NISSAN TEANA 2014 Service Manual

PWC-34
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> Main power window and door lock/unlock switch is OK.
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-65, "Removal and Instal-
lation". After that, refer to PWC-27, "ADDITIONAL SERVICE WHEN REPLACING CONTROL
UNIT : Special Repair Requirement".
POWER WINDOW MAIN SWITCH : S pecial Repair RequirementINFOID:0000000009460839
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to PWC-27, "ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check intermittent incident. Refer to GI-43, "Intermittent Incident"
.
2. CHECK ANTI-PINCH OPERATION
Check anti-pinch operation.
Refer to PWC-27, "ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> Inspection End.
NO >> Refer to PWC-30, "POWER WINDO W MAIN SWITCH : Component Function Check"
.
FRONT POWER WINDOW SWITCH
FRONT POWER WINDOW SWITCH : DescriptionINFOID:0000000009460840
• BCM supplies power.
• Front power window motor RH will be operated if power window and door lock/unlock switch RH is operated.
FRONT POWER WINDOW SWITCH : Component Function CheckINFOID:0000000009460841
Power Window And Door Lock/unlock Switch RH
1. CHECK POWER WINDOW MOTOR FUNCTION
Check front power window motor operation with power window and door lock/unlock switch RH.
Is the inspection result normal?
YES >> Power window and door lock/unlock switch RH power supply and ground circuit are OK.
NO >> Refer to PWC-35, "FRONT POWER WINDOW SWITCH : Diagnosis Procedure"
.
Terminal Main power window and door lock/unlock switch condition Continuity
9
1 Rear LH
UP
Ye s
7Rear RH
16 Front RH 8 Rear LH
NEUTRAL
9
7 Rear RH
6
2 Front RH
16
8Rear LH DOWN
6Rear RH
2Front RH
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

POWER SUPPLY AND GROUND CIRCUITPWC-35
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
FRONT POWER WINDOW SWIT CH : Diagnosis ProcedureINFOID:0000000009460842
Regarding Wiring Diagram information, refer to PWC-18, "Wiring Diagram - With Left Front Only Power Win-
dow Anti- Pinch".
Power Window And Door Lock/Unlock Switch RH Power Supply Circuit Check
1. CHECK POWER SUPPLY CIRCUIT (POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH)
1. Turn ignition switch ON.
2. Check voltage between power window and door lock/unlock switch RH connector D110 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM, power window and door lock/unlock switch RH, rear power window switch LH and rear power window switch RH.
3. Check continuity between BCM connector M21 and power window and door lock/unlock switch RH con-
nector D110.
4. Check continuity between BCM connector M21 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the harness or connectors.
3. CHECK HARNESS CONTINUI TY (POWER WINDOW AND DO OR LOCK/UNLOCK SWITCH RH)
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unl ock switch and power window and door lock/unlock
switch RH.
3. Check continuity between main power window and door lock/unlock switch connector D12 and power win-
dow and door lock/unlock switch RH connector D110.
4. Check continuity between main power window and door lock/unlock switch connector D12 and ground.
Te r m i n a l Vo l ta g e
(Approx.)
(+)
(–)
Power window and door lock/unlock
switch RH connector Te r m i n a l
D110 8 Ground Battery voltage
BCM connector Terminal Power window and door lock/unlock
switch RH connector Terminal Continuity
M21 140 D110 8 Yes
BCM connector Terminal GroundContinuity
M21 140 No
Main power window and door lock/unlock switch connector Te r m i n a lPower window and door lock/
unlock switch RH connector Terminal Continuity
D12 2
D110 11
Ye s
16 12
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PWC-36
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> GO TO 5
NO >> Repair or replace the harness or connectors.
4. CHECK BCM OUTPUT SIGNAL
1. Connect BCM.
2. Turn ignition switch ON.
3. Check voltage between BCM connector M21 and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
5. CHECK POWER WINDOW AND D OOR LOCK/UNLOCK SWITCH RH
Check power window and door lock/unlock switch RH.
Refer to PWC-36, "FRONT POWER WINDOW SWITCH : Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace power window and door lock/unlock switch RH. Refer to PWC-65, "Removal and Installa-
tion".
FRONT POWER WINDOW SWITCH : Component InspectionINFOID:0000000009460843
COMPONENT INSPECTION
1. CHECK POWER WINDOW AND D OOR LOCK/UNLOCK SWITCH RH
Check power window and door lock/unlock switch RH D110.
Is the inspection result normal?
YES >> Power window and door lock/unlock switch RH is OK.
NO >> Replace power window and door lock/unlock switch RH. Refer to PWC-66, "Removal and Installa-
tion".
REAR POWER WINDOW SWITCH
REAR POWER WINDOW SWITCH : DescriptionINFOID:0000000009460844
• BCM supplies power.
Main power window and door lock/unlock switch con-
nector Te r m i n a l
GroundContinuity
D12 2
No
16
Te r m i n a l s
Voltag e
(Approx.)
(+)
(–)
BCM connector Terminal
M21 140 Ground Battery voltage
Terminal Power window switch condition Continuity
87 UP
Ye s
12 6
12 6 NEUTRAL
711
86 DOWN
711
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

POWER SUPPLY AND GROUND CIRCUITPWC-37
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
• Rear power window motor will be operated if rear power window switch is operated. Rear power window switch.
REAR POWER WINDOW SWITCH : Component Function CheckINFOID:0000000009460845
Rear Power Window Switch
1. CHECK REAR POWER WINDOW MOTOR FUNCTION
Check rear power window motor operation with rear power window switch.
Is the inspection result normal?
YES >> Rear power window switch power supply and ground circuit are OK.
NO >> Refer to PWC-37, "REAR POWER WINDOW SWITCH : Diagnosis Procedure"
.
REAR POWER WINDOW SWITCH : Diagnosis ProcedureINFOID:0000000009460846
Regarding Wiring Diagram information, refer to PWC-18, "Wiring Diagram - With Left Front Only Power Win-
dow Anti- Pinch".
Rear Power Window Switch Power Supply Circuit Check
1. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between rear power window switch connector and ground.
Is the inspection result normal?
YES >> GO TO 2 (Rear power window switch LH).
YES >> GO TO 3 (Rear power window switch RH).
NO >> GO TO 4.
2. CHECK HARNESS CONTINUITY (REAR POWER WINDOW SWITCH LH)
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unloc k switch and rear power window switch LH.
3. Check continuity between main power window and door lock/unlock switch connector and rear power win- dow switch LH connector.
4. Check continuity between main power window and door lock/unlock switch connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the harness or connectors.
Te r m i n a l
ConditionVo l ta g e
(Approx.)
(+)
(–)
Rear power window
switch connector Te r m i n a l
LH D203 4 Ground Ignition switch ON Battery voltage
RH D303
Main power window and door lock/
unlock switch connector Te r m i n a lRear power window switch
LH connector Terminal Continuity
D12 8
D203 7
Ye s
98
Main power window and door lock/unlock switch connector Te r m i n a l
GroundContinuity
D12 8
No
9
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PWC-38
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
3. CHECK HARNESS CONTINUITY
(REAR POWER WINDOW SWITCH RH)
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unl ock switch and rear power window switch RH.
3. Check continuity between main power window and door lock/unlock switch connector and rear power win-
dow switch RH connector.
4. Check continuity between main power window and door lock/unlock switch connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the harness or connectors.
4. CHECK HARNESS CONTINUITY
1. Disconnect BCM, power window and door lock/unlock s witch RH, rear power window switch LH and rear
power window switch RH.
2. Check continuity between BCM connector and rear power window switch connector.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-80, "Removal and Installation".
NO >> Repair or replace harness or connectors.
5. CHECK REAR POWER WINDOW SWITCH
Check rear power window switch.
Refer to PWC-38, "REAR POWER WINDOW SWITCH : Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace rear power window switch. Refer to PWC-67, "Removal and Installation"
.
REAR POWER WINDOW SWITCH : Component InspectionINFOID:0000000009460847
COMPONENT INSPECTION
1. CHECK REAR POWER WINDOW SWITCH
Check rear power window switch.
Main power window and door lock/ unlock switch connector Te r m i n a lRear power window switch
RH connector Terminal Continuity
D12 6
D303 7
Ye s
78
Main power window and door lock/un- lock switch connector Te r m i n a l
GroundContinuity
D12 6
No
7
BCM
connector Terminal Rear power window switch connector Terminal Continuity
M21 140 LH D203
4Yes
RH D303
BCM connector Terminal GroundContinuity
M21 140 No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

POWER SUPPLY AND GROUND CIRCUITPWC-39
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
Is the inspection result normal?
YES >> Rear power window switch is OK.
NO >> Replace rear power window switch. Refer to PWC-67, "Removal and Installation"
.
Terminal Power window switch condition Continuity
45 UP
Ye s
86
86 NEUTRAL
57
46 DOWN
57
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PWC-40
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER WINDOW MOTOR
POWER WINDOW MOTOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000009460848
Door glass moves UP/DOWN by receiving the signal
from main power window and door lock/unlock switch.
DRIVER SIDE : Component Function CheckINFOID:0000000009460849
1. CHECK FRONT POWER WINDOW MOTOR LH CIRCUIT
Check front power window motor LH operation with the main power window and door lock/unlock switch.
Is the inspection result normal?
YES >> Front power window motor LH is OK.
NO >> Refer to PWC-40, "DRIVER SIDE : Diagnosis Procedure"
.
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000009460850
Regarding Wiring Diagram information, refer to PWC-18, "Wiring Diagram - With Left Front Only Power Win-
dow Anti- Pinch".
Front Power Window Motor LH Circuit Check
1. CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front power window motor LH.
3. Turn ignition switch ON.
4. Check voltage between front power window motor LH connector D9 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch.
3. Check continuity between main power window and door lock/unlock switch connector D8 and front power
window motor LH connector D9.
4. Check continuity between main power window and door lock/unlock switch connector D8 and ground.
Te r m i n a l Main power window and
door lock/unlock switch con- dition Vo l ta g e
(Approx.)
(+)
(–)
Front power window motor
LH connector Te r m i n a l
D9 1
Ground UP Battery voltage
DOWN 0
3 UP 0
DOWN Battery voltage
Main power window and door lock/un- lock switch connector Te r m i n a l
Front power window motor LH
connector Terminal Continuity
D8 17
D9 1
Ye s
19 3
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

POWER WINDOW MOTORPWC-41
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
Is the inspection result normal?
YES >> Replace main power window and door lock/unlock switch. Refer to PWC-65, "Removal and Instal-
lation". After that, refer to PWC-41, "DRIVER SIDE : Special Repair Requirement".
NO >> Repair or replace harness.
3. CHECK FRONT POWER WINDOW MOTOR LH
Check front power window motor LH.
Refer to PWC-41, "DRIVER SIDE : Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace front power window motor LH. Refer to GW-16, "Removal and Installation - Front Regula-
tor". After that, refer to PWC-41, "DRIVER SIDE : Special Repair Requirement".
DRIVER SIDE : Component InspectionINFOID:0000000009460851
COMPONENT INSPECTION
1.CHECK FRONT POWER WINDOW MOTOR LH
Check motor operation by connecting the battery voltage directly to power window motor D9.
Is the inspection result normal?
YES >> Front power window motor LH is OK.
NO >> Replace front power window motor LH. Refer to GW-16, "Removal and Installation - Front Regula-
tor". After that, refer to PWC-41, "DRIVER SIDE : Special Repair Requirement".
DRIVER SIDE : Special Repair RequirementINFOID:0000000009460852
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to PWC-27, "ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special
Repair Requirement".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check intermittent incident. Refer to GI-43, "Intermittent Incident"
.
2. CHECK ANTI-PINCH OPERATION
Check anti-pinch operation.
Refer to PWC-27, "ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special
Repair Requirement".
Is the inspection result normal?
YES >> Inspection end.
NO >> Refer to PWC-40, "DRIVER SIDE : Component Function Check"
.
PASSENGER SIDE
Main power window and door lock/un-
lock switch connector Te r m i n a l
GroundContinuity
D8 17
No
19
Te r m i n a l Motor condition
(+) (–)
31 DOWN
13 UP
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PWC-42
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER WINDOW MOTOR
PASSENGER SIDE : Description
INFOID:0000000009460853
Door glass moves UP/DOWN by receiving the signal from main power window and door lock/unlock switch or
power window and door lock/unlock switch RH.
PASSENGER SIDE : Component Function CheckINFOID:0000000009460854
1. CHECK FRONT POWER WINDOW MOTOR RH CIRCUIT
Check front power window motor RH operation with main power window and door lock/unlock switch or power
window and door lock/unlock switch.
Is the inspection result normal?
YES >> Front power window motor RH is OK.
NO >> Refer to PWC-42, "PASSENGER SIDE : Diagnosis Procedure"
.
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000009460855
Regarding Wiring Diagram information, refer to PWC-18, "Wiring Diagram - With Left Front Only Power Win-
dow Anti- Pinch".
Front Power Window Motor RH Circuit Check
1. CHECK POWER WINDOW AND DOOR LO CK/UNLOCK SWITCH RH OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front power window motor RH.
3. Turn ignition switch ON.
4. Check voltage between front power window motor RH connector D111 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect power window and door lock/unlock switch RH.
3. Check continuity between power window and door lock/unlock switch RH connector D110 and front power
window motor RH connector D111.
4. Check continuity between power window and door lock/unlock switch connector D110 and ground.
Te r m i n a l
Front power window motor RH condition Voltage (V)
(Approx.)
(+)
(–)
Front power window motor RH
connector Te r m i n a l
D 111 1
Ground UP Battery voltage
DOWN 0
3 UP 0
DOWN Battery voltage
Power window and door lock/un- lock switch RH connector Te r m i n a l
Front power window motor RH
connector Terminal Continuity
D110 7
D 111 1
Ye s
63
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

POWER WINDOW MOTORPWC-43
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
Is the inspection result normal?
YES >> Replace power window and door lock/unlock switch RH. Refer to PWC-65, "Removal and Installa-
tion".
NO >> Repair or replace the harness or connectors.
3. CHECK FRONT POWER WINDOW MOTOR RH
Check front power window motor RH.
Refer to PWC-43, "PASSENGER SIDE : Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace front power window motor RH. Refer to GW-16, "Removal and Installation - Front Regu-
lator".
PASSENGER SIDE : Component InspectionINFOID:0000000009460856
COMPONENT INSPECTION
COMPONENT INSPECTION
1. CHECK FRONT POWER WINDOW MOTOR RH
Check motor operation by connecting the battery volt age directly to front power window motor RH D111.
Is the inspection result normal?
YES >> Power window motor is OK.
NO >> Replace front power window motor RH. Refer to GW-16, "Removal and Installation - Front Regu-
lator".
REAR LH
REAR LH : DescriptionINFOID:0000000009460857
Door glass moves UP/DOWN by receiving the signal from main power window and door lock/unlock switch or
rear power window switch LH.
REAR LH : Component Function CheckINFOID:0000000009460858
1. CHECK REAR POWER WINDOW MOTOR LH CIRCUIT
Check rear power window motor LH operation with main power window and door lock/unlock switch or rear
power window switch LH.
Is the inspection result normal?
YES >> Rear power window motor LH is OK.
NO >> Refer to PWC-43, "REAR LH : Diagnosis Procedure"
REAR LH : Diagnosis ProcedureINFOID:0000000009460859
Regarding Wiring Diagram information, refer to PWC-18, "Wiring Diagram - With Left Front Only Power Win-
dow Anti- Pinch".
Power window and door lock/unlock switch RH
connector Te r m i n a l
Ground Continuity
D110 7
No
6
Te r m i n a l Motor condition
(+) (–)
31 DOWN
13 UP
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
