HARNESS LAYOUT
Body Harness (Cont’d)
EL-389

SEDAN—RHD models before VIN - P11U0548750
YEL255C
Body ground
Body ground Body ground
.Be sure to connect and lock the connectors securely after repair work.
Failure to do so may cause the ECM to have diagnostic trouble codes.
Do not disconnect these connectors except in the case of working
according to WORK FLOW of TROUBLE DIAGNOSES in EC and AT sections.
HARNESS LAYOUT
Body Harness (Cont’d)
EL-390

YEL256C
Body harnessG3
B3
W/24 : To
M13
G3
B4
W/6 : To
M14
G2
B5
W/12 : To
D2
F1
B8
BR/16 : Fuse block (J/B)
F1
B11
W/8 : Time control unit
G1
B12
W/20 : Time control unit
F3
B15
W/6 : Ultra sonic sub-sensor
F2
B16
W/8 : To
D22
E4
B17
W/4 : Seat belt pre-tensioner (Driver’s side)
F2
B18
—: Body ground
D1
B19
BR/1 : Front door switch (Passenger side)
F3
B20
B/3 : Front door switch (Driver’s side)
C3
B21
W/3 : Heated seat LH
E3
B22
W/2 : Power seat
E3
B24
B/1 : Parking brake switch
C1
B26
W/4 : Seat belt pre-tensioner (Passenger side)
C2
B27
—: Body ground
D1
B28
W/8 : To
D18
C1
B29
W/8 : Ultra sonic sensor
D4
B30
GY/2 : Fuel pump
D3
B31
GY/3 : Fuel level sensor unit
E4
B32
GY/2 : Rear wheel sensor RH
C2
B33
BR/2 : Rear wheel sensor LH
D1
B34
BR/1 : Rear door switch RH
C1
B37
B/2 : Rear speaker RH
C1
B38
BR/1 : Rear door switch LH
B1
B40
B/2 : Rear speaker LH
A1
B47
W/16 : CD auto changer
B1
B50
B/1 : High mounted stop lamp
B2
B51
W/2 : Trunk room lamp
C1
B52
W/4 : Rear wiper motor
A2
B53
W/8 : To
T1
A2
B54
W/8 : To
T14
E1
B56
W/10 : To
D11
E1
B57
W/16 : To
E115
E2
B58
W/12 : To
B101
B1
B59
B/1 : Rear window defogger
E3
B61
W/3 : Heated seat RH
C2
B65
—: Body ground
D3
B66
Y/12 : Diagnosis sensor unit
E3
B67
Y/12 : Diagnosis sensor unit
C3
B68
Y/2 : Side air bag module LH
E3
B69
Y/2 : Side air bag module RH
C2
B70
OR/2 : Satellite sensor LHF4
B71
Y/2 : Satellite sensor RH
F3
B72
—: Body ground
F1
B97
B/2 : Fuse block (J/B)
G3
B98
L/4 : Theft warning horn relay
G3
B99
GY/2 : Circuit breaker-2
G1
B121
W/6 : Central unlock/trunk release switch
D3
B122
W/3 : To
B130
E1
B123
W/12 : Auto level control unit
B2
B124
W/3 : To
B132
D3
B130
W/3 : To
B122
F2
B131
—/3 : Front sensor
B2
B132
W/3 : To
B124
B3
B133
—/3 : Rear sensor
Console harnessE2
B101
W/12 : To
B58
D2
B102
W/6 : Ultrasonic cancel switch
D2
B104
L/4 : Heated seat switch LH
E2
B105
W/4 : Heated seat switch RH
E2
B106
W/4 : Headlamp aiming switch
Tail harnessA2
T1
W/8 : To
B53
A3
T2
W/4 : Rear combination lamp LH
B4
T3
—: Body ground
B4
T4
—: Body ground
B4
T5
W/4 : Rear combination lamp RH
C4
T6
B/1 : Theft warning horn
A3
T9
BR/2 : License plate lamp LH
A3
T17
BR/4 : Not used (To trailer tow connection)
A3
T18
BR/4 : Link
A3
T19
BR/2 : License plate lamp RH
Tail harness No. 2A3
T7
W/8 : To
T16
A3
T8
W/2 : Back-up lamp
B3
T10
B/2 : Trunk room lamp switch
C3
T12
W/4 : Door unlock actuator assembly (Trunk)
B3
T13
W/2 : Rear fog lamp
B3
T20
W/3 : External trunk release switch
Tail sub-harnessA2
T14
W/8 : To
B54
A2
T16
W/8 : To
T7
