagn.com

PARKING BRAKE SWITCHBRC-125
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
4. Check continuity between combination meter connector M82 (type A) or M24 (type B) terminal 10 and ground.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-54, "Removal and Installation" (TYPE A) or MWI-115,
"Removal and Installation" (TYPE B).
NO >> Repair or replace malfunctioning components.
Component InspectionINFOID:0000000012430905
1.CHECK PARKING BRAKE SWITCH
1. Turn ignition switch OFF.
2. Disconnect parking brake switch connector.
3. Check continuity between parking brake switch terminal 1 and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace parking brake switch. Refer to PB-9, "
Removal and Installation".
Combination meter
—Continuity
Connector Terminal
M82 (type A) 10Ground No
M24 (type B)
Parking brake switch terminal —Condition Continuity
1 GroundParking brake actuated
Yes
Parking brake released No
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-126
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
VDC OFF SWITCH
VDC OFF SWITCH
Component Function CheckINFOID:0000000012430906
1.CHECK VDC OFF SWITCH OPERATION
Check that VDC OFF indicator lamp in combination meter turns ON/OFF when VDC OFF switch is operated.
Is the inspection result normal?
YES >> Inspection End.
NO >> Proceed to diagnosis procedure. Refer to BRC-126, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430907
Regarding Wiring Diagram information, refer to BRC-44, "Wiring Diagram".
1.CONNECTOR INSPECTION
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (c ontrol unit) and VDC OFF switch connectors.
3. Check connectors and terminals for deformation, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace as necessary.
2.CHECK VDC OFF SWITCH
Check VDC OFF switch. Refer to BRC-127, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace VDC OFF switch. Refer to BRC-146, "
Removal and Installation".
3.CHECK VDC OFF SWITCH SIGNAL
With CONSULT.
1. Connect ABS actuator and electric unit (c ontrol unit) and VDC OFF switch connectors.
2. Turn ignition switch ON.
3. In “Data Monitor” select “OFF SW” and check VDC OFF switch signal.
Is the inspection result normal?
YES >> Refer to BRC-52, "Work Flow".
NO >> GO TO 4.
4.CHECK VDC OFF SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (c ontrol unit) and VDC OFF switch connectors.
3. Check continuity between ABS actuator and electr ic unit (control unit) connector E33 terminal 20 and
VDC OFF switch connector M34 terminal 1.
4. Check continuity between ABS actuator and electric unit (control unit) connector terminal E33 terminal 20 and ground.
Condition DATA MONITOR
VDC OFF switch is pressed and released On
VDC OFF switch is pressed and released again Off
ABS actuator and electric unit (control unit) VDC OFF switch
Continuity
Connector Terminal Connector Terminal
E33 20 M34 1 Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

VDC OFF SWITCHBRC-127
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning components.
5.CHECK VDC OFF SW ITCH GROUND CIRCUIT
Check continuity between VDC OFF swit ch connector M34 terminal 2 and ground.
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Installa-
tion".
NO >> Repair or replace malfunctioning components.
Component InspectionINFOID:0000000012430908
1.CHECK VDC OFF SWITCH
1. Turn ignition switch OFF.
2. Disconnect VDC OFF switch connector.
3. Check continuity between terminals of VDC OFF switch connector.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace VDC OFF switch. Refer to BRC-146, "
Removal and Installation".
ABS actuator and electric unit (control unit)
—Contin u it y
Connector Terminal
E33 20Ground No
VDC OFF switch
—Continuity
Connector Terminal
M34 2 Ground Yes
VDC OFF switch terminals ConditionContinuity
1 – 2 VDC OFF switch pressed
Yes
VDC OFF switch released No
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-128
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
ABS WARNING LAMP
ABS WARNING LAMP
Component Function CheckINFOID:0000000012430909
1.CHECK ABS WARNING LAMP FUNCTION
Check that ABS warning lamp in combination meter turns ON for approximately 2 seconds after ignition switch
is turned ON.
Is the inspection result normal?
YES >> Inspection End.
NO >> Proceed to diagnosis procedure. Refer to BRC-128, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430910
1.PERFORM THE SELF DIAGNOSTIC
With CONSULT.
Perform “Self Diagnostic Result”.
Are any DTCs detected?
YES >> Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2.CHECK COMBINATION METER
Check if indication and operation of combination meter are normal. Refer to MWI-10, "
METER SYSTEM : Sys-
tem Description" (TYPE A) or MWI-61, "METER SYSTEM : System Description" (TYPE B).
Is the inspection result normal?
YES >> Replace ABS actuator and electr ic unit (control unit). Refer to BRC-144, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation" (TYPE A) or MWI-115,
"Removal and Installation" (TYPE B).
Revision: August 2015 2016 Versa Note

cardiagn.com

BRAKE WARNING LAMPBRC-129
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
BRAKE WARNING LAMP
Component Function CheckINFOID:0000000012430911
1.CHECK BRAKE WARNING LAMP FUNCTION (1)
Check that brake warning lamp in combination mete r turns ON for approximately 2 seconds after ignition
switch is turned ON.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Proceed to diagnosis procedure. Refer to BRC-129, "
Diagnosis Procedure".
2.CHECK BRAKE WARNING LAMP FUNCTION (2)
Check that brake warning lamp in combination meter turns ON/OFF when parking brake is operated.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check parking brake switch system. Refer to BRC-124, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430912
1.PERFORM THE SELF DIAGNOSTIC
With CONSULT.
Perform “Self Diagnostic Result”.
Are any DTCs detected?
YES >> Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2.CHECK COMBINATION METER
Check if indication and operation of combination meter are normal. Refer to MWI-10, "
METER SYSTEM : Sys-
tem Description" (TYPE A) or MWI-61, "METER SYSTEM : System Description" (TYPE B).
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation" (TYPE A) or MWI-115,
"Removal and Installation" (TYPE B).
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-130
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
VDC OFF INDICATOR LAMP
VDC OFF INDICATOR LAMP
Component Function CheckINFOID:0000000012430913
1.CHECK VDC OFF INDICA
TOR LAMP FUNCTION
Check that VDC OFF indicator lamp in combination meter turns ON for approximately 2 seconds after ignition
switch is turned ON.
Is the inspection result normal?
YES >> Inspection End.
NO >> Proceed to diagnosis procedure. Refer to BRC-130, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430914
1.PERFORM THE SELF DIAGNOSTIC
With CONSULT.
Perform “Self Diagnostic Result”.
Are any DTCs detected?
YES >> Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2.CHECK COMBINATION METER
Check if indication and operation of combination meter are normal. Refer to MWI-10, "
METER SYSTEM : Sys-
tem Description" (TYPE A) or MWI-61, "METER SYSTEM : System Description" (TYPE B).
Is the inspection result normal?
YES >> Replace ABS actuator and electr ic unit (control unit). Refer to BRC-144, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation" (TYPE A) or MWI-115,
"Removal and Installation" (TYPE B).
Revision: August 2015 2016 Versa Note

cardiagn.com

SLIP INDICATOR LAMPBRC-131
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
SLIP INDICATOR LAMP
Component Function CheckINFOID:0000000012430915
1.CHECK SLIP INDICATOR LAMP FUNCTION
Check that slip indicator lamp in combination meter turns ON for approximately 2 seconds after ignition switch
is turned ON.
Is the inspection result normal?
YES >> Inspection End.
NO >> Proceed to diagnosis procedure. Refer to BRC-131, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430916
1.PERFORM THE SELF DIAGNOSTIC
With CONSULT.
Perform “Self Diagnostic Result”.
Are any DTCs detected?
YES >> Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2.CHECK COMBINATION METER
Check if indication and operation of combination meter are normal. Refer to MWI-10, "
METER SYSTEM : Sys-
tem Description" (TYPE A) or MWI-61, "METER SYSTEM : System Description" (TYPE B).
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation" (TYPE A) or MWI-115,
"Removal and Installation" (TYPE B).
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-132
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
VDC/TCS/ABS
SYMPTOM DIAGNOSIS
VDC/TCS/ABS
Symptom TableINFOID:0000000012430917
If ABS warning lamp and SLIP indicator
lamp turn ON, perform self diagnostic.
NOTE:
• 1: The ABS does not operate when the speed is 10 km/h (6 MPH) or less.
• 2: Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly depressed (just place a foot on it).
However, this is normal:
- When shifting gears
- When driving on slippery road
- During cornering at high speed
- When passing over bumps or grooves [approximately 50 mm (1.97 in) or more]
- When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher] Symptom
Check itemReference
Excessive ABS function operation fre-
quency Brake force distribution
BRC-133, "
Diag-
nosis Procedure"Looseness of front and rear axle
Wheel sensor and rotor system
Unexpected pedal reaction Brake pedal stroke
BRC-134, "
Diag-
nosis Procedure"Make sure the braking force is sufficient when the ABS is not operating.
The braking distance is long Check stopping distance when the ABS is not operating. BRC-135, "
Diag-
nosis Procedure"
ABS function does not operate (Note 1) ABS actuator and electric
unit (control unit)BRC-136, "Diag-
nosis Procedure"
Pedal vibration or ABS operation sound
occurs (Note 2)Brake pedal
BRC-137, "Diag-
nosis Procedure"ABS actuator and electric unit (control unit)
Vehicle jerks during VDC/TCS/ABS con-
trol ABS actuator and electric unit (control unit)
BRC-138, "
Diag-
nosis Procedure"TCM
ECM
Revision: August 2015 2016 Versa Note

cardiagn.com
