height adjustment PEUGEOT 206 2002 Owners Manual
[x] Cancel search | Manufacturer: PEUGEOT, Model Year: 2002, Model line: 206, Model: PEUGEOT 206 2002Pages: 160, PDF Size: 2.03 MB
Page 2 of 160

3YOUR 206 AT A GLANCE
1Side window demisting vents
2 Adjustable side vent
3 Passenger air bag
4 Windscreen demisting vents
5 Multifunction display
6 Central locking switch
7 Hazard warning lights switch
8 Instrument dials lighting rheostat
9 Lights and direction indicators stalk
10 Steering wheel height adjustment control 11
Steering lock
12 Windscreen wiper stalk
13 Driver's air bag Horn
14 Audio equipment remote control
15 Headlamp height adjustment
16 Passenger air bag disarmingswitch*
17 Rear window locking switch
18 Storage compartment
19 Fuse box
20 Gear lever
21 Lighter 22
Alarm button
23 Front electric window switches
24 Electric mirrors switch
25 Handbrake
26 Front ashtray
27 Controls for heating, ventilation, air conditioningand heated rear screen and mirrors
28 Audio equipment
29 Adjustable centre vents
30 Glove box
31 Bonnet opening control
* According to destination.
17-06-2002
Page 13 of 160

9788
13YOUR 206 AT A GLANCE
STEERING WHEEL HEIGHT ADJUSTMENT
When stationary, lower the hand- le to unlock the steering wheel. Adjust to the desired height and lift the handle to lock the steeringwheel.OPENING THE BONNET From inside the vehicle :
pull
the handle. From the outside:
lift the catch
and raise the bonnet. Secure the strut to hold the bonnet open.
17-06-2002
Page 74 of 160

YOUR 206 IN DETAIL73
The adjustment is correct when the upper edge of thehead restraint is level withthe top of the head.
The head restraint is fitted with aframe with notches, which pre-vent the head restraint droppingdown (this is a safety device inthe case of impact).
To lower the head restraint, it is necessary to push simultaneously:
Ð the button located at the base of the head restraint frame,
Ð the head restraint downwards.
To remove the head restraint, press the lug.
Never drive with thehead restraints removed;they should be in placeand correctly adjusted. Rear head restraints These have one position for when they are being used (high) and a
storage position (low). They canbe removed.
To lower the head restraints, press the lug.
To remove them, pull upwards as far as the stop then press therelease control.
FRONT SEATS
1. Forwards-backwards
adjustment Lift the control and slide the seat forwards or backwards.
2. Access to rear seats (3 door) Place your fingers in one of the two handles and push forwards tofold the seat back and move theseat forwards. On repositioning,the seat returns to its initial posi-tion. It is impossible to access the rear seats if the front seat is in thereclining position.
3. Seat back angle adjustment Push one of the two handles
towards the rear.
4. Seat height adjustment Pull the handle upwards. Remove your weight from the seat to raise, or press on the seat
to lower.
5. Head restraint height adjustment
To raise the restraint, push it upwards. Press the switch again to stop operation.
17-06-2002
Page 77 of 160

YOUR 206 IN DETAIL73
The adjustment is correct when the upper edge of thehead restraint is level withthe top of the head.
The head restraint is fitted with aframe with notches, which pre-vent the head restraint droppingdown (this is a safety device inthe case of impact).
To lower the head restraint, it is necessary to push simultaneously:
Ð the button located at the base of the head restraint frame,
Ð the head restraint downwards.
To remove the head restraint, press the lug.
Never drive with thehead restraints removed;they should be in placeand correctly adjusted. Rear head restraints These have one position for when they are being used (high) and a
storage position (low). They canbe removed.
To lower the head restraints, press the lug.
To remove them, pull upwards as far as the stop then press therelease control.
FRONT SEATS
1. Forwards-backwards
adjustment Lift the control and slide the seat forwards or backwards.
2. Access to rear seats (3 door) Place your fingers in one of the two handles and push forwards tofold the seat back and move theseat forwards. On repositioning,the seat returns to its initial posi-tion. It is impossible to access the rear seats if the front seat is in thereclining position.
3. Seat back angle adjustment Push one of the two handles
towards the rear.
4. Seat height adjustment Pull the handle upwards. Remove your weight from the seat to raise, or press on the seat
to lower.
5. Head restraint height adjustment
To raise the restraint, push it upwards. Press the switch again to stop operation.
17-06-2002
Page 84 of 160

YOUR 206 IN DETAIL
82
SEAT BELTS Seat belt height adjustment:
Ð to lower: pull the control and slideit downwards.
Ð to raise: slide the control upwards. To lock the seat beltsPull the strap, then insert the end into the buckle. Front seat belts with pre- tensioner and force limiter Safety in the event of front impacts has been improved by the introduc-tion of seat belts with pre-tensionerand force limiter for the front seats.Depending on the seriousness ofthe impact, the pre-tensioning sys-tem instantly tightens the seat beltsand pulls them against the bodies ofthe occupants. The pre-tensioning seat belts are active when the ignition is on. The force limiter eases the pressure of the seat belt on the body of theoccupant in the event of an acci-dent. Rear seat belts The rear seats are fitted with two three-point inertia reel seat beltsand a lap belt (one-piece rear seat)or with three three-point inertia reelseat belts (two-part rear seat, 1/3 -2/3).
To be effective, a seat belt must be tightenedas close to the body aspossible.
Depending on the nature andseriousness of the impact, thepre-tensioning system may betriggered before and indepen-dently of the air bags. In all cases, the air bag warning light on the instrument panelcomes on. Following an impact, have the system checked by a PEUGEOT
dealer. The system has been designed to be fully operational for tenyears. Have it replaced at the end of this period.
17-06-2002
Page 106 of 160

YOUR 206 IN DETAIL97
HEADLAMP ADJUSTMENT Depending on the load in your vehicle, it is recommended that theheadlamp beam is adjusted. 0. 1 or 2 people in the front seats.
Ð. 3 people.
1. 5 people.
2. 5 people + maximum authorised load.
3. Driver + maximum authorisedload.
Initial setting is position 0.
STEERING WHEEL HEIGHT ADJUSTMENT
When stationary, lower the handle to unlock the steering wheel. Adjust to the desired height and lift the handle to lock the steeringwheel. HORN
Press one of the spokes orthe centre of the steeringwheel.
17-06-2002
