NISSAN TEANA 2008 Service Manual

AV
DISPLAY UNIT
AV-287
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
DISPLAY UNIT
Reference ValueINFOID:0000000003793620
TERMINAL LAYOUT
PHYSICAL VALUES
JPNIA0006ZZ
Te r m i n a l
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
1
(B/W)Ground Ground —Ignition
switch
ON —0 V
2
(Y)Ground Inverter VCC Inputignition
switch
ACC—9.0 V
3
(O)Ground Signal VCC InputIgnition
switch
ACC—9.0 V
4—Composite image signal
shield—— — —
5
(W)GroundComposite image signal
ground—Ignition
switch
ON—0 V
6
(R)GroundRGB image signal (G:
green)InputIgnition
switch
ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
7 — RGB ground — — — —
8
(W)GroundHorizontal synchronizing
(HP) signalOutputIgnition
switch
ON—
SKIB2236J
SKIB3601E

AV-288
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DISPLAY UNIT
9
(B)Ground RGB area (YS) signal InputIgnition
switch
ONWhen RGB image is dis-
played.5.0 V
When camera image, DVD
image or AUX image is dis-
played.
11
(R)GroundCommunication signal
(CONT→DISP)InputIgnition
switch
ONWhen adjusting display
brightness.
13
(BR)Ground Inverter ground —Ignition
switch
ON —0 V
14
(LG)Ground Signal ground —Ignition
switch
ON—0 V
15
(B)Ground Composite image signal InputIgnition
switch
ONWhen rear view camera im-
age, DVD image or AUX
image is displayed.
17
(W)Ground RGB image signal (R: red) InputIgnition
switch
ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
18
(B)Ground RGB image signal (B: blue) InputIgnition
switch
ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by
selecting“Color Spectrum
Bar” on DISPLAY DIAGNO-
SIS screen. Terminal
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
PKIB4948J
PKIB5039J
SKIB2251J
SKIB2238J
SKIB2237J

AV
DISPLAY UNIT
AV-289
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P19
(G)Ground RGB synchronizing signal InputIgnition
switch
ON—
20
(R)GroundVertical synchronizing (VP)
signalOutputIgnition
switch
ON—
21 — RGB synchronizing ground — — — —
22
(G)GroundCommunication signal
(DISP→CONT)OutputIgnition
switch
ONWhen adjusting display
brightness.
23 — Shield — — — —Te r m i n a l
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
SKIB3603E
SKIB3598E
PKIB5039J

AV-290
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DISPLAY UNIT
Wiring Diagram — BOSE AUDIO WITHOUT NAVIGATION SYSTEM —
INFOID:0000000003971969
JCNWM0917GB

AV
DISPLAY UNIT
AV-291
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
JCNWM0918GB

AV-292
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DISPLAY UNIT
JCNWM0919GB

AV
DISPLAY UNIT
AV-293
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
JCNWM0920GB

AV-294
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DISPLAY UNIT
JCNWM0921GB

AV
DISPLAY UNIT
AV-295
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
JCNWM0922GB

AV-296
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DISPLAY UNIT
JCNWM0923GB
