Page 3 of 224
!
i
Thank you for choosing a 207 CC, a
symbol of confi dence, passion and in-
spiration.
This handbook has been designed to
enable you to make the most of your
207 CC.
On the fi rst few pages, you will fi nd a
detailed summary, followed by a quick
reference guide intended to make it
easier for you to become familiar with
your coupé-cabriolet.
All of the details specifi c to your 207 CC,
comfort, safety, driving, are then pre-
sented in this handbook, to increase
your appreciation of the vehicle help
you get the most from it.
Each model may only be fi tted with
some of the equipment mentioned in
this handbook, depending on its version
and the specifi cation for the country in
which it is sold.
Page reference:
this symbol invites you to refer to
the pages which provide details
of the function.
Key
Protection of the environment:
this symbol accompanies advice
relating to protection of the envi-
ronment.
Information:
this symbol draws your attention
to additional information for better
use of your vehicle.
Warning:
this symbol marks warnings which
it is essential to observe for your
own safety, for the safety of others
or to avoid any risk of damaging
your vehicle.
Page 4 of 224
2
CONTENTS
Instrument panels 20
Indicator and warning lamps 21
Indicators 28
Adjustment buttons 32
Screens without audio
equipment 33
Screens with audio equipment 35
16/9 colour screen (Peugeot
Connect Navigation) 40
Trip computer 42■
■
■
■
■
■
■
■
Ventilation 45
Heating 47
Manual air conditioning 47
Rear screen demist - defrost 49
Digital air conditioning 50
Seats 52
Steering wheel adjustment 54
Mirrors 55
Interior fi ttings 57
Windstop 62■
■
■
■
■
■
■
■
■
■
COMFORT 45 Î 64
Remote control key 65
Alarm 69
Window controls 71
Doors 73
Boot 76
Fuel tank 77
Misfuel prevention (Diesel) 79■
■
■
■
■
■
■
ACCESS 65 Î 79
Lighting control stalk 80
Static directional lighting 83
Headlamp adjustment 83
Wiper control stalk 84
Courtesy lamp 85■
■
■
■
■
VISIBILITY 80 Î 85
Conventional child seats 86
ISOFIX child seats 90■
■
CHILD
SAFETY 86 Î 92 FAMILIARISATION 4 Î 17
INSTRUMENTS
and CONTROLS 20 Î 445
4
3
2
1
ECO-DRIVING 18 Î 19
Page 7 of 224
ii
5
FAMILIARISATION
OPENING
Remote control key
A.
Unfolding/Folding the key.
B.
Unlocking the vehicle.
C.
Unlocking and partially opening the
boot.
65
Also...
D.
Normal locking
or
Deadlocking of the vehicle.
Fuel tank
1.
Opening the fuel fi ller fl ap.
2.
Opening and hooking the fuel fi ller
cap.
Capacity of the tank: approximately
50 litres (petrol) or 48 litres (Diesel).
77
Boot
From outside
From inside
1.
Unlocking the complete vehicle or
unlocking the boot and the vehicle.
2.
Opening the boot lid.
1.
Key in the ignition switch.
2.
Unlocking using the manual cen-
tralised control or the door opening
control.
76
On Diesel vehicles, the fuel fi ller
neck incorporates a misfuel preven-
tion device which prevents fi lling
with petrol.
79
Page 18 of 224
!
16
FAMILIARISATION
Front passenger's airbag
Ignition switch
1.
Open the glove box.
2.
Insert the key.
3.
Select position:
"ON"
(activation), with front passen-
ger or "forwards facing" child seat,
"OFF"
(deactivation), with "rear facing"
child seat.
4.
Remove the key keeping the switch
in the new position.
102
1.
Stop
position.
2.
Ignition
position.
3.
Starting
position.
67
A.
Front left seat belt not fastened or
unfastened warning lamp lit in red.
B.
Front right seat belt not fastened or
unfastened warning lamp lit in red.
98
Front seat belts
A heavy object (key fob...), attached
to the key and weighing down on
its shaft in the ignition switch, could
cause a malfunction.
PASSENGER SAFETY START
Page 40 of 224
1INSTRUMENTS and CONTROLS
38
"Trip computer" menu
Once this menu has been selected, you
can consult information concerning the
status of the vehicle (alert log, status of
the functions...).
)
Press the "MENU"
key to access
the main menu.
)
Press the arrows, then the "OK"
key to select the "Trip computer"
menu.
)
In the "Trip computer"
menu, select
one of the following applications:
Alert log
This summarises the active warning
messages, displaying them succes-
sively on the multifunction screen.
Status of functions
This summarises the active or inactive
status of the functions present on the
vehicle.
Enter the distance to the destination
This allows you to enter an approximate
distance value to the fi nal destination.
Page 57 of 224
2
i
!
COMFORT
55
MIRRORS
Door mirrors
Adjustable mirror permitting the lateral
rearward vision necessary when over-
taking or parking.
Adjustment
)
Slide switch A
to the right or to the left
to select the corresponding mirror.
)
Move knob B
in all four directions to
adjust.
)
Return switch A
to the centre posi-
tion.
The folding and unfolding of the
door mirrors can be deactivated by
a PEUGEOT dealer or a qualifi ed
workshop.
Folding
)
From outside: lock the vehicle using
the remote control or the key.
)
From inside: with the ignition on, pull
switch A
rearwards.
Unfolding
)
From outside: unlock the vehicle us-
ing the remote control or the key.
)
From inside: with the ignition on, pull
switch A
rearwards. The objects observed are, in reality,
closer than they appear.
Take this into account to correctly
judge the distance of vehicles ap-
proaching from behind.
Page 67 of 224
3
!
i
ACCESS
Deadlocking renders the exterior
and interior door controls inopera-
tive.
It also deactivates the manual cen-
tralised control button.
Therefore, do not leave anyone
inside the vehicle when it is dead-
locked. If one of the doors or the boot is still
open, the central locking does not
take place.
REMOTE CONTROL KEY
System which permits central unlocking
or locking of the vehicle using the lock
or remotely. It also locates and starts
the vehicle, as well as providing protec-
tion against theft.
Unfolding the key
)
First press button A
to unfold the
key.
Unlocking the vehicle
Unlocking is confi rmed by rapid fl ashing
of the direction indicators for approxi-
mately two seconds.
According to version, the door mirrors
unfold at the same time.
Locking the vehicle
Deadlocking using the remote
control
)
Press the closed padlock to lock the
vehicle.
)
Press the closed padlock again
within fi ve seconds to deadlock the
vehicle.
)
Press the open padlock to
unlock the vehicle.
Unlocking using the key
)
Turn the key to the left in the driver's
door lock to unlock the vehicle.
)
Press the closed padlock
to lock the vehicle.
Normal locking using the key
)
Turn the key to the right in the driv-
er's door lock to lock the vehicle.
Locking is confi rmed by fi xed lighting of
the direction indicators for approximate-
ly two seconds.
According to version, the door mirrors
fold at the same time.
Unlocking using the remote control
Deadlocking using the key
)
Turn the key to the right in the driv-
er's door lock to lock the vehicle.
)
Turn the key to the right again within
fi ve seconds to deadlock the vehicle.
Deadlocking is confi rmed by fi xed
lighting of the direction indicators for
approximately two seconds.
According to version, the door mirrors
fold at the same time.
Normal locking using the remote
control
Page 68 of 224
3
i
ACCESS
66
The vehicle will relock automati-
cally after thirty seconds unless
a door is opened. This system
prevents unintentional unlocking.
The folding and unfolding of the
door mirrors can be deactivated by
a PEUGEOT dealer.
Folding the key
)
First press button A
to fold the key.
Locating your vehicle
)
Press the closed padlock to locate
your locked vehicle in a car park.
This is indicated by lighting of the cour-
tesy lamp and fl ashing of the direction
indicators for a few seconds.
Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the
ignition is switched on, this code must
be recognised in order for starting to be
possible.
This electronic engine immobiliser locks
the engine management system a few
minutes after the ignition is switched off
and prevents starting of the engine by
anyone who does not have the key.
Anti-theft protection
In the event of a fault, you are
informed by illumination of this
warning lamp, an audible signal
and a message in the screen.
In this case, your vehicle will not start;
contact a PEUGEOT dealer as soon as
possible.
Keep safely the label attached to the
keys given to you on acquisition of the
vehicle.
)
Press the boot unlocking but-
ton on the remote control for
more than 2 seconds. The
boot opens slightly.
Unlocking and partially opening
the boot
Page 69 of 224
3
i
ACCESS
67
Starting the vehicle
)
Insert the key in the ignition switch.
The system recognises the starting
code.
)
Turn the key fully towards the dash-
board to position 3 (Starting)
.
)
When the engine starts, release the
key.
Switching the vehicle off
)
Immobilise the vehicle.
)
Turn the key fully towards you to po-
sition 1 (Stop)
.
)
Remove the key from the ignition
switch.
Remote control problem
Following disconnection of the vehicle
battery, replacement of the remote con-
trol battery or in the event of a remote
control malfunction, you can no longer
unlock, lock or locate your vehicle.
)
First of all, use the key in the lock to
unlock or lock your vehicle.
)
Then, reinitialise the remote control.
If the problem persists, contact a
PEUGEOT dealer as soon as possible.
Changing the battery
Battery ref.: CR1620/3 volts.
Reinitialisation
)
Switch off the ignition.
)
Turn the key to position 2 (Ignition on)
.
)
Press the closed padlock immedi-
ately for a few seconds.
)
Switch off the ignition and remove
the key from the ignition switch.
The remote control is fully operational
again. If the battery is fl at, you are in-
formed by illumination of this
warning lamp, an audible signal
and a message in the multifunc-
tion screen.
)
Unclip the casing using a coin at the
notch.
)
Slide the fl at battery out of its location.
)
Slide the new battery into its loca-
tion observing the original direction.
)
Clip the casing.
)
Reinitialise the remote control.
Key in ignition
If the key has been left in the igni-
tion, an audible signal is heard on
opening the driver's door.
Page 70 of 224
3
!
ACCESS
68
Lost keys
Visit a PEUGEOT dealer with the vehicle's registration document, your per-
sonal identifi cation documents and if possible the key code label.
The PEUGEOT dealer will be able to fi nd the key code and the transponder
code required to order a new key.
Do not throw the remote control bat-
teries away, they contain metals which
are harmful to the environment.
Take them to an approved collection
point.
Remote control
The high frequency remote control is a sensitive system; do not operate it
while it is in your pocket as there is a possibility that it may unlock the vehicle,
without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and
out of sight of your vehicle. You run the risk of stopping it from working and the
remote control would have to be reinitialised.
The remote control does not operate when the key is in the ignition switch,
even when the ignition is switched off, except for reinitialisation.
Locking the vehicle
Driving with the doors locked may make access to the passenger compart-
ment by the emergency services more diffi cult in an emergency.
As a safety precaution (with children on board), remove the key from the igni-
tion switch when you leave the vehicle, even for a short time.
Anti-theft protection
Do not make any modifi cations to the electronic engine immobiliser system;
this could cause malfunctions.
When purchasing a second-hand vehicle
Have the pairing of all of the keys in your possession checked by a PEUGEOT
dealer, to ensure that only your keys can be used to open and start the vehicle.
