P0456 EVAP CONTROL SYSTEMEC-861
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
NO >> Replace EVAP control system pressure sensor.
16.CHECK EVAP PURGE LINE
Check EVAP purge line (pipe, rubber tube, fuel tank and EVAP canister) for cracks or improper connection.
Refer to EC-580, "EVAPORATIVE EMISSION SYSTEM : System Description"
.
Is the inspection result normal?
YES >> GO TO 17.
NO >> Repair or reconnect the hose.
17.CLEAN EVAP PURGE LINE
Clean EVAP purge line (pipe and rubber tube) using air blower.
>> GO TO 18.
18.CHECK EVAP/ORVR LINE
Check EVAP/ORVR line between EVAP canister and fuel tank for clogging, kink, looseness and improper con-
nection. For location, refer to EC-564, "On Board Refueling Vapor Recovery (ORVR)"
.
Is the inspection result normal?
YES >> GO TO 19.
NO >> Repair or replace hoses and tubes.
19.CHECK RECIRCULATION LINE
Check recirculation line between fuel filler tube and fuel tank for clogging, kink, cracks, looseness and
improper connection.
Is the inspection result normal?
YES >> GO TO 20.
NO >> Repair or replace hose, tube or fuel filler tube.
20.CHECK REFUELING EVAP VAPOR CUT VALVE
Refer to EC-976, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 21.
NO >> Replace refueling EVAP vapor cut valve with fuel tank.
21.CHECK FUEL LEVEL SENSOR
Refer to MWI-62, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 22.
NO >> Replace fuel level sensor unit.
22.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> INSPECTION END
Component InspectionINFOID:0000000009462706
1.CHECK FUEL FILLER CAP
1. Turn ignition switch OFF.
2. Remove fuel filler cap. Refer to FL-10, "Exploded View"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-862
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0456 EVAP CONTROL SYSTEM
3. Wipe clean valve housing.
4. Install fuel filler cap adapter (commercial service tool) to fuel filler cap.
5. Check valve opening pressure and vacuum.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE FUEL FILLER CAP
Replace fuel filler cap. Refer to FL-10, "Exploded View"
.
CAUTION:
Use only a genuine fuel filler cap as a replacement. If an incorrect fuel filler cap is used, the MIL may
illuminate.
>> INSPECTION END
SEF445Y
Pressure: 15.3 - 20.0 kPa (0.156 - 0.204 kg/cm2, 2.22 -
2.90 psi)
Vacuum: −6.0 to −3.3 kPa ( −0.061 to −0.034 kg/cm
2,
− 0.87 to −0.48 psi)
SEF943S
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0460 FUEL LEVEL SENSOREC-863
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0460 FUEL LEVEL SENSOR
DTC LogicINFOID:0000000009462707
DTC DETECTION LOGIC
NOTE:
• If DTC P0460 is displayed with DTC UXXXX, first perform the tr ouble diagnosis for DTC UXXXX.
• If DTC P0460 is displayed with DT C P0607, first perform the trouble diagnosis for DTC P0607. Refer
to EC-884, "DTC Logic"
.
When the vehicle is parked, the fuel level in the fuel tank is naturally stable. It means that output signal of the
fuel level sensor does not change. If ECM senses sloshi ng signal from the sensor, fuel level sensor malfunc-
tion is detected.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and wait maximum of 2 consecutive minutes.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-863, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462708
1.CHECK COMBINATION METER FUNCTION
Check combination meter function. Refer to MWI-18, "CONSULT Function (METER/M&A)"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Proceed to MWI-61, "Diagnosis Procedure"
.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0460 Fuel level sensor circuit
noise Even though the vehicle is parked, a signal be-
ing varied is sent from the fuel level sensor to
ECM. • Harness or connectors
(The CAN communication line is open or
shorted)
• Harness or connectors (The sensor circuit is open or shorted)
• Combination meter
• Fuel level sensor
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-864
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0461 FUEL LEVEL SENSOR
P0461 FUEL LEVEL SENSOR
DTC LogicINFOID:0000000009462709
DTC DETECTION LOGIC
NOTE:
• If DTC P0461 is displayed with DTC UXXXX, first perform the tr ouble diagnosis for DTC UXXXX.
• If DTC P0461 is displayed with DTC P0607, first pe rform the trouble diagnosis for DTC P0607. Refer
to EC-884, "DTC Logic"
.
Driving long distances naturally affect fuel gauge level.
This diagnosis detects the fuel gauge malfunction of the gauge not moving even after a long distance has
been driven.
DTC CONFIRMATION PROCEDURE
1.PERFORM COMPONENT FUNCTION CHECK
Perform component function check. Refer to EC-864, "Component Function Check"
.
Use component function check to check th e overall function of the fuel level sensor. During this check, a 1st
trip DTC might not be confirmed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-865, "Diagnosis Procedure"
.
Component Function CheckINFOID:0000000009462710
1.PRECONDITIONING
WARNING:
When performing the following procedure, always observe the hand ling of the fuel. Refer to FL-6,
"Exploded View".
TESTING CONDITION:
Before starting component function check, preparation of draining fuel and refilling fuel is required.
Will CONSULT be used?
YES >> GO TO 2.
NO >> GO TO 3.
2.PERFORM COMPONENT FUNCTION CHECK
With CONSULT
NOTE:
Start from step 10, if it is possibl e to confirm that the fuel cannot be drained by 30 (7-7/8 US gal, 6-5/
8 Imp gal) in advance.
1. Prepare a fuel container and a spare hose.
2. Release fuel pressure from fuel line, refer to EC-994, "Work Procedure"
.
3. Remove the fuel feed hose on the fuel level sensor unit.
4. Connect a spare fuel hose where the fuel feed hose was removed.
5. Turn ignition switch OFF and wait at least 10 seconds then turn ON.
6. Select “FUEL LEVEL SE” in “D ATA MONITOR” mode with CONSULT.
7. Check “FUEL LEVEL SE” output voltage and note it.
8. Select “FUEL PUMP RELAY” in “ACTIVE TEST” mode with CONSULT.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0461 Fuel level sensor circuit
range/performance The output signal of the fuel level sensor does
not change within the specified range even
though the vehicle has been driven a long dis-
tance. • Harness or connectors
(The CAN communication line is open or
shorted)
• Harness or connectors (The sensor circuit is open or shorted)
• Combination meter
• Fuel level sensor
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0461 FUEL LEVEL SENSOREC-865
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
9. Touch “ON” and drain fuel approximately 30
(7-7/8 US gal, 6-5/8 Imp gal) and stop it.
10. Check “FUEL LEVEL SE” output voltage and note it.
11. Fill fuel into the fuel tank for 30 (7-7/8 US gal, 6-5/8 Imp gal).
12. Check “FUEL LEVEL SE” output voltage and note it.
13. Confirm whether the voltage changes more than 0.03 V during step 7 to 10 and 10 to 12.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-865, "Diagnosis Procedure"
.
3.PERFORM COMPONENT FUNCTION CHECK
Without CONSULT
NOTE:
Start from step 8, if it is possible to confirm that the fuel cannot be drained by 30 (7-7/8 US gal, 6-5/8
Imp gal) in advance.
1. Prepare a fuel container and a spare hose.
2. Release fuel pressure from fuel line. Refer to EC-994, "Work Procedure"
.
3. Remove the fuel feed hose on the fuel level sensor unit. Refer to FL-6, "Exploded View"
.
4. Connect a spare fuel hose where the fuel feed hose was removed.
5. Turn ignition switch ON.
6. Drain fuel by 30 (7-7/8 US gal, 6-5/8 Imp gal) from the fuel tank using proper equipment.
7. Confirm that the fuel gauge indication varies.
8. Fill fuel into the fuel tank for 30 (7-7/8 US gal, 6-5/8 Imp gal).
9. Confirm that the fuel gauge indication varies.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-865, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009462711
1.CHECK COMBINATION METER FUNCTION
Check combination meter function. Refer to MWI-18, "CONSULT Function (METER/M&A)"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Proceed to MWI-61, "Diagnosis Procedure"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-866
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0462, P0463 FUEL LEVEL SENSOR
P0462, P0463 FUEL LEVEL SENSOR
DTC LogicINFOID:0000000009462712
DTC DETECTION LOGIC
NOTE:
• If DTC P0462 or P0463 is displayed with DTC UXXX X, first perform the trouble diagnosis for DTC
UXXXX.
• If DTC P0462 or P0463 is displayed with DTC P0607, first perform the trouble diagnosis for DTC
P0607.Refer to EC-884, "DTC Logic"
.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm th at battery voltage is more than 11 V at ignition
switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait at least 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-866, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462713
1.CHECK COMBINATION METER FUNCTION
Check combination meter function. Refer to MWI-18, "CONSULT Function (METER/M&A)"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Proceed to MWI-61, "Diagnosis Procedure"
.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0462 Fuel level sensor circuit
low input An excessively low voltage from the sensor is
sent to ECM. • Harness or connectors
(The CAN communication line is open or
shorted)
• Harness or connectors (The sensor circuit is open or shorted)
• Combination meter
• Fuel level sensor
P0463
Fuel level sensor circuit
high input An excessively high voltage from the sensor is
sent to ECM.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0500 VSSEC-867
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0500 VSS
DescriptionINFOID:0000000009462714
ECM receives vehicle speed signals from two different paths via CAN communication line: One is from the
ABS actuator and electric unit (control unit) via the combination unit and the other is from TCM.
DTC LogicINFOID:0000000009462715
DTC DETECTION LOGIC
NOTE:
• If DTC P0500 is displayed with DTC UXXXX, fi rst perform the trouble diagnosis for DTC UXXXX.
• If DTC P0500 is displayed with DTC P0607, first per form the trouble diagnosis for DTC P0607. Refer to EC-
884, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC CONFIRMATION PROCEDURE has been previously conducted, always perform the following proce-
dure before conducti ng the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is 10 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine.
2. Shift the selector lever to D range and wait at least for 2 seconds.
3. Drive the vehicle at least 5 seconds at 20 km/h (13 MPH) or more. CAUTION:
Always drive vehicle at a safe speed.
NOTE:
This procedure may be conducted with the drive wheels li fted in the shop or by driving the vehicle. If a
road test is expected to be easier, it is unnecessary to lift the vehicle.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-867, "Diagnosis Procedure"
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462716
1.CHECK DTC WITH TCM
Check DTC with TCM. Refer to TM-43, "CONSULT Function"
.
Is the inspection result normal?
YES >> GO TO 2.
DTC No. Trouble diagnosis
(Trouble diagnosis content) DTC detecting condition Possible cause
P0500 VEH SPEED SEN/CIRC
(Vehicle speed sensor) At 20 km/h (13 MPH), ECM detects the fol-
lowing status continuously for 5 seconds or
more: The difference between a vehicle
speed calculated by a secondary speed sen-
sor transmitted from TCM to ECM via CAN
communication and the vehicle speed indi-
cated on the combination meter exceeds
15km/h (10 MPH). • Harness or connector
(The CAN communication line is open
or shorted.)
• Combination meter
• ABS actuator and elec tric unit (control
unit)
• Wheel sensor
•TCM
• Secondary speed sensor
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-868
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0500 VSS
NO >> Perform trouble shooting relevant to DTC indicated.
2.CHECK DTC WITH ABS ACTUATOR AN
D ELECTRIC UNIT (CONTROL UNIT)
Check DTC with ABS actuator and elec tric unit (control unit). Refer to BRC-33, "CONSULT Function (ABS)"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Perform trouble shooting relevant to DTC indicated.
3.CHECK DTC WITH COMBINATION METER
Check DTC with combination meter. Refer to MWI-18, "CONSULT Function (METER/M&A)"
.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Perform trouble shooting relevant to DTC indicated.
4.CHECK SECONDARY SPEED SENSOR
Check secondary speed sensor. Refer to TM-358, "Diagnosis Procedure"
.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace or replace error-detected parts.
5.CHECK WHEEL SENSOR
Check wheel sensor. Refer to BRC-76, "Diagnosis Procedure"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace or replace error-detected parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0506 ISC SYSTEMEC-869
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0506 ISC SYSTEM
DescriptionINFOID:0000000009462717
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment of the air, which is let
into the intake manifold, by operating the electric thrott le control actuator. The operating of the throttle valve is
varied to allow for optimum control of the engine idli ng speed. The crankshaft position sensor (POS) detects
the actual engine speed and sends a signal to the ECM.
The ECM controls the electric throttle control actuator so that the engine speed coincides with the target value
memorized in the ECM. The target engine speed is t he lowest speed at which the engine can operate steadily.
The optimum value stored in the ECM is determined by taking into consideration various engine conditions,
such as during warming up, deceleration and engine load (air conditioner, power steering and cooling fan
operation, etc.).
DTC LogicINFOID:0000000009462718
DTC DETECTION LOGIC
NOTE:
If DTC P0506 is displayed with ot her DTC, first perform the trouble diagnosis for the other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
If the target idle speed is out of the specified value, perform EC-683, "Work Procedure"
, before con-
ducting DTC CONFIRMATION PROCEDURE.
TESTING CONDITION:
• Before performing the following procedure, confirm that battery voltage is more than 11 V at idle.
• Always perform the test at a temperature above −10 °C(14 °F).
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Restart engine and run it for at least 1 minute at idle speed.
6. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-869, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462719
1.CHECK INTAKE AIR LEAKAGE
1. Start engine and let it idle.
2. Listen for an intake air leakage after the mass air flow sensor.
Is intake air leakage detected?
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0506 Idle speed control sys-
tem RPM lower than ex-
pected The idle speed is less than the target idle speed
by 100 rpm or more. • Electric throttle control actuator
• Intake air leakage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-870
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0506 ISC SYSTEM
YES >> Discover air leakage location and repair.
NO >> Replace ECM. Refer to EC-997, "Removal and Installation"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
