< SYSTEM DESCRIPTION >[CVT: RE0F10D]
DIAGNOSIS SYSTEM (TCM)
TRGT PRI PRESSURE (MPa)Displays the target oil pressure of the primary pressure
solenoid valve calculated from oil pressure processing of
gear shift control.
TRGT SELECT PRESSURE (MPa) Displays the target oil pressure of the select solenoid
valve calculated from oil pressure processing of gear
shift control.
TRGT SEC PRESSURE (MPa) Displays the target oil pressure of the secondary pres-
sure solenoid valve calculated from oil pressure process-
ing of gear shift control.
ISOLT1 (A) ×Displays the command current from TCM to the torque
converter clutch solenoid valve.
ISOLT2 (A) ×Displays the command current from TCM to the line
pressure solenoid valve.
PRI SOLENOID (A) ×Displays the command current from TCM to the primary
pressure solenoid valve.
SEC SOLENOID CURRENT (A) ×Displays the command current from TCM to the second-
ary pressure solenoid valve.
SELECT SOLENOID CUR-
RENT (A)
×Displays the command current from TCM to the select
solenoid valve.
SOLMON1 (A) ××Monitors the command current from TCM to the torque
converter clutch solenoid valve and displays the moni-
tored value.
SOLMON2 (A) ××Monitors the command current from TCM to the line
pressure solenoid valve and displays the monitored val-
ue.
PRI SOL MON (A) ××Monitors the command current from TCM to the primary
pressure solenoid valve and displays the monitored val-
ue.
SEC SOL MON CURRENT (A) ××Monitors the command current from TCM to the second-
ary pressure solenoid valve and displays the monitored
value.
SELECT SOL MON CURRENT (A) ××Monitors the command current from TCM to the select
solenoid valve and displays the monitored value.
D POSITION SW (On/Off) ×Displays the operation status of the transmission range
switch (D position).
N POSITION SW (On/Off) ×Displays the operation status of the transmission range
switch (N position).
R POSITION SW (On/Off) ×Displays the operation status of the transmission range
switch (R position).
P POSITION SW (On/Off) ×Displays the operation status of the transmission range
switch (P position).
L POSITION SW* (On/Off) ×Displays the operation status of the transmission range
switch (L position).
DS RANGE SW (On/Off) ×Displays the operation status of the transmission range
switch (Ds position).
BRAKESW (On/Off) ××Displays the reception status of the stop lamp switch sig-
nal received through CAN communication.
IDLE SW (On/Off) ××Displays the reception status of the closed throttle posi-
tion signal received through CAN communication.
SPORT MODE SW (On/Off) ××Displays the reception status of the overdrive control
switch signal received through CAN communication.
Monitored item (Unit)
Monitor item selection
Remarks
ECU IN-
PUT SIG-
NALS MAIN SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DIAGNOSIS SYSTEM (TCM)TM-47
< SYSTEM DESCRIPTION > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
ECO MODE SW* (On/Off) ××Displays the reception status of the ECO mode switch
signal received through CAN communication.
STRDWNSW* (On/Off) ×Displays the operation status of the paddle shifter (down
switch).
STRUPSW* (On/Off) ×Displays the operation status of the paddle shifter (up
switch).
DOWNLVR* (On/Off) ×Displays the operation status of the selector lever (down
switch).
UPLVR* (On/Off) ×Displays the operation status of the selector lever (up
switch).
NONMMODE* (On/Off) ×Displays if the selector lever position is not at the manual
shift gate.
MMODE* (On/Off) ×Displays if the selector lever position is at the manual
shift gate.
TOW MODE SW* (On/Off) ×Displays the reception status of the TOW mode switch
signal received through CAN communication.
SHIFT IND SIGNAL Displays the transaxle value of shift position signal trans-
mitted via CAN communication.
CVT LAMP* (On/Off) Displays the transaxle status of the CVT warning lamp
signal transmitted through CAN communication.
SPORT MODE IND (On/Off) Displays the transaxle status of the O/D OFF indicator
lamp signal transmitted through CAN communication.
MANU MODE SIGNAL* (On/Off) Displays the transaxle status of the manual mode signal
transmitted through CAN communication.
DS RANGE SIGNAL (On/Off) Displays the shift position signal status from transmis-
sion range switch (DS position).
ECO MODE SIGNAL* (On/Off) Displays the transaxle status of the ECO mode signal
transmitted through CAN communication.
VDC ON (On/Off) ×Displays the reception status of the VDC operation signal
received through CAN communication.
TCS ON (On/Off) ×Displays the reception status of the TCS operation signal
received through CAN communication.
ABS FAIL SIGNAL (On/Off) ×Displays the reception status of the ABS malfunction sig-
nal received through CAN communication.
ABS ON (On/Off) ×Displays the reception status of the ABS operation signal
received through CAN communication.
RANGE ×Displays the gear position recognized by TCM.
M GEAR POS* ×Display the target gear of manual mode
G SEN SLOPE* (%) Displays the gradient angle calculated from the G sensor
signal voltage.
G SEN CALIBRATION* (YET/DONE) Displays the status of “G
SENSOR CALIBRATION” in
“Work Support”.
N IDLE STATUS* (On/Off) Displays idle neutral status.
ENGBRKLVL (On/Off) Displays the
setting of “ENGINE BRAKE ADJ” in “Work
Support”.
DRIVE MODE STATS* Displays the drive mode status recognized by TCM.
SNOW MODE* (On/Off) Displays whether it is the SNOW mode.
ECO MODE* (On/Off) Displays whether it is the ECO mode. Monitored item (Unit)
Monitor item selection
Remarks
ECU IN-
PUT SIG-
NALS MAIN SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TM-48
< SYSTEM DESCRIPTION >[CVT: RE0F10D]
DIAGNOSIS SYSTEM (TCM)
*: Not applicable but displayed.
WORK SUPPORT
Engine brake adjustment
Check the degradation level of the CVT fluid.
ACTIVE TEST
NORMAL MODE* (On/Off) D
isplays whether it is the NORMAL mode.
SPORT MODE* (On/Off) Displays whether it is the SPORT mode.
AIR BLDING STATE* (INCOMP/
COMP) Displays the status of “E
LECTRIC O.P. AIR BLEEDING”
in “Work Support”.
ELECTRIC OP DUTY* (%) Displays the command signal value (duty) of the electric
oil pump transmitted from TCM.
E-OP DUTY MON* (%) Monitors the status signal value (duty) transmitted from
the electric oil pump and displays the monitored value.
ELECTRIC OP RELAY* (On/Off) Displays the command status from TCM to the electric oil
pump relay.
E-OP RELAY MON* (On/Off) Monitors the command status from TCM to the oil pump
relay and displays the monitored value.
Monitored item (Unit)
Monitor item selection
Remarks
ECU IN-
PUT SIG-
NALS MAIN SIG-
NALS
Item name Description
CONFORM CVTF DETERIORTN Checks the degradation level of the CVT fluid under severe conditions.
ERASE MEMORY DATA Performs “erasing of the calibration data” and “erasing of the learned value” at the
same time.
G SENSOR CALIBRATION Compensates the G sensor.
ERASE LEARNING VALUE Erases lear ning value memorized by TCM.
ENGINE BRAKE ADJ. Although there is no malfunction on the transaxle and the CVT system, if a cus-
tomer make a complaint like “I do not feel comfortable with automatic operation of
the engine brake on downhill”, the engine brake may be cancelled with “engine
brake adjustment”.
ERASE CALIBRATION DATA Erases cali bration data memorized by TCM.
WRITE IP CHARA - REPLACEMENT AT/CVT Writes IP characteristics when transaxle assembly is replaced.
READ IP CHARA - REPLACEMENT TCM Reads IP characteristics when TCM is replaced.
WRITE IP CHARA - REPLACEMENT TCM Writes IP characteristics when TCM is replaced.
ENGINE BRAKE LEVEL
ON : Turn ON the engine brake control.
OFF : Turn OFF the engine brake control.
CVTF degradation level data
210,000 or more : Replacement of the CVT fluid is required.
Less than 210,000 : Replacement of the CVT fluid is not required.
Item name Description
CVT OIL COOLER FAN CIRCUIT Checks the operation of CVT oil cooler fan relay.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TCM
TM-49
< ECU DIAGNOSIS INFORMATION > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
ECU DIAGNOSIS INFORMATION
TCM
Reference ValueINFOID:0000000009464001
CONSULT DATA MONITOR STANDARD VALUE
• In CONSULT, electric shift timing or lock-up timing, i. e. operation timing of each solenoid valve, is displayed.
Therefore, if there is an obvious difference between t he shift timing estimated from a shift shock (or engine
speed variations) and that shown on the CONSULT, the mechanism parts (including the hydraulic circuit)
excluding the solenoids and sensors may be malfunctioning. In this case, check the mechanical parts follow-
ing the appropriate diagnosis procedure.
• Shift point (gear position) displayed on CONSULT slight ly differs from shift pattern described in Service Man-
ual. This is due to the following reasons.
- Actual shift pattern may vary slightly within specified tolerances.
- While shift pattern described in Service Manual indica tes start of each shift, CONSULT shows gear position
at end of shift.
- The solenoid display (ON/OFF) on CONSULT is changed at the start of gear shifting. In contrast, the gear
position display is changed at the time when gear shif ting calculated in the control unit is completed.
NOTE:
The following table includes information (items) inapplicable to this vehicle. For information (items) applicable
to this vehicle, refer to CONSULT display items.
Monitor item Condition Value/Status (Approx.)
VSP SENSOR While driving Almost same as the speedometer display.
ESTM VSP SIG While driving Almost same as the speedometer display.
INPUT SPEED SENSOR In driving (lock-up ON) Ap proximately matches the engine speed.
PRI SPEED SEN In driving (lock-up ON) Approximately matches the engine speed.
SEC REV SENSOR While driving VSP SENSOR × 40
ENG SPEED SIG Engine ru nning Almost same reading as tachometer
SEC PRESSURE SEN • After engine warm up
• Selector lever: “N” position
• At idle 1.2 – 1.3 V
PRI PRESSURE SEN • After engine warm up
• Selector lever: “N” position
• At idle 0.70 – 0.85 V
ATF TEMP SEN CVT fluid: Approx. 20
°C (68 °F) 2.01 – 2.05 V
CVT fluid: Approx. 50 °C (122 °F) 1.45 – 1.50 V
CVT fluid: Approx. 80 °C (176 °F) 0.90 – 0.94 V
G SENSOR Vehicle is level 0 V
VIGN SEN Ignition switch: ON 10 – 16 V
PVING VOLT Ignition switch: ON 10 – 16 V
VEHICLE SPEED While driving Almost sa me as the speedometer display.
INPUT REV In driving (lock-up ON) Almost same as the engine speed.
PRI SPEED In driving (lock-up ON) Approximately matches the engine speed.
SEC SPEED While driving VSP SENSOR × 40
ENG SPEED Engine running Almost same reading as tachometer
SLIP REV While driving Engine speed − Input speed
PULLEY GEAR RATIO In driving (forward) 2.70
− 0.38
In driving (reverse) 2.70
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TM-50
< ECU DIAGNOSIS INFORMATION >[CVT: RE0F10D]
TCM
G SPEEDVehicle stopped 0.00 G
During acceleration The value changes to the positive side
along with acceleration.
During deceleration The value changes to the positive side
along with deceleration.
ACCEL POSI SEN 1 Accelerator pedal released 0.00 deg
Accelerator pedal fully depressed 80.00 deg
VENG TRQ While driving The value changes along with acceleration/
deceleration.
PRI TRQ While driving The value changes along with acceleration/
deceleration.
TRQ RTO While driving The value changes along with acceleration/
deceleration.
SEC PRESSURE • After engine warm up
• Selector lever: “N” position
•At idle 1.1 MPa
PRI PRESSURE • After engine warm up
• Selector lever: “N” position
•At idle 0.40 – 0.45 MPa
FLUID TEMP Ignition switch ON. Displays the CVT fluid temperature.
DSR REV While driving It varies along with the driving condition.
TGT PLLY GR RATIO In driving (forward) 2.70
− 0.38
In driving (reverse) 2.70
LU PRS • Engine started
• Vehicle is stopped. −
0.500 MPa
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 20 km/h (12 MPH) or more 0.450 MPa
LINE PRS • After engine warm up
• Selector lever: “N” position
•At idle 1.1 MPa
TRGT PRI PRESSURE • After engine warm up
• Selector lever: “N” position
•At idle 0.40 – 0.45 MPa
TRGT SELECT PRESSURE • After engine warm up
• Selector lever: “N” position
•At idle 0 MPa
• Selector lever: “D” position
•At idle 0.3 – 0.5 MPa
TRGT SEC PRESSURE • After engine warm up
• Selector lever: “N” position
•At idle 1.1 MPa
ISOLT1 • Engine started
• Vehicle is stopped. 0.000 A
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 20 km/h (12 MPH) or more 0.500 A
ISOLT2 • After engine warm up
• Selector lever: “N” position
•At idle 0.800 – 0.850 A
Monitor item Condition Value/Status (Approx.)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TCM
TM-51
< ECU DIAGNOSIS INFORMATION > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
PRI SOLENOID • After engine warm up
• Selector lever: “N” position
• At idle 0.800 – 0.850 A
SEC SOLENOID CURRENT • After engine warm up
• Selector lever: “N” position
• At idle 0.800 – 0.850 A
SELECT SOLENOID CURRENT • After engine warm up
• Selector lever: “N” position
• At idle 1.000 A
SOLMON1 • Engine started
• Vehicle is stopped. 0.000 A
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 20 km/h (12 MPH) or more 0.500 A
SOLMON2 • After engine warm up
• Selector lever: “N” position
• At idle 0.800 – 0.850 A
PRI SOL MON • After engine warm up
• Selector lever: “N” position
• At idle 0.800 – 0.850 A
SEC SOL MON CURRENT • After engine warm up
• Selector lever: “N” position
• At idle 0.800 – 0.850 A
SELECT SOL MON CURRENT • After engine warm up
• Selector lever: “N” position
• At idle 1.000 A
D POSITION SW Selector lever: “D” position On
Other than the above Off
N POSITION SW Selector lever: “N” position On
Other than the above Off
R POSITION SW Selector lever: “R” position On
Other than the above Off
P POSITION SW Selector lever: “P” position On
Other than the above Off
L POSITION SW Always Off
DS RANGE SW Selector lever: “DS” position On
Other than the above Off
BRAKESW Brake pedal is depressed On
Brake pedal is released Off
IDLE SW Accelerator pedal is fully depressed On
Accelerator pedal is released Off
SPORT MODE SW Press the overdrive control switch On
Release the overdrive control switch Off
ECO MODE SW Always Off
STRDWNSW Always Off
STRUPSW Always Off
DOWNLVR Always Off
UPLVR Always Off
NONMMODE Always On Monitor item Condition Value/Status (Approx.)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TM-52
< ECU DIAGNOSIS INFORMATION >[CVT: RE0F10D]
TCM
MMODE Always Off
TOW MODE SW Always Off
SHIFT IND SIGNAL When the selector lever is positioned in be-
tween each position. OFF
Selector lever: P position P
Selector lever: R position R
Selector lever: N position N
Selector lever: D position D
CVT LAMP Approx. 2 seconds after ignition switch ON On
Other than the above Off
SPORT MODE IND In overdrive off On
Other than the above Off
MANU MODE SIGNAL Always Off
DS RANGE SIGNAL Selector lever in DS position On
Other than the above Off
ECO MODE SIGNAL Always Off
VDC ON Always Off
TCS ON Always Off
ABS FAIL SIGNAL When ABS malfunction signal is received On
Other than the above Off
ABS ON ABS is activated On
Other than the above Off
RANGE Selector lever: P and N positions N/P
Selector lever: R position R
Selector lever: D position D
Selector lever: DS position S
Selector lever: D position (in O/D OFF) S
M GEAR POS Always 1
G SEN SLOPE Flat road 0%
Uphill gradient The value changes to the positive side
along with uphill gradient. (Maximum
40.45%)
Downhill gradient The value changes to the negative side
along with downhill gradient. (Minimum
40.45%)
G SEN CALIBRATION When G sensor calibration is completed DONE
When G sensor calibration is not completed YET
N IDLE STATUS Always Off
ENGBRKLVL When the engine brake level of “ENGINE
BRAKE ADJ”. in “Work Support” is ON On
When the engine brake level of “ENGINE
BRAKE ADJ”. in “Work Support” is OFF Off
DRIVE MODE STATS While driving in D position AUTO
SNOW MODE Always Off
ECO MODE Always Off
NOTMAL MODE Always Off
SPORT MODE Always Off Monitor item Condition Value/Status (Approx.)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TCM
TM-53
< ECU DIAGNOSIS INFORMATION > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P*: These monitor items do not use.
TERMINAL LAYOUT
INPUT/OUTPUT SIGNAL STANDARD
AIR BLDING STATE Always COMP
ELECTRIC OP DUTY Always 0%
E-OP DUTY MON Always 0%
ELECTRIC OP RELAY Always Off
E-OP RELAY MON Always Off
CVT-B* — —
CVT-A* — — Monitor item Condition Value/Status (Approx.)
JSDIA2713ZZ
Te r m i n a l N o .
(Wire color) Description
Condition Value (Approx.)
+ − Signal Input/
Output
2
(SB) Ground DS position switch Input
Ignition
switch
ON Selector lever: “DS” posi-
tion 10
− 16 V
Other than the above 0 V
4
(LG) Ground D position switch Input Selector lever:
“D” position 10 − 16 V
Other than the above 0 V
5
(BR) Ground N position switch Input Selector lever:
“N” position 10 − 16 V
Other than the above 0 V
6
(L) Ground R position switch Input Selector lever:
“R” position 10 − 16 V
Other than the above 0 V
7
(V) Ground P position switch Input Selector lever:
“P” position 10 − 16 V
Other than the above 0 V
11
(Y) Ground Sensor ground Input Always 0 V
12
(V) Ground CVT fluid tempera-
ture sensor OutputIgnition
switch
ON CVT fluid: Approx. 20
°C
(68 °F) 2.01 – 2.05 V
CVT fluid: Approx. 50 °C
(122 °F) 1.45 – 1.50 V
CVT fluid: Approx. 80 °C
176 °F) 0.90 – 0.94 V
16
(Y) Ground
Secondary pres-
sure sensor Input
• Selector lever: “N” position
• At idle 1.67 – 1.69 V
17
(LG) Ground Primary pressure
sensor Input• Selector lever: “N” position
• At idle 0.90 – 0.92 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TM-54
< ECU DIAGNOSIS INFORMATION >[CVT: RE0F10D]
TCM
23
(P) —CAN-L
Input/
Output ——
24
(BR) Ground Input speed sensor Input • Selector lever:
“DS” position
• Vehicle speed: 20 km/h (12 MPH) 880 Hz
26
(LG) Ground Sensor power sup-
ply OutputIgnition switch: ON 5.0 V
Ignition switch: OFF 0 V
30
(BR) Ground Line pressure sole-
noid valve Output• After engine warming up
• Selector lever: “N” position
• At idle
• After engine warming up
• Selector lever: “N” position
• Depress the acce lerator pedal fully
33
(L) —CAN-H
Input/
Output ——
34
(V) Ground Output speed sen-
sor Input• Selector lever:
“DS” position
• Vehicle speed: 20 km/h (12 MPH) 200 Hz
35
(BR) Ground
Primary speed sen-
sor Input
• Selector lever:
“DS” position
• Vehicle speed: 20 km/h (12 MPH) 700 Hz
Te r m i n a l N o .
(Wire color) Description
Condition Value (Approx.)
+ − Signal Input/
Output
JSDIA3769GB
JSDIA1897GB
JSDIA1898GB
JSDIA1904GB
JSDIA1905GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TCM
TM-55
< ECU DIAGNOSIS INFORMATION > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P37
(Y) Ground
Select solenoid
valve OutputIn driving at “DS” position
Release the accelerator pedal after
the following conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 50 km/h (31 MPH) or more
38
(BR) Ground Torque converter
clutch solenoid
valve Output• Selector lever: “D” position
• Accelerator pedal position: 1/8 or
less
• Vehicle speed: 20 km/h (12 MPH) or more
• Engine started
• Vehicle is stopped
39
(L) Ground Secondary pres-
sure solenoid valve Output• Selector lever: “DS” position
• Vehicle speed: 20 km/h (12 MPH)
40
(LG) Ground
Primary pressure
solenoid valve Output
• Selector lever: “DS” position
• Vehicle speed: 20 km/h (12 MPH)
41
(B) Ground Ground Output Always 0 V
42
(B) Ground Ground Output Always 0 V
45
(P) Ground
Battery power sup-
ply (backup) Input Always 10
− 16 V
Te r m i n a l N o .
(Wire color) Description
Condition Value (Approx.)
+ − Signal Input/
OutputJSDIA1897GB
JSDIA1899GB
JSDIA1900GB
JSDIA1903GB
JSDIA1897GB
JSDIA1897GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
