NISSAN TIIDA 2007 Service Owner's Guide

AV-26
< ON-VEHICLE REPAIR >[AUDIO WITHOUT NAVIGATION]
REAR DOOR SPEAKER
REAR DOOR SPEAKER
Removal and InstallationINFOID:0000000001724679
REAR DOOR SPEAKER
Removal
1. Remove the rear door finisher. Refer to INT-13, "Removal and Installation".
2. Remove the rear door finisher screws (A), disconnect the con-
nector and remove the rear door speaker (1).
Installation
Installation is in the reverse order of removal.
SKIB4729E

AV
STEERING SWITCH
AV-27
< ON-VEHICLE REPAIR >[AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
STEERING SWITCH
Removal and InstallationINFOID:0000000001724685
STEERING WHEEL BLUETOOTH CONTROL SWITCH
Removal
1. Remove the steering wheel. Refer to ST-8, "Removal and Installation".
2. Remove the steering wheel finisher cover.
3. Remove the screws and the steering wheel Bluetooth control switch.
Installation
Installation is in the reverse order of removal.
1. Steering wheel finisher cover 2. Steering wheel 3. Steering wheel Bluetooth control
switch
A. Screws
AWNIA0257ZZ

AV-28
< ON-VEHICLE REPAIR >[AUDIO WITHOUT NAVIGATION]
AUDIO ANTENNA
AUDIO ANTENNA
Location of AntennaINFOID:0000000001724655
Removal and Installation of Roof AntennaINFOID:0000000001724656
REMOVAL
1. For hatchback, remove the luggage side upper finisher (LH). Refer to INT-35, "Removal and Installation".
2. For sedan, remove the rear pillar finisher. Refer to INT-33, "
Removal and Installation - Sedan".
3. Remove rear assist grip (LH). Refer to INT-33, "
Removal and Installation - Sedan".
4. Remove three clips of headlining (rear side). Pull down headlining (rear side) and obtain space for work
between vehicle and headlining.
5. Disconnect the roof antenna harness connectors.
LKIA0942E
1. Roof antenna 2. Roof antenna base 3. Audio unit
A. Audio antenna harness connector B. Harness clips C. Roof antenna harness connectors

AV
AUDIO ANTENNA
AV-29
< ON-VEHICLE REPAIR >[AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
6. Remove nut (A) and clips (B).
7. Remove the roof antenna.
INSTALLATION
Installation is in the reverse order of removal.
SKIB4772E

AV-30
< BASIC INSPECTION >[AUDIO WITH NAVIGATION]
DIAGNOSIS AND REPAIR WORKFLOW
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORKFLOW
Work FlowINFOID:0000000001728626
OVERALL SEQUENCE
 Reference 1··· Refer to AV-48, "CONSULT - III Function (MULTI AV)".
 Reference 2··· Refer to AV-108, "
Symptom Table".
DETAILED FLOW
1.CHECK SYMPTOM
Check the malfunction symptoms by performing the following items.
 Interview the customer to obtain the malfunction information (conditions and environment when the malfunc-
tion occurred).
 Check the symptom.
>> GO TO 2
2.SELF-DIAGNOSIS (CONSULT-III)
1. Connect CONSULT-III and perform a self-diagnosis for “MULTI AV”.
NOTE:
Skip to step 4 of the diagnosis procedure if “MULTI AV” is not displayed.
2. Check that any DTC No. is displayed in the self-diagnosis results.
JSNIA0039GB

AV
DIAGNOSIS AND REPAIR WORKFLOW
AV-31
< BASIC INSPECTION >[AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Is any DTC No. displayed?
YES >> GO TO 3
NO >> GO TO 4
3.CHECK SELF-DIAGNOSIS RESULTS (CONSULT-III)
1. Check the DTC No. indicated in the self-diagnosis results.
2. Perform the relevant diagnosis referring to the DTC Index. Refer to AV-103, "
DTC Index".
NOTE:
Start with the diagnosis for the CAN communication system if “CAN COMM CIRCUIT [U1000] and CONTROL
UNIT CAN [U1010]” is displayed.
>> GO TO 5
4.PERFORM DIAGNOSIS BY SYMPTOM
Perform the relevant diagnosis referring to the diagnosis chart by symptom. Refer to AV-108, "
Symptom
Table".
>> GO TO 5
5.REPAIR OR REPLACE MALFUNCTIONING PARTS
Repair or replace the identified malfunctioning parts.
NOTE:
Erase the stored self-diagnosis results after repairing or replacing the relevant components if any DTC No. has
been indicated in the self-diagnosis results.
>> GO TO 6
6.CHECK AFTER REPAIR
1. Perform a self-diagnosis for “MULTI AV” with CONSULT-III after repairing or replacing the malfunctioning
parts.
2. Check that any DTC No. is displayed in the self-diagnosis results.
Is any DTC No. displayed?
YES >> GO TO 3
NO >> GO TO 7
7.FINAL CHECK
Perform the operation to check that the malfunction symptom is solved or any other symptoms are present.
Is there any symptom?
YES >> GO TO 4
NO >> INSPECTION END.

AV-32
< FUNCTION DIAGNOSIS >[AUDIO WITH NAVIGATION]
MULTI AV SYSTEM
FUNCTION DIAGNOSIS
MULTI AV SYSTEM
System DiagramINFOID:0000000001728627
System DescriptionINFOID:0000000001728628
Multi AV system means that the following systems are integrated.
 Two AV communication lines (H, L) connect between units that configure MULTI AV system. NAVI control
unit controls by sending/receiving data one by one with each unit (slave unit) that configures them com-
pletely as a master unit.
 Two AV communication lines (H, L) adopt a twisted pair line that is resistant to noise.
 NAVI control unit is connected by CAN communication, and it receives data signal from ECM, combination
meter. It computes and displays fuel economy information value with the obtained information. Sending/
receiving of data signal is performed by BCM. Also, it sends the required signal of vehicle setting and
receives the response signal.
ALNIA0882GB
System name System explanation
NAVIGATION SYSTEMAV- 3 5 , "
System Description"
AUDIO SYSTEMXX-XX, "*****"
VEHICLE INFORMATION SYSTEM Status of audio, fuel economy, maintenance and navigation is
displayed.
 NAVI control unit displays the fuel consumption status and trip
computer status while receiving data signal through CAN com-
munication from ECM, combination meter and BCM.
HANDS-FREE PHONE SYSTEM Refer to the following “HANDS-FREE PHONE SYSTEM”.

AV
MULTI AV SYSTEM
AV-33
< FUNCTION DIAGNOSIS >[AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
 NAVI control unit is connected with display and serial communication, and it sends the required signal of dis-
play and display control and receives the response signal from front display. Also, it is connected with satel-
lite radio by serial communication, and it sends the operating signal and receives the display signal.
NOTE:
NAVI control unit can perform CONSULT-III self-operating function and on board self-diagnosis.
 CONSULT-III self diagnosis: Refer to AV-48, "
CONSULT - III Function (MULTI AV)".
 On board self diagnosis: Refer to AV-39, "
Diagnosis Description".
HANDS-FREE PHONE SYSTEM
 Hands-free communication can be operated by connecting using Bluetooth® with cellular phone.
 Operation is performed by steering switch, and operating condition is indicated on display.
 Guide sound that is heard during operation is input from NAVI control unit to audio unit and is output from
front speaker.
When a call is originated
Spoken voice sound output from the microphone (Mic. Signal) is input to NAVI control unit. NAVI control unit
outputs to cellular phone with Bluetooth
® communication as a TEL voice signal. Voice sound is then heard at
the other party.
When receiving a call
Voice sound is input to own cellular phone from the other party. TEL voice signal is output to front speaker, and
the signal is input to audio unit via NAVI control unit by establishing Bluetooth
® communication from cellular
phone.
Component Parts LocationINFOID:0000000001728629
1. AV control unit M43, M44 2. Display unit M100 3. Navi control unit B68, B69
ALNIA0891GB

AV-34
< FUNCTION DIAGNOSIS >[AUDIO WITH NAVIGATION]
MULTI AV SYSTEM
Component Description
INFOID:0000000001728630
4. Front door speaker
Driver side D12
Passenger side D1125. Rear door speaker
LH D207
RH D3076. Front tweeter
LH M109
RH M47
7. Steering wheel audio control switch-
es M1028. Microphone R15
Part name Description
NAVI CONTROL UNIT Map data can be read from the Map DVD-ROM by installing Map DVD-ROM.
 It is the master unit of the MULTI AV system, and it is connected to each con-
trol unit by means of communication. It operates each system according to
communication signals from the NAVI control unit.
 The NAVI control unit includes the audio, hands-free phone, navigation, and
vehicle information functions.
 It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
 It inputs the illumination signals that are required for the display dimming con-
trol.
 It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
MAP DVD-ROM A collection of Map data.
DISPLAY UNIT Display image is controlled by the serial communication from NAVI control
unit.
 RGB image signal is input from NAVI control unit (RGB, RGB area and RGB
synchronizing). Camera image signal is input from camera control unit.
 Synchronize signal (HP, VP) is output to NAVI control unit.
AV CONTROL UNIT Operational switch of MULTI AV system is integrated.
 NAVI control unit and AV communication are connected with AV control unit.
Operating signals of the switch are sent to the NAVI control unit.
FRONT DOOR SPEAKER Outputs sound signal from AV control unit.
 Outputs high, mid and low range sounds.
REAR DOOR SPEAKER Outputs sound signal from AV control unit.
 Outputs high, mid and low range sounds.
FRONT TWEETER Outputs sound signal from AV control unit.
 Outputs high range sound.
STEERING WHEEL AUDIO CONTROL SWITCH Operations for audio, hands-free phone, voice recognition and navigation,
etc. are possible.
 Steering switch signal (operation signal) is output to AV control unit.
MICROPHONE Used for hands-free phone operation and voice recognition.
 Mic. signal is sent to NAVI control unit.
 Power (Mic. VCC) is supplied from NAVI control unit.
GPS ANTENNA GPS signal is received and sent to NAVI control unit.
RADIO ANTENNA Radio signal received by antenna is sent to AV control unit.

AV
NAVIGATION SYSTEM
AV-35
< FUNCTION DIAGNOSIS >[AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NAVIGATION SYSTEM
System DiagramINFOID:0000000001728631
System DescriptionINFOID:0000000001728632
NAVIGATION SYSTEM
Location Detection Principle
The navigation system periodically calculates the vehicle's current
position according to the following three signals:
 Travel distance of the vehicle as determined by the vehicle speed
sensor
 Turning angle of the vehicle as determined by the gyroscope
(angular velocity sensor)
 Direction of vehicle travel as determined by the GPS antenna
(GPS information)
The current position of the vehicle is then identified by comparing the
calculated vehicle position with map data read from the map DVD-
ROM, which is stored in the DVD-ROM drive (map-matching), and
indicated on the screen as a vehicle mark. More accurate data is
judged and used by comparing vehicle position detection results found by the GPS with the result by map-
matching.
The current vehicle position will be calculated by detecting the dis-
tance the vehicle moved from the previous calculation point and its
direction.
 Travel distance
Travel distance calculations are based on the vehicle speed sen-
sor input signal. Therefore, the calculation may become incorrect
as the tires wear down. To prevent this, an automatic distance cor-
rection function has been adopted.
 Travel direction
Change in the travel direction of the vehicle is calculated by a gyro-
scope (angular velocity sensor) and a GPS antenna (GPS informa-
tion). They have both advantages and disadvantages.
JPNIA0157GB
SKIB1058E
SEL684V
