NISSAN TEANA 2014 Workshop Manual

BCS-36
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
TERMINAL LAYOUT
PHYSICAL VALUES
AWMIA1310ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS
BCM (BODY CONTROL MODULE)BCS-37
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
(+) (-)
1
(R) Ground Engine start switch Input Push-button igni-
tion switch Pressed 0V
Not pressed Battery voltage
3
(BR) Ground Auto light power sup-
ply 5V OutputPush-button igni-
tion switch OFF 0V
ACC or ON 5V
4
(Y) Ground Auto light signal Input
Push-button igni-
tion switch ON When outside of the vehi-
cle is bright Close to 5V
When outside of the vehi-
cle is dark Close to 0V
10
(W) Ground Combination switch
input 5 InputCombination
switch
(Wiper intermit-
tent dial 4) OFF 0V
TURN RH
1.0V
HEADLAMP 1
HI BEAM
TA I L L A M P
11
(BG) Ground Combination switch
input 4 InputCombination
switch
(Wiper intermit-
tent dial 4) OFF 0V
TURN LH
1.0V
PASSING
HEADLAMP 2
FR FOG
12
(W) Ground Combination switch
input 3 InputCombination
switch
(Wiper intermit-
tent dial 4) OFF 0V
FR WIPER LOW
1.0V
FR WIPER INT/AUTO
AUTO LIGHT
13
(G) Ground Combination switch
input 2 InputCombination
switch
(Wiper intermit-
tent dial 4) OFF 0V
FR WASHER
1.0V
INT VOLUME 3
PKIB4958J
PKIB4958J
PKIB4958J
PKIB4958J
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS-38
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
14
(P) Ground Combination switch
input 1 InputCombination
switch
(Wiper intermit-
tent dial 4) OFF 0V
FR WIPER HI
1.0V
INT VOLUME 1
INT VOLUME 2
17
(B) Ground Auto light reference
ground Input Push-button ignition switch ON 0V
18
(G) Ground Security indicator Output Security indicator ON 0V
Blinking 11 . 3 V
OFF Battery voltage
19
(G) Ground Lock switch signal Input
Door lock/unlock
switch Lock Battery voltage
Unlock 0V
20
(W) Ground Shift P Input Selector lever P position 0V
Any position other than P Battery voltage
21
(W) Ground Step lamp control Output Step lamp ON 0V
OFF Battery voltage
23
(L) Ground
Compressor ON sig-
nal Input A/C switch OFF 9.0 - 12.0V
ON 0V
24
(G) Ground Front door lock as-
sembly LH (key cylin-
der switch) Input
Key cylinder
switch OFF (neutral) 5V
ON (unlock) 0V
25
(BG) Ground Brake switch fuse Input — Battery voltage
26
(Y) Ground Shorting input Input Push-button ignition switch OFF Battery voltage
27
(G) Ground Brake switch lamp Input Stop lamp switch OFF (brake pedal is not de-
pressed) 0V
ON (brake pedal is de-
pressed) Battery voltage
29
(Y) Ground Front blower monitor Input
Front blower mo-
tor switch ON Battery voltage
OFF 0V
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
(+) (-)
PKIB4958J
JPMIA0014GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS
BCM (BODY CONTROL MODULE)BCS-39
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N30
(P) Ground Driver door lock sta-
tus Input Front door LH LOCK status
11 . 8 V
UNLOCK status 0V
32
(Y) Ground
Rear window defog-
ger ON signal Input
Rear window de-
fogger switch OFF 5V
ON 0V
33
(G) Ground Trunk lid opener can-
cel switch InputTrunk lid opener
cancel switch CANCEL
1.1V
ON 0V
34
(BG) Ground Unlock switch signal Input Door lock/unlock
switch Unlock Battery voltage
Lock 0V
36
(Y) Ground Hazard switch Input Hazard switch Pressed 0V
Not pressed
1.1V
39
(L) Ground Shift N/P Input Selector lever P or N position Battery voltage
Except P and N positions 0V
48
(BR) Ground
High side start switch
LED OutputPush-button igni-
tion switch illumi-
nation ON 5.5V
OFF 0V
52
(G) Ground Audio dongle
Input/
Output Push-button ignition switch OFF 5V
54
(P) Ground
Power window link/
communication Input/
Output Push-button igni-
tion switch ON
10.2V
OFF or ACC 0V
59
(P) Ground CAN low
Input/
Output ——
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
(+) (-)
JPMIA0011GB
JPMIA0012GB
JPMIA0012GB
JPMIA0013GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS-40
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
60
(L) Ground CAN high Input/
Output ——
61
(Y) Ground Rear defogger relay
output OutputRear window de-
fogger Active Battery voltage
Not activated 0V
62
(BR) Ground Starter relay output Output
Push-button igni-
tion switch ON When selector lever is in P
or N position and the brake
is depressed Battery voltage
When selector lever is in P
or N position and the brake
is not depressed 0V
64
(W) Ground Buzzer output Output Outside warning
buzzer Sounding 0V
Not sounding Battery voltage
66
(R) Ground Blower fan relay out-
put OutputPush-button igni-
tion switch OFF or ACC 0V
ON Battery voltage
67
(W) Ground Ignition electrical re-
lay output 2 OutputPush-button igni-
tion switch OFF or ACC 0V
ON Battery voltage
68
(P) Ground Dimmer signal output Output
Push-button igni-
tion switch ON Either of the following con-
ditions
• Lighting switch OFF
• The area around the ve- hicle is bright (Shine a
light on the optical sen-
sor) 0V
The area around the vehi-
cle is dark (Block the light
from the optical sensor) Battery voltage
69
(L) Ground CVT device output Output — Battery voltage
70
(G) Ground IPDM E/R ignition
output 1 OutputPush-button igni-
tion switch OFF or ACC 0V
ON Battery voltage
71
(V) Ground Driver request switch Input
Front door LH re-
quest switch ON (pressed) 0V
OFF (not pressed) 1.0V
72
(Y) Ground Passenger request
switch InputFront door RH re-
quest switch ON (pressed) 0V
OFF (not pressed) 1.0V
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
(+) (-)
JPMIA0016GB
JPMIA0016GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS
BCM (BODY CONTROL MODULE)BCS-41
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
74
(P) Ground Front door lock as-
sembly LH (key cylin-
der switch) (lock) InputFront door lock
assembly LH (key
cylinder switch) OFF (neutral) 5V
ON (lock) 0V
75
(BG) Ground Combination switch
output 5 OutputCombination
switch
(Wiper intermit-
tent dial 4) OFF
7.0 – 8.0V
INT VOLUME 2
1.2V
FR FOG
76
(W) Ground Combination switch
output 4 OutputCombination
switch
(Wiper intermit-
tent dial 4) OFF
7.0 – 8.0V
INT VOLUME 3
1.2V
AUTO LIGHT
TA I L L A M P
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
(+) (-)
PKIB4960J
PKIB4958J
PKIB4960J
PKIB4958J
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS-42
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
77
(R) Ground
Combination switch
output 3 OutputCombination
switch
(Wiper intermit-
tent dial 4) OFF
7.0 – 8.0V
INT VOLUME 1
1.2V
HEADLAMP 2
HI BEAM
78
(P) Ground Combination switch
output 2 OutputCombination
switch
(Wiper intermit-
tent dial 4) OFF
7.0 – 8.0V
FR WIPER HI
1.2V
FR WIPER INT/AUTO
PASSING
HEADLAMP 1
79
(G) Ground Combination switch
output 1 OutputCombination
switch
(Wiper intermit-
tent dial 4) OFF
7.0 – 8.0V
FR WASHER
1.2V
FR WIPER LOW
TURN LH
TURN RH
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
(+) (-)
PKIB4960J
PKIB4958J
PKIB4960J
PKIB4958J
PKIB4960J
PKIB4958J
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS
BCM (BODY CONTROL MODULE)BCS-43
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
80
(BR) Ground Trunk open switch Output trunk Open (trunk actuator is ac-
tivated) Battery voltage
Close (trunk actuator is not
activated) 0V
82
(Y) Ground Left rear door switch Input Rear door LH
switch OFF (when rear door LH
closes)
11 . 8 V
ON (when rear door LH
opens) 0V
85
(BG) Ground Trunk room lamp Output Trunk room lamp ON 0V
OFF Battery voltage
91
(V) Ground Trunk lid opening Output Trunk lid Open (trunk lid opener ac-
tuator is activated) Battery voltage
Close (trunk lid opener ac-
tuator is not activated) 0V
92
(LG) Ground Right rear flasher Output
Push-button igni-
tion switch ON Turn signal switch OFF 0V
Turn signal switch RH 6.5 V
93
(V) Ground Right rear door
switch InputRear door RH
switch OFF (when rear door RH
closes)
11 . 8 V
ON (when rear door RH
opens) 0V
94
(SB) Ground Passenger door
switch InputFront door RH
switch OFF (when front door RH
closes)
11 . 8 V
ON (when front door RH
opens) 0V
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
(+) (-)
JPMIA0011GB
PKID0926E
JPMIA0011GB
JPMIA0011GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS-44
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
96
(BR) Ground Driver door switch Input Front door LH
switch OFF (front door LH
CLOSE)
11 . 8 V
ON (front door LH OPEN) 0V
97
(SB) Ground Trunk switch Input Trunk switch OFF (trunk is closed)
11 . 8 V
ON (trunk is open) 0V
99
(G) Ground Rear parcel shelf an-
tenna B OutputPush-button igni-
tion switch OFF When Intelligent Key is in
the passenger compart-
ment
When Intelligent Key is not
in the passenger compart-
ment
100 (R) Ground Rear parcel shelf an-
tenna A OutputPush-button igni-
tion switch OFF When Intelligent Key is in
the passenger compart-
ment
When Intelligent Key is not
in the passenger compart-
ment
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
(+) (-)
JPMIA0011GB
JPMIA0011GB
JMKIA0062GB
JMKIA0063GB
JMKIA0062GB
JMKIA0063GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS
BCM (BODY CONTROL MODULE)BCS-45
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
101
(G) Ground
Rear bumper anten-
na B OutputWhen the trunk
request switch is
operated with
push-button igni-
tion switch OFF When Intelligent Key is in
the antenna detection area
When Intelligent Key is not
in the antenna detection
area
102 (W) Ground Rear bumper anten-
na A OutputWhen the trunk
request switch is
operated with
push-button igni-
tion switch OFF When Intelligent Key is in
the antenna detection area
When Intelligent Key is not
in the antenna detection
area
103 (Y) Ground Left rear flasher Output
Push-button igni-
tion switch ON Turn signal switch OFF 0V
Turn signal switch LH 6.5 V
104
(BR) Ground Reverse lamp output Output
Push-button igni-
tion switch ON R position
6.5V
Any position other than R 0V
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
(+) (-)
JMKIA0062GB
JMKIA0063GB
JMKIA0062GB
JMKIA0063GB
PKID0926E
PKID0926E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
