NISSAN TEANA 2014 Service Manual

FRONT FOG LAMPEXL-125
< PERIODIC MAINTENANCE >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
5. Adjust the cutoff line height (A) with the aiming adjustment screw so that the distance (X) between the horizontal center line
of front fog lamp (H) and (A) becomes 100 mm (4 in).
A : Cutoff line
B : High illuminance area
H : Horizontal center line of front fog lamp
V : Vertical center line of front fog lamp
X : Cutoff line height
JPLIA0008ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EXL-126
< REMOVAL AND INSTALLATION >
FRONT COMBINATION LAMP
REMOVAL AND INSTALLATION
FRONT COMBINATION LAMP
Exploded View - XenonINFOID:0000000009463619
COMBINATION LAMP - XENON
Removal and Installation - XenonINFOID:0000000009463620
FRONT COMBINATION LAMP - XENON
Removal
1. Disconnect the battery negative terminal. Refer to PG-73, "Removal and Installation (Battery)".
2. Remove the front bumper fascia. Refer to EXT-17, "Removal and Installation"
.
3. Ensure the lighting switch is OFF.
ALLIA1136ZZ
1. Front combination lamp 2. Halogen lamp bulb (high beam) 3. Ballast
4. Xenon lamp bulb 5. Plastic cover 6. Side marker bulb socket
7. Side marker lamp bulb
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

FRONT COMBINATION LAMPEXL-127
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
4. Remove the front combination lamp bolts (A).
5. Pull the front combination lamp (1) forward.
6. Disconnect the harness connectors from the front combination
lamp (1).
Installation
Installation is in the reverse order of removal.
NOTE:
After installation perform headlamp aiming adjustment. Refer to EXL-122, "Aiming Adjustment"
.
Bulb Replacement - XenonINFOID:0000000009463621
WARNING:
Do not touch bulb by hand while it is lit or right after being turned off. Burning may result.
CAUTION:
• Do not touch glass surface of the bulb with bare hand s or allow oil or grease to get on it to prevent
damage to bulb.
• Do not leave the bulb out of the lamp reflector fo r a long time because dust, moisture, smoke, etc.
may affect the performance of the lamp.
HEADLAMP HIGH BEAM
Removal
1. Position the front fender pr otector aside. Refer to EXT-26, "FENDER PROTECTOR : Removal and Instal-
lation".
2. Rotate the headlamp high beam socket countercloc kwise and remove from front combination lamp.
Installation
Installation is in the reverse order of removal.
CAUTION:
After installing, be sure to install the bulb socket securely to ensure watertightness.
HEADLAMP LOW BEAM XENON
CAUTION:
• Disconnect the battery negative terminal or remove the fuse.
• HID control unit and xenon bu lb socket cannot be disassembled.
Removal
1. Disconnect the battery negative te rminal (xenon only). Refer to PG-73, "Removal and Installation (Bat-
tery)".
2. Position the front fender pr otector aside. Refer to EXT-26, "FENDER PROTECTOR : Removal and Instal-
lation".
3. Rotate the plastic cover counterclockwise and remove from the front combination lamp.
4. Rotate the xenon bulb socket counterclockwise and remove from xenon bulb.
5. Remove the retaining spring and the xenon bulb from the front combination lamp. CAUTION:
Do not break the xenon bulb ceramic tube when replacing the bulb.
Installation
Installation is in the reverse order of removal.
CAUTION:
After installing the headlamp bulb, be sure to inst all the plastic cover securely to ensure watertight-
ness.
SIDE MARKER LAMP
ALLIA1132ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EXL-128
< REMOVAL AND INSTALLATION >
FRONT COMBINATION LAMP
Removal
1. Position the front fender protector aside. Refer to EXT-26, "FENDER PROTECTOR : Removal and Instal-
lation".
2. Rotate the side marker lamp bulb socket counterclockwise and remove.
3. Remove the side marker bulb from the front combination lamp.
Installation
Installation is in the reverse order of removal.
CAUTION:
After installing, be sure to install the bu lb socket securely to ensure watertightness.
Exploded View - HalogenINFOID:0000000009463622
COMBINATION LAMP - HALOGEN
Removal and Installation - HalogenINFOID:0000000009463623
FRONT COMBINATION LAMP - Halogen
Removal
1. Remove the front bumper fascia. Refer to EXT-17, "Removal and Installation".
2. Ensure the lighting switch is OFF.
ALLIA1137ZZ
1. Front combination lamp 2. Halogen lamp bulb (high beam) 3. Halogen lamp bulb (low beam)
4. Side marker bulb socket 5. Side marker bulb
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

FRONT COMBINATION LAMPEXL-129
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
3. Remove the front combination lamp bolts (A).
4. Pull the front combination lamp (1) forward.
5. Disconnect the harness connectors from the front combination
lamp (1).
Installation
Installation is in the reverse order of removal.
NOTE:
After installation perform headlamp aiming adjustment. Refer to EXL-122, "Aiming Adjustment"
.
Bulb Replacement - HalogenINFOID:0000000009463624
WARNING:
Do not touch bulb by hand while it is lit or right after being turned off. Burning may result.
CAUTION:
• Do not touch glass surface of the bulb with bare hand s or allow oil or grease to get on it to prevent
damage to bulb.
• Do not leave the bulb out of the lamp reflector fo r a long time because dust, moisture, smoke, etc.
may affect the performance of the lamp.
HEADLAMP HIGH BEAM
Removal
1. Position the front fender pr otector aside. Refer to EXT-26, "FENDER PROTECTOR : Removal and Instal-
lation".
2. Rotate the headlamp high beam socket countercloc kwise and remove from front combination lamp.
Installation
Installation is in the reverse order of removal.
CAUTION:
After installing, be sure to install the bulb socket securely to ensure watertightness.
HEADLAMP LOW BEAM HALOGEN
Removal
1. Position the front fender protector aside. Refer to EXT-26, "FENDER PROTECTOR : Removal and Instal-
lation".
2. Rotate the headlamp low beam sockets countercloc kwise and remove from front combination lamp.
Installation
Installation is in the reverse order of removal.
CAUTION:
After installing, be sure to install the bulb socket securely to ensure watertightness.
SIDE MARKER LAMP
Removal
1. Position the front fender protector aside. Refer to EXT-26, "FENDER PROTECTOR : Removal and Instal-
lation".
2. Rotate the side marker lamp bulb socket counterclockwise and remove.
3. Remove the side marker bulb from the front combination lamp.
Installation
Installation is in the reverse order of removal.
CAUTION:
After installing, be sure to install the bulb socket securely to ensure watertightness.
ALLIA1132ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EXL-130
< REMOVAL AND INSTALLATION >
TURN SIGNAL AND HAZARD WARNING LAMPS
TURN SIGNAL AND HAZARD WARNING LAMPS
Removal and InstallationINFOID:0000000009463625
REMOVAL
1. Remove the front fender protector side cover.
2. Position the fender protector aside. Refer to EXT-26, "FENDER PROTECTOR : Removal and Installa-
tion".
3. Disconnect the harness connector from the turn signal and hazard warning lamp.
4. Remove front fog lamp finisher. Refer to EXT-17, "Removal and Installation"
.
5. Remove the screw (A) from the turn signal and hazard warning lamp (1) and remove.
INSTALLATION
Installation is in the reverse order of removal.
Bulb ReplacementINFOID:0000000009463626
WARNING:
• Do not touch bulb by hand while it is lit or right after being turned off. Burning may result.
CAUTION:
• Do not touch glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent
damage to bulb.
• Do not leave the bulb out of the lamp reflector fo r a long time because dust, moisture, smoke, etc.
may affect the performance of the lamp.
REMOVAL
1. Remove the front fender protector side cover.
2. Position the front fender protector aside. Refer to EXT-26, "FENDER PROTECTOR : Removal and Instal-
lation".
3. Disconnect the harness connector from the turn signal and hazard warning lamp.
4. Rotate the turn signal and hazard warning lamp bulb socket counterclockwise and remove it.
5. Remove turn signal and hazard warning lamp bulb from the bulb socket.
Installation
Installation is in the reverse order of removal.
CAUTION:
After installing, be sure to install the bu lb socket securely to ensure watertightness.
ALLIA1143ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

FRONT FOG LAMPEXL-131
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
FRONT FOG LAMP
Removal and InstallationINFOID:0000000009463627
REMOVAL
1. Remove the front fender protector side cover.
2. Position the fender protector aside. Refer to EXT-26, "FENDER PROTECTOR : Removal and Installa-
tion".
3. Disconnect the harness connector (B) from the front fog lamp (1).
4. Remove the screws (A) and the front fog lamp (1).
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
After installing, perform fog lamp aiming adjustment. Refer to EXL-124, "Aiming Adjustment"
.
Bulb ReplacementINFOID:0000000009463628
WARNING:
• Do not touch bulb by hand while it is lit or right after being turned off. Burning may result.
CAUTION:
• Do not touch glass surface of the bulb with bare hand s or allow oil or grease to get on it to prevent
damage to bulb.
• Do not leave the bulb out of the lamp reflector fo r a long time because dust, moisture, smoke, etc.
may affect the performance of the lamp.
FRONT FOG LAMP BULB
Removal
1. Remove the front fender protector side cover.
2. Position the front fender pr otector aside. Refer to EXT-26, "FENDER PROTECTOR : Removal and Instal-
lation".
3. Disconnect the harness connector from the front fog lamp bulb.
4. Rotate the front fog lamp bulb socket counterclockwise and remove.
Installation
Installation is in the reverse order of removal.
CAUTION:
After installing, be sure to install the bulb socket securely to ensure watertightness.
DAYTIME LIGHT BULB (IF EQUIPPED)
Removal
1. Remove the front fender protector side cover.
2. Position the front fender pr otector aside. Refer to EXT-26, "FENDER PROTECTOR : Removal and Instal-
lation".
3. Disconnect the harness connector from the daytime light lamp.
4. Release the pawls and remove the daytime light lamp bulb.
Installation
Installation is in the reverse order of removal.
ALLIA1148ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EXL-132
< REMOVAL AND INSTALLATION >
FRONT FOG LAMP
CAUTION:
After installing, be sure to install the bu lb socket securely to ensure watertightness.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DOOR MIRROR TURN SIGNAL LAMPEXL-133
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
DOOR MIRROR TURN SIGNAL LAMP
Removal and InstallationINFOID:0000000009463629
REMOVAL
1. Remove the door mirror rear finisher. Refer to MIR-20, "Removal and Installation".
2. Remove the screws (A) and door mirror side turn signal lamp (1).
3. Disconnect the harness connector from the door mirror side turn signal lamp and remove.
INSTALLATION
Installation is in the reverse order of removal.
Bulb ReplacementINFOID:0000000009463630
DOOR MIRROR SIDE TURN SIGNAL LAMP
The door mirror side turn signal lamp bulb is integrated into the door mirror side turn signal lamp and is ser-
viced as an assembly. Refer to EXL-133, "Removal and Installation"
.
ALLIA1142ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EXL-134
< REMOVAL AND INSTALLATION >
HIGH-MOUNTED STOP LAMP
HIGH-MOUNTED STOP LAMP
Removal and InstallationINFOID:0000000009463631
HIGH-MOUNTED STOP LAMP - WITH REAR SPOILER
The high-mount stop lamp is integrated into the rear spoiler and is serviced as an assembly. Refer to EXT-38,
"Removal and Installation".
HIGH-MOUNTED STOP LAMP - WITH PARCEL SHELF
Removal
1. Slide high-mounted stop lamp (1) rearward on parcel shelf to
provide clearance for front tabs (A).
2. Lift front of lamp assembly up and pull forward to provide clear- ance for rear tabs (B).
3. Disconnect the harness connector from the high-mounted stop lamp and remove.
Installation
Installation is in the reverse order of removal.
Bulb ReplacementINFOID:0000000009463632
HIGH-MOUNTED STOP LAMP - WITH REAR SPOILER
The high-mounted stop lamp bulb is integrated into the rear spoiler and is serviced as an assembly. Refer to
EXT-38, "Removal and Installation"
.
HIGH-MOUNTED STOP LAMP - WITH PARCEL SHELF
The high-mounted stop lamp bulb is integrated into the high-mounted stop lamp and is serviced as an assem-
bly. Refer to EXL-134, "Removal and Installation"
.
ALLIA1135ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
