 Intake door position is basically set to the FRE when the FRE indi-
cator is ON or DEF switch is ON.
 Intake door position is basically set to the REC when the REC indi-
cator is ON.
 The intake door automatic control selects the FRE, the 20% FRE,
or the REC depending on the target air mix door opening angle,
based on in-vehicle temperature, ambient temperature, and sun-
load.
JPIIA0634GB

HAC-34
< FUNCTION DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
BLOWER MOTOR CONTROL SYSTEM
BLOWER MOTOR CONTROL SYSTEM
System DiagramINFOID:0000000003846315
System DescriptionINFOID:0000000003846316
Blower speed is automatically controlled by the temperature setting, ambient temperature, in-vehicle tempera-
ture, intake temperature, amount of sunload and air mix door position.
By pressing the AUTO switch, the blower motor starts to gradually increase air flow volume.
When engine coolant temperature is low, the blower motor operation is delayed to prevent cool air from flow-
ing.
SYSTEM OPERATION
System Operation
 For air flow, the manual selection (1-7) with the fan control dial has priority.
 If the AUTO switch is pressed or if the DEF switch is pressed while in the OFF condition, it changes to the
automatic control by A/C auto amp.
 When increasing the air flow, it changes the duty ratio of the blower motor drive signal to prevent the air flow
from suddenly increasing.
 There are the following types of air flow control: starting air flow control, starting air flow control at low cool-
ant temperature, starting air flow control at high in-vehicle temperature, and air flow control at actuator oper-
ation in addition to manual control, normal automatic air flow control.
Normal Automatic Air Flow Control
 When the target temperature is set by the temperature control switch of A/C control, the A/C auto amp. per-
forms the calculation and decides the target according to the signal from each sensor.
 The A/C auto amp. changes the duty ratio of blower motor drive signal and controls the air flow continuously
so that the air flow becomes the target air flow.
 The minimum air flow will change according to the sunload when the air discharge outlet is VENT or B/L.
Fan Speed Control Specification
JPIIA0502GB
JPIIA0635GB

BLOWER MOTOR CONTROL SYSTEM
HAC-35
< FUNCTION DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P Starting Air Flow Control
 When starting the automatic control of air flow, the system gradually increases the duty ratio of the blower
motor drive signal to prevent too much air from blowing.
 The time period from when the air flow changes from LO to HI is approximately 8 seconds.
 It becomes the starting air flow control at low coolant temperature according to the calculation result of the A/
C auto amp. and engine coolant temperature [approximately 56°C (133°F) or less] during the automatic air
flow control.
 Do not perform the starting air flow control when the air discharge outlet is set to DEF.
Starting Fan Speed Control
Start up from COLD SOAK Condition (Automatic mode)
In cold start up condition where the engine coolant temperature is below 56°C (133°F), the blower does not
operate for a short period of time (up to 150 seconds). The exact start delay time varies depending on the
ambient temperature and engine coolant temperature.
In the most extreme case (very low ambient temperature) the blower start delay is 150 seconds as described
above. After this delay, the blower will operate at low speed until the engine coolant temperature rises above
56°C (133°F), and then the blower speed increases to the objective speed.
Start up from usual or HOT SOAK Condition (Automatic mode)
The blower will begin operation momentarily after the AUTO switch is pressed. The blower speed rises gradu-
ally to the objective speed over a time period of 3 seconds or less (actual time depends on the objective
blower speed).

HAC-36
< FUNCTION DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
MAGNET CLUTCH CONTROL SYSTEM
MAGNET CLUTCH CONTROL SYSTEM
System DiagramINFOID:0000000003846317
System DescriptionINFOID:0000000003846318
The A/C auto amp. controls compressor operation by ambient temperature, intake air temperature and signal
from ECM.
SYSTEM OPERATION
When the A/C switch, the AUTO switch, or the DEF switch is pressed, A/C auto amp. transmit the A/C switch
signal and blower fan motor switch signal to the ECM, via CAN communication.
ECM judges whether compressor can be turned ON, based on each sensor status (refrigerant-pressure sen-
sor signal, throttle angle, etc.). If the ECM judges that the compressor can be turned ON, it sends A/C com-
pressor request signal to the IPDM E/R, via CAN communication.
Upon receipt of A/C compressor request signal from the ECM, the IPDM E/R turns the A/C relay ON to oper-
ate the compressor.
When sending A/C compressor request signal to the IPDM E/R via CAN communication line, the ECM simul-
taneously sends A/C compressor feedback signal to A/C auto amp. via CAN communication line.
The ECM sends A/C compressor feedback signal to A/C auto amp., then, uses input A/C compressor feed-
back signal to control air inlet.
Compressor Protection Control
The ECM makes the A/C relay turn OFF and stops the compressor when pressure on the high-pressure side
detected by the refrigerant pressure sensor is over approximately 3,119 kPa (31.19bar, 31.8 kg/cm
2, 452 psi),
or below approximately 118 kPa (1.18bar, 1.2 kg/cm
2, 17 psi).
Low Temperature Protection Control
Turn the A/C relay to OFF and stop the compressor by the signal from the A/C auto amp according to the
evaporator passing air temperature detected by the intake sensor and the ambient temperature detected by
the ambient sensor.
JPIIA0504GB

CAN COMMUNICATION SYSTEM
HAC-37
< FUNCTION DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
CAN COMMUNICATION SYSTEM
System DescriptionINFOID:0000000003846319
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto each vehicle, and each control unit shares information and links with
other control units during operation (not independent). In CAN communication, control units are connected
with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less
wiring. Each control unit transmits/receives data but selectively reads required data only. For details, refer to
LAN-22, "
CAN System Specification Chart".

HAC-38
< FUNCTION DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
DIAGNOSIS SYSTEM (HVAC)
DIAGNOSIS SYSTEM (HVAC)
CONSULT-III FunctionINFOID:0000000003846320
CONSULT-III can display each diagnosis item using the diagnosis test modes shown as per the following.
CONSULT-III application items
SELF DIAGNOSTIC RESULT
Refer to HAC-85, "DTC Index".
Display Item List
Diagnosis mode Description
ECU Identification Displays the A/C auto amp. number.
Self Diagnostic Result Displays the diagnosis results judged by A/C auto amp.
Data Monitor Displays A/C auto amp. input/output data in real time.
Active Test The signals used to activate each device are forcibly supplied from A/C auto amp.
Work SupportChanges the setting for each system function.
 Temperature setting trimmer
 Inlet port memory function (FRE)
 Inlet port memory function (REC)
 Foot position setting trimmer
DTCItems
(CONSULT-III screen terms)Diagnostic item is detected when... Possible cause
U1000 CAN COMM CIRCUITWhen A/C auto amp. is not transmitting
or receiving CAN communication signal
for 2 or more seconds.CAN communication system
U1010 CONTROL UNIT (CAN)When detecting error during the initial
diagnosis of CAN controller of A/C auto
amp.A/C auto amp.
B257B AMB TEMP SEN (SHORT)Detected temperature at ambient sen-
sor −44°C (−47°F) or less Ambient sensor
 A/C auto amp.
 Harness and connector
(Ambient sensor circuit is open,
or there is a short in the circuit) B257C AMB TEMP SEN (OPEN)Detected temperature at ambient sen-
sor 100°C (212°F) or more
B2578IN CAR SENSOR (OUT OF RANGE
[LOW])Detected temperature at in-vehicle sen-
sor −44°C (−47°F) or less In-vehicle sensor
 A/C auto amp.
 Harness and connector
(In-vehicle sensor circuit is open,
or there is a short in the circuit) B2579IN CAR SENSOR (OUT OF RANGE
[HI])Detected temperature at in-vehicle sen-
sor 100°C (212°F) or more
B2581 EVAP TEMP SEN (SHORT)Detected temperature at intake sensor
−33°C (−27°F) or less Intake sensor
 A/C auto amp.
 Harness and connector
(Intake sensor circuit is open, or
there is a short in the circuit) B2582 EVAP TEMP SEN (OPEN)Detected temperature at intake sensor
69°C (156°F) or more
B2630
*SUNLOAD SEN (SHORT)Detected calorie at sunload sensor 64.7
w/m2 (30 kcal/m2·h) or less Sunload sensor
 A/C auto amp.
 Harness and connector
(Sunload sensor circuit is open,
or there is a short in the circuit) B2631
*SUNLOAD SEN (OPEN)Detected calorie at sunload sensor
2832 w/m2 (1304 kcal/m2·h) or more
B2632 DR AIRMIX ACTR (SHORT)Air mix door PBR (driver side) position
5% or less Air mix door motor (driver side)
 A/C auto amp.
 Harness and connector
(CAN communication line is open
or shorted)
(Air mix door motor is open or
shorted) B2633 DR AIRMIX ACTR (OPEN)Air mix door PBR (driver side) position
95% or more

DIAGNOSIS SYSTEM (HVAC)
HAC-39
< FUNCTION DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
*: Perform self-diagnosis under sunshine. When performing indoors, aim a light (more than 60 W) at sunload sensor, otherwise self-diag-
nosis indicates even though the sunload sensor is functioning normally.
DATA MONITOR
Display item list
B2634 PASS AIRMIX ACTR (SHORT)Air mix door PBR (passenger side) po-
sition 5% or less Air mix door motor (passenger
side)
 A/C auto amp.
 Harness and connector
(CAN communication line is open
or shorted)
(Air mix door motor is open or
shorted) B2635 PASS AIRMIX ACTR (OPEN)Air mix door PBR (passenger side) po-
sition 95% or more
B2636 DR VENT DOOR FAILWhen the malfunctioning door position
is detected at VENT position
 Mode door motor
 A/C auto amp.
 Harness and connector
(CAN communication line is open
or shorted)
(Mode door motor is open or
shorted) B2637 DR B/L DOOR FAILWhen the malfunctioning door position
is detected at B/L position
B2638 DR D/F1 DOOR FAILWhen the malfunctioning door position
is detected at FOOT position
B2639 DR DEF DOOR FAILWhen the malfunctioning door position
is detected at DEF position
B263D FRE DOOR FAILWhen the malfunctioning intake door
position is detected at FRE position Intake door motor
 A/C auto amp.
 Harness and connector
(CAN communication line is open
or shorted)
(Intake door motor is open or
shorted) B263E 20P FRE DOOR FAILWhen the malfunctioning intake door
position is detected at 20% FRE posi-
tion
B263F REC DOOR FAILWhen the malfunctioning intake door
position is detected at REC position
B2654 D/F2 DOOR FAILWhen the malfunctioning door position
is detected at D/F position Mode door motor
 A/C auto amp.
 Harness and connector
(CAN communication line is open
or shorted)
(Mode door motor is open or
shorted) B2655 B/L2 DOOR FAILWhen the malfunctioning door position
is detected at B/L2 position
B2656 BTC FRE DOOR FAILWhen the malfunctioning intake door
position is detected Intake door motor
 A/C auto amp.
 Harness and connector
(CAN communication line is open
or shorted)
(Intake door motor is open or
shorted) DTCItems
(CONSULT-III screen terms)Diagnostic item is detected when... Possible cause
Monitor item [Unit] Description
COMP REQ SIG [On/Off] Displays A/C switch ON/OFF status transmitted to other units via CAN communication
FAN REQ SIG [On/Off]Displays blower switch ON/OFF status transmitted to other units via CAN communica-
tion
AMB TEMP SEN [°C]Ambient sensor value converted from ambient sensor signal received from ambient
sensor
IN-VEH TEMP [°C]In-vehicle sensor value converted from in-vehicle sensor signal received from in-vehi-
cle sensor
INT TEMP SEN [°C] Intake sensor value converted from intake sensor signal received from intake sensor
SUNLOAD SEN
[w/m
2]Sunload sensor value converted from sunload sensor signal received from sunload
sensor
AMB SEN CAL [°C] Ambient sensor value calculated by A/C auto amp.
IN-VEH CAL [°C] In-vehicle sensor value calculated by A/C auto amp.

HAC-40
< FUNCTION DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
DIAGNOSIS SYSTEM (HVAC)
ACTIVE TEST
HVAC TEST
NOTE:
 Perform the inspection of each output device after starting the engine because the compressor is operated.
 When choosing to “MODE 7”, error message is displayed but it is not malfunction.
WORK SUPPORT
INT TEMP CAL [°C] Intake sensor value calculated by A/C auto amp.
SUNL SEN CAL
[w/m
2]Sunload sensor value calculated by A/C auto amp.
FAN DUTY [%] Duty ratio of blower motor judged by A/C auto amp.
XMTarget discharge air temperature judged by A/C auto amp. according to the tempera-
ture setting and the value from each sensor
ENG COOL TEMP [°C] Water temperature signal value received from ECM via CAN communication
VEHICLE SPEED[Mph
(km/h)]Vehicle speed signal value received from meter via CAN communication Monitor item [Unit] Description
Test item Description
ALL SEG Indicator all segment lighting
HVAC TESTThe operation check of A/C system can be performed by selecting the mode. Refer to the fol-
lowing table for the conditions of each mode.
Te s t i t e m
MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 MODE 6 MODE 7
Mode door position VENT B/L1 B/L2 AUTO FOOT D/F DEF -
Intake door position REC REC 20% FRE FRE FRE FRE -
Air mix door position
(driver & passenger
side)FULL COLD FULL COLD FULL HOT FULL HOT FULL HOT FULL HOT -
Blower motor duty ratio 37% 91% 65% 65% 65% 91% -
Compressor (Magnet
clutch)ON ON OFF OFF ON ON -
Work item Description Reference
TEMP SET CORRECTIf the temperature felt by the customer is different than the air flow
temperature controlled by the temperature setting, the auto ampli-
fier control temperature can be adjusted to compensate for the
temperature setting. HAC-10, "
Temperature
Setting Trimmer"
BLOW SETIn the FOOT mode, the air blowing to the DEF can change ON/
OFF. HAC-10, "Foot Position
Setting Trimmer"

DIAGNOSIS SYSTEM (HVAC)
HAC-41
< FUNCTION DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
NOTE:
When the battery cable is disconnected from the negative terminal or when the battery voltage becomes 10 V
or less, the setting of WORK SUPPORT may be cancelled.
FRE MEMORY SET If the ignition switch is turned to the OFF position while the FRE
switch is set to ON (fresh air intake), “Perform the memory” or
“Do not perform the memory” of the FRE switch ON (fresh air in-
take) condition can be selected.
 If “Perform the memory” was set, the FRE switch will be ON
(fresh air intake) when turning the ignition switch to the ON posi-
tion again.
 If “Do not perform the memory” was set, the air inlets will be con-
trolled automatically when turning the ignition switch to the ON
position again. HAC-11, "Inlet Port Mem-
ory Function (FRE)"
REC MEMORY SET If the ignition switch is turned to the OFF position while the REC
switch is set to ON (recirculation), “Perform the memory” or “Do
not perform the memory” of the REC switch ON (recirculation)
condition can be selected.
 If “Perform the memory” was set, the REC switch will be ON (re-
circulation) when turning the ignition switch to the ON position
again.
 If “Do not perform the memory” was set, the air inlets will be con-
trolled automatically when turning the ignition switch to the ON
position again. HAC-11, "Inlet Port Mem-
ory Function (REC)"
Work item Description Reference

HAC-42
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
U1000 CAN COMM CIRCUIT
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000003846322
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with two
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication Signal Chart. Refer to LAN-13, "
How to Use CAN Communication Signal Chart".
DTC LogicINFOID:0000000003846323
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003846324
1.CHECK WITH SELF-DIAGNOSIS FUNCTION OF CONSULT-III
1. Turn ignition switch ON and wait for 2 or more seconds.
2. Using CONSULT-III, perform “SELF-DIAGNOSIS RESULTS” of HVAC.
Is
“CAN COMM CIRCUIT” displayed?
YES >> Perform trouble diagnosis for the CAN communication system. Refer to LAN-14, "Trouble Diagno-
sis Flow Chart".
NO >> Perform the intermittent malfunction diagnosis. Refer to GI-35, "
Intermittent Incident".
DTCItems
(CONSULT-III screen terms)Diagnostic item is detected when... Possible cause
U1000 CAN COMM CIRCUITWhen A/C auto amp. is not transmitting
or receiving CAN communication signal
for 2 or more seconds.CAN communication system
