Checks
12 V battery
The battery does not require any maintenance.
However, check that the terminals are clean
and correctly tightened, particularly in summer
and winter.
Particle filter (Diesel)
The start of saturation of the
particle filter is indicated by
the fixed illumination of this warning lamp
accompanied by a warning message in the
screen (if a display screen is fitted).
As soon as the traffic conditions permit,
regenerate the filter by driving at a speed of at
least 40 mph (60 km/h) until the warning lamp
goes off.
If the warning lamp stays on, this indicates a
low additive level.
On a new vehicle, the first particle
filter regeneration operations may be
accompanied by a "burnt" smell, which
is perfectly normal.
Following prolonged operation of the
vehicle at very low speed or at idle,
you may, in exceptional circumstances,
notice the emission of water vapour at
the exhaust on acceleration. This does
not affect the behaviour of the vehicle
or the environment.
Unless otherwise indicated, check these components in accordance with the manufacturer's service schedule and according to your engine.
Other wise, have them checked by a PEUGEOT dealer or a qualified workshop.
Air filter and passenger compartment filter
Refer to the manufacturer's
service schedule for details of the
replacement intervals for these
components.
Oil filter
Replace the oil filter each time the
engine oil is changed.
Refer to the manufacturer's
service schedule for details of
the replacement interval for this
component.
When carrying out work on the battery, refer
to the "Practical information" section for
details of the precautions to be taken before
disconnecting the battery and following its
reconnection.
Depending on the environment (e.g. dusty
atmosphere) and the use of the vehicle (e.g.
city driving), replace them twice as often if
necessary
.
A clogged passenger compartment filter may
have an adverse effect on the per formance
of the air conditioning system and generate
undesirable odours.
10
Checks

170
301_en_Chap10_verifications_ed01-2014
Manual gearbox
The gearbox does not require any
maintenance (no oil change).
Refer to the manufacturer's service
schedule for the checking interval for
this component.
Electronic gearbox
The gearbox does not require any
maintenance (no oil change).
Refer to the manufacturer's service
schedule for details of the checking
interval for this component.
Automatic gearbox
The gearbox does not require any
maintenance (no oil change).
Refer to the manufacturer's service
schedule for details of the level
checking interval for this component.Brake wear depends on the style
of driving, particularly in the case
of vehicles used in town, over short
distances. It may be necessary to have
the condition of the brakes checked,
even between vehicle services.
Brake pads
For information on checking brake
disc wear, contact a PEUGEOT
dealer or a qualified workshop.
Brake disc wear
Parking brake
If excessive travel or a loss of
effectiveness of this system is
noticed, the parking brake must be
checked, even between two services.
Only use products recommended by
PEUGEOT or products of equivalent
quality and specification.
In order to optimise the operation of
units as important as those in the
braking system, PEUGEOT selects and
offers very specific products.
After washing the vehicle, dampness,
or in wintry conditions, ice can form
on the brake discs and pads: braking
efficiency may be reduced. Make light
brake applications to dry and defrost
the brakes.
Checking this system must be done by a
PEUGEOT dealer or a qualified workshop.
Unless there is a leak in the circuit, a drop in
the brake fluid level indicates that the brake
pads are worn.
Checks

171
301_en_Chap11_caracteristiques-techniques_ed01-2014
EngineVTi 72 V T i 115
Gearbox Manual
(5-speed) Electronic
(5-speed) Manual
(5-speed) Automatic
(4-speed)
Model code : DD... HMY0HMY0/P NFP0NFP9
Cubic capacity (cc) 1 19 91 587
Bore x stroke (mm) 75 x 90.578.5 x 82
Max power: EU standard (kW)* 5385
Max power engine speed (rpm) 5 5006 050
Max torque: EU standard (Nm) 11 0150
Max torque engine speed (rpm) 3 0004 000
Fuel Unleaded 91 RON to 98 RONUnleaded 91 RON to 98 RON
Catalytic converter yesyes
Engine oil capacity in litres
(with filter replacement) 3.25
3.5
Petrol engines
* The maximum power corresponds to the value type approved on a test bed, under conditions defined by European legislation (Directive 1999/99/EC).
11
Technical data

172
301_en_Chap11_caracteristiques-techniques_ed01-2014
EngineVTi 72V T i 115
Gearbox Manual
(5-speed) Electronic
(5-speed) Manual
(5-speed) Automatic
(4-speed)
Model code: DD.... HMY0HMY0/P NFP0NFP9
-

U
nladen weight 9801 090
-

K
erb weight* 1 0551 165
-

G
ross vehicle weight (GV W) 1 4591 467 1 5241 559
-

G
ross train weight (GTW)
o

n a 12 % gradient 1 909
1 9172 2 742 309
-

B
raked trailer (within GTW limit)
o

n a 10 % or 12 % gradient 450
750
-

B
raked trailer** (with load transfer within the
GTW limit) 720
1 010
-
U

nbraked trailer 450580600
-
R

ecommended nose weight 5555
* The kerb weight is equal to the unladen weight + driver (75 kg).
**

T
he weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
Petrol weights (in kg)
Technical data

173
301_en_Chap11_caracteristiques-techniques_ed01-2014
EngineHDi 92
Gearbox Manual
(5-speed)
Model code: DD... 9HJC9HP0
Cubic capacity (cc) 1 560
Bore x stroke (mm) 75 x 88
Max power: EU standard (kW)* 68
Max power engine speed (rpm) 4 000
Max torque: EU standard (Nm) 230
Max torque engine speed (rpm) 1 750
Fuel Diesel
Catalytic converter yes
Particle filter noyes
Engine oil capcity in litres
(with filter replacement) 3.75
Diesel engine
* The maximum power corresponds to the value type approved on a test bed, under conditions defined by European legislation (Directive 1999/99/EC).
11
Technical data

174
301_en_Chap11_caracteristiques-techniques_ed01-2014
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load. * The kerb weight is equal to the unladen weight + driver (75 kg).
**
T
he weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Engine
HDi 92
Gearbox Manual
(5-speed)
Model codes: DD... 9HJC9HP0
-
U
nladen weight
1 090
-
K
erb weight*
1 165
-
G
ross vehicle weight (GV W)
1 5491 548
-
G
ross train weight (GTW)
o

n a 12% gradient
2 299
2 298
-
B
raked trailer (within GTW limit)
o

n a 10% or 12% gradient
750
-
B
raked trailer** (with load transfer with the
GTW limit) 1 010
-
U
nbraked trailer
580
-
R
ecommended nose weight
55
Diesel weights (in kg)
Technical data

175
301_en_Chap11_caracteristiques-techniques_ed01-2014
Dimensions (in mm)
11
Technical data

176
301_en_Chap11_caracteristiques-techniques_ed01-2014
Identification markings
A. Vehicle identification number (VIN) under the bonnet.
T

his number is engraved on the bodywork
near the passenger compartment filter. The tyre pressures must be checked
when the tyres are cold, at least once
a month.
Low tyre pressures introduces the risk
of a burst tyre and also increase fuel
consumption.
B.
V

ehicle identification number on the
dashboard.
T

his number is indicated on a self-
adhesive label which is visible through the
windscreen. C. M
anufacturer's label.
T
he VIN is indicated on a self-destroying
label affixed to the lower right hand centre
pillar.
D.
T

yre/paint label.
T

his label is affixed to the driver's side
centre pillar. It bears the following information:
-

t
he tyre pressures, for unladen and laden
conditions,
-
t
he tyre sizes,
-
t
he spare tyre inflation pressure,
-
t
he paint colour code.
Various visible markings for the identification of your vehicle.
Technical data

177
301_en_Chap12a_RD5(RD45)_ed01-2014
Your audio system is coded in such a way that it will
only operate in your vehicle.
Audio system / Bluetooth®
01 First steps
For safety reasons, the driver must only carry out
operations which require prolonged attention while the
vehicle is stationary.
When the engine is switched off and to prevent
discharging of the battery, the audio system may switch
off after a few minutes.
CONTENTS
02
Steering mounted
controls
03

Main
menu
04
Audio
05

Using
the telephone
06

Audio
settings
07

Screen menu map(s)
Frequently

asked questions p.
p.
p.
p.
p.
p.
p.
p.
178
179
180
181
191
200
201
203

01
178
301_en_Chap12a_RD5(RD45)_ed01-2014
On / Off.
FIRST STEPS
Volume adjustment.
Select screen display
between modes:
Full screen: Audio (or
telephone if call in progress) /
In a window: Audio
(or

telephone if call in
progress)

- T
ime or Trip
computer.
Long press: black screen
(DARK).
Selection of AM / FM
wavebands. Select preset radio station.
Long press: store a station.
Display the list of stations received,
CD/MP3
tracks or folders.
Long press: managing the
classification of MP3/WMA files /
update the list of stations received. TA (Traffic Announcement)
function On / Off.
Long press: access to type of
information.
Confirmation
or display of
contextual menu. Automatic search up / down
for radio frequencies.
Select previous / next CD,
USB, streaming track.
Navigation in a list.
Abandon the current operation.
Up one level (menu or folder). Manual step by step search up / down for
radio frequencies.
Select previous / next MP3
folder.
Select previous / next folder / genre / artist /
playlist in the USB device.
Navigation in a list.
Select source:
Radio, CD, AUX, USB,
Streaming.
Accept an incoming call.
Access to main menu.
Audio settings:
audio ambiences, treble, bass,
loudness, distribution, left/
right balance, front/rear fader,
automatic volume.
