Peugeot 406 2002.5 Manual PDF
Manufacturer: PEUGEOT, Model Year: 2002.5, Model line: 406, Model: Peugeot 406 2002.5Pages: 174, PDF Size: 2.65 MB
Page 71 of 174

29-07-2002
The control unit
This is located in the boot on the right hand side. In the
estate, open the panel to access it.
1. CD ROM eject button.
2. CD ROM compartment.
3. The ON indicator light indicates that the control unit is
supplied with power.
4. The CD indicator light indicates that there is a CD
ROM in the control unit.The last voice message recall control
Pressing the button briefly
on the end of the lights
stalk repeats the last voice
message.
The CD ROM This contains all the mapping
data.
It must be inserted with the
printed face upwards.
Use only CD ROMs approved by PEUGEOT.
The satellite navigation system is active once the globe
appears in bold.
YOUR 406 IN DETAIL 97
The use of copied CDs can cause malfunctions.
Page 72 of 174

29-07-2002
Main menu
Switch on the ignition.
Press the "Menu"button to access the main menu.
Select a function using the direction arrows, then confirm ( "VAL" button). The
"Navigation/guidance" menu offers various options
for selecting guidance:
By entering the address of a new destination.
By selecting a service (Hotel, station, airport...) available in a town.
By selecting an address stored in one of the two directo ries.
By resuming previously interrupted guidance or by stop ping current guidance. Two messages may be displayed
depending on the previous actions: "Resume guid
ance" or "Stop guidance" .
Radio functions are suspended when the system is in guidance mode.
YOUR 406 IN DETAIL
98
Navigation / Guidance
Following selection of the "Navigation/guidance"menu,
a screen warns you about the use of the navigation sys
tem. Follow the regulations in force and do not use the
remote control while driving.
Press the "VAL"button to access the next screen.
Page 73 of 174

29-07-2002
Entering a new destination
The last town entered is displayed.
To enter the name of another town, select each letter using
the direction arrows then confirm ("VAL"button) for each
letter.
If an error is made, the "Correct" function enables the last
letter entered to be deleted.
As the name is entered, the "List"function indicates the
number of towns beginning with the same letters. If the li st
contains less than 5 names, these are displayed automat
ically. Select a town then confirm ( "VAL"button).
The "Change" function enables the town entered to be
completely cleared.
When the complete name of the town is displayed, select
the "Validate" function then press the "VAL"button.
Note: following confirmation of a letter, only those letters
which could make up an existing name appear. Enter the name of the street. Select the
"Validate"function
then press the "VAL"button.
Note: the guidance can be activated from the time the
town is entered, without the name of a street or a number.
To do this, select the "Town centre"function.
YOUR 406 IN DETAIL 99
Enter the number in the street. Select the "Validate"func
tion then press the "VAL"button.
Note: the guidance can be activated as soon as the town
and street are entered, without a number. To do this, sele ct
the "Validate" function.
