NISSAN TEANA 2014 Service Manual

RF-26
< DTC/CIRCUIT DIAGNOSIS >
MOONROOF SWITCH
MOONROOF SWITCH
DescriptionINFOID:0000000009461309
Transmits switch operation signal to moonroof motor assembly.
Diagnosis ProcedureINFOID:0000000009461310
Regarding Wiring Diagram information, refer to RF-12, "Wiring Diagram".
1.CHECK MOONROOF SWITCH INPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between moonroof motor assembly harness connector R5 and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> GO TO 2.
2.CHECK MOONROOF SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect moonroof motor assembly connector and moonroof switch connector.
3. Check continuity between moonroof motor assemb ly harness connector R5 and moonroof switch harness
connector R6.
4. Check continuity between moonroof moto r assembly harness connector R5 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the harness or connectors.
3.CHECK MOONROOF SWITCH GROUND CIRCUIT
Check continuity between moonroof switch harness connector R6 and ground.
(+)
(–) Condition Voltag e
(Approx.)
Moonroof motor assembly
Connector Terminals
R5 5
GroundMoonroof switch is operated
TILT DOWN or SLIDE
OPEN 0
Other than above Battery voltage
10 Moonroof switch is operated
TILT UP or SLIDE CLOSE 0
Other than above Battery voltage
Moonroof motor assembly Moonroof switch Continuity
Connector Terminal Connector Terminal
R5 5
R6 3
Ye s
10 4
Moonroof motor assembly GroundContinuity
Connector Terminal
R5 5
No
10
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

MOONROOF SWITCHRF-27
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
RF
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the harness or connectors.
4.CHECK MOONROOF SWITCH
Check moonroof switch.
Refer to RF-27, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace moonroof switch. Refer to INL-63, "Removal and Installation"
.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
Component InspectionINFOID:0000000009461311
MOONROOF SWITCH
1. CHECK MOONROOF SWITCH
1. Turn ignition switch OFF.
2. Disconnect moonroof switch.
3. Check continuity between moonroof switch terminals.
Is the inspection result normal?
YES >> Moonroof switch is OK.
NO >> Replace moonroof switch. Refer to INL-63, "Removal and Installation"
.
Moonroof switch
GroundContinuity
Connector Terminal
R6 1 Yes
Terminals Condition Continuity
3 1Moonroof switch is operated TILT DOWN or SLIDE OPEN
OPEN Ye s
Other than above No
4 Moonroof switch is operated TILT UP or SLIDE CLOSE
CLOSE Ye s
Other than above No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

RF-28
< DTC/CIRCUIT DIAGNOSIS >
DOOR SWITCH
DOOR SWITCH
DescriptionINFOID:0000000009461312
Detects door open/close condition.
Component Function CheckINFOID:0000000009461313
1.CHECK FUNCTION
With CONSULT
Check door switches DOOR SW-DR, DOOR SW-AS in Data Monitor mode with CONSULT.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to RF-28, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009461314
Regarding Wiring Diagram information, refer to DLK-51, "Wiring Diagram".
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 4
NO >> GO TO 2
Monitor item Condition
DOOR SW-DR CLOSE → OPEN: OFF → ON
DOOR SW-AS
Te r m i n a l s
Door condition Voltage (V)
(Approx.)
(+)
(–)
BCM
connector Te r m i n a l
M19 96
GroundFront door switch
LH OPEN 0
CLOSE
94 Front door switch
RH OPEN 0
CLOSE
JPMIA0011GB
JPMIA0011GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DOOR SWITCHRF-29
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
RF
N
O P
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM connector and door switch connector.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness between BCM and door switch.
3.CHECK DOOR SWITCH
Refer to RF-29, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 4
NO >> Replace malfunctioning door switch.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
Component InspectionINFOID:0000000009461315
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Disconnect door switch connector.
3. Check door switch.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace malfunctioning door switch.
BCM connector Terminal Door switch
connector Terminal Continuity
M19 96 Front door switch LH Ground
part of
door
switch Ye s
94 Front door switch RH
BCM connector Terminal GroundContinuity
M19 96
No
94
Te r m i n a l Door switch condition Continuity
Door switch
3 Ground part of
door switch Pressed No
Released Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

RF-30
< SYMPTOM DIAGNOSIS >
MOONROOF DOES NOT OPERATE PROPERLY
SYMPTOM DIAGNOSIS
MOONROOF DOES NOT OPERATE PROPERLY
Diagnosis ProcedureINFOID:0000000009461316
1. CHECK BCM POWER SUPPLY AND GROUND CIRCUIT
Check BCM power supply and ground circuit.
Refer to BCS-74, "Diagnosis Procedure"
.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning parts.
2. CHECK MOONROOF MOTOR ASSEMBLY POWER SUPPLY AND GROUND CIRCUIT
Check moonroof motor assembly power supply and ground circuit.
Refer to RF-22, "MOONROOF MOTOR ASSEM BLY : Component Function Check"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

AUTO OPERATION DOES NOT OPERATERF-31
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
RF
N
O P
AUTO OPERATION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000009461317
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to RF-20, "ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> Inspection End.
NO >> Perform basic inspection. Refer to RF-18, "Work Flow"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

RF-32
< SYMPTOM DIAGNOSIS >
MOONROOF DOES NOT OPERATE ANTI-PINCH FUNCTION
MOONROOF DOES NOT OPERATE ANTI-PINCH FUNCTION
Diagnosis ProcedureINFOID:0000000009461318
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to RF-20, "ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> Inspection End.
NO >> Perform basic inspection. Refer to RF-18, "Work Flow"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DOES NOT STOP FULLY-OPEN OR FULLY-CLOSED POSITION
RF-33
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
RF
N
O P
DOES NOT STOP FULLY-OPEN OR FULLY-CLOSED POSITION
Diagnosis ProcedureINFOID:0000000009461319
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to RF-20, "ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> Inspection End.
NO >> Perform basic inspection. Refer to RF-18, "Work Flow"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

RF-34
< SYMPTOM DIAGNOSIS >
RETAINED POWER OPERATION DOES NOT OPERATE PROPERLY
RETAINED POWER OPERATION DOES NOT OPERATE PROPERLY
Diagnosis ProcedureINFOID:0000000009461320
1.CHECK FRONT DOOR SWITCH
Check front door switch.
Refer to DLK-100, "Component Function Check"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

SQUEAK AND RATTLE TROUBLE DIAGNOSESRF-35
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
RF
N
O P
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Work FlowINFOID:0000000009461321
CUSTOMER INTERVIEW
Interview the customer if possible, to determine the c onditions that exist when the noise occurs. Use the Diag-
nostic Worksheet during the interv iew to document the facts and conditions when the noise occurs and any
customer's comments; refer to RF-39, "Diagnostic Worksheet"
. This information is necessary to duplicate the
conditions that exist when the noise occurs.
• The customer may not be able to provide a detailed descr iption or the location of the noise. Attempt to obtain
all the facts and conditions that exist when the noise occurs (or does not occur).
• If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer is
concerned about. This can be accomplished by test driving the vehicle with the customer.
• After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
are provided so the customer, service adviser and technician are all speaking the same language when
defining the noise.
• Squeak —(Like tennis shoes on a clean floor)
Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard surfaces
= higher pitch noise/softer surfaces = lower pitch noises/edge to surface = chirping.
• Creak—(Like walking on an old wooden floor)
Creak characteristics include firm contact/slow mo vement/twisting with a rotational movement/pitch depen-
dent on materials/often brought on by activity.
• Rattle—(Like shaking a baby rattle)
Rattle characteristics include the fast repeated contac t/vibration or similar movement/loose parts/missing
clip or fastener/incorrect clearance.
• Knock —(Like a knock on a door)
Knock characteristics include hollow sounding/someti mes repeating/often brought on by driver action.
• Tick—(Like a clock second hand) Tick characteristics include gentle contacting of li ght materials/loose components/can be caused by driver
action or road conditions.
• Thump—(Heavy, muffled knock noise) Thump characteristics include softer k nock/dead sound often brought on by activity.
• Buzz—(Like a bumble bee)
Buzz characteristics include high frequency rattle/firm contact.
• Often the degree of acceptable noise level will vary depending upon the person. A noise that you may judge as acceptable may be very irritating to the customer.
• Weather conditions, especially humidity and temperature, may have a great effect on noise level.
DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on
the Diagnostic Worksheet regarding the conditions or lo cation of the noise. This information can be used to
duplicate the same conditions when you confirm the repair.
SBT842
