YOUR 307 SW IN DETAIL
98
3rd row rear seat belts The 3rd row rear seats are fitted with two three-point inertia reel seatbelts.
To put on the seat belt, insert buckle C
then buckle Dinto their respective
stalks.
To remove the seat belt, proceed in
the reverse order, then move buckleD to the location Eprovided.
To be effective, a seat belt must be tightened asclose to the body as pos-sible.
If the seats are fitted with arm-rests, the lap section of the seatbelt must always pass under thearmrest. Do not invert the seat belt buckles as they will not carry out their
function fully. Depending on the nature and the seriousness of the impact, thepre-tensioners may be triggeredbefore and independently of trig-gering of the airbags. In all cases, the airbag warning light comes on. Following a collision, have the system checked by a PEUGEOT
dealer. The system has been designed to be fully operational for ten years.
For greater safety, have it chec- ked by a PEUGEOT dealer afterthis period.
2nd row rear centre seat belt The 2nd row rear centre seat has a three-point inertia reel seat beltincorporated in the centre of theroof. Pass buckle A, then buckle B, into
the strap guide working from the inside to the outside of the seat. Insert buckle Ainto its stalk (right),
then buckle Binto its stalk (left).
To remove the seat belt, proceed in
the reverse order, then move buckleB to the magnet of the roof fixing
point.

22-07-2002
5 seats 4 seats with table position
SEAT MODULARITY AND DIFFERENT CONFIGURATIONS
YOUR 307 SW IN DETAIL
99
The design of your vehicle and of its seats offers multiple seat configurations. There are
side seats which can be installed in the 2nd or 3rd
row, on the right or on the left. Once the centre seat has been removed from the 2nd row,
you can recentre the side seats for more comfort. There is also a centre seat, fitted in the central position of the
2nd row, which can also be installed in the left position in the
3rd row. In this case, you must use the 3rd row rear left seat belt without passing it through the strap guide.
You can add up to two additional seatsin the 3rd row, on the
right or on the left.
The various operations resulting in modification of the existing configuration must be carried outwhen the vehicle is stationary (see "Seats" section).
Examples of varied arrangements combining comfort and practicality:

22-07-2002
YOUR 307 SW IN DETAIL
100
4 seats with side seat in the 3rd row Loading of a large volume5 seats with centre seat in the 3rd row
Transportation of long objects

22-07-2002
YOUR 307 SW IN DETAIL101
101
7 seats with two additional seats 5 seats with two folded additional seats 6 seats with an additional seat and the centre seat in the 3rd row
5 seats with table position and one additional seat

THE KEYS The keys allow you to switch on the ignition and to independently opera-te the locks on the front doors, thefuel filler cap, the glove box and thepassenger air bag disarming switch. Central locking
From the driver's door, the keys allow you to lock, deadlock or unlock thedoors and tailgate, as well as fold backthe exterior mirrors. If one of the doors or the boot is open, the central locking does not work; anaudible signal indicates this when locking by remote control. The remote control performs the same functions at a distance.The remote control LockingPress button
Ato lock the vehicle.
This is confirmed by fixed lighting of the direction indicators for approxi-mately two seconds. Note : a long press on button A, in
addition to locking, automatically closes the windows.
Vehicles fitted with deadlocking
Warning: deadlocking renders the
internal and external door locking controls inoperative. One press on button Adeadlocks
the vehicle.This is confirmed by fixed lighting of the direction indicators for approxi-mately two seconds. Note: a long press on button A, in
addition to deadlocking, automatically closes the windows.
A second press on button Awithin
five seconds of deadlocking changes this to normal locking. This is confirmed by fixed lighting of the direction indicators for approxi-mately two seconds. Unlocking Press button
Bto unlock the vehicle.
This is confirmed by rapid flashing of the direction indicators. Note: if the vehicle is locked and
unlocking is activated inadvertently without the doors being openedwithin 30 seconds, the vehicle will
lock itself automatically.
Locating your car
To locate your car, if you have locked it, in a car park: press button A. The courtesy
lights come on and the direction indicators flash for a fewseconds.
YOUR 307 SW IN DETAIL
102
22-07-2002

Electronic engine immobiliser This locks the engine control system as soon as the ignition has been
switched off and therefore preventsstarting of the vehicle by anyone
who does not have the key. The ignition key has an electronic chip which has a special code.When the ignition is switched on, thecode must be recognised for startingto be possible. If the system does not function correctly, the central locking button
indicator light, situated in the centreof the fascia, flashes rapidly whenthe ignition is switched on (2ndnotch), accompanied by an audiblesignal and the message "Anti-theft
device faulty" on the multi-function
display. In this case your vehicle will not start.
Contact a PEUGEOT dealer as soon as possible.
Confidential card The confidential card contains the identification code necessary for anywork carried out by a PEUGEOT
dealer on the system. This code ishidden by a film which should be
removed only if necessary. Keep your card in a safe place, never inside the vehicle. Key in ignition
A buzzer sounds on opening the dri-
ver's door, if the key has been left inthe ignition. Changing the battery of the remote control
Warning that the battery is flat is given by an audible signal accompa-nied by the message
''Remote
control battery low'' on the multi-
function display.
To replace the battery, remove the screw then unclip the casing using acoin at the ring (CR 2016/3 volt battery). If the remote control does not work after the battery has been changed,reprogramme the remote control. Programming the remote control Switch off the ignition.
Switch the ignition on again.
Immediately press button A.
Switch off the ignition and remo- ve the remote control key from
the ignition lock. The remotecontrol is now working again.
YOUR 307 SW IN DETAIL 103
22-07-2002

22-07-2002
Make a careful note of the number on each key. The key number is coded on the label attached to the key. If the key is lost, your PEUGEOT dealer can rapidly supply you with new keys. The high-frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a possibility that it may unlock your vehicle without your knowledge.
The remote control cannot operate if the key is in the ignition, even if the ignition is switched off, except for reprogram-ming. Nevertheless, do not operate the deadlocking device if there is someone inside the vehicle.As a safety measure (when there are children on board), remove the ignition key when leaving the vehicle, even for a short time.
Do not handle the buttons of your remote control when out of range of your vehicle. You run the risk of stopping it from working. It would then be necessary to reprogramme the remote control. When buying a second-hand car: - Ensure that you are given the confidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the only ones that can start your vehicle.
Do not make any modifications to the electronic engine immobiliser system.
YOUR 307 SW IN DETAIL
104

Electronic engine immobiliser This locks the engine control system as soon as the ignition has been
switched off and therefore preventsstarting of the vehicle by anyone
who does not have the key. The ignition key has an electronic chip which has a special code.When the ignition is switched on, thecode must be recognised for startingto be possible. If the system does not function correctly, the central locking button
indicator light, situated in the centreof the fascia, flashes rapidly whenthe ignition is switched on (2ndnotch), accompanied by an audiblesignal and the message "Anti-theft
device faulty" on the multi-function
display. In this case your vehicle will not start.
Contact a PEUGEOT dealer as soon as possible.
Confidential card The confidential card contains the identification code necessary for anywork carried out by a PEUGEOT
dealer on the system. This code ishidden by a film which should be
removed only if necessary. Keep your card in a safe place, never inside the vehicle. Key in ignition
A buzzer sounds on opening the dri-
ver's door, if the key has been left inthe ignition. Changing the battery of the remote control
Warning that the battery is flat is given by an audible signal accompa-nied by the message
''Remote
control battery low'' on the multi-
function display.
To replace the battery, remove the screw then unclip the casing using acoin at the ring (CR 2016/3 volt battery). If the remote control does not work after the battery has been changed,reprogramme the remote control. Programming the remote control Switch off the ignition.
Switch the ignition on again.
Immediately press button A.
Switch off the ignition and remo- ve the remote control key from
the ignition lock. The remotecontrol is now working again.
YOUR 307 SW IN DETAIL 103
22-07-2002

22-07-2002
Make a careful note of the number on each key. The key number is coded on the label attached to the key. If the key is lost, your PEUGEOT dealer can rapidly supply you with new keys. The high-frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a possibility that it may unlock your vehicle without your knowledge.
The remote control cannot operate if the key is in the ignition, even if the ignition is switched off, except for reprogram-ming. Nevertheless, do not operate the deadlocking device if there is someone inside the vehicle.As a safety measure (when there are children on board), remove the ignition key when leaving the vehicle, even for a short time.
Do not handle the buttons of your remote control when out of range of your vehicle. You run the risk of stopping it from working. It would then be necessary to reprogramme the remote control. When buying a second-hand car: - Ensure that you are given the confidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the only ones that can start your vehicle.
Do not make any modifications to the electronic engine immobiliser system.
YOUR 307 SW IN DETAIL
104

22-07-2002
THE ALARM This provides two types of protec- tion: Ðexterior protection: it sounds if
a door, the boot or the bonnet is opened.
Ð interior protection: it sounds if
the volume inside the passengercompartment changes (breakingof a window or a movement insi-de the vehicle).
Setting the alarm Switch off the ignition and get out of the vehicle.
Set the alarm within five minutesof getting out of the vehicle, bylocking or deadlocking using theremote control (button Aindica-
tor light flashes once persecond).
Note: if you wish to lock your vehicle
without setting the alarm, use thedoor lock. When the alarm is triggered, thesiren sounds and the direction indi-cator lights flash for thirty seconds. After triggering, the alarm remains set.
Warning:
if the alarm has been
triggered ten times in succession, on the eleventh time it becomesinactive. Note: if button Aindicator light
flashes rapidly, the alarm has been triggered while you were away fromyour vehicle.
Disarming Unlock the vehicle with the remote control key (button Aindicator light
goes out). Note: if the alarm has been triggered
while you were away from your vehicle, the rapid flashing of the indi-cator light will stop when you switchon the ignition.
To set the alarm with exterior protection only If, while you are away from the vehicle, you wish to leave a windowpartially open or a pet inside thevehicle, you should choose exterior
protection only. Switch off the ignition,
In the next ten seconds, press button Auntil the indicator light is
on continuously,
Get out of the vehicle,
Set the alarm by locking or dead-locking using the remote control(button Aindicator light flashes
once a second).
Note: when the alarm is set but the
remote control does not operate: Unlock the doors with the key
and open the door. The alarm istriggered.
Switch on the ignition in the next
ten seconds. The alarm is disar-med.
Incorrect operation When the ignition is switched on, if button Alights for ten seconds, there
is a fault in the siren connection.
Contact a PEUGEOT dealer to have the system checked. Automatic activation* The alarm is activated automatically two minutes after the last closure ofa door or the boot. In order to avoid accidental triggering of the alarm when a door or the bootis opened, it is essential to first pressthe unlocking button on the remotecontrol.
* According to destination.
YOUR 307 SW IN DETAIL 105
