NISSAN TEANA 2014 Service Manual

P0603 ECM POWER SUPPLYEC-881
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0603 ECM POWER SUPPLY
DTC LogicINFOID:0000000009462732
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait at least 10 second.
2. Turn ignition switch OFF and wait at least 5 minutes.
3. Turn ignition switch ON, wait at least 10 seconds.
4. Repeat steps 2 and 3 for five times.
5. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-881, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462733
1.CHECK ECM POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the voltage between ECM harness connector terminals.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform the trouble diagnosis for power supply circuit.
2.CHECK INTERMITTENT INCIDENT
Check intermittent incident. Refer to GI-43, "Intermittent Incident"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0603 ECM power supply cir-
cuit ECM back up RAM system does not function
properly. • Harness or connectors
[ECM power supply (b ack up) circuit is
open or shorted.]
•ECM
ECM
Vol tag e
+–
Connector Terminal Connector Terminal F78 26 E32 128 Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-882
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0603 ECM POWER SUPPLY
2. Erase DTC.
3. Perform DTC CONFIRMATION PROCEDURE. See EC-881, "DTC Logic"
.
Is the 1st trip DTC P0603 displayed again?
YES >> Replace ECM. Refer to EC-997, "Removal and Installation".
NO >> INSPECTION END
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0605 ECMEC-883
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0605 ECM
DTC LogicINFOID:0000000009462734
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE FOR MALFUNCTION A
1. Turn ignition switch ON.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-883, "Diagnosis Procedure".
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE FOR MALFUNCTION B
1. Turn ignition switch ON and wait at least 1 second.
2. Turn ignition switch OFF, wait at least 10 seconds, and then turn it ON.
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-883, "Diagnosis Procedure".
NO >> GO TO 4.
4.PERFORM DTC CONFIRMATION PROCEDURE FOR MALFUNCTION C
1. Turn ignition switch ON and wait at least 1 second.
2. Turn ignition switch OFF, wait at least 10 seconds, and then turn it ON.
3. Repeat step 2 for 32 times.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-883, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462735
1.INSPECTION START
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC CONFIRMATION PROCEDURE. See EC-883, "DTC Logic"
.
Is the 1st trip DTC P0605 displayed again?
YES >> Replace ECM. Refer to EC-997, "Removal and Installation".
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0605 Engine control module A) ECM calculation function is malfunctioning.
•ECM
B) ECM EEP-ROM system is malfunctioning.
C) ECM self shut-off function is malfunctioning.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-884
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0607 ECM
P0607 ECM
DTC LogicINFOID:0000000009462736
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check DTC.
Is DTC detected?
YES >> Proceed to EC-884, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462737
1.INSPECTION START
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC CONFIRMATION PROCEDURE.
See EC-884, "DTC Logic"
.
4. Check DTC.
Is the DTC P0607 displayed again?
Yes >> Replace ECM. Refer to EC-997, "Removal and Installation".
No >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0607 CAN communication bus When detecting error during the initial diagno-
sis of CAN controller of ECM. •ECM
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0643 SENSOR POWER SUPPLYEC-885
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0643 SENSOR POWER SUPPLY
DescriptionINFOID:0000000009462738
ECM supplies a voltage of 5 V to some of the sensors systematically divided into 2 groups, respectively.
Accordingly, when a short circuit develops in a sensor power source, a malfunction may occur simultaneously
in the sensors belonging to the same group as the short-circuited sensor.
Sensor power supply 1
• Accelerator pedal position (APP) sensor 1
• Camshaft position (CMP) sensor (PHASE)
• Electric throttle control actuator
• Battery current sensor
NOTE:
If sensor power supply 1 circuit is malfunctioning, DTC P0643 is displayed.
Sensor power supply 2
• Accelerator pedal position (APP) sensor 2
• Crankshaft position (CKP) sensor (POS)
• Refrigerant pressure sensor
• EVAP control system pressure sensor
• Engine oil pressure sensor
DTC LogicINFOID:0000000009462739
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 8 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Proceed to EC-885, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462740
1.CHECK SENSOR POWER SUPPLY 1
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
DTC No. Trouble diagnosis name
(Trouble diagnosis con- tent) DTC detecting condition Possible cause
P0643 SENSOR POWER/
CIRC
(Sensor power supply 1
circuit short) ECM detects a voltage of power source
for sensor is excessively low or high. Sensor power supply 1 circuit
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-886
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0643 SENSOR POWER SUPPLY
3. Turn ignition switch ON.
4. Check the voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> GO TO 2.
2.CHECK SENSOR POWER SUPPLY 1 ROUTING CIRCUIT FOR SHORT
1. Turn ignition switch OFF.
2. Disconnect following sensor harness connector.
3. Check harness for short to power and to ground, between the following terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK COMPONENTS
Check the following.
• Throttle position sensor (Refer to EC-745, "Component Inspection"
.)
• Battery current sensor (Refer to EC-898, "Component Inspection"
.)
• Camshaft position sensor (P HASE) (bank 1) (Refer to EC-822, "Component Inspection"
.)
• Camshaft position sensor (P HASE) (bank 2) (Refer to EC-822, "Component Inspection"
.)
• Accelerator pedal position sensor (Refer to EC-941, "Component Inspection"
.)
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace malfunctioning component.
+
−Voltag e
(Approx.)
ECM
Connector Terminal F78 24
Ground 5 V
F79 75
83
87
E32 99
ECM Sensor + Name -
Connector Terminal Connector Terminal F78 24 TP sensor F57 1
F79 75 Battery current sensor F5 1
83 CMP sensor (PHASE) (bank 1) F77 1
87 CMP sensor (PHASE) (bank 2) F60 1
E32 99 APP sensor 1 E40 4
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0850 PNP SWITCHEC-887
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0850 PNP SWITCH
DescriptionINFOID:0000000009462741
When the selector lever position is P or N, park/
neutral position (PNP) signal from the transmission range
switch is sent to ECM.
DTC LogicINFOID:0000000009462742
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.INSPECTION START
Will CONSULT be used?
Will CONSULT be used?
YES >> GO TO 2.
NO >> GO TO 5.
2.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 3.
3.CHECK PNP SIGNAL
With CONSULT
1. Turn ignition switch ON.
2. Select “P/N POSI SW” in “DATA MONITOR” mode with CONSULT. Then check the “P/N POSI SW” signal
under the following conditions.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Proceed to EC-888, "Diagnosis Procedure"
.
4.PERFORM DTC CONFIRMATION PROCEDURE
1. Select “DATA MONITOR” mode with CONSULT.
2. Start engine and warm it up to normal operating temperature.
3. Maintain the following conditions for at least 50 consecutive seconds.
CAUTION:
Always drive vehicle at a safe speed.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0850 Park/neutral position
switch The signal of the park/neutral position (PNP)
signal does not change during driving after the
engine is started. • Harness or connectors
[The park/neutral position (PNP) signal
circuit is open or shorted.]
• Transmission range switch
Position (Selector lever) Known-good signal
N or P position ON
Except above position OFF
ENG SPEED 1,100 - 6,375 rpm
COOLAN TEMP/S More than 65 °C (149 °F)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-888
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0850 PNP SWITCH
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-888, "Diagnosis Procedure".
NO >> INSPECTION END
5.PERFORM COMPONENT FUNCTION CHECK
Perform component function check. Refer to EC-888, "Component Function Check"
.
NOTE:
Use component function check to check the overall func tion of the park/neutral position (PNP) signal circuit.
During this check, a 1st trip DTC might not be confirmed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-888, "Diagnosis Procedure"
.
Component Function CheckINFOID:0000000009462743
1.PERFORM COMPONENT FUNCTION CHECK
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-888, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009462744
1.CHECK TRANSMISSION RANGE SWITCH POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect transmission range switch harness connector.
3. Turn ignition switch ON.
4. Check the voltage between transmission range switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK TRANSMISSION RANGE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between transmission range switch harness connector and IPDM E/R harness con-
nector.
B/FUEL SCHDL 2.2 - 31.8 msec
VHCL SPEED SE More than 64 km/h (40 mph)
Selector lever Suitable position
ECM Condition Voltage
Connector +–
Terminal Terminal
E32 118 128 Selector lever
position P or N Battery voltage
Except above Approx. 0 V
+ −Voltag e
Transmission range switch
Connector Terminal F85 1 Ground Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0850 PNP SWITCHEC-889
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK TRANSMISSION RANGE SWITCH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between transmission r ange switch harness connector and ECM harness connector.
4. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK TRANSMISSION RANGE SWITCH
Check the transmission range switch. Refer to TM-303, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace transaxle assembly. Refer to TM-407, "Removal and Installation"
.
+−
Continuity
Transmission range switch IPDM E/R
Connector Terminal Connector Terminal F85 1 F83 61 Existed
+ −
Continuity
Transmission range switch ECM
Connector Terminal Connector Terminal F85 2 E32 118 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-890
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P1148, P1168 CLOSED LOOP CONTROL
P1148, P1168 CLOSED LOOP CONTROL
DTC LogicINFOID:0000000009462745
DTC DETECTION LOGIC
NOTE:
DTC P1148 or P1168 is displayed wi th another DTC for A/F sensor 1.
Perform the trouble diagnosi s for the corresponding DTC.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1148 Closed loop control
function (bank 1) The closed loop control function for bank 1 does
not operate even when vehicle is being driven
in the specified condition. • Harness or connectors
(The A/F sensor 1 circuit is open or short-
ed.)
• A/F sensor 1
• A/F sensor 1 heater
P1168 Closed loop control
function (bank 2) The closed loop control function for bank 2 does
not operate even when vehicle is being driven
in the specified condition.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
