C1105, C1106, C1107, C1108 WHEEL SENSOR
DTC DescriptionINFOID:0000000012430856
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Start the engine.
2. Drive the vehicle at approx. 50 km/h ( 31 MPH) or more for approx. 2 minutes.
3. Stop the vehicle.
4. Turn the ignition switch OFF.
DTC Display Item
(Trouble diagnosis content) Malfunction detected condition
C1105 RR RH SENSOR-2
(Rear RH wheel sensor-2) • When power supply voltage of rear RH wheel sensor is low.
• When distance between rear RH wheel sensor and rear RH wheel sensor rotor is large.
• When installation of rear RH wheel sensor or rear RH wheel sensor rotor is not normal.
• When there is contamination on or damage to the rear RH wheel sensor or rear RH sen-
sor rotor.
C1106 RR LH SENSOR-2
(Rear LH wheel sensor-2) • When power supply voltage of rear LH wheel sensor is low.
• When distance between rear LH wheel sensor and rear LH wheel sensor rotor is large.
• When installation of rear LH wheel sensor or rear LH wheel sensor rotor is not normal.
• When there is contamination on or damage to the rear LH wheel sensor or rear LH sen-
sor rotor.
C1107 FR RH SENSOR-2
(Front RH wheel sensor-2) • When power supply voltage of front RH wheel sensor is low.
• When distance between front RH wheel sensor and front RH wheel sensor rotor is large.
• When installation of front RH wheel sensor or front RH wheel sensor rotor is not normal.
• When there is contamination on or damage to the front RH wheel sensor or front RH sen-
sor rotor.
C1108 FR LH SENSOR-2
(Front LH wheel sensor-2) • When power supply voltage of front LH wheel sensor is low.
• When distance between front LH wheel sensor and front LH wheel sensor rotor is large.
• When installation of front LH wheel sensor or front LH wheel sensor rotor is not normal.
• When there is contamination on or damage to the front LH wheel sensor or front LH sen-
sor rotor.
PAST DTC CRNT DTC
• Harness or connector
• Wheel sensor
• Sensor rotor
• Tire size
• ABS actuator and electric unit (control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery • Harness or connector
• Wheel sensor
• Sensor rotor
• ABS actuator and electric unit (control unit)
• Tire size
• ABS actuator and electric unit
(control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery
• Vehicle was not driven after previous repair
