Peugeot 307 SW Dag 2002.5 Owner's Manual

YOUR 307 SW IN DETAIL
114
Distance remaining to be tra- velled This is the distance remaining to the destination. It can either be calcula-ted by the navigation if guidance is
activated, or entered by the user,minus the distance covered since thedistance was entered. Note:if digits are missing, dashes
are displayed in their place.
Average speed This is the average speed calculated since the computer was last set tozero (with the ignition on). The warnings log This summarises the active warning messages by displaying them on themultifunction screen. The excess speed warning function* This monitors the maximum speed required. In the event that the pro-grammed speed is exceeded, themessage "Speed too high" appears
on the multifunction screen, accom-panied by an audible signal. Programming Accelerate to the desired speed. Keep pressing the control to store in
memory.
Range This shows the distance that can still be covered with the fuel remaining inthe tank. Note:
this figure may increase if
there is a change in the style of dri- ving or the road surface, producing asignificant drop in the currentconsumption. If horizontal segments are displayed for long periods instead of digits,
contact a PEUGEOT dealer. Current consumption This is the average fuel consumption during the last few seconds. This function is displayed only when the vehicle is travelling at a speedgreater than 30 km/h.
Average consumption This is the average fuel consumption since the computer was last set tozero. Distance travelled This indicates the distance travelled since the computer was last set tozero.
* During the year. Activation Keep pressing the control until the display indiciates
"Excess speed
ON" .
Switching off Keep pressing the control until the display indiciates "Excess speed
OFF" .
The routes The routes "1"and "2"are indepen-
dent but have identical application.Route "1"for example allows you to
make daily calculations and route "2" monthly calculations.
22-07-2002

22-07-2002
YOUR 307 SW IN DETAIL115
Trip computer function This function allows inputting of the distance to the destination (whenguidance is not activated; otherwisethe information is given by the navi-gation) and also changing of the
units (¡C or ¡F, km and litres or milesand gallons). Diagnostics This function tells you the warnings, the quantity of emergency fuel andthe GPS cover present at the timeconsulted. Note: these alerts have previously
been displayed in the form of mes- sages and/or warning lights on thecontrol unit. There are 6 categories of diagnostics:
- engine diagnostics (warnings lin- ked to the engine and gearbox etc....),
- brake diagnostics,
- suspension diagnostics (warnings linked to the suspension, ESP etc....),
- wheel diagnostics (warnings linked to tyres),
- doors and windows diagnostics,
- passenger compartment diagnos- tics. Distance to destination When guidance is not activated, this enables an approximate value to beentered to make all the trip computercalculations possible.
Specific features of the mono- chrome screen CT and thecolour screen DT General menu Press the
"MENU"button to access
the general menu.Select the icon "Trip computer"
using the knob, then validate to
access the "Trip computer" menu.
The ''trip computer'' menu offers various choices:
- Trip computer configuration,
- Diagnostics.
"Trip computer" context menu The context menu associated with the "Trip Computer" application
appears as a superimposed display
when the Trip Computer is the appli-cation currently being used in the
main screen window. Briefly press the continuous applica-
tion "Trip computer" button to selectone of the following functions:
- warnings log,
- Distance to destination.

22-07-2002
ELECTRIC WINDOWS
1 - Driver's electric window switch.
2 - Passenger's electric windowswitch.
3 - Rear right electric window switch.
4 - Rear left electric window switch.
5 - Disarming of the rear electric window switches (child lock). You have two options: Manual operation:
press or pull switch 1gently. The
window stops as soon as the switch is released.
Automatic operation: press or pull switch 1fully. One
touch completely opens or closes
the window.
Safety auto-reverse When the window rises and meets an obstacle, it stops and lowersagain. Notes:
- in the case of frost, if the window will not rise, press the switch until it
opens completely, then pull it againuntil it closes.
- following reconnection of the batte- ry, if the window will not rise, relea-se the switch and pull it again until
it closes completely. Hold the swit-ch for approximately one secondafter closing.
YOUR 307 SW IN DETAIL
116
EXTERIOR MIRRORS Electric rear view mirrors
Slide switch Ato the right or to
the left to select the correspon-
ding mirror.
Move knob Bin all four directions
to adjust.
Return switch Ato the centre
position.
When parked, the mirrors can be
folded back manually, electrically bypulling knob Arearwards or automa-
tically when locking the vehicle. The exterior mirrors are unfolded by switching on the ignition to thesecond notch or to the ON position. Note : the function that controls fol-
ding of the mirrors when locking the vehicle can be disarmed. Contact a
PEUGEOT dealer.

22-07-2002
ELECTRIC WINDOWS
1 - Driver's electric window switch.
2 - Passenger's electric windowswitch.
3 - Rear right electric window switch.
4 - Rear left electric window switch.
5 - Disarming of the rear electric window switches (child lock). You have two options: Manual operation:
press or pull switch 1gently. The
window stops as soon as the switch is released.
Automatic operation: press or pull switch 1fully. One
touch completely opens or closes
the window.
Safety auto-reverse When the window rises and meets an obstacle, it stops and lowersagain. Notes:
- in the case of frost, if the window will not rise, press the switch until it
opens completely, then pull it againuntil it closes.
- following reconnection of the batte- ry, if the window will not rise, relea-se the switch and pull it again until
it closes completely. Hold the swit-ch for approximately one secondafter closing.
YOUR 307 SW IN DETAIL
116
EXTERIOR MIRRORS Electric rear view mirrors
Slide switch Ato the right or to
the left to select the correspon-
ding mirror.
Move knob Bin all four directions
to adjust.
Return switch Ato the centre
position.
When parked, the mirrors can be
folded back manually, electrically bypulling knob Arearwards or automa-
tically when locking the vehicle. The exterior mirrors are unfolded by switching on the ignition to thesecond notch or to the ON position. Note : the function that controls fol-
ding of the mirrors when locking the vehicle can be disarmed. Contact a
PEUGEOT dealer.

22-07-2002
YOUR 307 SW IN DETAIL117
The end of the driver's mirror is aspheric (outerarea indicated by a dottedline) in order to reducethe "blind spot".
Objects seen in the driver andpassenger mirrors are in reality
closer than they appear. Therefore, this must be taken into account in order to correctly judgethe proximity of vehicles approa-
ching from the rear.
Automatic day/night interior mirror This automatically and gradually changes between the day and night positions.
To prevent dazzling, the glass of the mirror darkens automatically depending onthe intensity of the light from behind. It clears as the light (headlamps of following
vehicles, sunlight) decreases, ensuring maximum visibility. Operation Switch on the ignition and press switch 1:
Ð Indicator light 2lit (switch pressed): automatic operation.
Ð Indicator light 2off: automatic system off. The mirror remains at its most clear.
Special feature
To ensure maximum visibility during manoeuvres, the mirror clears automatically when reverse gear is engaged.
Manual interior mirror The interior mirror has two positions:
- day (normal),
- night (anti-dazzle).
To change from one to the other, push or pull the lever on the lower
edge of the mirror.

22-07-2002
YOUR 307 SW IN DETAIL117
The end of the driver's mirror is aspheric (outerarea indicated by a dottedline) in order to reducethe "blind spot".
Objects seen in the driver andpassenger mirrors are in reality
closer than they appear. Therefore, this must be taken into account in order to correctly judgethe proximity of vehicles approa-
ching from the rear.
Automatic day/night interior mirror This automatically and gradually changes between the day and night positions.
To prevent dazzling, the glass of the mirror darkens automatically depending onthe intensity of the light from behind. It clears as the light (headlamps of following
vehicles, sunlight) decreases, ensuring maximum visibility. Operation Switch on the ignition and press switch 1:
Ð Indicator light 2lit (switch pressed): automatic operation.
Ð Indicator light 2off: automatic system off. The mirror remains at its most clear.
Special feature
To ensure maximum visibility during manoeuvres, the mirror clears automatically when reverse gear is engaged.
Manual interior mirror The interior mirror has two positions:
- day (normal),
- night (anti-dazzle).
To change from one to the other, push or pull the lever on the lower
edge of the mirror.

22-07-2002
YOUR 307 SW IN DETAIL
118
SUN VISOR WITH
ILLUMINATED COURTESYMIRROR With the ignition on, the mirror is automatically illuminated when theflap is opened.
AREAS FOR TOLL CARDS /
CAR PARK TICKETS The athermic windscreen has two non-reflective zones located either
side of the base of the interior mirror.
They are intended for affixing toll cards and/or car park tickets.

22-07-2002
ADJUSTING THE HEADLAMPS Depending on the load in your vehicle, adjusting the beam of theheadlamps is recommended as fol-lows. 0 1 or 2 people in the front seats.
- 3 people.
1 5 or 7 people.
2 5 or 7 people + maximum authori- sed load.
3 Driver + maximum authorisedload.
Initial setting is position 0. HAZARD WARNING LIGHTS Press the button, the direction indi- cators flash. They can operate with the ignition
off. Automatic lighting of hazard warning lights*
When braking in an emergency, depending on the force of decelera-tion, the hazard warning lights come
on automatically. They switch offautomatically the first time you acce-lerate.
It is also possible to switch them off by pressing the button.
* According to country.STEERING WHEEL HEIGHT
AND DEPTH ADJUSTMENT
When the vehicle is stationary, unlock the steering wheel by pullinghandle
A.
Adjust the height and depth of thesteering wheel, then lock it bypushing handle Adown fully.
HORN Press one of the spokes or the centre of the steering wheel.
YOUR 307 SW IN DETAIL 119

22-07-2002
COURTESY LIGHTS
1 - Front courtesy light
2 - Front map reading lights
3 - 2nd row rear reading lights
4 - 3rd row rear courtesy lightWith the key in the accessories position (1st notch) or with the ignition on, operate the relevant switch. The front and rear courtesy lights and the reading lights come on when the ignition key is removed, on unlocking the vehicle or on opening one of the doors.
They gradually go off after the ignition has been switched on or the vehicle is locked. Pressing switch 1turns on the front and rear courtesy lights and the reading lights for a duration of ten minutes.
Pressing switch 3or 4turns on the reading light concerned or the rear courtesy light for a duration of ten minutes.
Note: The courtesy lights and the reading lights can be deactivated by pressing switch 1for more than three seconds.
However, a short press on switch 1switches the front courtesy light on and off. The map reading lights are not affected by
this and may be switched on. To re-activate the lights, press the switch for more than three seconds.
