PEUGEOT 206 2002 Owners Manual
Manufacturer: PEUGEOT, Model Year: 2002, Model line: 206, Model: PEUGEOT 206 2002Pages: 160, PDF Size: 2.03 MB
Page 1 of 160
2YOUR 206 AT A GLANCE
17-06-2002
Page 2 of 160
3YOUR 206 AT A GLANCE
1Side window demisting vents
2 Adjustable side vent
3 Passenger air bag
4 Windscreen demisting vents
5 Multifunction display
6 Central locking switch
7 Hazard warning lights switch
8 Instrument dials lighting rheostat
9 Lights and direction indicators stalk
10 Steering wheel height adjustment control 11
Steering lock
12 Windscreen wiper stalk
13 Driver's air bag Horn
14 Audio equipment remote control
15 Headlamp height adjustment
16 Passenger air bag disarmingswitch*
17 Rear window locking switch
18 Storage compartment
19 Fuse box
20 Gear lever
21 Lighter 22
Alarm button
23 Front electric window switches
24 Electric mirrors switch
25 Handbrake
26 Front ashtray
27 Controls for heating, ventilation, air conditioningand heated rear screen and mirrors
28 Audio equipment
29 Adjustable centre vents
30 Glove box
31 Bonnet opening control
* According to destination.
17-06-2002
Page 3 of 160
83
4YOUR 206 AT A GLANCE
KEYS The keys enable you to switch on the ignition, independently ope-rate the locks on the front doorsand the tailgate (saloon) as wellas operating the passenger airbag disarming switch and thefuel filler flap. Central locking
From the driver's door, you can lock and unlock the doors andthe boot. If one of the doors, the boot (206 SW) or the rear screen (206 SW) is open, the centrallocking will not work.Remote control Pressing button
Ato remotely
lock the vehicle. This is confirmed by fixed lighting of the direction indicators forapproximately two seconds. Pressing button Bto remotely
unlock the vehicle. This is confirmed by rapid fla- shing of the direction indicatorsfor approximately two seconds. 206 SW : press and hold button
B to unlock the vehicle and open
the rear screen. Leaving the ignition key in If you leave the key in the igni- tion, a buzzer reminds you of this
when opening the driver's door. Locating the vehicle
To locate your vehicle, when you have left it locked in a car park: press button A, the courtesy
lights will switch on and the indicator lights flash for a fewseconds. STARTING The 4 positions of the key in the ignition:
STOP position:
The ignition is
off.
1st notch, Accessories posi- tion: The ignition is off but the
accessories can be used. 2nd notch, Running position: The ignition is on. Starting position: Operates the
starter. Steering lock Before starting, unlock the stee-
ring if necessary, by gently tur-ning the steering wheel at the
same time as you turn the key. It is advisable to press the clutch pedal while operating the starter
to make starting easier.
17-06-2002
Page 4 of 160
83
4YOUR 206 AT A GLANCE
KEYS The keys enable you to switch on the ignition, independently ope-rate the locks on the front doorsand the tailgate (saloon) as wellas operating the passenger airbag disarming switch and thefuel filler flap. Central locking
From the driver's door, you can lock and unlock the doors andthe boot. If one of the doors, the boot (206 SW) or the rear screen (206 SW) is open, the centrallocking will not work.Remote control Pressing button
Ato remotely
lock the vehicle. This is confirmed by fixed lighting of the direction indicators forapproximately two seconds. Pressing button Bto remotely
unlock the vehicle. This is confirmed by rapid fla- shing of the direction indicatorsfor approximately two seconds. 206 SW : press and hold button
B to unlock the vehicle and open
the rear screen. Leaving the ignition key in If you leave the key in the igni- tion, a buzzer reminds you of this
when opening the driver's door. Locating the vehicle
To locate your vehicle, when you have left it locked in a car park: press button A, the courtesy
lights will switch on and the indicator lights flash for a fewseconds. STARTING The 4 positions of the key in the ignition:
STOP position:
The ignition is
off.
1st notch, Accessories posi- tion: The ignition is off but the
accessories can be used. 2nd notch, Running position: The ignition is on. Starting position: Operates the
starter. Steering lock Before starting, unlock the stee-
ring if necessary, by gently tur-ning the steering wheel at the
same time as you turn the key. It is advisable to press the clutch pedal while operating the starter
to make starting easier.
17-06-2002
Page 5 of 160
107
5YOUR 206 AT A GLANCE
Never race a coldengine.
Never run the enginein a confined space.
Do not make any modificationsto the steering lock.
Starting a petrol engine
Do not press the accelerator.
Operate the starter, without
releasing the key, until the engi-ne turns.Starting a dieselengine Do not press the acce-
lerator.
Turn the key to the ''Running''
position. If the engine is warm enough, the pre-heat light does not come
on and you can start immediately. If the pre-heat light comes on, wait for it to go out before opera-
ting the starter. If the engine stalls, it is necessa- ry to return the key to the
''STOP'' position before restar-
ting. FRONT AIR BAGS
Precautions regarding thepassenger air bag For a vehicle fitted with a disar- ming switch :Ð disarm theair bag ifyou install arear-facingchild seat,
Ð arm the air bag for anadult pas-
senger.
For a vehicle not fitted with adisarming switch: Ð do not ins-tall a rear-facing childseat on thefront pas-senger seat.
In no circumstances should youplace your feet or any otherobject on the fascia.
Operating check
* According to destination.
Disarming the passenger air bag* Insert the ignition key in the switch 1
and turn it to:
Ð the ''ON'' position, the passen-
ger air bag is armed,
Ð the ''OFF'' position, the pas-
senger air bag is disarmed.
With the ignition on (2nd notchof the ignition), illumination ofthis warning light, accompaniedby an audible signal and themessage "Passenger air bag
disarmed" on the multi-function
display, indicates that the passenger air bag is disarmed(switch in the "OFF"position).
The warning light remains onthroughout the disarming process.
17-06-2002
Page 6 of 160
8991
8YOUR 206 AT A GLANCE
STEERING WHEEL CONTROLS Lights Front and rear lights(ring A)
Lights off Side lights Dipped / main beam headlamps Automatic switching on of lights
Automatic switching on of lights
To activate or deactivate the function, place the key in theaccessories position, with thelights stalk in position 0and
press the end of the stalk formore than four seconds. Rear fog lamp
(ring B)
Rear fog lamp (rotation of the ring forwards)
Front fog lamps / Rear fog lamp(ring C)
Front fog lamps (1st rotation of the ringforwards)
Front fog lampsand rear fog lamp(2nd rotation of thering forwards) Windscreen wipers Front
2 Fast wipe
1 Normal wipe
I Intermittent wipe
or
AUTO Automatic wipe
0 Off
Single wipe
Wash-wipe: pull the stalk towards you. Rear
Off Intermittent wipe
Automatic wipe In the AUTO position,
the windscreen wiper operates automaticallyand adjusts its speed
to the intensity of therainfall. Wash-
wipe
17-06-2002
Page 7 of 160
72
9YOUR 206 AT A GLANCE
SEATS Fold-down seat back (all models)
Ð Remove the head restraint,
Ð Tilt the modifiable seat,
Ð Push one of the handles 1
towards the rear to fold down the seat back until it is in a hori-zontal position.
Modifiable passenger seat
Storage compartment
Ð Push the seat as far back as possible,
Ð Raise then pull the front of the seat to unlock it, then tilt the modifiable seat.
3-door version
only.
17-06-2002
Page 8 of 160
7675
10YOUR 206 AT A GLANCE
Rear seats ➜Lift the front of the seat cushion 1,
➜ Tilt the seat cushion 1against the front seats,
➜ Position the seat belt under the belt holder 2,
➜ Pull control 3to unlock the seat back 4,
➜ Remove or lower the head restraint,
➜ Tilt the seat back 4.
When refitting, take care not to trap the seat belts.
Removing the modifiable front passenger seat ➜
Push the seat as far back as possible,
➜ Raise then pull the front of theseat to unlock it,
➜ Tilt the seat,
➜ By pulling upwards, tilt theseat from left to right to makeit easier to remove.
17-06-2002
Page 9 of 160
7675
10YOUR 206 AT A GLANCE
Rear seats ➜Lift the front of the seat cushion 1,
➜ Tilt the seat cushion 1against the front seats,
➜ Position the seat belt under the belt holder 2,
➜ Pull control 3to unlock the seat back 4,
➜ Remove or lower the head restraint,
➜ Tilt the seat back 4.
When refitting, take care not to trap the seat belts.
Removing the modifiable front passenger seat ➜
Push the seat as far back as possible,
➜ Raise then pull the front of theseat to unlock it,
➜ Tilt the seat,
➜ By pulling upwards, tilt theseat from left to right to makeit easier to remove.
17-06-2002
Page 10 of 160
107
5YOUR 206 AT A GLANCE
Never race a coldengine.
Never run the enginein a confined space.
Do not make any modificationsto the steering lock.
Starting a petrol engine
Do not press the accelerator.
Operate the starter, without
releasing the key, until the engi-ne turns.Starting a dieselengine Do not press the acce-
lerator.
Turn the key to the ''Running''
position. If the engine is warm enough, the pre-heat light does not come
on and you can start immediately. If the pre-heat light comes on, wait for it to go out before opera-
ting the starter. If the engine stalls, it is necessa- ry to return the key to the
''STOP'' position before restar-
ting. FRONT AIR BAGS
Precautions regarding thepassenger air bag For a vehicle fitted with a disar- ming switch :Ð disarm theair bag ifyou install arear-facingchild seat,
Ð arm the air bag for anadult pas-
senger.
For a vehicle not fitted with adisarming switch: Ð do not ins-tall a rear-facing childseat on thefront pas-senger seat.
In no circumstances should youplace your feet or any otherobject on the fascia.
Operating check
* According to destination.
Disarming the passenger air bag* Insert the ignition key in the switch 1
and turn it to:
Ð the ''ON'' position, the passen-
ger air bag is armed,
Ð the ''OFF'' position, the pas-
senger air bag is disarmed.
With the ignition on (2nd notchof the ignition), illumination ofthis warning light, accompaniedby an audible signal and themessage "Passenger air bag
disarmed" on the multi-function
display, indicates that the passenger air bag is disarmed(switch in the "OFF"position).
The warning light remains onthroughout the disarming process.
17-06-2002
