NISSAN TIIDA 2007 Service Repair Manual

REAR WIPER MOTOR
WW-79
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
Clearance "L" is between the edge of the back door glass and the tip
of the rear wiper blade as shown.
L : 26.5±10.3 mm (1.04 ± 0.406 in)
JPLIA0289ZZ

WW-80
< ON-VEHICLE REPAIR >
REAR WASHER NOZZLE AND TUBE
REAR WASHER NOZZLE AND TUBE
Washer Tube LayoutINFOID:0000000001366677
NOTE:
Connect the check valve (2) to the washer fluid tube (1) so that the
directional arrow on the check valve (2) points towards the washer
nozzle tube (3).
Removal and InstallationINFOID:0000000001366678
REAR WASHER NOZZLE
Removal
1. Remove the back door window garnish. Refer to XX-XX, "*****".
2. Disconnect rear washer tube from rear washer nozzle.
3. Release retaining clips and remove washer nozzle.
Installation
1 Washer fluid reservoir 2 Washer fluid tube to rear door 3 Rear washer nozzle
4Check valve
LKIA0790E
WKIA4242E
LKIA0545E

REAR WASHER NOZZLE AND TUBE
WW-81
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
Installation is in the reverse order of removal.
NOTE:
Inspect rear washer nozzle for proper spray pattern, adjust as necessary. Refer to XX-XX, "*****"
.
AdjustmentINFOID:0000000001366679
 Adjust the washer nozzle (1) to specification (A) using suitable tool
as shown.
 Washer nozzle (1)
 Washer spray area (A)
 Black print area (B)
 Wiping area edge (C)
 30 mm (1.18 in) (D)
 161 mm (6.34 in) (E)
AWLIA0142ZZ
AWLIA0143ZZ
