YOUR 206 CC IN DETAIL77
Closing the roof Never switch the ignition off during operation of the roof.
Ensure that the screen 1is hoo-
ked on (no object must be placed on the screen; if there is luggagein the boot, this must not push thescreen upwards).
 Close the boot correctly.
 With the vehicle stationary and
the handbrake applied, turn theignition key to position M.
 Press switch 3until your hear a
signal which confirms that theroof closing operation is complete.
When carrying out this operation,the front windows and then the rearquarter panel windows open, themoving parcel shelf folds up, theboot lid opens, the roof unfolds andpositions itself, then the boot lidcloses again.  Only then, lock the two hooks 2.
Note: The control buttons for the
windows become operational again at the end of the roof operation. Operating malfunction: If the cycle does not begin, check that the screen is pulled correctly
and that the boot is closed correctly. If movement of the roof stops, a con- tinuous audible signal sounds:
Release switch 3, then press it
again to finish closing the roof.
If the problem persists, contact a
PEUGEOT dealer to have the sys-tem checked. When the vehicle is moving, if a con- tinuous audible signal can be heard,this means that the roof or the bootlid, or both, are not locked:  Stop the vehicle and apply the handbrake,
 Open the roof and close it again
completely, in accordance withthe procedure.
If the problem persists, contact a
PEUGEOT dealer to have the system checked.
The roof must not be oper- ated when a loaded lug-gage carrier is fitted to theboot lid.
During roof opening and closingoperations, to avoid any risk of
injury, ensure that there is no-onein the proximity of the movingparts. Never release button 3 for more than five minutes when the roofis in an intermediate position(neither completely open or
closed). However, in the event
of danger, release the controlknob and the operation will stop
instantly. You can resume thecycle before the audible signalceases.
In the case of an electric or hydraulic malfunction of the roof, itis possible to close the roof manu-
ally. When the side windows no longer
open completely, it is impossible tooperate the roof; however it is pos-sible to close it by using a specialprocedure. Please consult the breakdown procedure described at the endof this handbook.

30-06-2003
YOUR 206 CC IN DETAIL
78
THE LIGHTS STALK Front and rear lights Selection is by turning ring
A.
Lights off Side lights Dipped/main beam headlamps
Automatic switchingon of lights
Dipped/Main beam change Pull the stalk towards you. Note: with the ignition off, if the dri-
ver's door is open, a buzzer sounds if you have left your lights on. Front fog lamps and rear fog lamp Rotate the ring Bforwards to switch
on and backwards to switch off. The status is confirmed by the light onthe instrument panel.
Front fog lamps (1st for-wards turn of the ring)
The front fog lamps operate with theside lights and dipped headlamps. When the main beam headlamps are switched on, the front fog lamps are
switched off. They are switched onagain when the main beam head-
lamps are switched off. Front fog lamps and rearfog lamp (2nd forwardsturn of the ring)
Note: to switch off the rear fog lamp
and the front fog lamps, turn the ringtwice backwards.
In good or rainy weather, both day and night, thefront fog lamps and therear fog lamp are dazzling
and are prohibited. Do not forget to switch them off when they are no longer needed.
Note: when the lights are switched
off automatically or when the dipped
headlamps are switched off manual-
ly, the front fog lamps, the rear foglamp and the side lights will remainon (turn the ring backwards to swit-
ch off the front fog lamps. The side
lights will then be switched off). "Follow me home" lighting In poor light or at night, if you leave your vehicle, the side lights and dip-ped headlamps can be left on forapproximately one minute.
To do this:
- place the key in the STOPposition,
- place the lights stalk in the 0posi-
tion,
- flash the headlamps,- get out of the vehicle and lock it.

30-06-2003
Direction indicators (flashers)Left:downwards.
Right: upwards. YOUR 206 CC IN DETAIL
79AUTOMATIC SWITCHING ON OF LIGHTS Side lights and dipped beam head- lamps switch on automatically if thelight is poor and when the wind-
screen wipers operate continuously.
They switch off at the same time when the light becomes brightenough or the windscreen wipers
are switched off. Note:
In foggy weather or in snow
the brightness sensor can detect
sufficient light. As a result, the lights
will not come on automatically. This function is active when the
vehicle is supplied to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Press the end of the lights stalk for more than four seconds. Operating check Activation Acivation of this function is accom- panied by an audible signal and themessage
"Automatic lighting
active'' on the multifunction display.
Disarming Disarming of the function is accom- panied by an audible signal. Note: the function is temporarily dis-
armed when the driver uses the manual lighting controls. If the brightness sensor does not function correctly , the system acti-
vates the function (the lights come
on). The driver is alerted by an audi-ble signal, accompanied by the mes-sage "Auto lighting fault" on the
multifunction display.
Contact a PEUGEOT dealer to have the system checked.
The brightness sensor, coupled
with the rain sensor, is located inthe centre of the windscreen,
behind the interior mirror. It isused for automatic switching onof the lights.

30-06-2003
Direction indicators (flashers)Left:downwards.
Right: upwards. YOUR 206 CC IN DETAIL
79AUTOMATIC SWITCHING ON OF LIGHTS Side lights and dipped beam head- lamps switch on automatically if thelight is poor and when the wind-
screen wipers operate continuously.
They switch off at the same time when the light becomes brightenough or the windscreen wipers
are switched off. Note:
In foggy weather or in snow
the brightness sensor can detect
sufficient light. As a result, the lights
will not come on automatically. This function is active when the
vehicle is supplied to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Press the end of the lights stalk for more than four seconds. Operating check Activation Acivation of this function is accom- panied by an audible signal and themessage
"Automatic lighting
active'' on the multifunction display.
Disarming Disarming of the function is accom- panied by an audible signal. Note: the function is temporarily dis-
armed when the driver uses the manual lighting controls. If the brightness sensor does not function correctly , the system acti-
vates the function (the lights come
on). The driver is alerted by an audi-ble signal, accompanied by the mes-sage "Auto lighting fault" on the
multifunction display.
Contact a PEUGEOT dealer to have the system checked.
The brightness sensor, coupled
with the rain sensor, is located inthe centre of the windscreen,
behind the interior mirror. It isused for automatic switching onof the lights.

30-06-2003
YOUR 206 CC IN DETAIL
80
After the ignition has been switched off, if the stalk was in awipe position, you mustreactivate this function: - move the stalk to any position,
- then move it back to the required
position.
Windscreen wash Pull the wipers stalk towards you.The windscreen wash, then the windscreen wipers, operate for afixed period.
Front windscreen wiper withintermittent wipe 2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
I Intermittent wipe.
0 Off.
Single wipe (press downwards).
In the Intermittent position, the
wiping speed is in proportion to thevehicle speed.
Front windscreen wiper with automatic wipe
2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
AUTO Automatic wipe.
0 Off.
Single wipe (press downwards).
In the AUTOposition, the wiping
speed is in proportion to the intensityof the rainfall.
WINDSCREEN WIPER STALK

30-06-2003
YOUR 206 CC IN DETAIL81
Do not cover the rain sen- sor located on the wind-screen behind the interior
mirror.
When using an automatic carwash, switch off the ignition orcheck that the wiper stalk is not inthe automatic position.
In winter, it is advisable to wait forthe windscreen to completely clearof ice before operating the auto-matic wipe.
Automatic timed windscreenwipers In the
AUTOposition, the wind-
screen wipers operate automatically and adapt their speed to the inten-
sity of the rainfall. Operating checkActivation When the function is activated, the message "Automatic wiping
active" appears on the multifunction
display. In the event of malfunction , the
driver is informed by an audible sig- nal and the message "Auto wiper
fault" on the multifunction display.
In the event of malfunction in the
AUTO position, the windscreen
wiper will operate in intermittentmode.
Contact a PEUGEOT dealer to have the system checked.

30-06-2003
YOUR 206 CC IN DETAIL
82
TRIP COMPUTER
Pressing the button on the end of the wash/wipe stalkenables the following data to
be displayed:
Display B
- the range
- the distance travelled
- the average consumption
- the current consumption
- the average speed Zero reset Press the stalk for more than two seconds. Display C
- the current consumption and the range,
- the average consumption, the distance travelled and the
average speed calculated over a period "1",
- the average consumption, the distance travelled and the average speed calculated over a period "2".
Periods "1"and "2"are defined by the frequency of the
zero reset. They allow, for instance, daily calculations over period "1"and monthly calculations over period "2".
Zero reset When the required period is displayed, press the stalk for more than two seconds.

30-06-2003
YOUR 206 CC IN DETAIL83
Range The display shows the distance that can still be covered with the fuelremaining in the tank. Note:
this figure may rise if there is
a change in driving style or road sur- face, causing a significant drop incurrent fuel consumption. If there are less than 3 litres of fuel in the tank, only three segments willbe displayed.
Current fuel consumption This gives the fuel consumption recorded during the last two
seconds. This function is only dis-played when the vehicle is travellingat more than 12 m.p.h. (20 km/h).
Average consumption This is the ratio between the amount of fuel consumed and the distancetravelled since the computer waslast reset to zero.
Average speed This is obtained by dividing the dis- tance travelled by the period of timethe vehicle has been in use (with theignition on), since the computer waslast reset to zero. Distance travelled This shows the distance travelled since the computer was last reset tozero. After the trip computer has been reset to zero, the range databecomes meaningful only after thevehicle has been in use for a certainperiod. If horizontal segments are displayed instead of figures when driving, con-
tact a PEUGEOT dealer.

30-06-2003
YOUR 206 CC IN DETAIL
84
ELECTRIC WINDOWS
1. DriverÕs electric window
switch.
2. PassengerÕs electric window switch.
Each switch controls, on its own side, the front window and the rear
quarter panel window. Manual operation  Press the switch (to open) or pull it (to close) without going beyondthe point of resistance. The window stops when the switch is released. The rear quarter panel window can only be opened when thefront window is completely open,after an inactive period of onesecond. Automatic operation


Opening
The windows open automatically(when the ignition key is in the ÔonÕposition, with the engine runningor the vehicle moving).  Press the switch past the point of resistance:
Ð Press briefly to completely open the front window; pressbriefly again to completelyopen the rear quarter panel
window,
Ð Sustained pressure opens the front window, then the rear
quarter panel, completely.


Closing
Only the front window on the dri-
verÕs side closes automatically(engine running or vehicle mov-ing), when the rear quarter panelis closed.  Briefly pull the switch past the point of resistance to complete-
ly close the driverÕs front win-
dow.
Note: the window switches do not
function while the roof is being opera-ted.
Always remove the key from the ignition whenleaving the vehicle, evenfor a short time.
If an obstacle is detected whenoperating the electric windows, youmust reverse the movement of the
window. To do this, press the con-trol concerned. When the driver operates the pas- senger electric window controls, hemust ensure that no one is pre-venting correct closing of the win-dows. The driver must ensure that pas- sengers use the electric windows
correctly. Be aware of children when operat- ing the windows.

30-06-2003
YOUR 206 CC IN DETAIL85
Manual interior mirror The interior mirror has two positions: - day (normal),- night (anti-dazzle).
To change from one to the other, push or pull the lever on the lower
edge of the mirror.ELECTRIC EXTERIOR MIRRORS
Turn knob
1to the right or to the left
to select the corresponding mirror. Move knob 1in all four directions to
adjust. Fold-back electric mirrors With the ignition on, turn knob 1to
position A.
The outside of the mirror on the driver's side is con-vex (area at edge definedby dotted line) in order toeliminate the 'blind spot'. Furthermore, objects in the
driver's and passenger's mirrors are in reality closer than they
appear. This must be taken into account to judge correctly the distance ofvehicles approaching from behind.
