NISSAN TEANA 2014 Service Manual

P1553 BATTERY CURRENT SENSOREC-901
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P1553 BATTERY CURRENT SENSOR
DTC LogicINFOID:0000000009462762
DTC DETECTION LOGIC
NOTE:
If DTC P1553 is displayed with DTC P0643, first pe rform the trouble diagnosis for DTC P0643. Refer to
EC-885, "DTC Logic"
.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 8 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and wait at least 10 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-901, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462763
1.CHECK BATTERY CURRENT SENSOR POWER SUPPLY
1. Disconnect battery current sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between battery cu rrent sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
2.CHECK BATTERY CURRENT SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between battery current sensor harness connector and ECM harness connector.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1553 Battery current sensor perfor-
mance The signal voltage transmitted from the
sensor to ECM is higher than the amount
of the maximum power generation. • Harness or connectors
(The sensor circuit is open or shorted.)
• Battery current sensor
Battery current sensor Ground Voltage (V)
Connector Terminal
F5 1 Ground Approx. 5
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
F5 3 F79 68 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-902
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P1553 BATTERY CURRENT SENSOR
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
3.CHECK BATTERY CURRENT SENSOR INPUT SIGNAL CIRCUIT
1. Check the continuity between battery current sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK BATTERY CURRENT SENSOR
Check battery current sensor. Refer to EC-904, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace battery negative cable assembly.
Component InspectionINFOID:0000000009462764
1.CHECK BATTERY CURRENT SENSOR
1. Turn ignition switch OFF.
2. Reconnect harness connectors disconnected.
3. Disconnect battery negative cable.
4. Install jumper cable between battery negative terminal and body ground.
5. Turn ignition switch ON.
6. Check the voltage between ECM harness connector terminals under the following conditions.
Before measuring the terminal voltage, confirm that the battery is fully charged. Refer to PG-4, "How to Handle Battery".
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace battery negative cable assembly.
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
F5 4 F79 66 Existed
ECM Voltage (V)
Connector +–
Te r m i n a l Te r m i n a l
F79 66 68 Approx. 2.5
JPBIA3287ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P1554 BATTERY CURRENT SENSOREC-903
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P1554 BATTERY CURRENT SENSOR
DTC LogicINFOID:0000000009462765
DTC DETECTION LOGIC
NOTE:
If DTC P1554 is displayed with DTC P0643, first pe rform the trouble diagnosis for DTC P0643. Refer to
EC-885, "DTC Logic"
.
DTC CONFIRMATION PROCEDURE
1.PERFORM COMPONENT FUNCTION CHECK
Perform component function check. Refer to EC-903, "Component Function Check"
.
NOTE:
Use component function check to check the overall functi on of the battery current sensor circuit. During this
check, a 1st trip DTC might not be confirmed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-903, "Diagnosis Procedure"
.
Component Function CheckINFOID:0000000009462766
1.PRECONDITIONING
TESTING CONDITION:
• Before performing the following procedure, confirm that battery voltage is more than 12.8 V at idle.
• Before performing the following procedure, confi rm that all load switches and A/C switch are turned
OFF.
>> GO TO 2.
2.PERFORM COMPONENT FUNCTION CHECK
With CONSULT
1. Start engine and let it idle.
2. Select “BAT CUR SEN” in “DATA MONITOR” mode with CONSULT.
3. Check “BAT CUR SEN” indication for 10 seconds.
“BAT CUR SEN” should be above 2,300mV at least once.
Without CONSULT
1. Start engine and let it idle.
2. Check voltage between ECM harness connector terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-903, "Diagnosis Procedure"
Diagnosis ProcedureINFOID:0000000009462767
1.CHECK BATTERY CURRENT SENSOR POWER SUPPLY
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1554 Battery current sensor perfor-
mance The output voltage of the battery current
sensor is lower than the specified value
while the battery voltage is high enough. • Harness or connectors
(The sensor circuit is open or shorted.)
• Battery current sensor
ECM
Voltage (V)
Connector +–
Te r m i n a l
F79 66 68 Above 2.3 at least once
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-904
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P1554 BATTERY CURRENT SENSOR
1. Disconnect battery current sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between battery current sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
2.CHECK BATTERY CURRENT SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between battery current sensor harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
3.CHECK BATTERY CURRENT SENSOR INPUT SIGNAL CIRCUIT
1. Check the continuity between battery current sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK BATTERY CURRENT SENSOR
Check battery current sensor. Refer to EC-904, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace battery negative cable assembly.
Component InspectionINFOID:0000000009462768
1.CHECK BATTERY CURRENT SENSOR
1. Turn ignition switch OFF.
2. Reconnect harness connectors disconnected.
Battery current sensor Ground Voltage (V)
Connector Terminal
F5 1 Ground Approx. 5
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
F5 3 F79 68 Existed
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
F5 4 F79 66 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P1554 BATTERY CURRENT SENSOREC-905
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
3. Disconnect battery negative cable.
4. Install jumper cable between battery negative terminal and body ground.
5. Turn ignition switch ON.
6. Check the voltage between ECM harness connector terminals under the following conditions.
Before measuring the terminal voltage, confirm that the battery is fully charged. Refer to PG-4, "How to Handle Battery".
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace battery negative cable assembly.
ECM
Voltage (V)
Connector +–
Te r m i n a l Te r m i n a l
F79 66 68 Approx. 2.5
JPBIA3287ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-906
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P1556, P1557 BATTERY
TEMPERATURE SENSOR
P1556, P1557 BATTERY TEMPERATURE SENSOR
DTC LogicINFOID:0000000009462769
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is 10 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine and let it idle at least 10 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-906, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462770
1.CHECK BATTERY TEMPERATURE SENSOR INPUT SIGNAL
1. Disconnect battery current sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between battery current sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK BATTERY TEMPERATURE SE NSOR INPUT SIGNAL CIRCUIT
1. Turn ignition switch ON.
2. Disconnect ECM harness connector.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P1556 BAT TMP SEN/CIRC
(Battery temperature sensor cir-
cuit low input) Signal voltage from Battery temperature
sensor remains 0.16V or less for 5 sec-
onds or more. • Harness or connectors
[Battery current sensor (Battery tem-
perature sensor) ci rcuit is shorted.]
[Camshaft position sensor (PHESE)
circuit is open or shorted.]
(Accelerator pedal position sensor 2
circuit is shorted.)
(Throttle position sensor circuit is
shorted.)
• Battery current sensor (Battery tem-
perature sensor)
• Camshaft position sensor (PHESE)
• Accelerator pedal position sensor
• Throttle position sensor
P1557
BAT TMP SEN/CIRC
(Battery temperature sensor cir-
cuit high input) Signal voltage from Battery temperature
sensor remains 4.84V or more for 5 sec-
onds or more.
Battery current sensor Ground Voltage (V)
Connector Terminal
F5 2 Ground Approx. 5
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P1556, P1557 BATTERY TEMPERATURE SENSOR
EC-907
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
3. Check the continuity between battery current
sensor harness connector and ECM harness connector.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK BATTERY TEMPERATURE SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between battery current sensor harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK BATTERY TEMPERATURE SENSOR
Check battery temperature sensor. Refer to EC-907, "Component Inspection (Battery Temperature Sensor)"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace battery negative cable assembly.
Component Inspection (Bat tery Temperature Sensor)INFOID:0000000009462771
1.CHECK BATTERY TEMPERATURE SENSOR
1. Turn ignition switch OFF.
2. Disconnect battery current sensor.
3. Check the resistance between battery current sensor connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace battery negative cable assembly.
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
F5 2 F79 67 Existed
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
F5 3 F79 68 Existed
Battery current sensor Resistance
+ −
Te r m i n a l
23 continuity with the resis-
tance value 100 Ω or more
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-908
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P1564 ASCD STEERING SWITCH
P1564 ASCD STEERING SWITCH
DTC LogicINFOID:0000000009462772
DTC DETECTION LOGIC
NOTE:
If DTC P1564 is displayed with DTC P0605, first pe rform the trouble diagnosis for DTC P0605. Refer to
EC-883, "DTC Logic"
.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait at least 10 seconds.
2. Press MAIN switch for at least 10 seconds, then release it and wait at least 10 seconds.
3. Press CANCEL switch for at least 10 seconds , then release it and wait at least 10 seconds.
4. Press RESUME/ACCELERATE switch for at least 10 seconds, then release it and wait at least 10 sec-
onds.
5. Press SET/COAST switch for at least 10 seconds , then release it and wait at least 10 seconds.
6. Check DTC.
Is DTC detected?
YES >> Proceed to EC-908, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462773
1.CHECK ASCD STEERING SWITCH CIRCUIT
With CONSULT
1. Turn ignition switch ON.
2. Select “MAIN SW”, “CANCEL SW”, “RESUME/A CC SW” and “SET SW” in “DATA MONITOR” mode with
CONSULT.
3. Check each item indication under the following conditions.
DTC No. Trouble diagnosis
name DTC detecting condition Possible cause
P1564 ASCD steering switch • An excessively high voltage signal from the
ASCD steering switch is sent to ECM.
• ECM detects that input signal from the ASCD steering switch is out of the specified
range.
• ECM detects that the ASCD steering switch is stuck ON. • Harness or connectors
(The switch circuit is open or shorted.)
•ASCD steering switch
•ECM
Monitor item Condition Indication
MAIN SW ON/OFF (MAIN)
switch Pressed ON
Released OFF
CANCEL SW CANCEL switch Pressed ON
Released OFF
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P1564 ASCD STEERING SWITCHEC-909
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Without CONSULT
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals under the following conditions.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> GO TO 2.
2.CHECK ASCD STEERING SWITCH GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect combination switch harness connector M88.
4. Check the continuity between combi nation switch and ECM harness connector.
5. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK ASCD STEERING SWITCH INPUT SIGNAL CIRCUIT
1. Check the continuity between combi nation switch and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK ASCD STEERING SWITCH
Check ASCD steering switch. Refer to EC-910, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
RESUME/ACC SW ACCEL/RES switchPressed ON
Released OFF
SET SW COAST/SET switch Pressed ON
Released OFF
ECM Condition Voltage (V)
Con-
nector +–
Te r m i n a l Te r m i n a l
E32 101 108 ON/OFF (MAIN) switch: Pressed Approx. 0
CANCEL switch: Pressed Approx. 1
COAST/SET switch: Pressed Approx. 2
ACCEL/RES switch: Pressed Approx. 3
All ASCD steering switches: Released Approx. 4
Monitor item Condition Indication
Combination switch ECM
Continuity
Terminal Connector Terminal
16 E32 108 Existed
Combination switch ECM Continuity
Terminal Connector Terminal
13 E32 101 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-910
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P1564 ASCD STEERING SWITCH
NO >> Replace ASCD steering switch. Refer to
EC-548, "ENGINE CONTROL SYSTEM : Component
Parts Location".
Component InspectionINFOID:0000000009462774
1.CHECK ASCD STEERING SWITCH
1. Turn ignition switch OFF.
2. Disconnect combination switch (spiral cable) harness connector.
3. Check resistance between combination switch har ness connector terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace ASCD steering switch. Refer to EC-548, "ENGINE CONTROL SYSTEM : Component
Parts Location".
Combination switch
Condition Resistance ( Ω)
Connector Terminals
M88 13 and 16 ON/OFF (MAIN) switch: Pressed Approx. 0
CANCEL switch: Pressed Approx. 250
COAST/SET switch: Pressed Approx. 660
ACCEL/RES switch: Pressed Approx. 1,480
All ASCD steering switches: Released Approx. 4,000
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
