NISSAN TEANA 2008 Service Manual

AV
BOSE AMP.
AV-327
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
JCNWM0932GB

AV-328
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
BOSE AMP.
JCNWM0933GB

AV
BOSE AMP.
AV-329
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NOTE:
The name MULTIFUNCTION SWITCH indicates the integration of PRESET SWITCH and MULTIFUNCTION
SWITCH virtually.
JCNWM0934GB

AV-330
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DVD PLAYER
DVD PLAYER
Reference ValuesINFOID:0000000003793618
TERMINAL LAYOUT
PHYSICAL VALUES
JPNIA1095ZZ
Terminal
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
1
(B/W)Ground Ground —Ignition
switch
ON—0 V
2
(Y)Ground Battery power supply InputIgnition
switch
OFF— Battery voltage
3
(R/L)Ground Illumination signal InputIgnition
switch
OFFLighting switch is OFF. 0 V
Lighting switch is ON. 12.0 V
4
(V/W)Ground ACC power supply InputIgnition
switch
ACC— Battery voltage
5—Shield —— — —
6—Shield —— — —
7
(V)GroundComposite (DVD and AUX)
image signalOutputIgnition
switch
ONWhen DVD image or AUX
image is displayed.
8
(G)GroundComposite (AUX) image
signalOutputIgnition
switch
ONWhen AUX image is dis-
played.
9
(G)GroundComposite (DVD and AUX)
image signal ground—Ignition
switch
ON—0 V
10
(V)GroundComposite image (AUX)
signal ground—Ignition
switch
ON—0 V
SKIB2251J
SKIB2251J

AV
DVD PLAYER
AV-331
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P13
(B)11
(G)AUX sound signal LH InputIgnition
switch
ONAUX sound output.
14
(W)12
(R)AUX sound signal RH InputIgnition
switch
ONAUX sound output.
15 — AUX sound signal shield — — — —
21
(B)22
(G)Stereo (DVD and AUX
sound) sound signal LH OutputIgnition
switch
ONDVD
*1 or AUX sound out-
put.
23
(R)24
(W)Stereo (DVD and AUX
sound) sound signal RH OutputIgnition
switch
ONDVD
*1 or AUX sound out-
put.
25 — Stereo sound signal shield — — — —
29
(R)—AV communication signal
(L)Input/
Output—— —
30
(L)—AV communication signal
(H)Input/
Output—— —
31
(P)—AV communication signal
(L)Input/
Output—— —
32
(L)—AV communication signal
(H)Input/
Output—— —
34 — Shield — — — —
36
(W)35
(B)Surround sound signal front
RHOutputIgnition
switch
ONDVD sound output.
*2
Te r m i n a l
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E

AV-332
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DVD PLAYER
 *1: Stereo sounds are input only when the 2 channel stereo sound is played.
 *2: All surround sounds are input only when the 5.1 channel surround sound is played.38
(W)37
(B)Surround sound signal front
LHOutputIgnition
switch
ONDVD sound output.
*2
40
(W)39
(B)Surround sound signal cen-
terOutputIgnition
switch
ONDVD sound output.*2
42
(L)41
(R)Surround sound signal
wooferOutputIgnition
switch
ONDVD sound output.*2
43 — Shield — — — —
44 — Shield — — — —
46
(W)45
(B)Surround sound signal rear
RHOutputIgnition
switch
ONDVD sound output.
*2
48
(W)47
(B)Surround sound signal rear
LHOutputIgnition
switch
ONDVD sound output.*2
Terminal
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E

AV
DVD PLAYER
AV-333
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Wiring Diagram — BOSE AUDIO WITHOUT NAVIGATION SYSTEM —INFOID:0000000003971971
JCNWM0917GB

AV-334
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DVD PLAYER
JCNWM0918GB

AV
DVD PLAYER
AV-335
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
JCNWM0919GB

AV-336
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DVD PLAYER
JCNWM0920GB
