NISSAN PRIMERA 1999 Electronic Repair Manual

YEL966C
HARNESS LAYOUT
Engine Room Harness (Cont'd)
EL-379

PASSENGER COMPARTMENT—LHD models
YEL967C
HARNESS LAYOUT
Engine Room Harness (Cont’d)
EL-380

PASSENGER COMPARTMENT—RHD models
YEL968C
HARNESS LAYOUT
Engine Room Harness (Cont’d)
EL-381

Main Harness
LHD MODELS
YEL969C
HARNESS LAYOUT
EL-382

YEL970C
HARNESS LAYOUT
Main Harness (Cont’d)
EL-383

RHD MODELS
YEL971C
HARNESS LAYOUT
Main Harness (Cont’d)
EL-384

YEL972C
HARNESS LAYOUT
Main Harness (Cont’d)
EL-385

Body Harness
SEDAN—LHD models before VIN - P11U0548750
Body ground Body groundBody ground
.Be sure to connect and lock the connectors securely after repair work.
Failure to do so may cause the ECM to have diagnostic trouble codes.
Do not disconnect these connectors except in the case of working
according to WORK FLOW of TROUBLE DIAGNOSES in EC and AT sections.
YEL253C
HARNESS LAYOUT
EL-386

YEL254C
Body harnessA3
B3
W/24 : To
M13
A2
B4
W/6 : To
M14
A1
B5
W/12 : To
D2
B2
B8
BR/16 : Fuse block (J/B)
A1
B11
W/8 : Time control unit
A1
B12
W/20 : Time control unit
D1
B15
W/6 : Ultra sonic sub-sensor
E1
B16
W/8 : To
D22
E2
B17
W/4 : Seat belt pre-tensioner (Passenger side)
E1
B18
—: Body ground
D2
B19
BR/1 : Front door switch (Passenger side)
B3
B20
B/3 : Front door switch (Driver’s side)
B4
B21
W/3 : Heated seat LH
C4
B22
W/2 : Power seat
C2
B24
B/1 : Parking brake switch
B4
B26
W/4 : Seat belt pre-tensioner (Driver’s side)
B2
B27
—: Body ground
B2
B28
W/8 : To
D18
B3
B29
W/8 : Ultra sonic sensor
D4
B30
GY/2 : Fuel pump
D4

B31
GY/3 : Fuel level sensor unit
E3
B32
GY/2 : Rear wheel sensor RH
D4
B33
BR/2 : Rear wheel sensor LH
E1
B34
BR/1 : Rear door switch RH
F2
B37
B/2 : Rear speaker RH
D3
B38
BR/1 : Rear door switch LH
E2
B40
B/2 : Rear speaker LH
D2
B47
W/16 : CD auto changer
F2
B50
B/1 : High mounted stop lamp
F3
B51
W/2 : Trunk room lamp
F3
B52
W/4 : Rear wiper motor
E3
B53
W/8 : To
T1
E3
B54
W/8 : To
T14
C1
B56
W/10 : To
D11
C1
B57
W/16 : To
E115
C2
B58
W/12 : To
B101
D1
B59
B/1 : Rear window defogger
D3
B61
W/3 : Heated seat RH
B3
B65
—: Body ground
C3
B66
Y/12 : Diagnosis sensor unit
C3
B67
Y/12 : Diagnosis sensor unit
B4
B68
Y/2 : Side air bag module LH
D3
B69
Y/2 : Side air bag module RH
B4
B70
OR/2 : Satellite sensor LHD2
B71
Y/2 : Satellite sensor RH
D2
B72
—: Body ground
B1
B97
B/2 : Fuse block (J/B)
A3
B98
L/4 : Theft warning horn relay
A3
B99
GY/2 : Circuit breaker-2
A1
B121
W/6 : Central unlock/trunk release switch
C3
B122
W/3 : To
B130
C2
B123
W/12 : Auto level control unit
C4
B124
W/3 : To
B132
C4
B130
W/3 : To
B122
B2
B131
/3 : Front sensor
D4
B132
W/3 : To
B124
F3
B133
/3 : Rear sensor
Console harnessC2
B101
W/12 : To
B58
C2
B102
W/6 : Ultrasonic cancel switch
B3
B104
L/4 : Heated seat switch LH
C2
B105
W/4 : Heated seat switch RH
C2
B106
W/4 : Headlamp aiming switch
Tail harnessE3
T1
W/8 : To
B53
F4
T2
W/4 : Rear combination lamp LH
F3
T3
—: Body ground
G3
T4
—: Body ground
G3
T5
W/4 : Rear combination lamp RH
G2
T6
B/1 : Theft warning horn
F4
T9
BR/2 : License plate lamp LH
D4
T17
BR/4 : Not used (To trailer tow connection)
E4
T18
BR/4 : Link
F3
T19
BR/2 : License plate lamp RH
Tail harness No. 2F3
T7
W/8 : To
T16
F4
T8
W/2 : Rear fog lamp
G3
T10
B/2 : Trunk room lamp switch
G2
T12
W/4 : Door unlock actuator assembly (Trunk)
G2
T13
W/2 : Back-up lamp
G3
T20
W/3 : External trunk release switch
Tail sub-harnessE4
T14
W/8 : To
B54
E4
T16
W/8 : To
T7
HARNESS LAYOUT
Body Harness (Cont’d)
EL-387

SEDAN—LHD models after VIN - P11U0548750
YEL973C
HARNESS LAYOUT
Body Harness (Cont’d)
EL-388
